Introduction
Thank you for purchasing "F-01D" mobile terminal.
Before using your Xi terminal, or when necessary,
read this manual to ensure safe use and handling.
Before using the Xi terminal
･
F-01D supports LTE, W-CDMA, GSM/GPRS, Wireless
LAN System.
･
Because your Xi terminal uses wireless transmission, it
may not function in locations where it is difficult for
radio waves to penetrate, such as tunnels, underground
passages and some buildings, in areas where radio
waves are weak, or out of Xi and FOMA service area.
Even when you are high up in a tall building or
condominium and nothing blocks your view outside,
your Xi terminal may not be able to receive or transmit
signals. Also, communication may be interrupted even
when the signal status icon on your Xi terminal indicates
there are strong radio waves and you are not moving
(traveling).
･
Your Xi terminal makes wireless communication. When
you are operating your Xi terminal while moving to a
location subject to weaker radio wave conditions, the
transmitted digital data may not be correctly decoded
and as a result the received contents may differ
somewhat from the actual contents.
･
Maintain a separate record of the data (Contacts,
Schedule, Memo, etc.) you saved in the Xi terminal.
Note that DOCOMO assumes no responsibility for any
loss of saved contents of data resulting from
malfunction, repair, changing of the model or other
handling of the Xi terminal.
･
In the Xi terminal, as it is for a PC, some applications that
you install may give instability of the operation, or may
send your location information or personal information
registered to the Xi terminal to outside via the Internet
and the information may be used improperly. Please
thoroughly check a provider and operation status of the
application etc. which you want to use beforehand and
then use it.
･
You are recommended to save important data to
microSD card.
･
This Xi terminal supports Xi Area, FOMA Plus-Area and
FOMA HIGH-SPEED Area.
･
Descriptions in this manual are for the Xi terminal with a
DOCOMO's miniUIM inserted.
SIM unlock
This Xi terminal supports SIM unlock. If you release SIM
lock, you can use UIM by a carrier other than NTT
DOCOMO.
･
The SIM unlock service is provided at a docomo Shop.
･
A SIM unlock charge is separately required.
･
If you use a UIM other than by DOCOMO, available
services and functions will be limited. DOCOMO is not
liable to any failures or malfunctions.
･
For details of SIM unlock, refer to NTT DOCOMO
website.
About manuals for F-01D
"Quick Start Guide" (in Japanese only)
This manual provides information about screens and
operations of basic functions.
"Instruction Manual” (installed in Xi terminal)
This manual provides information and operations of all
the functions. (In Japanese only)
In the Applications menu, [Instruction Manual]
→
Select a
search method
"Instruction manual" (PDF file)
This manual provides information and operations of all
the functions.
〈
From PC
〉
http://www.nttdocomo.co.jp/support/trouble/
manual/download/index.html
*You can download the latest information.
F-01D_EN_ninshou.pdf
Contents/Precautions
1
Other options
→
P115
･
In this manual, "F-01D" mobile terminal is usually
referred to as "Xi terminal".
･
The images or illustration used in this manual are
examples. They may differ from the actual displays.
･
In this manual, "authenticate" indicates the
operating procedure for entering the terminal
security code in 4-8 digits (
→
P44).
･
Unauthorized copying of parts of or this entire
manual is prohibited.
･
The contents in this manual, URL and contents are
subject to change without prior notice.
Accessories and main options
<F-01D and included accessories>
F-01D (including warranty)
Quick start guide
(Japanese)
電子辞書データ DVD
(Electronic dictionary
data DVD) (Sample)
AC Adapter F05
Desktop Holder F35 USB Cable for PC
connection T01
Desktop Holder F35 is
made of recycled ABS
from used products.
FOMA AC adapter 01/02
FOMA charging microUSB adapter T01
<Main options>
F-01D_EN_ninshou.pdf
2
Contents/Precautions
Contents
■
