Introduction
Turn FOMA terminal OFF near high-
precision electronic control
equipment or electronic equipment
using low-power signals.
May cause the equipment to fail or
malfunction.
*
Examples of electronic equipment to avoid.
Hearing aids, implanted pacemakers or
defibrillators, other electronic medical equipment,
fire alarms, automatic doors and other automatic
control equipment.
Users wearing implanted pacemakers or
defibrillators or other electronic medical equipment
should check with the manufacturer or sales outlet
about the effect of radio frequencies on the
equipment.
When the display or camera lens is
accidentally broken, be careful of
broken glass or exposed internal parts
of FOMA terminal.
Surfaces of display and camera lens are made
of plastic panels and they are structured for
the glass not to scatter, however, if you
mistakenly touch broken or exposed parts,
you may be injured.
To sound the high-pitched alarm,
always keep FOMA terminal away
from your ears.
May cause hearing loss.
CAUTION
Do not swing FOMA terminal by its
strap.
May cause the terminal damage or failure, or
injury to yourself or others.
When using the motion tracking or
motion sensor, check the safety
around you, hold FOMA terminal
firmly, and do not shake it
unnecessarily.
The motion tracking and motion sensor are
functions to operate by tilting or shaking
FOMA terminal. There is a risk that FOMA
terminal hits people or objects around you by
shaking it too much, causing a serious
accident or damage.
If you put a metal strap or the like to
FOMA terminal, be careful not to let
the strap hit people or objects around
you when performing motion tracking
or using motion sensor.
Accidents such as injury, malfunction or
damage may result.
If the display part is accidentally
broken and liquid crystal leaks out, do
not put the liquid in your mouth,
inhale, or make contact with your skin.
If the liquid gets into your eyes or
mouth, rinse it with clean water and
see a doctor immediately.
And, if the liquid adheres to skin or
clothing, use alcohol etc. to wipe it off,
then wash with soap.
May cause loss of sight or skin problems.
Do not bring the speaker close to your
ear when the ring alert is sounding or
you are playing a melody with FOMA
terminal.
May cause hearing loss.
In rare cases, using the phone in some
vehicle models can cause the vehicle's
electronic equipment to malfunction
or fail.
In this case, do not use the phone because it
may hamper safe driving.
Do
Do
Do
Don’t
Don’t
Don’t
Don’t
Don’t
Do
F-03B_EN_FCC
10
Introduction
Mobile phones can give some users
skin problems such as itching, allergic
reactions or rashes. If you develop skin
problems, stop using the phone
immediately, and see a doctor.
FOMA terminal contains metal in
the parts below.
When opening or closing FOMA
terminal, take care not to have your
fingers or strap caught by the
terminal.
May cause injuries or damages.
When watching 1Seg, take a certain
distance from the display in a fully
bright place.
May cause your eyesight to be impaired.
■
Check that the battery type matches the
type displayed on the battery pack label.
DANGER
Do not connect a wire or other metal
objects to the jack. And, do not carry
or store FOMA terminal with objects
like a metal necklace.
May cause the battery pack to leak, heat, burst
or ignite.
Do not try to force the battery pack
onto FOMA terminal if you are having
trouble installing it. Always install it
after checking that it is correctly
oriented.
May cause the battery pack to leak, heat, burst
or ignite.
Do not throw the battery pack into the
fire.
May cause the battery pack to leak, heat, burst
or ignite.
Do not nail the battery pack, hit with
a hammer or step on it.
May cause the battery pack to leak, heat, burst
or ignite.
If the battery pack's fluid contacts
eyes, immediately flush the eyes with
clean water and see a doctor right
away. Do not rub the eyes.
May cause loss of sight.
Part Material Surface treatment
Back cover plate SUS None
Rear side of the
back cover
Screw
Movable back
panel
Paint (Terminal color
: BLACK, RED, GOLD)
Deposition
(Terminal color :
TITANIUM BROWN)
Top end of
movable back
panel
Chrome plating
(Terminal color:
BLACK)
Paint (Terminal
color : RED, GOLD)
Gold plating
(Terminal color :
TITANIUM
BROWN)
Do
Charging jack SUS Gold plating
External
connection jack
Nameplate attach
place
PC board
Battery pack
connector jack
Beryllium
copper
Open assist
button (Terminal
color : TITANIUM
BROWN)
K18 None
Handling battery pack
Display Battery type
Li-ion 00 Li-ion battery
Part Material Surface treatment
Do
Do
Don’t
Don’t
Don’t
Don’t
Do
F-03B_EN_FCC
11
Introduction
WARNING
If the battery pack seems to have
abnormalities such as deformation or
scratches due to an external impact or
falling, stop using it immediately.
May cause the battery pack to leak, heat, burst
or ignite, and the equipment to malfunction
or catch fire.
If the battery pack does not have a full
charge after being charged for the
specified time, stop charging it.
May cause the battery pack to leak, heat, burst
or ignite.
If the battery pack leaks or gives off a
strange smell, immediately remove it
from the vicinity of open flames.
The vapors from leaking battery pack fluid
may ignite or explode.
Be careful not to let your pet bite the
battery pack.
May cause the battery pack to leak, heat, burst
or ignite, and the equipment to malfunction
or catch fire.
CAUTION
Do not discard old battery packs
together with other garbage.
May cause igniting or environmental
destruction. Tape the terminals of old battery
packs to insulate them, and then bring them
into a sales outlet such as docomo Shop. If
your local municipality has a battery recycling
program, dispose of them as provided for.
Do not charge a wet battery pack.
May cause heat generation, ignition or
rupture of the battery pack.
If the battery pack's fluid contacts skin
or clothes, immediately flush the
contacted area thoroughly with clean
water.
May hurt the skin.
WARNING
Do not use the adapter cord or power
cord if it gets damaged.
May cause electric shock, heat or fire.
Do not use the AC adapter or desktop
holder in a bathroom or other highly
humid area.
May cause electric shock.
Always use the DC adapter with a
negative-ground vehicle. Do not plug
it into a positive-ground vehicle.
May cause fire.
When it starts to thunder, do not
touch FOMA terminal and adapter.
May be subject to lightning strike and could
cause electric shock.
Do not short the charging jack while it
is connected to the outlet or cigarette
lighter socket. Do not touch the
charging jack with a part of your body
such as your hand or finger.
May cause fire, malfunction, electric shock or
injuries.
Place the adapter and desktop holder
in a stable location while charging. Do
not cover or wrap the adapter and
desktop holder with a cloth or blanket.
May cause FOMA terminal to be removed or
the optional devices to be heated, resulting in
fire or troubles.
Do not place heavy objects on the
adapter cord or power cord.
May cause electric shock or fire.
Do not touch the adapter cord,
desktop holder or outlet with wet
hands.
May cause electric shock.
Don’t
Do
Do
Do
Handling adapter and desktop
holder
Don’t
Don’t
Do
Don’t
Don’t
Don’t
Don’t
Don’t
Don’t
Don’t
No wet hands
F-03B_EN_FCC
12
Introduction
Only use with the specified power
source and voltage.
If incorrect voltage is used, this may cause fire
or failure. When using FOMA terminal
overseas, use AC Adapter for global use.
AC adapter : AC100V
DC adapter : 12 or 24V DC (specific for
negative ground vehicle)
AC adapter for global use : Between 100V and
240V AC (Connect to the AC outlet for
internal household use)
If the DC adapter's fuse blows, replace
it only with the specified fuse.
Using other fuses may cause fire or
equipment failure. For the specified fuse, see
the instructions that come with the DC
adapter.
Wipe off any dust that accumulates on
the power plug.
May cause fire.
When you connect the AC adapter to
an outlet, make sure not to touch with
metal such as metal straps and firmly
connect to the outlet.
May cause electric shock, electrical short or
fire.
When you disconnect the adapter
from the outlet or cigarette lighter
socket, do not pull the adapter cord or
power cord with excessive force.
Instead, hold the power plug to
disconnect.
Pulling the cord could damage it, possibly
leading to electric shock or fire.
Always remove the power plug from
the outlet when not using the adapter
for an extended period.
May cause electric shock, fire or malfunction.
Immediately remove the power plug
from the outlet or cigarette lighter
socket if water or other fluids get into
the adapter.
May cause electric shock, smoke or fire.
Always remove the power plug from
the cigarette lighter socket when
cleaning the equipment.
May cause electric shock.
CAUTION
Be careful of the cut surface when
removing UIM (ICs).
May hurt hands or fingers.
■
These precautions are based on the
guidelines produced at the Electromagnetic
Compatibility Conference Japan, regarding
the protection of electronic medical
equipment from radio waves emitted by
mobile phone units.
WARNING
Obey the following rules inside
medical facilities.
･
Do not bring FOMA terminal into operating
rooms (ORs), intensive care units (ICUs) or
coronary care units (CCUs).
･
Turn FOMA terminal OFF in hospital wards.
･
Turn FOMA terminal OFF in hospital
lobbies and corridors if electronic medical
equipment could be nearby.
･
If the medical facility has specified zones
where use or possession of mobile devices
is prohibited, obey those instructions.
･
If the function to automatically turn ON the
power is set, cancel the setting before
turning the power OFF.
Turn FOMA terminal OFF in crowded
trains or other public places where
pacemaker or defibrillator wearers
could be nearby.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
Do
Do
Do
Do
Handling UIM
Do
Unplug
Unplug
Unplug
Do
Handling mobile phones near
electronic medical equipment
Do
Do
F-03B_EN_FCC
13
Introduction
Wearers of implanted pacemakers or
defibrillators must carry and use
FOMA terminal at least 22 cm away
from the implanted device.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
When electronic medical equipment
other than implanted pacemakers or
defibrillators are in use outside of
medical facilities (such as in home care
settings), check with the device
manufacturer to determine how the
device is affected by electrical signals.
FOMA terminal's signals may affect the
performance of electronic medical
equipment.
Do
Do
F-03B_EN_FCC
14
Introduction
Handling precautions
・
F-03B is waterproof/dustproof, however, do not allow water or dust to seep
into FOMA terminal and do not allow accessories or optional devices to get wet
or let dust attach.
- FOMA terminal is provided with waterproofness/dustproofness of IPX5 and IPX8
(which exceeds IPX7) by firmly closing the external connection jack cap and
installing the back cover in a locked state, however, it is not complete
waterproofness/dustproofness. Do not install/remove the battery pack or do not
open/close the external connection jack cap and back cover in the rain or with
waterdrop adhered to them. Water may seep inside and cause corrosion or
malfunction. Also, accessories and optional devices are not waterproof/
dustproof. Malfunctions, which are determined to be caused by water or dust as
result of inspections, are not covered by the warranty. Since these conditions are
outside the scope of the warranty, a repair, if at all possible, is charged.
・
Clean FOMA terminal with a dry soft cloth (such as a cloth for eyeglasses).
- The display of FOMA terminal may have been applied special coating to improve
clearness of the color LCD. When cleaning FOMA terminal, rubbing it roughly
with a dry cloth can scratch the display. Take care when handling the unit, and
clean it with a dry soft cloth (such as a cloth for eyeglasses). Drops of water or
dirt left on the display can cause stains or remove the coating.
- If FOMA terminal is wiped with alcohol, paint thinner, benzine or detergent, the
printing may disappear or color may fade.
・
Clean the jack occasionally with a dry cotton swab etc.
- If the jack is soiled, connection gets worse and it may cause power to be turned
off or insufficient battery charge, so clean the jack with a dry cotton swab etc.
Also, be careful never to damage the jack when cleaning it.
・
Do not place FOMA terminal near an air-conditioner outlet.
- The rapid change in temperature may cause condensation, causing internal
corrosion and malfunction.
・
When using, be careful not to subject excessive force to FOMA terminal or the
battery.
- If FOMA terminal is crammed into a brimming bag or placed in a pocket and sat
on, display, internal PCBs or battery pack may be damaged or malfunction. And,
if external devices are plugged into the external connection jack (earphone/
microphone jack), the breakage of the connector or malfunction may result.
・
Carefully read the separate instructions that come with FOMA terminal and
adapter.
・
Do not rub or scrape the display with a metal piece etc.
- It may scratch the display, causing malfunction or damage.
・
Avoid extreme temperature.
- Use FOMA terminal where the temperature ranges between 5 and 40
℃
(limited
to the temporary use in a bathroom etc. when temperature is above 36
℃
) and
humidity ranges between 45 and 85%.
・
FOMA terminal may affect land-line phones, TVs or radios in use nearby, so use
it as far as possible from these appliances.
・
Maintain a separate record of the data you saved in your FOMA terminal.
- If the data is deleted, DOCOMO assumes no responsibility for the loss of any
data.
・
Do not drop FOMA terminal or subject it to shocks.
- May cause malfunction or damage.
・
Do not plug external devices into the external connection jack (earphone/
microphone jack) at a slant, or do not pull it forcibly while it is plugged.
- May cause malfunction or damage.
・
Do not close FOMA terminal with the strap etc. held inside.
- May cause malfunction or damage.
・
It is normal for FOMA terminal to become warm during use or charging.
Continue to use it.
・
Do not leave FOMA terminal with the camera in areas under strong direct
sunlight.
- May cause discoloring or burn-in of materials.
General
FOMA terminal
F-03B_EN_FCC
15
Introduction
・
FOMA terminal should normally be used with the external connection jack cap
closed.
- Dust and/or water brought into FOMA terminal cause troubles.
・
Do not use FOMA terminal with the back cover removed.
- It may cause the battery to come off, or may cause a malfunction or damage.
・
Do not put extremely thick stickers on the display or the key side.
- Doing so may cause malfunction.
・
Do not put strong impact on the fingerprint sensor or scratch its surface.
- It may cause malfunction of fingerprint sensor and disable authentication
operation and pointing operation.
・
Clean the fingerprint sensor with a dry soft cloth (such as a cloth for eyeglasses).
- If the fingerprint sensor is dirty or water is sit on its surface, the sensor does not
read fingerprints, decreases its authentication performance, erroneously
operates authentication function with no finger on it, disables pointing
operation.
・
While microSD card is being used, do not take the card out and do not turn off
FOMA terminal.
- May cause data loss or malfunction.
・
Do not bring magnetic cards etc. close to FOMA terminal.
- Magnetic data in cash cards, credit cards, telephone cards, floppy disks, etc. may
be erased.
・
Do not bring magnetized objects close to FOMA terminal.
- Bringing strong magnetism close may cause a malfunction.
・
The battery pack is a consumable part.
- Replace the battery pack if FOMA terminal has extremely short operation time
on a full charge, though it may vary by operating conditions. Purchase a new
battery pack of the specified type.
・
Charge the battery in an area within the proper ambient temperature range (5-
35
℃
).
・
Always charge before using it for the first time or after extended disuse.
・
The operation time provided by the battery pack varies by the operating
environment and battery pack's deterioration.
・
The battery pack may swell out as it comes to near the end of its lifetime
depending on the usage conditions, but it is not a problem.
・
Be careful especially about the following points when preserving or leaving the
battery pack for a long time.
- Keeping under the state of the full charge (right after charging ends)
- Keeping under the state of the empty charge (too exhausted to turn on FOMA
terminal)
They may cause the battery pack performance to be degraded or its lifetime to be
shortened.
For necessary battery level to keep for a long time, the display of battery icon is a
state of approximately 2 or 3 cells.
・
Charge the battery in an area within the proper ambient temperature range (5-
35
℃
).
・
Do not charge the battery in the areas below.
- In areas of excessive humidity, dust or vibrations
- Near land-line phones or TVs/radios
・
It is normal for the adapter to become hot while charging. Continue to use it.
・
When using the DC adapter for charging, keep the vehicle engine running.
- The vehicle's battery could become flat.
・
When using an outlet with a mechanism preventing unplugging, follow the
handling instructions for that outlet.
・
Do not give strong shock. Do not deform the charging jack.
- Doing so may cause malfunction.
Battery pack
Adapter
F-03B_EN_FCC
16
Introduction
・
Do not use excessive force to install/remove UIM.
・
It is normal for UIM to become warm during use. Continue to use it.
・
Note that DOCOMO assumes no responsibility for malfunctions occurring as the
result of inserting and using a UIM with another IC card reader/writer.
・
Always keep UIM ICs clean.
・
Clean UIM with a soft, dry cloth (such as a cloth for eyeglasses).
・
Maintain a separate record of the data you saved in UIM.
- If the data is deleted, DOCOMO assumes no responsibility for the loss of any
data.
・
To preserve the environment, bring the old UIM to a sales outlet such as
docomo Shop.
・
Avoid extreme temperature.
・
Take care not to scratch, touch accidentally or short IC.
- May cause data loss or malfunction.
・
Do not drop UIM or subject it to shocks.
- Doing so may cause malfunction.
・
Do not bend UIM or place heavy objects on it.
- Doing so may cause malfunction.
・
Do not install UIM into FOMA terminal with a label or sticker put on UIM.
- Doing so may cause malfunction.
・
This FOMA terminal is equipped with the security features, that are compliant
with Bluetooth standards for communication via Bluetooth. However,
depending on the settings, there may not be enough security. Be aware of
security risks when using Bluetooth.
・
DOCOMO assumes no responsibility for any information which may be leaked
during communication via Bluetooth.
・
You can use headset, handsfree, audio, dial-up connection, object push and
serial port devices with FOMA terminal. An audio/video remote control may be
available with an audio device (only Bluetooth compatible devices).
・
Frequency bands
Frequency bands used by FOMA terminal Bluetooth function are as below.
a
2.4 : Radio equipment that uses the 2400 MHz band.
b
FH : The modulation is the FH-SS method.
c
1 : The expected interference distance is 10 m or shorter.
d
: All bandwidths between 2400 MHz and 2483.5 MHz are used,
and the bandwidth used by mobile object identification devices cannot be
avoided.
Cautions on using Bluetooth devices
In the bandwidth used by this handset, in addition to home electric appliances
such as a microwave oven and industrial/scientific/medical devices, in-plant
radio stations used to identify mobile objects used in production lines of a
factory that require a license, specified low power radio stations, or amateur
radio stations that do not require a license (hereafter "other radio stations") can
be in operation.
1. Before using this terminal, check whether other radio stations are in
operation in your neighborhood.
2. If radio wave interference occurs between the terminal and "other radio
stations", use the terminal in a different location or "Turn the power OFF" to
avoid the radio wave interference.
3. For more detailed information, contact "General Inquiries" using the phone
number on the back of this manual.
UIM
Bluetooth
®
devices
ab
d
c
2.4FH1
F-03B_EN_FCC
17
Introduction
・
FeliCa reader/writer function of FOMA terminal uses weak waves requiring no
licenses for radio stations.
・
It uses 13.56 MHz frequency band. When using other reader/writers in your
surroundings, keep FOMA terminal away sufficiently from them. Before using
the FeliCa reader/writer, confirm that there are no radio stations using the same
frequency band nearby.
・
Do not use a remodeled FOMA terminal. Using a remodeled terminal violates
the Radio Law.
FOMA terminal is certified according to technical standard conformance of
specified wireless equipment based on the Radio Law, and as a proof of it, the
"Technical Compliance Mark " is depicted on the engraved sticker of FOMA
terminal.
If you remodel FOMA terminal by removing its screws, your certification of
technical standard conformance becomes invalid.
Do not use FOMA terminal with its certification of technical standard conformance
invalid as it violates the Radio Law.
・
Be careful when you use FOMA terminal while driving a car etc.
Using a mobile phone while driving is subject to penal regulations.
If you inevitably receive a call, tell the caller that you will "call back" by handsfree,
then park in a safe place and call back.
・
Use the Bluetooth function only in Japan.
The Bluetooth function of the FOMA terminal is compliant with wireless standards
and is authorized for use only in Japan.
If you use this function overseas, you may be punished.
・
Use FeliCa reader/writer function only in Japan.
FeliCa reader/writer function of FOMA terminal conforms to Japanese radio
standards.
If you use this function overseas, you may be punished.
FeliCa reader/writer
CAUTION
Waterproofness/Dustproofness
F-03B is provided with the following waterproofness by firmly
closing the external connection jack cap, installing the back cover
and locking the cover.
・
IPX5 (Former JIS protection code 5)
*1
・
IPX8
*3
that is a higher standard than IPX7 (former JIS protection
code 7)
*2
Also, F-03B is dustproof to IP5X (former JIS protection code 5)
*4
if
the external connection jack cap is strictly closed as well as the back
cover is mounted and locked.
*1
Code IPX5 means that a phone keeps functioning after directly applying a jet
flow of 12.5 L/min. for at least 3 minutes from a distance of 2.5-3 m on a
rotating turntable.
*2
Code IPX7 means that a phone keeps functioning after it is slowly submerged
to depth of 1 m in static tap water at room temperature, left there for 30
minutes and then taken out.
*3
Code IPX8 means that it provides waterproofness of which exceeds of IPX7
standard.
*4
Code IP5X means that a device is protected against the ingress of dust specific
to dustproof test (25
μ
m or smaller in diameter), so that the ingress will not
interfere with predefined operation and safety of the device.
F-03B provides the following waterproof performances of IPX8.
･
F-03B keeps functioning after it is slowly submerged to depth of 1.5
m in static tap water at room temperature, left there for 30 minutes
and then taken out.
･
The mobile phone keeps shooting still images or moving pictures in
30 minutes in static tap water at room temperature.
F-03B_EN_FCC
18
Introduction
✜
What you can do with waterproofness and
dustproofness of F-03B
・
You can talk or watch 1Seg programs without using an umbrella in
the rain (for rainfall of 20 mm or less per hour).
- When your hands or FOMA terminal are wet, avoid installing/
removing the back cover or opening/closing the external
connection jack cap.
・
You can wash mud or dirt away.
- If FOMA terminal gets dirty, flush away immediately as predefined
(
⇒
P20).
・
You can touch the terminal with your hand that is wet with salt
water or seawater.
- Do not operate the terminal.
- If you touch the terminal with your wet hand, flush away
immediately as predefined (
⇒
P20).
・
You can also shoot still images and moving pictures in the pool
depth of 1.5 m.
- Do not perform other operations underwater than shooting still
images and moving pictures.
- If you put the terminal in water of swimming pool, be sure to have
it within 30 minutes.
- If FOMA terminal gets wet with water from the swimming pool,
wash it as predefined (
⇒
P20).
・
You can use FOMA terminal in a bathroom.
- Do not put the terminal in the bathtub. Do not use the terminal in
hot water. Doing so may cause malfunction.
- Never put FOMA terminal in hot spring water or water containing
soap, detergent or bath powder.
To ensure waterproofness/dustproofness
To avoid water and dust ingress, be sure to observe the following
points.
・
If FOMA terminal should get wet with salt water, sea water or soft
drink, you can flush away. However, do not let the terminal get wet
with liquids other than tap water at room temperature.
・
Open/close the external connection jack cap as described below.
<Opening the external connection jack cap>
Place your finger at groove on the hinge side to open the cap.
<Closing the external connection jack cap>
Close with the tab for the back cover at the rear side of the cap fitted
into the concave of this terminal. Make sure that the cap is
completely closed without slack.
Groove on the hinge side
Tab on the back
cover side
