F-04B_E1kou

Basic Operation

Before Using

Battery level

Battery level is always displayed on the display, but you can check

it by menu operation etc.

Display unit

ameh

LifeKit

Clock & Other

Info &

Reset

Battery level

Keypad unit

ameh

LifeKit

Keypad unit

Remaining

keypad power

In separated style, while pressing

on QWERTY keypad,

press

. You can check it by the color of arch light.

Point

･

When FOMA terminal turns ON and the units are joined, if battery level of

either unit becomes 1 and the other unit is in battery level 3, power

feeding is executed automatically (interunit power feeding). A message

appears at the start of power feeding and the power feeding ends when

battery levels of both units become same.

Indication

Display unit

Keypad unit

Sounding by menu

operation

3 times Twice Once

Arch light

Green Yellow Red

Ample charge Almost exhausted

(Charge the battery)

Before Using

Turning power ON - Configuring default setting

Perform the following operations after turning the power ON for the first time.

On numeric keypad,

(2 sec. or

more) or on front keypad,

(2 sec.

or more)

"Yes" or "No" on a confirmation

screen of enlarged menu setting

The screen shown to the right appears.

Set required items

[Complete]

Always set Password and Request permit/

deny. If you exit without setting, Initial

setting screen reappears when the power

is turned ON the next time.

on a confirmation screen of software update

function

The stand-by display appears.

Point

･

When FOMA terminal turn ON with the units joined, after initial settings,

keypad unit is automatically registered as Bluetooth device and

appears on the display.

･

In separated style, you can turn on or off the power per unit. However,

when the power is turned off by pressing front key or

while

connecting to Bluetooth, the power of keypad unit also turns off.

･

If no operation is performed, the display light is turned off automatically

according to the settings in Light time-out or Power saving mode. The

display light turns on again if there is any operation or incoming call.

Turning the power off :

On numeric keypad,

(2 sec. or more) or on

front keypad,

(2 sec. or more)

Changing initial settings :

mehgeg

Changing screen display to English :

mehbfce

Select "English"

F-04B_E1kou

Basic Operation

Before Using

Motion sensor

You can operate FOMA terminal by double-tapping (tapping it

twice) or tilting it.

✜

Stopping alarm sound

While alarm is sounding with FOMA terminal closed, double-tapping

the front or back side stops the sound. The alarm stops or starts

snooze.

✜

Auto rotation

In basic style or separated style, vertical and horizontal display, or

vertical/horizontal orientation or size of images (JPEG format)

switches according to the tilt of FOMA terminal or display unit.

✜

Auto switching of still images

When saving a shot still image, Sense orientation is executed and

vertically long/horizontally long or up side/down side switches

according to the tilt of the FOMA terminal.

✜

Scrolling Browser screen

By tilting FOMA terminal while pressing

, the screen can be scrolled

up/down/right/left/slantwise. Scrolling speed becomes faster as the

FOMA terminal is tilted greatly.

✜

Varying Flash images

Motion sensor compatible Flash image which is set to stand-by

display varies according to the tilt of FOMA terminal.

･

You can disable Motion sensor, or select Valid/Invalid for each function.

【モーションセンサー設定

(Setting Motion sensor)

】

Information

Before Using

User information

You can check your own phone number.

For details of checking/changing a mail address, refer to "Mobile

Phone User's Guide [i-mode] FOMA version".

ame0

User information

The screen shown to the right appears.

Point

Editing user information :

On User information edit screen,

Authenticate

Edit

Checking a phone number during a call :

se0

<User information

screen>

F-04B_E1kou

Basic Operation

Screen Explanation

Viewing display

The current state can be checked by the icon appearing on the display. Major icons are as follows.

Battery level (Battery icon)

Signal strength (Antenna icon)

Self mode ON

In data transfer mode

Connecting to i-mode

Infrared communication in operation

Bluetooth ON

The total calls cost exceeds the limit

Bluetooth connection being

established

Communication using handsfree-

compatible device in progress

Handsfree ON

Femtocell setting available

Power saving mode activated

Positioning with GPS

Location request setting

Displaying SSL/TLS page etc.

Auto-send mail exists

A phonebook entry or schedule has

secret attribute

High-pitched alarm ON

Kid-safe mode ON

Unread Area Mail exists

Unread i-mode mail exists

Arrival i-concier information exists

Unreceived i-mode mail exists in i-

mode Center

During i-

ppli operation

ppli call received

Interunit communication status

Alarm clock ON

Schedule reminder ON

Inside OFFICEED area

Top of the display

Strong Out of service area or where

radio waves do not reach

Weak

Arrival information (Starting from the left,

missed call, recorded message, voice mail

service, unread message, unread ToruCa,

ppli call)

Silent mode ON

Call alert volume OFF

Vibrator for voice call ON

In Public mode (Drive mode)

Record message ON

Keypad dial lock ON

GPS Location request failed

Personal data lock ON

Music&Video Channel program

obtaining failure

Reading UIM

IC card lock ON

Available multi-cursor key

Recording 1Seg

ppli Auto start failed

microSD card installed during

Communication mode

Connected to external device using

USB cable

Pedometer/ACT monitor is set

Software update rewrite notice

Auto-update of latest pattern definition

failure

Bottom of the display

F-04B_E1kou

Basic Operation

Task area

The icon indicating the

function (task) in progress

appears in the task area.

Guide area and key operation

Operations that can be performed by

pressing

and

are displayed in the guide area.

To perform an operation in the guide

area, press the corresponding key.

on the guide area corresponds to

multi-cursor keys

Task area

Guide area

Screen Explanation

Status in separated style

In separated style, you can check the status of FOMA terminal by

indicator on the display or indicator light of keypad unit.

✜

Display

In addition to battery level of keypad unit (

⇒

P24), available functions

for keypad unit are displayed.

Only phone call available

Only key operation available

Phone call and key operation available

✜

Bluetooth light blink

Blue :

Connected to Bluetooth

Red :

Disconnected from Bluetooth

Yellow :

QWERTY keypad locked

✜

Arch light blink

Red purple :

Unit search activated

Ye l l o w

→

Green :

Game mode activated

Light blue

→

Blue

→

Purple :

Game mode ended

Red :

Display unit battery almost runs down

In addition, arch light turns on or blinks in conjunction with indicator

light of display for phone call or mail receiving.

F-04B_E1kou

Basic Operation

Screen Explanation

Menu operation

On the stand-by display, press

and then perform the

functions from the menu. You can select a menu item with

shortcut operations, which use the keypad,

and

, or with

multi-cursor operation, which uses the multi-cursor key to move

the cursor.

<Example> Selecting "Calculator"

Shortcut operations

ame7e4

Multi-cursor key operations

ame

Move the cursor to "

Accessory"

[Select]

Move the cursor to "

Calculator"

[Select]

Point

･

Even when a function is running, you can perform the same operation if

"MENU" is displayed on the guide area.

･

To return to the previous screen, press

. To return to the stand-by

display, press

･

On the stand-by display with Info/calendar layout, Shortcut icons set, or

with arrival information icon or i-concier information displayed, press

to change the display to Focus mode that allows you to quickly display the

related information.

You can switch among "Kisekae menu", the design of which can be

changed using Kisekae Tool (

⇒

P44), "Basic menu", which has the

fixed menu numbers, and "Custom menu", to which menu items

can be saved freely.

A Kisekae menu matched with the color of FOMA terminal is set by

default.

Point

･

In some types of Kisekae menus, the menu structure is changed according

to usage frequency, or the number assigned to menu item (item number)

may not be applicable.

･

The menu that appears when

is pressed on the stand-by display can

be changed from Select startup menu.

⇒

P40

m 7 4

Switching menu screens

F-04B_E1kou

Basic Operation

Screen Explanation

Using touch panel

You can use the display as touch panel. You can perform the same

operation by touch operation as on the screen to move the cursor

with key operation. Major touch operations are as follows.

Types of touch operations

Touch

Touch the display lightly once and release the finger. The

operation becomes effective when you release your finger

from the display. This operation is mainly for selecting

menus, items, etc.

Double-

touch

Touch the display lightly twice and release the finger. The

operation becomes effective when you release your finger

from the display. This operation is mainly for zooming in/

out or switching the display.

Slide

Keep touching the display, move your finger up, down,

right or left. This operation is for scrolling a screen,

rewinding/fast-forwarding a video, etc.

Slide

quickly

Touch the display lightly and flick your finger up, down,

right or left. This operation is for switching pages or

images, or moving to a different chapter or tune, etc.

e.g.: Slidee.g.: Touch

Touch-specific operations

Function selection from the

stand-by display

Use stand-by touch buttons (4

buttons at the bottom of the

screen) and stand-by launcher

(shown to the lower right).

Guidance button

Return to the previous screen

(

), exit a function (

), or

operate a function displayed in

the guide area (

Menu buttons for touch

operation

Buttons that correspond to a

function are displayed.

Moving focus and selecting

menu/item

Touch a menu or item to select,

move the focus for touch

operation, then touch the menu

or item again.

Menu button for touch operation

e.g. : Outgoing call screen e.g. : My document

Slide on the list Touch an item

directly

F-04B_E1kou

Basic Operation

Link items or confirmation

screens

Directly touch an item.

Numeric value setting roller

Set numeric values

such as date and

time, rotate the roller

by slide operation.

Direction/Determination button

When using i-mode browser in

flip style, use the direction/

determination button to operate

menus or items on the screen.

Channel switch panel/Volume

adjust panel/Slider

While playing 1Seg or a moving

picture, slide vertically or

horizontally to display a panel,

and then touch or slide.

Touch or slide the slider to adjust

a value.

Switching tabs and scrolling

Switch tabs of phonebook etc. or

scroll by sliding.

Temporary zooming

In mail or Full Browser function

etc., double-touch the screen to

zoom in.

仮

Screen Explanation

使いかたガイド

(Guide)

You can check overviews and operations of functions, and

troubleshooting. (In Japanese only)

amef

LifeKit

Guide

Select

a search method

(Contents) :

Search from a list of

functions.

索引

(Index) :

Search from a list of words

sorted according to Japanese syllabary.

フリーワード検索

(Free word search) :

Enter a keyword to search for.

ブックマーク

(Bookmark) :

Search from a

list of registered bookmarks.

困ったときには

(Troubleshooting) :

Search from lists of

troubles or error messages.

Point

･

On a description screen, select "

この機能を使う

(Use this function)" to

perform a function. Selecting a link item in "

関連機能

(Related functions)",

or "

→コチラ

(See more)" displays a corresponding description screen.

･

Terms indicated with

【】

in this manual are index terms in "Guide".

･

You can also access

フリーワード検索

from Quick search.

⇒

P121

Information

F-04B_E1kou

Basic Operation

You can notify your phone number (caller ID) to the other party's

terminal when making a voice call.

ameh

Settings&NWservices

NW Services

Caller ID

Caller ID notification

Activate/

Deactivate

Notify

Select "

Not notify" if you do not want to notify.

Point

･

Caller ID is your important personal information. Carefully consider

whether you want to include caller ID information when making a call.

･

If an announcement of requesting caller ID is heard when making a call,

make a call again after setting your caller ID to "Notify".

Caller ID notification

(Default : Notify)

F-04B_E1kou

156

Others

Appendix

Specific absorption rate (SAR) of mobile phone

This model phone FOMA F-04B meets the MIC's

technical regulation

governing exposure to radio waves.

The technical regulation established permitted levels of radio frequency

energy, based on standards that were developed by independent scientific

organizations through periodic and thorough evaluation of scientific studies.

The regulation employs a unit of measurement known as the Specific

Absorption Rate, or SAR. The SAR limit is 2 watts/kilogram (W/kg)

averaged

over 10 grams of tissue. The limit includes a substantial safety margin designed

to assure the safety of all persons, regardless of age and health. The value of

the limit is equal to the international guidelines recommended by ICNIRP.

All phone models should be confirmed to comply with the regulation, before

they are available for sale to the public. The highest SAR value for this FOMA

F-04B is 1.440 W/kg. It was taken by the Telecom Engineering Center (TELEC).

The test for SAR was conducted according to the MIC testing procedure using

standard operating positions with the phone transmitting at its highest

permitted power level in all tested frequency bands. While there may be

differences between the SAR levels of various phones and at various positions,

they all meet the MIC's technical regulation. Although the SAR is determined at

the highest certified power level, the actual SAR of the phone during operation

can be well below the maximum value.

For further information about SAR, please see the websites below.

World Health Organization (WHO) :

http://www.who.int/peh-emf/

ICNIRP :

http://www.icnirp.de/

MIC :

http://www.tele.soumu.go.jp/e/ele/body/index.htm

TELEC :

http://www.telec.or.jp/ENG/Index_e.htm

NTT DOCOMO :

http://www.nttdocomo.co.jp/english/product/

FUJITSU LIMITED :

http://www.fmworld.net/product/phone/sar/

Ministry of Internal Affairs and Communications.

The technical regulation is provided in Article 14-2 of the Ministry Ordinance

Regulating Radio Equipment.

International Commission on Non-Ionizing Radiation Protection.

The product "F-04B" is declared to conform with the essential requirements of

European Union Directive 1999/5/EC Radio and Telecommunications Terminal

Equipment Directive 3.1(a), 3.1(b) and 3.2. The Declaration of Conformity can

be found on http://www.fmworld.net/product/phone/doc/.

This mobile phone complies with the EU requirements for exposure to radio

waves.

Your mobile phone is a radio transceiver, designed and manufactured not to

exceed the SAR

limits

for exposure to radio-frequency(RF) energy, which

SAR

value, when tested for compliance against the standard was 1.26 W/Kg.

While there may be differences between the SAR

levels of various phones and

at various positions, they all meet

***

the EU requirements for RF exposure.

* The exposure standard for mobile phones employs a unit of measurement

known as the Specific Absorption Rate, or SAR.

** The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/

Kg) averaged over ten grams of tissue, recommended by The Council of the

European Union. The limit incorporates a substantial margin of safety to give

additional protection for the public and to account for any variations in

measurements.

*** Tests for SAR have been conducted using standard operation positions with

the phone transmitting at its highest certified power level in all tested

frequency bands. Although the SAR is determined at the highest certified

power level, the actual SAR level of the phone while operating can be well

below the maximum value. This is because the phone is designed to operate

at multiple power levels so as to use only the power required to reach the

network. In general, the closer you are to a base station antenna, the lower the

power output.

Declaration of Conformity

F-04B_E1kou

157

Others

･

This device complies with part 15 of the FCC rules.

Operation is subject to the following two conditions :

this device may not cause harmful interference, and

this device must accept any interference received, including interference

that may cause undesired operation.

･

Changes or modifications made in or to the radio phone, not expressly

approved by the manufacturer, will void the user's authority to operate the

equipment.

This model phone meets the U.S. Government's requirements for exposure to

radio waves.

This model phone contains a radio transmitter and receiver. This model phone

is designed and manufactured not to exceed the emission limits for exposure

to radio frequency (RF) energy as set by the FCC of the U.S. Government. These

limits are part of comprehensive guidelines and establish permitted levels of RF

energy for the general population. The guidelines are based on standards that

were developed by independent scientific organizations through periodic and

thorough evaluation of scientific studies.

The exposure standard for wireless mobile phones employs a unit of

measurement known as the Specific Absorption Rate (SAR). The SAR limit set

by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating

positions as accepted by the FCC with the phone transmitting at its highest

certified power level in all tested frequency bands. Although the SAR is

determined at the highest certified power level, the actual SAR level of the

phone while operating can be well below the maximum value. This is because

the phone is designed to operate at multiple power levels so as to use only the

power required to reach the network. In general, the closer you are to a wireless

base station antenna, the lower the power output level of the phone.

Before a phone model is available for sale to the public, it must be tested and

certified to prove to the FCC that it does not exceed the limit established by the

U.S. government-adopted requirement for safe exposure. The tests are

performed on position and locations (for example, at the ear and worn on the

body) as required by FCC for each model. The highest SAR value for this model

phone as reported to the FCC, when tested for use at the ear, is 0.978 W/kg, and

when worn on the body, is 0.147 W/kg. (Body-worn measurements differ

among phone models, depending upon available accessories and FCC

requirements).

While there may be differences between the SAR levels of various phones and

at various positions, they all meet the U.S. government requirements.

The FCC has granted an Equipment Authorization for this model phone with all

reported SAR levels evaluated as in compliance with the FCC RF exposure

guidelines. SAR information on this model phone is on file with the FCC and

can be found under the Equipment Authorization Search section at http://

www.fcc.gov/oet/ea/fccid/ (please search on FCC ID VQK-F04B).

For body worn operation, this phone has been tested and meets the FCC RF

exposure guidelines when used with an accessory designated for this product

or when used with an accessory that contains no metal and which positions the

handset at a minimum distance of 1.5 cm from the body.

In the United States, the SAR limit for wireless mobile phones used by the general public

is 1.6 Watts/kg (W/kg), averaged over one gram of tissue. SAR values may vary

depending upon national reporting requirements and the network band.

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation.

Federal Communications Commission (FCC)

Notice

FCC RF Exposure Information

F-04B_E1kou

158

Others

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

AIRCRAFT

Switch off your wireless device when boarding an aircraft or whenever you are

instructed to do so by airline staff. If your device offers flight mode or similar

feature consult airline staff as to whether it can be used on board.

DRIVING

Full attention should be given to driving at all times and local laws and

regulations restricting the use of wireless devices while driving must be

observed.

HOSPITALS

Mobile phones should be switched off wherever you are requested to do so in

hospitals, clinics or health care facilities. These requests are designed to

prevent possible interference with sensitive medical equipment.

PETROL STATIONS

Obey all posted signs with respect to the use of wireless devices or other radio

equipment in locations with flammable material and chemicals. Switch off your

wireless device whenever you are instructed to do so by authorized staff.

INTERFERENCE

Care must be taken when using the phone in close proximity to personal

medical devices, such as pacemakers and hearing aids.

Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 15 cm be

maintained between a mobile phone and a pace maker to avoid potential

interference with the pacemaker. To achieve this use the phone on the opposite

ear to your pacemaker and does not carry it in a breast pocket.

Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the

event of such interference, you may want to consult your hearing aid

manufacturer to discuss alternatives.

For other Medical Devices :

Please consult your physician and the device manufacturer to determine if

operation of your phone may interfere with the operation of your medical

device.

Important Safety Information

F-04B_E1kou

159

Others

Appendix

Export Administration Regulations

This product and its accessories may be under coverage of the Export

Administration Regulations of Japan ("Foreign Exchange and Foreign Trade

Control Laws" and the related laws and regulations). And, they are also under

coverage of Export Administration Regulations of the U.S. When exporting

and reexporting this product and its accessories, take necessary procedures

on your responsibility and expense. For details, contact Ministry of Economy,

Trade and Industry of Japan or US Department of Commerce.

Appendix

Intellectual Property Right

Except for the case protected by copyright laws such as personal use, use of

FOMA terminal to reproduce, alter, or publicly transmit recorded pictures or

sounds, or copyrighted text, images, music or software downloaded from

websites without the copyright holder's authorization is prohibited.

Note that taking photos or recordings at some demonstrations, performances

or exhibitions may be prohibited even when only for personal use.

Avoid taking pictures of others with FOMA terminal without their consent or

disclosing recorded pictures of others without their consent to general public

through Internet websites etc., because they may infringe on portrait rights.

Company and product names mentioned in this manual are trademarks or

registered trademarks of their respective holders.

･

"FOMA", "i-motion", "i-mode", "i-

ppli", "mopera", "WORLD CALL", "WORLD

WING", "Deco-mail", "Chara-den", "i-Channel", "Dual Network", "Security

Scan", "Public mode", "ToruCa", "2in1", "DCMX", "OFFICEED", "docomo

PRIME series" and logos of "FOMA", "i-mode", "i-

ppli", "Music&Video

Channel" are trademarks or registered trademarks of NTT DOCOMO.

･

Microsoft

, Windows

, Windows Vista

, Windows 7

™

, Windows Media

™

and PowerPoint

™

are trademarks or registered trademarks of "Microsoft

Corporation" in the US and other countries.

･

Microsoft Excel and Microsoft Word are product names of Microsoft

Corporation in the U.S.A. In this manual, they may be described as Excel and

Word.

･

"Multitask" is a registered trademark of NEC Corporation.

･

"Catch Phone (Call Waiting Service)" is a registered trademark of Nippon

Telegraph and Telephone Corporation.

･

Free Dial logo mark is a registered trademark of NTT Communications

Corporation.

･

Java and all Java-related trademarks and logos are trademarks or registered

trademarks of Sun Microsystems, Inc. in the US and other countries.

Copyrights and portrait rights

Trademarks

F-04B_E1kou

160

Others

･

This product contains NetFront Browser,

NetFront Sync Client of ACCESS CO., LTD.

ACCESS, the ACCESS logo and NetFront are registered trademarks or

trademarks of ACCESS CO., LTD. in the United States, Japan and/or other

countries.

･

™

rights reserved.

JBlend and JBlend-related trademarks are trademarks or registered

trademarks of Aplix Corporation in Japan and other countries.

･

This product contains Adobe

Flash

Lite

and Adobe Reader

technology of Adobe Systems Incorporated.

Adobe Flash Lite Copyright

2003-2009 Adobe Systems Incorporated. All

rights reserved.

Adobe Reader Mobile Copyright

1993-2009 Adobe Systems Incorporated.

Adobe, Adobe Reader, Flash and Flash Lite are either

registered trademarks or trademarks of Adobe Systems

Incorporated in the United States and/or other countries.

･

QR code is a registered trademark of Denso Wave Inc.

･

microSDHC Logo is a trademark.

･

FeliCa is a registered trademark of Sony Corporation.

･

"CROSS YOU" is a trademark of Sony Corporation.

･

is a registered trademark of FeliCa Networks, Inc.

･

Word, Excel and PowerPoint file display technologies

are powered by Picsel Technologies.

Picsel, Picsel File Viewer and the Picsel cube logo are trademarks or

registered trademarks of Picsel Technologies.

･

McAfee

is registered trademarks or trademarks of McAfee, Inc. and/or its

affiliates in the US and/or other countries.

･

G-GUIDE, G-GUIDE MOBILE and their logos are registered

trademarks in Japan of U.S. Gemstar-TV Guide International, Inc.

and/or its affiliates.

･

QuickTime is a registered trademark of Apple Inc. in the US and other

countries.

･

ATOK + APOT of Justsystem Corporation is installed in this product as

Japanese character conversion function.

"ATOK" "APOT (Advanced Prediction Optimization Technology)" are

registered trademarks of Justsystem Corporation.

･

is a trademark or registered trademark of Nuance

Communications, Inc. in US and of Nuance corporations in other

countries.

･

This equipment is provided with the software licensed by Symbian Software

Ltd. or the licensor

1998-2009. and Symbian OS are trademarks of

Symbian Ltd. or the licensor.

･

"Privacy mode" is a registered trademark of FUJITSU LIMITED.

･

Bluetooth

and its logo are registered trademarks of Bluetooth SIG, Inc., and

NTT DOCOMO uses them under license. Other trademarks and names inhere

to their respective owners.

･

Napster is a registered trademark of Napster, LLC. and/or its affiliates in the

US and/or other countries.

･

Manufactured under license from Dolby Laboratories. Dolby and the double-

D symbol are trademarks of Dolby Laboratories.

･

"Uni-Type" is a registered trademark of LIM Corp., Ltd.

･

FrameSolid is the registered trademark of Morpho, Inc. in Japan and other

countries.

･

The auto object tracking technology utilized is TrackSolid

™

, a product of

Morpho, Inc. TrackSolid

™

is trademark of Morpho, Inc.

･

Google is registered trademark of Google Inc.

･

ズーキーパー

(Zookeeper) is a trademark or registered trademark of

KITERETSU Inc.

･

日英版しゃべって翻訳

for F (J-E Speech Translation for F)" is trademark of

ATR-Trek.

･

Other company and product names mentioned in this manual are

trademarks or registered trademarks of their respective holders.

･

The abbreviations of operating systems (Japanese versions) below are used

in this manual.

- Windows Vista stands for Windows Vista

(Home Basic, Home Premium,

Business, Enterprise and Ultimate).

F-04B_E1kou

161

Others

- Windows XP indicates the Microsoft

Windows

XP Professional

operating system or Microsoft

Windows

XP Home Edition operating

system.

- Windows 2000 indicates the Microsoft

Windows

2000 Professional

operating system.

･

FeliCa is a contactless IC card technology developed by Sony Corporation.

･

This product contains a module developed by the Independent JPEG Group.

･

The image interpolation technology utilized is FrameSolid, a product of

Morpho, Inc.

･

This product is equipped with the technologies of GestureTek, Inc.

･

学研モバイル国語辞典

(Gakken Mobile JpnDic)", "

学研モバイル和英辞典

(Gakken Mobile JE Dic)", "

学研モバイル英和辞典

(Gakken Mobile EJ Dic)", "

今

日は何の日

(Today's trivia)" and "

今日の歴史

(Today in history)" are

copyrighted by GAKKEN CO., LTD.

･

This product is equipped with the copyright protection technology protected

by US Patent and other intellectual property right, and approved for use by

Rovi Corporation.

The copyright protection technology is used for the function of link this

product with projector, and permitted for use only in domestic and limited

viewing purpose.

Reverse engineering and disassembly of this product are prohibited.

U.S. Patent Nos. 5,315,448; 5,583,936; 6,516,132; 6,836,549; and 7,492,896.

･

This product is licensed based on MPEG-4 Visual Patent Portfolio License.

The use of MPEG-4 Video Codec function is allowed for personal and

nonprofit use only in the cases below.

- Recording moving pictures and i-motion that conform to MPEG-4 Visual

Standard (hereinafter referred to as MPEG-4 Video)

- Playing MPEG-4 Videos recorded personally by consumers not engaged in

profit activities

- Playing MPEG-4 Video supplied from the provider licensed from MPEG-LA

For further utilizing such as promotion, in-house use or profit-making

business, please contact MPEG LA, LLC in U.S.

･

Content owners use Windows Media digital rights management technology

(WMDRM) to protect their intellectual property, including copyrights. This

device uses WMDRM software to access WMDRM-protected content. If the

WMDRM software fails to protect the content, content owners may ask

Microsoft to revoke the software's ability to use WMDRM to play or copy

protected content. Revocation does not affect unprotected content. When

downloading licenses for protected content, you agree that Microsoft may

include a "Revocation List" with the licenses. Content owners may require

you to upgrade WMDRM to access their content. If you decline an upgrade,

you cannot access a content that requires the upgrade.

Others

* Unavailable from land-line phones, etc.

Repairs

■

From DOCOMO mobile phones

(In Japanese only)

■

From land-line phones

(In Japanese only)

0120-800-000

(toll free)

(No prefix)

151

(toll free)

●

Please confirm the phone number before you dial.

●

For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo shop etc. near you on the NTT DOCOMO website or the i-mode site.

NTT DOCOMO website http://www.nttdocomo.co.jp/english/ i-mode site iMenu⇒お客様サポート (user support)⇒ドコモショップ (docomo Shop) * In Japanese only

* Service available in: English, Portuguese, Chinese, Spanish, Korean.

* Available from mobile phones and PHSs.

General Inquiries <docomo Information Center>

0120-005-250 (toll free)

* You are charged a call fee to Japan when calling from a land-line phone, etc.

※If you use F-04B, you should dial the number ＋81-3-5366-3114 (to enter '＋',

press and hold the '0' key for at least one second).

* You are charged a call fee to Japan when calling from a land-line phone, etc.

※If you use F-04B, you should dial the number ＋81-3-6718-1414 (to enter '＋',

press and hold the '0' key for at least one second).

Loss or theft of FOMA terminal or payment of cumulative cost overseas

(available 24 hours a day)

■

From DOCOMO mobile phones

(available 24 hours a day)

■

From DOCOMO mobile phones

International call access code

for the country you stay

■

From land-line phones <Universal number>

International prefix number

for the universal number

■

From land-line phones <Universal number>

-81-3-5366-3114* (toll free) International call access code

for the country you stay -81-3-6718-1414* (toll free)

-800-0120-0151*International prefix number

for the universal number -800-5931-8600*

Don't forget your mobile phone ･･･ or your manners!

When using your mobile phone in a public place, don't forget to

show common courtesy and consideration for others around you.

■

From DOCOMO mobile phones

(In Japanese only)

■

From land-line phones

(In Japanese only)

0120-800-000

(toll free)

(No prefix)

113

(toll free)

* Unavailable from land-line phones, etc.

* Available from mobile phones and PHSs.

●

If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.

●

If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after returning to Japan.

You might be charged a domestic call fee according to the call rate for the country you stay.

※

For international call access codes for major countries/international prefix numbers

for the universal number, refer to DOCOMO International Services website.

You might be charged a domestic call fee according to the call rate for the country you stay.

※

For international call access codes for major countries/international prefix numbers

for the universal number, refer to DOCOMO International Services website.

Failures encountered overseas

CA92002-5792

2010.X (1st Edition)

To prevent damage to the environment,

bring used battery packs to a docomo

service counter, a docomo agent or a

recycle center.

Fujitsu F04B-S Fujitsu F-04B Cellular Phone User Manual F 04B E H1 eps

Fujitsu Limited Fujitsu F-04B Cellular Phone F 04B E H1 eps

Contents

user manual 4

Navigation menu

Namespaces

Views

Navigation
