Contents
Manual Part 2
F-06B_EN_FCC
9
Introduction
Be careful especially when using
FOMA terminal connected to the
adapter continuously for a long time.
If you use i-
α
ppli, a videophone call or 1Seg
watching while charging the battery for a
long time, FOMA terminal, battery pack and
adapter may be heated.
Directly touching a hot part for a long time,
you may have redness, itching or rash on
your skin, or it may result in low-temperature
burns depending on your constitution and/or
health condition.
WARNING
Do not direct the infrared data port
toward your eye and transmit signals.
May affect your eyes. Faulty operation could
result from directing the infrared data port
toward other infrared equipment and
transmitting signals.
Do not turn on the light by getting the
lighting part closer to other person's
eyes.
May impair eyesight. And may cause
accidents like injury etc., by dazzling or
astounding other people.
Do not put FOMA terminal in the place
such as the dashboard near the air-
bag, where the influence of air-bag
explosion is expected.
When the air-bag explodes, FOMA terminal
may hit yourself or others and could cause
injury, equipment malfunction or damage.
When you use electronic medical
equipment, do not keep the terminal
in your chest pocket or inside pocket.
Using your FOMA terminal near medical
electronic equipment could cause equipment
failure.
Do not put foreign objects such as
liquid like water, metal pieces or
burnable things into UIM or microSD
card slot.
May cause fire, electric shock or malfunction.
Do not turn on the light aiming
directly at the driver of the car etc.
May disturb driving and cause an accident.
Turn FOMA terminal OFF in areas
where use is prohibited, such as in
airplanes and hospitals.
May cause electronic equipment or electronic
medical equipment to fail or malfunction. If
the function which automatically turns the
power ON is set, cancel the setting before
turning the power OFF.
When using the phone in a medical facility, be
sure to observe the regulations of the facility.
If you do prohibited act such as using the
phone in an airplane, you may be punished
according to law.
When you talk by setting handsfree,
always keep FOMA terminal away
from your ear.
And, when connecting the earphone/
microphone to FOMA terminal and
play a game or music, adjust the
volume moderately.
Too loud volume may cause a hearing loss.
And, if you cannot hear the sound around you
clearly, it may cause an accident.
If you have weak heart, be careful
when setting the Vibrate alert
(vibration) or alert volume setting.
Could affect heart function.
If it starts thunder while using the
terminal outdoors, turn the power
OFF immediately, and move to a safe
location.
May be subject to lightning strike and could
cause electric shock.
Handling FOMA terminal
Do
Don’t
Don’t
Don’t
Don’t
Don’t
Don’t
Do
Do
Do
Do
F-06B_EN_FCC
10
Introduction
Turn FOMA terminal OFF near high-
precision electronic control
equipment or electronic equipment
using low-power signals.
May cause the equipment to fail or
malfunction.
*
Examples of electronic equipment to avoid.
Hearing aids, implanted pacemakers or
defibrillators, other electronic medical equipment,
fire alarms, automatic doors and other automatic
control equipment.
Users wearing implanted pacemakers or
defibrillators or other electronic medical
equipment should check with the manufacturer or
sales outlet about the effect of radio frequencies
on the equipment.
When the display or camera lens is
accidentally broken, be careful of
broken glass or exposed internal parts
of FOMA terminal.
Surfaces of display and camera lens are made
of plastic panels and they are structured for
the glass not to scatter, however, if you
mistakenly touch broken or exposed parts,
you may be injured.
To sound the high-pitched alarm,
always keep FOMA terminal away
from your ears.
May cause hearing loss.
CAUTION
Do not swing FOMA terminal by its
strap.
May cause the terminal damage or failure, or
injury to yourself or others.
When using the motion tracking or
motion sensor, check the safety
around you, hold FOMA terminal
firmly, and do not shake it
unnecessarily.
The motion tracking and motion sensor are
functions to operate by tilting or shaking
FOMA terminal. There is a risk that FOMA
terminal hits people or objects around you by
shaking it too much, causing a serious
accident or damage.
If you put a metal strap or the like to
FOMA terminal, be careful not to let
the strap hit people or objects around
you when performing motion tracking
or using motion sensor.
Accidents such as injury, malfunction or
damage may result.
If the display part is accidentally
broken and liquid crystal leaks out, do
not put the liquid in your mouth,
inhale, or make contact with your skin.
If the liquid gets into your eyes or
mouth, rinse it with clean water and
see a doctor immediately.
And, if the liquid adheres to skin or
clothing, use alcohol etc. to wipe it off,
then wash with soap.
May cause loss of sight or skin problems.
Do not bring the speaker close to your
ear when the ring alert is sounding or
you are playing a melody with FOMA
terminal.
May cause hearing loss.
In rare cases, using the phone in some
vehicle models can cause the vehicle's
electronic equipment to malfunction
or fail.
In this case, do not use the phone because it
may hamper safe driving.
Do
Do
Do
Don’t
Don’t
Don’t
Don’t
Don’t
Do
F-06B_EN_FCC
11
Introduction
Mobile phones can give some users
skin problems such as itching, allergic
reactions or rashes. If you develop skin
problems, stop using the phone
immediately, and see a doctor.
FOMA terminal contains metal in the
parts below.
When opening or closing FOMA
terminal, take care not to have your
fingers or strap caught by the
terminal.
May cause injuries or damages.
When watching 1Seg, take a certain
distance from the display in a fully
bright place.
May cause your eyesight to be impaired.
■
Check that the battery type matches the
type displayed on the battery pack label.
DANGER
Do not connect a wire or other metal
objects to the jack. And, do not carry
or store FOMA terminal with objects
like a metal necklace.
May cause the battery pack to leak, heat, burst
or ignite.
Do not try to force the battery pack
onto FOMA terminal if you are having
trouble installing it. Always install it
after checking that it is correctly
oriented.
May cause the battery pack to leak, heat, burst
or ignite.
Do not throw the battery pack into the
fire.
May cause the battery pack to leak, heat, burst
or ignite.
Do not nail the battery pack, hit with a
hammer or step on it.
May cause the battery pack to leak, heat, burst
or ignite.
If the battery pack's fluid contacts
eyes, immediately flush the eyes with
clean water and see a doctor right
away. Do not rub the eyes.
May cause loss of sight.
WARNING
If the battery pack seems to have
abnormalities such as deformation or
scratches due to an external impact or
falling, stop using it immediately.
May cause the battery pack to leak, heat, burst
or ignite, and the equipment to malfunction
or catch fire.
If the battery pack does not have a full
charge after being charged for the
specified time, stop charging it.
May cause the battery pack to leak, heat, burst
or ignite.
If the battery pack leaks or gives off a
strange smell, immediately remove it
from the vicinity of open flames.
The vapors from leaking battery pack fluid
may ignite or explode.
Be careful not to let your pet bite the
battery pack.
Part Material Surface treatment
Charging jack ABS Gold plating
Battery pack
connector jack
Beryllium
copper
Gold plating
Back cover plate SUS None
Rear side of the
back cover
SUS None
Screw SUS None
External
connection jack
SUS Gold plating
Nameplate
attach place
PC board Gold plating
Slide swing
module
SUS Electrodeposition
coating
1Seg antenna SUS None
Do
Do
Handling battery pack
Display Battery type
Li-ion 00 Li-ion battery
Do
Don’t
Don’t
Don’t
Don’t
Do
Don’t
Do
Do
Do
F-06B_EN_FCC
12
Introduction
May cause the battery pack to leak, heat, burst
or ignite, and the equipment to malfunction
or catch fire.
CAUTION
Do not discard old battery packs
together with other garbage.
May cause igniting or environmental
destruction. Tape the terminals of old battery
packs to insulate them, and then bring them
into a sales outlet such as docomo Shop. If
your local municipality has a battery recycling
program, dispose of them as provided for.
Do not charge a wet battery pack.
May cause heat generation, ignition or
rupture of the battery pack.
If the battery pack's fluid contacts skin
or clothes, immediately flush the
contacted area thoroughly with clean
water.
May hurt the skin.
WARNING
Do not use the adapter cord or power
cord if it gets damaged.
May cause electric shock, heat or fire.
Do not use the AC adapter or desktop
holder in a bathroom or other highly
humid area.
May cause electric shock.
Always use the DC adapter with a
negative-ground vehicle. Do not plug
it into a positive-ground vehicle.
May cause fire.
When it starts to thunder, do not
touch FOMA terminal and adapter.
May be subject to lightning strike and could
cause electric shock.
Do not short the charging jack while it
is connected to the outlet or cigarette
lighter socket. Do not touch the
charging jack with a part of your body
such as your hand or finger.
May cause fire, malfunction, electric shock or
injuries.
Place the adapter and desktop holder
in a stable location while charging. Do
not cover or wrap the adapter and
desktop holder with a cloth or blanket.
May cause FOMA terminal to be removed or
the optional devices to be heated, resulting in
fire or troubles.
Do not place heavy objects on the
adapter cord or power cord.
May cause electric shock or fire.
Do not touch the adapter cord,
desktop holder or outlet with wet
hands.
May cause electric shock.
Only use with the specified power
source and voltage.
If incorrect voltage is used, this may cause fire
or failure. When using FOMA terminal
overseas, use AC Adapter for global use.
AC adapter : AC100V
DC adapter : 12 or 24V DC (specific for
negative ground vehicle)
AC adapter for global use : Between 100V and
240V AC (Connect to the AC outlet for
internal household use)
If the DC adapter's fuse blows, replace
it only with the specified fuse.
Using other fuses may cause fire or
equipment failure. For the specified fuse, see
the instructions that come with the DC
adapter.
Wipe off any dust that accumulates on
the power plug.
May cause fire.
When you connect the AC adapter to
an outlet, make sure not to touch with
metal such as metal straps and firmly
connect to the outlet.
May cause electric shock, electrical short or
fire.
Handling adapter and desktop
holder
Don’t
Don’t
Do
Don’t
Don’t
Don’t
Don’t
Don’t
Don’t
Don’t
No wet hands
Do
Do
Do
Do
F-06B_EN_FCC
13
Introduction
When you disconnect the adapter
from the outlet or cigarette lighter
socket, do not pull the adapter cord or
power cord with excessive force.
Instead, hold the power plug to
disconnect.
Pulling the cord could damage it, possibly
leading to electric shock or fire.
Always remove the power plug from
the outlet when not using the adapter
for an extended period.
May cause electric shock, fire or malfunction.
Immediately remove the power plug
from the outlet or cigarette lighter
socket if water or other fluids get into
the adapter.
May cause electric shock, smoke or fire.
Always remove the power plug from
the cigarette lighter socket when
cleaning the equipment.
May cause electric shock.
CAUTION
Be careful of the cut surface when
removing UIM (ICs).
May hurt hands or fingers.
■
These precautions are based on the
guidelines produced at the Electromagnetic
Compatibility Conference Japan, regarding
the protection of electronic medical
equipment from radio waves emitted by
mobile phone units.
WARNING
Obey the following rules inside
medical facilities.
･
Do not bring FOMA terminal into operating
rooms (ORs), intensive care units (ICUs) or
coronary care units (CCUs).
･
Turn FOMA terminal OFF in hospital wards.
･
Turn FOMA terminal OFF in hospital
lobbies and corridors if electronic medical
equipment could be nearby.
･
If the medical facility has specified zones
where use or possession of mobile devices
is prohibited, obey those instructions.
･
If the function to automatically turn ON the
power is set, cancel the setting before
turning the power OFF.
Turn FOMA terminal OFF in crowded
trains or other public places where
pacemaker or defibrillator wearers
could be nearby.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
Wearers of implanted pacemakers or
defibrillators must carry and use
FOMA terminal at least 22 cm away
from the implanted device.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
When electronic medical equipment
other than implanted pacemakers or
defibrillators are in use outside of
medical facilities (such as in home care
settings), check with the device
manufacturer to determine how the
device is affected by electrical signals.
FOMA terminal's signals may affect the
performance of electronic medical
equipment.
Handling UIM
Do
Unplug
Unplug
Unplug
Do
Handling mobile phones near
electronic medical equipment
Do
Do
Do
Do
F-06B_EN_FCC
14
Introduction
Handling precautions
・
F-06B is waterproof, however, do not allow water or dust to seep into FOMA
terminal and do not allow accessories or optional devices to get wet or let dust
attach.
- FOMA terminal is provided with waterproofness of IPX5 and IPX8 (which
exceeds IPX7) by firmly closing the external connection jack cap and installing
the back cover in a locked state, however, it is not complete waterproofness. Do
not install/remove the battery pack or do not open/close the external connection
jack cap and back cover in the rain or with waterdrop adhered to them. Water
may seep inside and cause corrosion or malfunction. Also, accessories and
optional devices are not waterproof. Malfunctions, which are determined to be
caused by water as result of inspections, are not covered by the warranty. Since
these conditions are outside the scope of the warranty, a repair, if at all possible,
is charged.
・
Clean FOMA terminal with a dry soft cloth (such as a cloth for eyeglasses).
- The display of FOMA terminal may have been applied special coating to improve
clearness of the color LCD. When cleaning FOMA terminal, rubbing it roughly
with a dry cloth can scratch the display. Take care when handling the unit, and
clean it with a dry soft cloth (such as a cloth for eyeglasses). Drops of water or
dirt left on the display can cause stains or remove the coating.
- If FOMA terminal is wiped with alcohol, paint thinner, benzine or detergent, the
printing may disappear or color may fade.
・
Clean the jack occasionally with a dry cotton swab etc.
- If the jack is soiled, connection gets worse and it may cause power to be turned
off or insufficient battery charge, so clean the jack with a dry cotton swab etc.
Also, be careful never to damage the jack when cleaning it.
・
Do not place FOMA terminal near an air-conditioner outlet.
- The rapid change in temperature may cause condensation, causing internal
corrosion and malfunction.
・
When using, be careful not to subject excessive force to FOMA terminal or the
battery.
- If FOMA terminal is crammed into a brimming bag or placed in a pocket and sat
on, display, internal PCBs or battery pack may be damaged or malfunction. And,
if external devices are plugged into the external connection jack (earphone/
microphone jack), the breakage of the connector or malfunction may result.
・
Carefully read the separate instructions that come with FOMA terminal and
adapter.
・
Do not rub or scrape the display with a metal piece etc.
- It may scratch the display, causing malfunction or damage.
・
Do not press the surface of the touch panel strongly or operate it with sharp
objects such as a nail, a ballpoint pen and a pin.
- It may damage the touch panel.
・
Avoid extreme temperature.
- Use FOMA terminal where the temperature ranges between 5 and 40
℃
(limited
to the temporary use in a bathroom etc. when temperature is above 36
℃
) and
humidity ranges between 45 and 85%.
・
FOMA terminal may affect land-line phones, TVs or radios in use nearby, so use
it as far as possible from these appliances.
・
Maintain a separate record of the data you saved in your FOMA terminal.
- If the data is deleted, DOCOMO assumes no responsibility for the loss of any
data.
・
Do not drop FOMA terminal or subject it to shocks.
- May cause malfunction or damage.
・
Do not plug external devices into the external connection jack (earphone/
microphone jack) at a slant, or do not pull it forcibly while it is plugged.
- May cause malfunction or damage.
・
Do not close FOMA terminal with the strap etc. held inside.
- May cause malfunction or damage.
・
It is normal for FOMA terminal to become warm during use or charging.
Continue to use it.
General
FOMA terminal
F-06B_EN_FCC
15
Introduction
・
Do not leave FOMA terminal with the camera in areas under strong direct
sunlight.
- May cause discoloring or burn-in of materials.
・
FOMA terminal should normally be used with the external connection jack cap
closed.
- Dust and/or water brought into FOMA terminal cause troubles.
・
Do not use FOMA terminal with the back cover removed.
- Label or sticker may be hooked when opening/closing FOMA terminal and may
cause malfunction or damage.
・
Do not put label or sticker on the back side of display.
- Doing so may cause malfunction.
・
Do not put strong impact on the fingerprint sensor or scratch its surface.
- It may cause malfunction of fingerprint sensor and disable authentication
operation.
・
Clean the fingerprint sensor with a dry soft cloth (such as a cloth for eyeglasses).
- If the fingerprint sensor is dirty or water is sit on its surface, the sensor does not
read fingerprints, decreases its authentication performance, or erroneously
operates authentication function with no finger on it.
・
While microSD card is being used, do not take the card out and do not turn off
FOMA terminal.
- May cause data loss or malfunction.
・
Do not bring magnetic cards etc. close to FOMA terminal.
- Magnetic data in cash cards, credit cards, telephone cards, floppy disks, etc. may
be erased.
・
Do not bring magnetized objects close to FOMA terminal.
- Bringing strong magnetism close may cause a malfunction.
・
The battery pack is a consumable part.
- Replace the battery pack if FOMA terminal has extremely short operation time
on a full charge, though it may vary by operating conditions. Purchase a new
battery pack of the specified type.
・
Charge the battery in an area within the proper ambient temperature range (5-
35
℃
).
・
Always charge before using it for the first time or after extended disuse.
・
The operation time provided by the battery pack varies by the operating
environment and battery pack's deterioration.
・
The battery pack may swell out as it comes to near the end of its lifetime
depending on the usage conditions, but it is not a problem.
・
Be careful especially about the following points when preserving or leaving the
battery pack for a long time.
- Keeping under the state of the full charge (right after charging ends)
- Keeping under the state of the empty charge (too exhausted to turn on FOMA
terminal)
They may cause the battery pack performance to be degraded or its lifetime to be
shortened.
For necessary battery level to keep for a long time, the display of battery icon is a
state of approximately 2 or 3 cells.
・
Charge the battery in an area within the proper ambient temperature range (5-
35
℃
).
・
Do not charge the battery in the areas below.
- In areas of excessive humidity, dust or vibrations
- Near land-line phones or TVs/radios
・
It is normal for the adapter to become hot while charging. Continue to use it.
・
When using the DC adapter for charging, keep the vehicle engine running.
- The vehicle's battery could become flat.
・
When using an outlet with a mechanism preventing unplugging, follow the
handling instructions for that outlet.
・
Do not give strong shock. Do not deform the charging jack.
- Doing so may cause malfunction.
Battery pack
Adapter
F-06B_EN_FCC
16
Introduction
・
Do not use excessive force to install/remove UIM.
・
It is normal for UIM to become warm during use. Continue to use it.
・
Note that DOCOMO assumes no responsibility for malfunctions occurring as the
result of inserting and using a UIM with another IC card reader/writer.
・
Always keep UIM ICs clean.
・
Clean UIM with a soft, dry cloth (such as a cloth for eyeglasses).
・
Maintain a separate record of the data you saved in UIM.
- If the data is deleted, DOCOMO assumes no responsibility for the loss of any
data.
・
To preserve the environment, bring the old UIM to a sales outlet such as
docomo Shop.
・
Avoid extreme temperature.
・
Take care not to scratch, touch accidentally or short IC.
- May cause data loss or malfunction.
・
Do not drop UIM or subject it to shocks.
- May cause malfunction.
・
Do not bend UIM or place heavy objects on it.
- May cause malfunction.
・
Do not install UIM into FOMA terminal with a label or sticker put on UIM.
- May cause malfunction.
・
This FOMA terminal is equipped with the security features, that are compliant
with Bluetooth standards for communication via Bluetooth. However,
depending on the settings, there may not be enough security. Be aware of
security risks when using Bluetooth.
・
DOCOMO assumes no responsibility for any information which may be leaked
during communication via Bluetooth.
・
You can use handsfree, headset, audio, keyboard, dial-up connection, object
push and serial port devices with FOMA terminal. An audio/video remote
control may be available with an audio device (only Bluetooth compatible
devices).
・
Frequency bands
Frequency bands used by FOMA terminal Bluetooth function are as below.
a
2.4 : Radio equipment that uses the 2400 MHz band.
b
FH : The modulation is the FH-SS method.
c
1 : The expected interference distance is 10 m or shorter.
d
: All bandwidths between 2400 MHz and 2483.5 MHz are used,
and the bandwidth used by mobile object identification devices cannot be
avoided.
Cautions on using Bluetooth devices
In the bandwidth used by this terminal, in addition to home electric appliances
such as a microwave oven and industrial/scientific/medical devices, in-plant
radio stations used to identify mobile objects used in production lines of a
factory that require a license, specified low power radio stations, or amateur
radio stations that do not require a license (hereafter "other radio stations") can
be in operation.
1. Before using this terminal, check whether other radio stations are in
operation in your neighborhood.
2. If radio wave interference occurs between the terminal and "other radio
stations", use the terminal in a different location or "Turn the power OFF" to
avoid the radio wave interference.
3. For more detailed information, contact "General Inquiries" using the phone
number on the back of this manual.
UIM
Bluetooth
®
devices
Wireless LAN (WLAN)
ab
d
c
2.4FH1
F-06B_EN_FCC
17
Introduction
・
Wireless LAN
Do not use Wireless LAN in a place where magnetized by electric products, AV, OA
equipment, etc. or where electromagnetic wave is generated.
- If magnetism or electrostatic noise affects FOMA terminal, noise may be
increased or communication may not be available (especially when using
microwave oven, it may affect the terminal).
- Using near TV or radio may cause poor reception or TV screen may be blurred.
- When multiple wireless LAN access points exist near FOMA terminal and they
use the same channel, search may not be performed correctly.
・
Frequency bands
Frequency bands for WLAN devices are written on battery pack insert section of
phone. Label description are as follows.
a
2.4 : Radio equipment that uses the 2400 MHz band.
b
DS : The modulation is the DS-SS method.
c
OF : The modulation is the OFDM method.
d
4 : The expected interference distance is 40 m or shorter.
e
: All bandwidths between 2400 MHz and 2483.5 MHz are
used, and the bandwidth used by mobile object identification devices cannot
be avoided.
To use wireless LAN in FOMA terminal in 5.2/5.3 GHz, do not use outside because
of Radio Law.
Available channel varies by countries.
To use in airplane, confirm with airline company in advance.
Cautions on using 2.4GHz devices
In the bandwidth used by WLAN devices, in addition to home electric
appliances such as a microwave oven and industrial/scientific/medical devices,
in-plant radio stations for identification of mobile objects used in production
lines of a factory (a license is required), specified low power radio stations (a
license is not required), or amateur radio stations (a license is required) can be
in operation.
1. Before using this device, confirm that in-plant radio stations for
identification of mobile objects, specified low power radio stations or
amateur radio stations are not in operation in your neighborhood.
2. If this device generates harmful radio wave interference against in-plant
radio stations for identification of mobile objects, change the using
frequency promptly or stop using wireless LAN function, and contact
"General Inquiries" on the last page of this manual, then consult about
treatment for prevention of the interference (for example, installation of
partitions etc.).
3. In addition, if you have any problems such as this device generates radio
wave interference against specified low power radio stations for
identification of mobile objects or amateur radio stations, etc., contact
"General Inquiries" on the last page of this manual.
・
FeliCa reader/writer function of FOMA terminal uses weak waves requiring no
licenses for radio stations.
・
It uses 13.56 MHz frequency band. When using other reader/writers in your
surroundings, keep FOMA terminal away sufficiently from them. Before using
the FeliCa reader/writer, confirm that there are no radio stations using the same
frequency band nearby.
・
FM transmitter of FOMA terminal uses weak waves requiring no licenses for
radio stations.
2.4DS/OF4
abc
e
d
FeliCa reader/writer
FM transmitter
F-06B_EN_FCC
18
Introduction
・
It uses 77.4 - 85.0MHz frequency band. To use it, set frequency not to common
to FM radio station of the area you use to avoid affecting FM radio users in
neighborhood.
・
Do not use a remodeled FOMA terminal. Using a remodeled terminal violates
the Radio Law.
FOMA terminal is certified according to technical standard conformance of specified
wireless equipment based on the Radio Law, and as a proof of it, the "Technical
Compliance Mark " is depicted on the engraved sticker of FOMA terminal.
If you remodel FOMA terminal by removing its screws, your certification of
technical standard conformance becomes invalid.
Do not use FOMA terminal with its certification of technical standard conformance
invalid as it violates the Radio Law.
・
Be careful when you use FOMA terminal while driving a car etc.
Using a mobile phone while driving is subject to penal regulations.
If you inevitably receive a call, tell the caller that you will "call back" by handsfree,
then park in a safe place and call back.
・
Use the Bluetooth function only in Japan.
The Bluetooth function of the FOMA terminal is compliant with wireless standards
and is authorized for use only in Japan.
If you use this function overseas, you may be punished.
・
Use the wireless LAN function only in Japan.
The wireless LAN function of FOMA terminal is compliant with wireless standards
and is authorized for use only in Japan.
If you use this function overseas, you may be punished.
・
Use FeliCa reader/writer function only in Japan.
FeliCa reader/writer function of FOMA terminal conforms to Japanese radio
standards.
If you use this function overseas, you may be punished.
・
Use FM transmitter only in Japan.
FM transmitter of FOMA terminal is compliant with wireless standards and is
authorized for use only in Japan.
If you use this function overseas, you may be punished.
CAUTION
Waterproofness
F-06B is provided with the following waterproofness by firmly
closing the external connection jack cap, installing the back cover
and locking the cover.
・
IPX5 (Former JIS protection code 5)
*1
・
IPX8
*3
that is a higher standard than IPX7 (former JIS protection
code 7)
*2
*1
Code IPX5 means that a phone keeps functioning after directly applying a
jet flow of 12.5 L/min. for at least 3 minutes from a distance of 2.5-3 m on a
rotating turntable.
*2
Code IPX7 means that a phone keeps functioning after it is slowly
submerged to depth of 1 m in static tap water at room temperature, left there
for 30 minutes and then taken out.
*3
Code IPX8 means that it provides waterproofness of which exceeds of IPX7
standard.
F-06B provides the following waterproof performances of IPX8.
･
F-06B keeps functioning after it is slowly submerged to depth of 1.5
m in static tap water at room temperature, left there for 30 minutes
and then taken out.
･
The mobile phone keeps shooting still images or moving pictures in
30 minutes in static tap water at room temperature.
F-06B_EN_FCC
19
Introduction
✜
What you can do with waterproofness of F-06B
・
You can talk or watch 1Seg programs without using an umbrella in
the rain (for rainfall of 20 mm or less per hour).
- When your hands or FOMA terminal are wet, avoid installing/
removing the back cover or opening/closing the external
connection jack cap.
・
You can also shoot still images and moving pictures in the pool
depth of 1.5 m.
- Do not perform other operations underwater than shooting still
images and moving pictures.
- If you put the terminal in water of swimming pool, be sure to have
it within 30 minutes.
- If FOMA terminal gets wet with water from the swimming pool,
wash it in after-mentioned procedure and drain the water as
predefined (
⇒
P21).
・
You can use FOMA terminal in a bathroom.
- Do not put the terminal in the bathtub. Do not use the terminal in
hot water. Doing so may cause malfunction.
- Never put FOMA terminal in hot spring water or water containing
soap, detergent or bath powder.
・
You can immerse FOMA terminal in static water of wash bowl and
wash dirt out with shaking the terminal.
- Install the back cover and with it locked, holding the external
connection jack cap not to be opened and wash it with your hands
not using brush, sponge, etc.
To ensure waterproofness
To avoid water ingress, be sure to observe the points below.
・
Do not throw any liquid other than room-temperature tap water on
FOMA terminal, or soak it in such liquid.
・
Open/close the external connection jack cap as described below.
<Opening the external connection jack cap>
Place your finger at groove on the hinge side to open the cap.
<Closing the external connection jack cap>
Close with the tab for the back cover at the rear side of the cap fitted
into the concave of this terminal. Make sure that the cap is
completely closed without slack.
Groove on the hinge side
Tab on the back cover side
F-06B_EN_FCC
20
Introduction
・
Install the back cover as described below.
<Installing the back cover>
Align 8 tabs of the back cover with concaves of FOMA terminal.
While pressing the back cover in the direction of
a
so that there is
no gap between FOMA terminal and back cover, slide the back cover
in the direction of
b
to install, then slide the back cover lever in the
direction of
c
to lock.
*
Make sure that the back cover is completely closed without slack. Slide the
back cover in the direction of the arrow shown on the lever, and then make
sure the cover is securely locked before using.
・
Securely lock the back cover and firmly close the external connection
jack cap. Even a fine obstacle (one hair, one grain of sand, tiny fiber,
etc.) put between contact surfaces may allow water to enter.
・
Do not poke the microphone, earpiece or speaker with a swab or
sharp object.
・
Do not let FOMA terminal fall. It may become scratched causing the
waterproof performance to degrade.
・
The external connection jack cap and the rubber packing of the inner
lid play an important role for keeping waterproof performance. Do
not remove or scratch it. Also, prevent dust from adhering to it.
To keep the FOMA terminal waterproof, replacement of parts is
required every 2 years regardless of whether FOMA terminal appears
normal or abnormal. DOCOMO replaces the parts as a chargeable
service. Bring FOMA terminal to a sales outlet such as a DOCOMO-
specified repair office.
Important precautions
Do not perform actions shown in the illustrations below.
Observe the following precautions to use FOMA terminal properly.
・
Accessories and optional devices are not waterproof. When
watching 1Seg etc. with FOMA terminal installed in the included
desktop holder, do not use it in a bath room, shower room, kitchen
or lavatory even if it is not connected to the AC adapter.
b
a
c
Back cover
Lever
Using Soap/Detergent/
Bath power
Soaking in ocean water
Applying strong water flow Using in hot spring
Soiling with sand/mud
<Example>
F-06B_EN_FCC
21
Introduction
・
Do not apply water flow stronger than allowed (
⇒
P18) (e.g., such
water flow that gives you pain when applied to your skin directly
from a faucet or shower). F-06B provides the following waterproof
performances of IPX5. However, it causes malfunction.
・
Do not put FOMA terminal in hot water, use it in a sauna or apply hot
airflow (from a hair dryer etc.) to it.
・
Do not move in water or slam the terminal against the surface of
water with FOMA terminal opened.
・
If you put the terminal in tap water or in water of swimming pool, be
sure to have it within 30 minutes.
・
When you use the terminal in swimming pool, obey rules of the
facility.
・
FOMA terminal does not float on water.
・
Do not leave water on FOMA terminal. May short-circuit the power
jacks, or in a cold region, water may freeze causing malfunction.
・
Do not leave water on the microphone, earpiece or speaker. Such
water may interfere with talking.
・
If the back cover is damaged, replace it. Water may enter inside from
a damaged section causing troubles such as electric shocks or
corrosion of the battery.
・
If FOMA terminal gets wet with water or other liquids with the
external connection jack cap or back cover open, the liquid may get
inside the terminal causing electric shocks or malfunction. Stop
using FOMA terminal, turn the power OFF, remove the battery pack
and contact a DOCOMO-specified repair office.
・
If rubber gasket on the external connection jack cap or inner lid is
damaged or deformed, replace it at DOCOMO-specified repair office.
DOCOMO does not guarantee actual operations under all states.
Malfunctions deemed to be caused by inappropriate operation by the
customer are not covered by the warranty.
When FOMA terminal is wet, water may flow out after wiping it off;
drain the water in the following steps.
a
Wipe FOMA terminal surface with dry, clean cloth etc.
Draining the water from FOMA terminal
F-06B_EN_FCC
22
Introduction
b
Shake FOMA terminal approximately 20 times, firmly holding its
hinge section, until there is no more water splattering.
c
Softly press dry, clean cloth etc., against FOMA terminal to wipe
off water remaining in the microphone, earpiece, speaker, keys,
hinges or charging jack.
d
Remove the back cover and wipe off any drops of water around
the inner lid and the rear side of the back cover. Never open the
inner lid. After wiping off the water, install and lock the back
cover.
Removing back cover
⇒
P24
e
Wipe off water drained from FOMA terminal with dry, clean cloth
etc., and dry naturally.
･
Water, if any, remaining in FOMA terminal may ooze up after
wiping off.
･
Do not wipe off water remaining in concaves directly with a cotton
swab etc.
To drain water off the speaker,
shake FOMA terminal with the speaker upward
Around the inner lid
Rear side of the back cover
F-06B_EN_FCC
23
Introduction
Check the following before and after charging.
・
Check that FOMA terminal is not wet. Never try to charge the battery
pack when FOMA terminal is wet.
・
Accessories and optional devices are not waterproof.
・
When charging the battery when or after FOMA terminal is wet,
adequately drain it and wipe off water with a dry, clean cloth etc.,
before connecting the included desktop holder or opening the
external connection jack cap.
・
When the external connection jack cap is opened for charging, close
the cap firmly after charging. It is recommended that the desktop
holder be used for charging to prevent water from seeping inside
from the external connection jack.
・
Do not use the AC adapter or desktop holder in a bathroom, shower
room, kitchen, lavatory or other highly humid area. May cause fire or
electric shock.
・
Do not touch the AC adapter or desktop holder with wet hands. May
cause electric shock.
Charging
F-06B_EN_FCC
24
Basic Operation
Before Using
Attaching UIM (FOMA card)/battery pack
After turning power OFF, close FOMA terminal and hold it in your
hand so that you can properly attach UIM/battery pack.
✜
Removing Back Cover
Slide the back cover lever in the direction of
a
to unlock, and then
slide the cover in the direction of
b
by 2 mm with a thumb to remove
it. Pinch the tab of the inner cover and open the cover in the direction
of
c
until it stops.
✜
Installing UIM
Pull the tab with your nail and pull out the tray until it clicks (
a
). Hold
UIM with the IC side down, align the beveled corner with the tray (
b
)
and push into the tray until it stops (
c
).
Point
･
UIM (blue) is not available for this FOMA terminal. If you have the UIM
(blue), bring it to a docomo Shop.
✜
Installing battery pack
With the label side of the battery pack upward, align convex parts of
the battery pack with concave parts of FOMA terminal and slide the
battery pack in the direction of
a
, press the battery pack in the
direction of
b
to set it in, and then close the inner cover.
✜
Installing back cover
Place the 8 tabs of back cover to the notches, press back cover in the
direction of
a
to avoid forming any clearance between FOMA
terminal and back cover, then slide it in the direction of
b
to install it.
Finally, slide the lever in the direction of
c
to lock.
Point
･
The inner cover is designed to be firmly closed for maintaining
waterproofness. Opening the cover forcibly may injure your nails or
fingers.
･
To prevent damage due to excessive force, the hinge of the inner cover
(the section where FOMA terminal makes contacts) is designed to be
removed. If it is detached, align metal pins on the inner cover with the
slots on FOMA terminal, and then press the cover until it clicks.
Lever
Back cover
Press here with your thumb
Tab
Tray
IC
UIM
Corner cut
Tab
Battery pack
Convex part
Concave part
Back cover
Lever
F-06B_EN_FCC
25
Basic Operation
Before Using
Charging
The battery pack does not have a full charge at time of purchase.
Use AC adapter for FOMA terminal to charge the battery before
using FOMA terminal.
a
Insert the connector of AC adapter horizontally to the
accessory desktop holder, with the arrow mark side upward.
b
Unfold the AC adapters power plug and insert it into a
100V AC outlet.
c
With FOMA terminal closed, insert it into the desktop holder.
*
Check that the light turns on.
d
After charging is completed, remove FOMA terminal
from the desktop holder.
a
Open jack cap (
a
) of FOMA terminal, hold the
connector horizontally with the arrow side upward and
insert it to the jack. (
b
)
b
Unfold the power plug and insert it into a 100V AC
outlet.
*
Check that the light turns on.
c
When charging is over, pull out the power plug from
the outlet, and pull out from FOMA terminal
horizontally while pressing the release buttons on both
sides of the connector.
✜
Operations for charging
When charging starts, a charge start alert sounds. While charging, the
light turns on and the battery icon on the display blinks. When
charging is over, a charge completion alert sounds.
Using desktop holder and AC adapter in
combination for charging
Light AC adapter
Release
button
100V AC outlet
Power plug
Connector
Desktop holder
Insert at the back side
Charging using AC adapter
Light
Connector
Release button
AC
adapter
Jack cap
100V AC outlet
Power plug
External
connection
jack
F-06B_EN_FCC
26
Basic Operation
Before Using
Turning power ON - Configuring default setting
Perform the following operations after turning the power ON for
the first time.
af
(2 sec. or more)
b
"Yes" or "No" on a confirmation
screen of enlarged menu setting
The screen shown to the right appears.
c
Set required items
eC
[Complete]
Always set Password and Request permit/
deny. If you exit without setting, Initial
setting screen reappears when the power
is turned ON the next time.
dg
on a confirmation screen of software update
function
The stand-by display appears.
Point
･
If no operation is performed, the display light is turned off automatically
according to the settings in Light time-out or Power saving mode. The
display light turns on again if there is any operation or incoming call.
Turning power off :
f
(2 sec. or more)
Changing the initial setting :
mehhb
Changing screen display to English :
mehdde
Select "English"
<Initial setting screen>
Before Using
User information
Check your own phone number.
For details of checking/changing a mail address, refer to "Mobile
Phone User's Guide [i-mode] FOMA version".
ame0
User information
The screen shown to the right appears.
Point
Editing user information :
On User information edit screen,
Ce
Authenticate
e
Edit
eC
Checking a phone number during a call :
se0
<User information
screen>
F-06B_EN_FCC
27
Basic Operation
Screen Explanation
Viewing display
The current state can be checked by the icon appearing on the screen. Major icons are as follows.
Battery level (Battery icon)
Signal strength (Antenna icon)
:
Self mode ON
:
In data transfer mode
:
Connecting to i-mode
:
Infrared communication in operation
:
Bluetooth ON
:
The total calls cost exceeds the limit
:
Bluetooth connection being
established
:
Communication using handsfree-
compatible device in progress
:
Handsfree ON
:
Power saver mode ON
:
Positioning with GPS
:
Location request setting
●
:
Security lock ON
●
:
Kid-safe mode ON
:
A phonebook entry or schedule has
secret attribute
●
:
High-pitched alarm "ON"
:
Unread Area Mail exists
:
Unread i-mode mail exists
:
Arrival i-concier information exists
:
Unreceived i-mode mail exists in i-
mode Center
:
Displaying SSL/TLS page etc.
:
Auto-send mail exists
:
Music&Video Channel program
obtaining reservation exists
:
During i-
α
ppli operation
:
i-
α
ppli call exists
:
Alarm clock ON
:
Schedule reminder ON
:
Inside OFFICEED area
●
:
WLAN connection status
Top of the display
Ample
charge
Almost exhausted
(Charge the battery)
Strong Out of service area or where
radio waves do not reach
Weak
Arrival information (Starting from the left,
missed call, recorded message, voice mail
service, unread message, unread ToruCa,
i-
α
ppli call)
:
Manner mode ON
:
Call alert volume OFF
:
Vibration mode for voice call ON
:
In Public mode (Drive mode)
:
Record message setting ON
:
Keypad dial lock ON
:
GPS Request failed
:
Personal data lock ON
:
Music&Video Channel program
obtaining failure
:
Reading UIM
:
IC card lock ON
:
Available multi-cursor key
:
Performing 1Seg recording
reservation
:
i-
α
ppli Auto start failed
:
microSD card installed during
Communication mode
:
Connected to external device using
USB cable
●
:
Pedometer/ACT monitor is set
:
Software update rewrite notice
:
Auto-update of latest pattern definition
failure
Bottom of the display
F-06B_EN_FCC
28
Basic Operation
Screen Explanation
Menu operation
On the stand-by display, press
m
and then perform the
functions from the menu. You can select a menu item with
shortcut operations, which use the keypad,
*
and
#
, or with
multi-cursor operation, which uses the multi-cursor key to move
the cursor.
<Example> Selecting "Calculator"
Shortcut operations
ame6e2
Multi-cursor key operations
ame
Move the cursor to "
f
LifeKit"
eg
[OK]
e
Move the cursor to "
b
Calculator"
eg
[OK]
Point
･
Even when a function is running, you can perform the same operation if
"Submenu" is displayed on the guide area.
･
To return to the previous screen, press
c
. To return to the stand-by
display, press
f
.
･
On the stand-by display with Info/calendar layout, Shortcut icons set, or
with arrival information icon or i-concier information displayed, press
g
to change the display to Focus mode that allows you to quickly display the
related information.
You can switch among "Kisekae menu", the design of which can be
changed using Kisekae Tool (
⇒
P40), "Basic menu", which has the
fixed menu numbers, and "Custom menu", to which menu items
can be saved freely.
A Kisekae menu matched with the color of FOMA terminal is set by
default.
Point
･
In some types of Kisekae menus, the menu structure is changed according
to usage frequency, or the number assigned to menu item (item number)
may not be applicable.
･
The menu that appears when
m
is pressed on the stand-by display can
be changed from the start menu.
⇒
P37
m 7 4
Switching menu screens
<Custom menu><Kisekae menu>
<Basic menu>
IC
F-06B_EN_FCC
29
Basic Operation
The icon indicating the
function (task) in progress
appears in the task area.
Operations that can be performed
by pressing
m
,
I
,
g
,
C
and
a
are displayed in the guide
area. To perform an operation in the
guide area, press the corresponding
key.
The display in the guide area
automatically switches according to
the tilt of FOMA terminal.
Task area
Guide area and key operation
･
You can operate FOMA terminal by double-tapping (tapping it twice) or
tilting it to stop alarm sound, switch images, or scroll Browser screen,
etc.
【 モーションセンサー
(Motion sensor)
】
<Vertical display>
Task area
<Horizontal display>
Guide area
Information
Screen Explanation
Using touch panel
You can use the display as touch panel. You can perform the same
operation by touch operation as on the screen to move the cursor
with key operation.
Touch
Touch the display lightly once and release the finger. The
operation becomes effective when you release your finger
from the display. This operation is mainly for selecting
menus, items, etc.
Double-
touch
Touch the display lightly twice and release the finger. The
operation becomes effective when you release your finger
from the display. This operation is mainly for zooming in/
out or switching the display.
Slide
Keep touching the display, move your finger up, down,
right or left. This operation is for scrolling a screen,
rewinding/fast-forwarding a video, etc.
Slide
quickly
Touch the display lightly and flick your finger up, down,
right or left. This operation is for switching pages or
images, or moving to a different chapter or tune, etc.
Example: SlideExample: Touch
F-06B_EN_FCC
30
Basic Operation
You can notify your phone number (caller ID) to the other party's
terminal when making a voice call.
ameg
TEL function
ed
Dial/Receive call
setting
ec
Caller ID notification
ea
Activate/
Deactivate
ea
Notify
Select "
b
Not notify" if you do not want to notify.
Point
･
Caller ID is your important personal information. Carefully consider
whether you want to include caller ID information when making a call.
･
If an announcement of requesting caller ID is heard when making a call,
set the caller ID notification or call again with prefix "186".
Caller ID notification
(Default : Notify)
F-06B_EN_FCC
132
Others
Appendix
Specific absorption rate (SAR) of mobile phone
This model phone FOMA F-06B meets the MIC's
*1
technical regulation
governing exposure to radio waves.
The technical regulation established permitted levels of radio frequency
energy, based on standards that were developed by independent scientific
organizations through periodic and thorough evaluation of scientific studies.
The regulation employs a unit of measurement known as the Specific
Absorption Rate, or SAR. The SAR limit is 2 watts/kilogram (W/kg)
*2
averaged
over 10 grams of tissue. The limit includes a substantial safety margin designed
to assure the safety of all persons, regardless of age and health. The value of
the limit is equal to the international guidelines recommended by ICNIRP.
*3
All phone models should be confirmed to comply with the regulation, before
they are available for sale to the public. The highest SAR value for this FOMA
F-06B is 0.433 W/kg. It was taken by the Telecom Engineering Center (TELEC).
The test for SAR was conducted according to the MIC testing procedure using
standard operating positions with the phone transmitting at its highest
permitted power level in all tested frequency bands. While there may be
differences between the SAR levels of various phones and at various positions,
they all meet the MIC's technical regulation. Although the SAR is determined at
the highest certified power level, the actual SAR of the phone during operation
can be well below the maximum value.
For further information about SAR, please see the websites below.
World Health Organization (WHO) :
http://www.who.int/peh-emf/
ICNIRP :
http://www.icnirp.de/
MIC :
http://www.tele.soumu.go.jp/e/sys/ele/index.htm
TELEC :
http://www.telec.or.jp/ENG/Index_e.htm
NTT DOCOMO :
http://www.nttdocomo.co.jp/english/product/sar/
FUJITSU LIMITED :
http://www.fmworld.net/product/phone/sar/
*1
Ministry of Internal Affairs and Communications.
*2
The technical regulation is provided in Article 14-2 of the Ministry Ordinance
Regulating Radio Equipment.
*3
International Commission on Non-Ionizing Radiation Protection.
The product "F-06B" is declared to conform with the essential requirements of
European Union Directive 1999/5/EC Radio and Telecommunications Terminal
Equipment Directive 3.1(a), 3.1(b) and 3.2. The Declaration of Conformity can
be found on http://www.fmworld.net/product/phone/doc/.
This mobile phone complies with the EU requirements for exposure to radio
waves.
Your mobile phone is a radio transceiver, designed and manufactured not to
exceed the SAR
*
limits
**
for exposure to radio-frequency(RF) energy, which
SAR
*
value, when tested for compliance against the standard was 0.380W/Kg.
While there may be differences between the SAR
*
levels of various phones and
at various positions, they all meet
***
the EU requirements for RF exposure.
* The exposure standard for mobile phones employs a unit of measurement
known as the Specific Absorption Rate, or SAR.
** The SAR limit for mobile phones used by the public is 2.0 watts/kilogram (W/
Kg) averaged over ten grams of tissue, recommended by The Council of the
European Union. The limit incorporates a substantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
*** Tests for SAR have been conducted using standard operation positions with
the phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while operating can be well
below the maximum value. This is because the phone is designed to operate
at multiple power levels so as to use only the power required to reach the
network. In general, the closer you are to a base station antenna, the lower the
power output.
Declaration of Conformity
F-06B_EN_FCC
133
Others
･
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions :
a
this device may not cause harmful interference, and
b
this device must accept any interference received, including interference
that may cause undesired operation.
･
Changes or modifications made in or to the radio phone, not expressly
approved by the manufacturer, will void the user's authority to operate the
equipment.
This model phone meets the U.S. Government's requirements for exposure to
radio waves.
This model phone contains a radio transmitter and receiver. This model phone
is designed and manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy as set by the FCC of the U.S. Government. These
limits are part of comprehensive guidelines and establish permitted levels of RF
energy for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through periodic and
thorough evaluation of scientific studies.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate (SAR). The SAR limit set
by the FCC is 1.6 W/kg. Tests for SAR are conducted using standard operating
positions as accepted by the FCC with the phone transmitting at its highest
certified power level in all tested frequency bands. Although the SAR is
determined at the highest certified power level, the actual SAR level of the
phone while operating can be well below the maximum value. This is because
the phone is designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a wireless
base station antenna, the lower the power output level of the phone.
Before a phone model is available for sale to the public, it must be tested and
certified to prove to the FCC that it does not exceed the limit established by the
U.S. government-adopted requirement for safe exposure. The tests are
performed on position and locations (for example, at the ear and worn on the
body) as required by FCC for each model. The highest SAR value for this model
phone as reported to the FCC, when tested for use at the ear, is 0.380W/kg, and
when worn on the body, is 0.511W/kg. (Body-worn measurements differ
among phone models, depending upon available accessories and FCC
requirements).
While there may be differences between the SAR levels of various phones and
at various positions, they all meet the U.S. government requirements.
The FCC has granted an Equipment Authorization for this model phone with all
reported SAR levels evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone is on file with the FCC and
can be found under the Equipment Authorization Search section at http://
www.fcc.gov/oet/ea/fccid/ (please search on FCC ID VQK-F06B).
For body worn operation, this phone has been tested and meets the FCC RF
exposure guidelines when used with an accessory designated for this product
or when used with an accessory that contains no metal and which positions the
handset at a minimum distance of 1.5 cm from the body.
*
In the United States, the SAR limit for wireless mobile phones used by the general public
is 1.6 Watts/kg (W/kg), averaged over one gram of tissue. SAR values may vary
depending upon national reporting requirements and the network band.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation.
Federal Communications Commission
(FCC) Notice
FCC RF Exposure Information
F-06B_EN_FCC
134
Others
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
AIRCRAFT
Switch off your wireless device when boarding an aircraft or whenever you are
instructed to do so by airline staff. If your device offers flight mode or similar
feature consult airline staff as to whether it can be used on board.
DRIVING
Full attention should be given to driving at all times and local laws and
regulations restricting the use of wireless devices while driving must be
observed.
HOSPITALS
Mobile phones should be switched off wherever you are requested to do so in
hospitals, clinics or health care facilities. These requests are designed to
prevent possible interference with sensitive medical equipment.
PETROL STATIONS
Obey all posted signs with respect to the use of wireless devices or other radio
equipment in locations with flammable material and chemicals. Switch off your
wireless device whenever you are instructed to do so by authorized staff.
INTERFERENCE
Care must be taken when using the phone in close proximity to personal
medical devices, such as pacemakers and hearing aids.
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of 15 cm be
maintained between a mobile phone and a pace maker to avoid potential
interference with the pacemaker. To achieve this use the phone on the opposite
ear to your pacemaker and does not carry it in a breast pocket.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the
event of such interference, you may want to consult your hearing aid
manufacturer to discuss alternatives.
For other Medical Devices :
Please consult your physician and the device manufacturer to determine if
operation of your phone may interfere with the operation of your medical
device.
Important Safety Information
F-06B_EN_FCC
135
Others
Appendix
Export Administration Regulations
This product and its accessories may be under coverage of the Export
Administration Regulations of Japan ("Foreign Exchange and Foreign Trade
Control Laws" and the related laws and regulations). And, they are also under
coverage of Export Administration Regulations of the U.S. When exporting
and reexporting this product and its accessories, take necessary procedures
on your responsibility and expense. For details, contact Ministry of Economy,
Trade and Industry of Japan or US Department of Commerce.
Appendix
Intellectual Property Right
Except for the case protected by copyright laws such as personal use, use of
FOMA terminal to reproduce, alter, or publicly transmit recorded pictures or
sounds, or copyrighted text, images, music or software downloaded from
websites without the copyright holder's authorization is prohibited.
Note that taking photos or recordings at some demonstrations, performances
or exhibitions may be prohibited even when only for personal use.
Avoid taking pictures of others with FOMA terminal without their consent or
disclosing recorded pictures of others without their consent to general public
through Internet websites etc., because they may infringe on portrait rights.
Company and product names mentioned in this manual are trademarks or
registered trademarks of their respective holders.
･
"FOMA", "i-motion", "i-mode", "i-
α
ppli", "mopera", "WORLD CALL", "WORLD
WING", "Deco-mail", "Chara-den", "i-Channel", "i-area", "iD", "ToruCa",
"2in1", "DCMX", "OFFICEED", "docomo PRIME series", "i Bodymo" and logos
of "FOMA", "i-mode", "i-
α
ppli", "Music&Video Channel", "DCMX", "iD", "iC"
are trademarks or registered trademarks of NTT DOCOMO.
･
Microsoft
®
, Windows
®
, Windows Vista
®
, Windows Media
®
and
PowerPoint
®
are trademarks or registered trademarks of "Microsoft
Corporation" in the US and other countries.
･
Microsoft Excel and Microsoft Word are product names of Microsoft
Corporation in the U.S.A. In this manual, they may be described as Excel and
Word.
･
"Multitask" is a registered trademark of NEC Corporation.
･
"Catch Phone (Call Waiting Service)" is a registered trademark of Nippon
Telegraph and Telephone Corporation.
･
Free Dial logo mark is a registered trademark of NTT Communications
Corporation.
･
Java and all Java-related trademarks and logos are trademarks or registered
trademarks of Sun Microsystems, Inc. in the US and other countries.
Copyrights and portrait rights
Trademarks
F-06B_EN_FCC
136
Others
･
This product contains NetFront Browser,
NetFront Sync Client of ACCESS CO., LTD.
ACCESS, the ACCESS logo and NetFront are registered trademarks or
trademarks of ACCESS CO., LTD. in the United States, Japan and/or other
countries.
Copyright
©
2009 ACCESS CO., LTD. All rights reserved.
･
Powered by JBlend
™
Copyright 2002-2009 Aplix Corporation. All
rights reserved.
JBlend and JBlend-related trademarks are trademarks or registered
trademarks of Aplix Corporation in Japan and other countries.
･
This product contains Adobe
®
Flash
®
Lite
®
and Adobe Reader
®
LE
technology of Adobe Systems Incorporated.
Adobe Flash Lite Copyright
©
2003-2010 Adobe Systems Incorporated. All
rights reserved.
Adobe Reader Mobile Copyright
©
1993-2010 Adobe Systems Incorporated.
All rights reserved.
Adobe, Adobe Reader, Flash and Flash Lite are either
registered trademarks or trademarks of Adobe Systems
Incorporated in the United States and/or other countries.
･
QR code is a registered trademark of Denso Wave Inc.
･
microSDHC Logo is a trademark of SD-3C, LLC.
･
FeliCa is a registered trademark of Sony Corporation.
･
"CROSS YOU" is a trademark of Sony Corporation.
･
is a registered trademark of FeliCa Networks, Inc.
･
Word, Excel and PowerPoint file display technologies
are powered by Picsel Technologies.
Picsel, Picsel File Viewer and the Picsel cube logo are trademarks or
registered trademarks of Picsel Technologies.
･
McAfee
®
is registered trademarks or trademarks of McAfee, Inc. and/or its
affiliates in the US and/or other countries.
･
G-GUIDE, G-GUIDE MOBILE and their logos are registered
trademarks in Japan of U.S. Gemstar-TV Guide International, Inc.
and/or its affiliates.
･
QuickTime is a registered trademark of Apple Inc. in the US and other
countries.
･
ATOK + APOT of Justsystem Corporation is installed in this product as
Japanese character conversion function.
"ATOK" "APOT (Advanced Prediction Optimization Technology)" are
registered trademarks of Justsystem Corporation.
･
T9
®
is a trademark or registered trademark of Nuance
Communications, Inc. in US and of Nuance corporations in other
countries.
･
This equipment is provided with the software licensed by Symbian Software
Ltd. or the licensor
©
1998-2010. and Symbian OS are trademarks of
Symbian Ltd. or the licensor.
･
"Privacy mode" is a registered trademark of FUJITSU LIMITED.
･
Bluetooth
®
and its logo are registered trademarks of Bluetooth SIG, Inc., and
NTT DOCOMO uses them under license. Other trademarks and names inhere
to their respective owners.
･
Napster is a registered trademark of Napster, LLC. and/or its affiliates in the
US and/or other countries.
･
Manufactured under license from Dolby Laboratories. Dolby and the double-
D symbol are trademarks of Dolby Laboratories.
･
"Uni-Type" is a registered trademark of LIM Corp., Ltd.
･
FrameSolid is the registered trademark of Morpho, Inc. in Japan and other
countries.
･
The auto object tracking technology utilized is TrackSolid
™
, a product of
Morpho, Inc. TrackSolid
™
is trademark of Morpho, Inc.
･
Google is registered trademark of Google Inc.
･
ズーキーパー
(Zookeeper) is a trademark or registered trademark of
KITERETSU Inc.
･
"
日英版しゃべって翻訳
for F (J-E Speech Translation for F)" is trademark of
ATR-Trek.
･
Wi-Fi
®
, Wi-Fi Alliance
®
, and logos of Wi-Fi and Wi-Fi CERTIFIED are
registered trademarks of Wi-Fi Alliance.
･
Wi-Fi CERTIFIED
™
, WMM
™
, WPA
™
, WPA2
™
and Wi-Fi Protected Setup
™
are trademarks of Wi-Fi Alliance.
･
IrSimpre
™
, IrSS
™
and IrSimpleShot
™
are trademarks of Infrered
Data Association
®
.
F-06B_EN_FCC
137
Others
･
Other company and product names mentioned in this manual are
trademarks or registered trademarks of their respective holders.
･
The abbreviations of operating systems (Japanese versions) below are used
in this manual.
- Windows 7 stands for Microsoft
®
Windows
®
7 (Starter, Home Basic, Home
Premium, Professional, Enterprise and Ultimate).
- Windows Vista stands for Windows Vista
®
(Home Basic, Home Premium,
Business, Enterprise and Ultimate).
- Windows XP indicates the Microsoft
®
Windows
®
XP Professional
operating system or Microsoft
®
Windows
®
XP Home Edition operating
system.
･
FeliCa is a contactless IC card technology developed by Sony Corporation.
･
This product contains a module developed by the Independent JPEG Group.
･
The image interpolation technology utilized is FrameSolid, a product of
Morpho, Inc.
･
This product is equipped with the technologies of GestureTek, Inc.
Copyright
©
2006-2010, GestureTek, Inc. All Rights Reserved.
･
This product is licensed based on MPEG-4 Visual Patent Portfolio License.
The use of MPEG-4 Video Codec function is allowed for personal and
nonprofit use only in the cases below.
- Recording moving pictures and i-motion that conform to MPEG-4 Visual
Standard (hereinafter referred to as MPEG-4 Video)
- Playing MPEG-4 Videos recorded personally by consumers not engaged in
profit activities
- Playing MPEG-4 Video supplied from the provider licensed from MPEG-LA
For further utilizing such as promotion, in-house use or profit-making
business, please contact MPEG LA, LLC in U.S.
･
Content owners use Windows Media digital rights management technology
(WMDRM) to protect their intellectual property, including copyrights. This
device uses WMDRM software to access WMDRM-protected content. If the
WMDRM software fails to protect the content, content owners may ask
Microsoft to revoke the software's ability to use WMDRM to play or copy
protected content. Revocation does not affect unprotected content. When
downloading licenses for protected content, you agree that Microsoft may
include a "Revocation List" with the licenses. Content owners may require
you to upgrade WMDRM to access their content. If you decline an upgrade,
you cannot access a content that requires the upgrade.
Others
* Available from mobile phones and PHSs.
(including non-DOCOMO phones).
* Unavailable from part of IP phones.
* Unavailable from land-line phones, etc.
Repairs
■
From DOCOMO mobile phones
(In Japanese only)
■
From land-line phones
(In Japanese only)
0120-800-000
(toll free)
(No prefix)
151
(toll free)
●
Please confirm the phone number before you dial.
●
For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo shop etc. near you on the NTT DOCOMO website or the i-mode site.
NTT DOCOMO website http://www.nttdocomo.co.jp/english/ i-mode site iMenu⇒お客様サポート (user support)⇒ドコモショップ (docomo Shop) * In Japanese only
* Service available in: English, Portuguese, Chinese, Spanish, Korean.
* Available from mobile phones and PHSs (including non-DOCOMO phones).
* Unavailable from part of IP phones.
General Inquiries <docomo Information Center>
0120-005-250 (toll free)
* You are charged a call fee to Japan when calling from a land-line phone, etc.
※If you use F-06B, you should dial the number ＋81-3-6832-6600 (to enter '＋',
press and hold the '0' key for at least one second).
* You are charged a call fee to Japan when calling from a land-line phone, etc.
※If you use F-06B, you should dial the number ＋81-3-6718-1414 (to enter '＋',
press and hold the '0' key for at least one second).
Loss or theft of FOMA terminal or payment of cumulative cost overseas
<docomo Information Center>
(available 24 hours a day)
■
From DOCOMO mobile phones
(available 24 hours a day)
■
From DOCOMO mobile phones
International call access code
for the country you stay
■
From land-line phones <Universal number>
International prefix number
for the universal number
■
From land-line phones <Universal number>
-81-3-6832-6600* (toll free) International call access code
for the country you stay -81-3-6718-1414* (toll free)
-8000120-0151*International prefix number
for the universal number -8005931-8600*
Don't forget your mobile phone ･･･ or your manners!
When using your mobile phone in a public place, don't forget to
show common courtesy and consideration for others around you.
■
From DOCOMO mobile phones
(In Japanese only)
■
From land-line phones
(In Japanese only)
0120-800-000
(toll free)
(No prefix)
113
(toll free)
* Unavailable from land-line phones, etc.
* Available from mobile phones and PHSs.
(including non-DOCOMO phones).
* Unavailable from part of IP phones.
●
If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.
●
If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after returning to Japan.
*
You might be charged a domestic call fee according to the call rate for the country you stay.
※
For international call access codes for major countries/international prefix numbers
for the universal number, refer to DOCOMO International Services website.
*
You might be charged a domestic call fee according to the call rate for the country you stay.
※
For international call access codes for major countries/international prefix numbers
for the universal number, refer to DOCOMO International Services website.
Failures encountered overseas
<Network Support and Operation Center>
CA92002-5802
2010.X (1st Edition)
To prevent damage to the environment,
bring used battery packs to a docomo
service counter, a docomo agent or a
recycle center.
(Business hours : 9:00 a.m. to 9:00 p.m.) (Business hours : 24 hours (open all year round)
(Business hours : 9:00 a.m. to 8:00 p.m.)
