Contents
Manual part 2
12 Easy Search/Contents/Precautions
F-09A_E1kou
CAUTION
Do not leave the equipment on
unstable or sloping surfaces.
May cause malfunction or injuries.
Do not store the equipment in
extremely humid, dusty or hot areas.
May cause malfunction.
Children using the equipment should
be instructed in proper operation by an
adult. Do not allow them to use the
equipment without adult supervision.
May cause injuries.
Store the equipment out of reach of
small children.
May be accidentally swallowed or cause
injuries.
Be careful especially when using
FOMA terminal connected to the
adapter (including battery charger)
continuously for a long time.
If you execute i-
α
ppli, use videophone call or
watch 1Seg while charging the battery pack,
FOMA terminal, battery pack and adapter
(including battery charger) may become hot.
Directly touching a hot part for a long time,
you may have redness, itching or rash on
your skin, or it may result in low-
temperature burns depending on your
constitution and/or health condition.
◆
Handling FOMA terminal
WARNING
Do not direct the infrared data port
toward your eye and transmit signals.
May affect your eyes. Faulty operation could
result from directing the infrared data port
toward other infrared equipment and
transmitting signals.
Do not turn on the light by getting the
lighting part closer to other person's
eyes.
May impair eyesight. And may cause
accidents like injury etc., by dazzling or
astounding other people.
Do not put FOMA terminal in the place
such as the dashboard near the air-
bag, where the influence of air-bag
explosion is expected.
When the air-bag explodes, FOMA terminal
may hit yourself or others and could cause
injury, equipment malfunction or damage.
When you use electronic medical
equipment, do not keep the terminal in
your chest pocket or inside pocket.
Using your FOMA terminal near medical
electronic equipment could cause
equipment failure.
Do not put foreign objects such as
liquid like water, metal pieces or
burnable things into UIM or microSD
card slot.
May cause fire, electric shock or
malfunction.
Do not turn on the light aiming directly
at the driver of the car etc.
May disturb driving and cause an accident.
Turn FOMA terminal OFF in areas
where use is prohibited, such as in
airplanes and hospitals.
May cause electronic equipment or
electronic medical equipment to fail or
malfunction. If the function which
automatically turns the power ON is set,
cancel the setting before turning the power
OFF.
When using the phone in a medical facility,
be sure to observe the regulations of the
facility. If you do prohibited act such as using
the phone in an airplane, you may be
punished according to law.
When you talk by setting handsfree,
always keep FOMA terminal away
from your ear.
And, when connecting the earphone/
microphone to FOMA terminal and
play a game or music, adjust the
volume moderately.
Too loud volume may cause a hearing loss.
And, if you cannot hear the sound around
you clearly, it may cause an accident.
Don't
Don't
Do
Do
Do
Don't
Don't
Don't
Don't
Don't
Don't
Do
Do
F-09A.book Page 12 Thursday, March 5, 2009 11:37 AM
13
Easy Search/Contents/Precautions
F-09A_E1kou
If you have weak heart, be careful
when setting the Vibrate alert
(vibration) or alert volume setting.
Could affect heart function.
If it starts thunder while using the
terminal outdoors, turn the power
OFF immediately, and move to a safe
location.
May be subject to lightning strike and could
cause electric shock.
Turn FOMA terminal OFF near high-
precision electronic control equipment
or electronic equipment using low-
power signals.
May cause the equipment to fail or
malfunction.
*
Examples of electronic equipment to avoid.
Hearing aids, implanted pacemakers or
defibrillators, other electronic medical equipment,
fire alarms, automatic doors and other automatic
control equipment.
Users wearing implanted pacemakers or
defibrillators or other electronic medical
equipment should check with the manufacturer or
sales outlet about the effect of radio frequencies
on the equipment.
When the display or camera lens is
accidentally broken, be careful of
broken glass or exposed internal parts
of FOMA terminal.
Surfaces of display and camera lens are
made of plastic panels and they are
structured for the glass not to scatter,
however, if you mistakenly touch broken or
exposed parts, you may be injured.
CAUTION
Do not swing FOMA terminal by its
strap.
May cause the terminal damage or failure, or
injury to yourself or others.
When using the motion tracking or
motion sensor, check the safety
around you, hold FOMA terminal
firmly, and do not shake it
unnecessarily.
The motion tracking and motion sensor are
functions to operate by tilting or shaking
FOMA terminal. There is a risk that FOMA
terminal hits people or objects around you
by shaking it too much, causing a serious
accident or damage.
If you put a metal strap or the like to
FOMA terminal, be careful not to let
the strap hit people or objects around
you when performing motion tracking
or using motion sensor.
Accidents such as injury, malfunction or
damage may result.
Do not place magnetic disks or cards
with magnetic stripes near FOMA
terminal or place inside and fold the
terminal.
Data stored on media such as cash cards,
credit cards, telephone cards and floppy
disks may be erased if the storage medium is
placed near the phone.
Do not bring magnetized objects close
to FOMA terminal.
Bringing strong magnetism close may cause
a malfunction.
If the display part is accidentally
broken and liquid crystal leaks out, do
not put the liquid in your mouth,
inhale, or make contact with your skin.
If the liquid gets into your eyes or
mouth, rinse it with clean water and
see a doctor immediately.
And, if the liquid adheres to skin or
clothing, use alcohol etc. to wipe it off,
then wash with soap.
May cause loss of sight or skin problems.
Do not bring the speaker close to your
ear when the ring alert is sounding or
you are playing a melody with FOMA
terminal.
May cause hearing loss.
In rare cases, using the phone in some
vehicle models can cause the vehicle's
electronic equipment to malfunction
or fail.
In this case, do not use the phone because it
may hamper safe driving.
Do
Do
Do
Do
Don't
Don't
Don't
Don't
Don't
Don't
Don't
Do
F-09A.book Page 13 Thursday, March 5, 2009 11:37 AM
14 Easy Search/Contents/Precautions
F-09A_E1kou
Mobile phones can give some users
skin problems such as itching, allergic
reactions or rashes. If you develop skin
problems, stop using the phone
immediately, and see a doctor.
FOMA terminal contains metal in the
parts below.
When opening or closing FOMA
terminal, take care not to have your
fingers or strap caught by the terminal.
May cause injuries or damages.
When watching 1Seg, take a certain
distance from the display in a fully
bright place.
May cause your eyesight to be impaired.
◆
Handling battery pack
■
Check that the battery type matches the
type displayed on the battery pack label.
DANGER
Do not connect a wire or other metal
objects to the jack. And, do not carry or
store FOMA terminal with objects like
a metal necklace.
May cause the battery pack to leak, heat,
burst or ignite.
Do not try to force the battery pack
onto FOMA terminal if you are having
trouble installing it. Always install it
after checking that it is correctly
oriented.
May cause the battery pack to leak, heat,
burst or ignite.
Do not throw the battery pack into the
fire.
May cause the battery pack to leak, heat,
burst or ignite.
Do not nail the battery pack, hit with a
hammer or step on it.
May cause the battery pack to leak, heat,
burst or ignite.
If the battery pack's fluid contacts
eyes, immediately flush the eyes with
clean water and see a doctor right
away. Do not rub the eyes.
May cause loss of sight.
Part Material Surface
treatment
Charging jack Copper Gold plating
Slide and swing module SUS Black coating
Widget key PC-ABS Metal
evaporation
Lock plate of back cover SUS None
Screw to fix slide and swing
module
Copper Black nickel
plating
Screw to fix a case Steel Zinc plating
Do
Do
Do
Display Battery type
Li-ion 00 Li-ion battery
Don't
Don't
Don't
Don't
Do
F-09A.book Page 14 Thursday, March 5, 2009 11:37 AM
15
Easy Search/Contents/Precautions
F-09A_E1kou
WARNING
If the battery pack seems to have
abnormalities such as deformation or
scratches due to an external impact or
falling, stop using it immediately.
May cause the battery pack to leak, heat,
burst or ignite, and the equipment to
malfunction or catch fire.
If the battery pack does not have a full
charge after being charged for the
specified time, stop charging it.
May cause the battery pack to leak, heat,
burst or ignite.
If the battery pack leaks or gives off a
strange smell, immediately remove it
from the vicinity of open flames.
The vapors from leaking battery pack fluid
may ignite or explode.
Be careful not to let your pet bite the
battery pack.
May cause the battery pack to leak, heat,
burst or ignite, and the equipment to
malfunction or catch fire.
CAUTION
Do not discard old battery packs
together with other garbage.
May cause igniting or environmental
destruction. Tape the terminals of old
battery packs to insulate them, and then
bring them into a sales outlet such as
docomo Shop. If your local municipality has
a battery recycling program, dispose of them
as provided for.
Do not charge a wet battery pack.
May cause heat generation, ignition or
rupture of the battery pack.
If the battery pack's fluid contacts skin
or clothes, immediately flush the
contacted area thoroughly with clean
water.
May hurt the skin.
◆
Handling optional devices (AC
Adapter/DC Adapter/Desktop
Holder/In-Car Holder)
WARNING
Do not use the adapter (including
battery charger) cord or power cord if
it gets damaged.
May cause electric shock, heat or fire.
Do not use the AC adapter or desktop
holder in a bathroom or other highly
humid area.
May cause electric shock.
Always use the DC adapter with a
negative-ground vehicle. Do not plug it
into a positive-ground vehicle.
May cause fire.
When it starts to thunder, do not touch
FOMA terminal and adapter (including
battery charger).
May be subject to lightning strike and could
cause electric shock.
Do not short the charging jack while it
is connected to the outlet or cigarette
lighter socket. Do not touch the
charging jack with a part of your body
such as your hand or finger.
May cause fire, malfunction, electric shock
or injuries.
Place battery charger and desktop
holder in a stable location while
charging. Do not cover or wrap battery
charger and desktop holder with a
cloth, blanket, etc.
May cause FOMA terminal to be removed or
the optional devices to be heated, resulting
in fire or troubles.
Do not place heavy objects on the
adapter (including battery charger)
cord or power cord.
May cause electric shock or fire.
Don't
Do
Do
Do
Don't
Don't
Do
Don't
Don't
Don't
Don't
Don't
Don't
Don't
F-09A.book Page 15 Thursday, March 5, 2009 11:37 AM
16 Easy Search/Contents/Precautions
F-09A_E1kou
Do not touch the adapter (including
battery charger) cord or outlet with
wet hands.
May cause electric shock.
Only use with the specified power
source and voltage.
If incorrect voltage is used, this may cause
fire or failure. When using FOMA terminal
overseas, use AC Adapter for global use.
AC adapter : AC100V
DC adapter : 12 or 24V DC (specific for
negative ground vehicle)
AC adapter for global use : Between 100V
and 240V AC (Connect to the AC outlet for
internal household use)
If the DC adapter's fuse blows, replace
it only with the specified fuse.
Using other fuses may cause fire or
equipment failure. For the specified fuse, see
the instructions that come with the DC
adapter.
Wipe off any dust that accumulates on
the power plug.
May cause fire.
When you connect the AC adapter to
an outlet, make sure not to touch with
metal such as metal straps and firmly
connect to the outlet.
May cause electric shock, electrical short or
fire.
When you disconnect the adapter
(including battery charger) from the
outlet or cigarette lighter socket, do
not pull the adapter (including battery
charger) cord or power cord with
excessive force; instead hold the plug
to disconnect.
Pulling the cord could damage it, possibly
leading to electric shock or fire.
Always remove the power plug from
the outlet when not using the adapter
for an extended period.
May cause electric shock, fire or
malfunction.
Immediately remove the power plug
from the outlet or cigarette lighter
socket if water or other fluids get into
the adapter.
May cause electric shock, smoke or fire.
Always remove the power plug from
the cigarette lighter socket when
cleaning the equipment.
May cause electric shock.
◆
Handling UIM
CAUTION
Be careful of the cut surface when
removing UIM (ICs).
May hurt hands or fingers.
◆
Handling mobile phones near
electronic medical equipment
■
These precautions are based on the
guidelines produced at the
Electromagnetic Compatibility
Conference Japan, regarding the
protection of electronic medical
equipment from radio waves emitted by
mobile phone units.
WARNING
Obey the following rules inside
medical facilities.
･
Do not bring FOMA terminal into
operating rooms (ORs), intensive care
units (ICUs) or coronary care units (CCUs).
･
Turn FOMA terminal OFF in hospital
wards.
･
Turn FOMA terminal OFF in hospital
lobbies and corridors if electronic medical
equipment could be nearby.
･
If the medical facility has specified zones
where use or possession of mobile
devices is prohibited, obey those
instructions.
･
If the function to automatically turn ON
the power is set, cancel the setting before
turning the power OFF.
Turn FOMA terminal OFF in crowded
trains or other public places where
pacemaker or defibrillator wearers
could be nearby.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
No wet hands
Do
Do
Do
Do
Do
Unplug
Unplug
Unplug
Do
Do
Do
F-09A.book Page 16 Thursday, March 5, 2009 11:37 AM
17
Easy Search/Contents/Precautions
F-09A_E1kou
Wearers of implanted pacemakers or
defibrillators must carry and use
FOMA terminal at least 22 cm away
from the implanted device.
FOMA terminal's signals may affect the
operation of implanted pacemakers or
defibrillators, and other devices.
When electronic medical equipment
other than implanted pacemakers or
defibrillators are in use outside of
medical facilities (such as in home care
settings), check with the device
manufacturer to determine how the
device is affected by electrical signals.
FOMA terminal's signals may affect the
performance of electronic medical
equipment.
Do
Do
F-09A.book Page 17 Thursday, March 5, 2009 11:37 AM
18 Easy Search/Contents/Precautions
F-09A_E1kou
Handling precautions
◆
General
・
Do not get FOMA terminal etc. wet
- FOMA terminal, battery back, adapter (including battery charger) and UIM are not water-
proof. Do not use them in extremely humid places such as a bath, and do not expose them to
rain. When you carry the terminal close to your body, dampness from sweat may cause internal
corrosion and malfunction. Malfunctions deemed to have been caused by water are not
covered by the warranty, and repairs may not be possible. Since these conditions are outside
the scope of the warranty, a repair, if at all possible, is charged.
・
Clean FOMA terminal with a dry soft cloth (such as a cloth for eyeglasses).
- The display of FOMA terminal may have been applied special coating to improve clearness of
the color LCD. When cleaning FOMA terminal, rubbing it roughly with a dry cloth can scratch
the display. Take care when handling the unit, and clean it with a dry soft cloth (such as a cloth
for eyeglasses). Drops of water or dirt left on the display can cause stains or remove the
coating.
- If FOMA terminal is wiped with alcohol, paint thinner, benzine or detergent, the printing may
disappear or color may fade.
・
Clean the jack occasionally with a dry cotton swab.
- If the jack is dirty, the contact may become poor and the power may shut OFF. A dirty jack
can result in poor charging, so clean it with a dry cloth or cotton swab.
・
Do not place FOMA terminal near an air-conditioner outlet.
- The rapid change in temperature may cause condensation, causing internal corrosion and
malfunction.
・
When using, be careful not to subject excessive force to FOMA terminal or the
battery.
- If FOMA terminal is crammed into a brimming bag or placed in a pocket and sat on, display,
internal PCBs or battery pack may be damaged or malfunction. And, if external devices are
plugged into the external connection jack (earphone/microphone jack), the breakage of the
connector or malfunction may result.
・
Carefully read the separate instructions that come with FOMA terminal, adapter
(including battery charger) and desktop holder.
・
Do not rub or scrape the display with a metal piece etc.
- It may scratch the display, causing malfunction or damage.
・
Do not press the surface of the touch panel strongly or operate it with sharp
objects such as a nail, a ballpoint pen and a pin.
- It may damage the touch panel.
◆
FOMA terminal
・
Avoid extreme temperature.
- Use FOMA terminal where the ambient temperature ranges between 5 and 35
℃
and humidity
ranges between 45 and 85%.
・
FOMA terminal may affect land-line phones, TVs or radios in use nearby, so use
it as far as possible from these appliances.
・
Maintain a separate record of the data you saved in your FOMA terminal.
- If the data is deleted, DOCOMO assumes no responsibility for the loss of any data.
・
Do not drop FOMA terminal or subject it to shocks.
- May cause malfunction or damage.
・
Do not plug external devices into the external connection jack (earphone/
microphone jack) at a slant, or do not pull it forcibly while it is plugged.
- May cause malfunction or damage.
・
Do not close FOMA terminal with the strap etc. held inside.
- May cause malfunction or damage.
・
It is normal for FOMA terminal to become warm during use or charging. Continue
to use it.
・
Do not leave FOMA terminal with the camera in areas under strong direct
sunlight.
- May cause discoloring or burn-in of materials.
・
FOMA terminal should normally be used with the external connection jack cap
and the microSD card slot cover closed.
- Dust and/or water brought into FOMA terminal cause troubles.
・
Do not use FOMA terminal with the back cover removed.
- It may cause the battery to come off, or may cause a malfunction or damage.
・
Do not attach labels or stickers on the exposed rear side of the FOMA terminal
display.
- Labels or stickers may get stuck when FOMA terminal is opened/closed causing malfunction
or damage.
・
Do not put strong impact on the fingerprint sensor or scratch its surface.
- It may cause malfunction of fingerprint sensor and disable authentication operation and
pointing operation.
・
Clean the fingerprint sensor with a dry soft cloth (such as a cloth for eyeglasses).
F-09A.book Page 18 Thursday, March 5, 2009 11:37 AM
19
Easy Search/Contents/Precautions
F-09A_E1kou
- If the fingerprint sensor is dirty or water is sit on its surface, the sensor does not read
fingerprints, decreases its authentication performance, erroneously operates authentication
function with no finger on it, disables pointing operation.
・
While microSD card is being accessed, do not take the card out and do not turn
off FOMA terminal.
- It may cause data loss or malfunction.
◆
Battery pack
・
The battery pack is a consumable part.
- Replace the battery pack if FOMA terminal has extremely short operation time on a full
charge, though it may vary by operating conditions. Purchase a new battery pack of the
specified type.
・
Charge the battery in an area within the proper ambient temperature range (5-35
℃
).
・
Always charge before using it for the first time or after extended disuse.
・
The operation time provided by the battery pack varies by the operating
environment and battery pack's deterioration.
・
The battery pack may swell out as it comes to near the end of its lifetime
depending on the usage conditions, but it is not a problem.
・
Be careful especially about the following points when preserving or leaving the
battery pack for a long time.
- Keeping under the state of the full charge (right after charging ends)
- Keeping under the state of the empty charge (too exhausted to turn on FOMA terminal)
They may cause the battery pack performance to be degraded or its lifetime to be
shortened.
For necessary battery level to keep for a long time, the display of battery icon is a
state of approximately 2 or 3 cells.
◆
Adapter (including battery charger)
・
Charge the battery in an area within the proper ambient temperature range (5-35
℃
).
・
Do not charge the battery in the areas below.
- In areas of excessive humidity, dust or vibrations
- Near land-line phones or TVs/radios
・
It is normal for the adapter (including battery charger) to become warm while
charging. Continue to use it.
・
When using the DC adapter for charging, keep the vehicle engine running.
- The vehicle's battery could become flat.
・
When using an outlet with a mechanism preventing unplugging, follow the
handling instructions for that outlet.
・
Do not give strong shock. Do not deform the charging jack.
- May cause malfunction.
F-09A.book Page 19 Thursday, March 5, 2009 11:37 AM
20 Easy Search/Contents/Precautions
F-09A_E1kou
◆
UIM
・
Do not use excessive force to install/remove UIM.
・
It is normal for UIM to become warm during use. Continue to use it.
・
Note that DOCOMO assumes no responsibility for malfunctions occurring as the
result of inserting and using a UIM with another IC card reader/writer.
・
Always keep UIM ICs clean.
・
Clean UIM with a soft, dry cloth (such as a cloth for eyeglasses).
・
Maintain a separate record of the data you saved in UIM.
- If the data is deleted, DOCOMO assumes no responsibility for the loss of any data.
・
To preserve the environment, bring the old UIM to a sales outlet such as docomo
Shop.
・
Avoid extreme temperature.
・
Take care not to scratch, touch accidentally or short IC.
- May cause data loss or malfunction.
・
Do not drop UIM or subject it to shocks.
- May cause malfunction.
・
Do not bend UIM or place heavy objects on it.
- May cause malfunction.
・
Do not install UIM into FOMA terminal with a label or sticker put on UIM.
- May cause malfunction.
◆
Bluetooth devices
・
This FOMA terminal is equipped with the security features, that are compliant
with Bluetooth standards for communication via Bluetooth. However, depending
on the settings, there may not be enough security. Be aware of security risks
when using Bluetooth.
・
DOCOMO assumes no responsibility for any information which may be leaked
during communication via Bluetooth.
・
You can use handsfree, headset, audio, dial-up connection, object push and serial
port devices with FOMA terminal. An audio/video remote control may be
available with an audio device (only Bluetooth compatible devices).
・
Frequency bands
Frequency bands used by FOMA terminal Bluetooth function are as below.
a
2.4 : Radio equipment that uses the 2400 MHz band.
b
FH : The modulation is the FH-SS method.
c
1 : The expected interference distance is 10 m or shorter.
d
: All bandwidths between 2400 MHz and 2483.5 MHz are used,
and the bandwidth used by mobile object identification devices cannot be
avoided.
Cautions on using Bluetooth devices
In the bandwidth used by this handset, in addition to home electric appliances
such as a microwave oven and industrial/scientific/medical devices, in-plant radio
stations used to identify mobile objects used in production lines of a factory that
require a license, specified low power radio stations, or amateur radio stations
that do not require a license (hereafter "other radio stations") can be in operation.
1. Before using this terminal, check whether other radio stations are in operation
in your neighborhood.
2. If radio wave interference occurs between the terminal and "other radio
stations", use the terminal in a different location or "Turn the power OFF" to
avoid the radio wave interference.
3. For more detailed information, contact "General Inquiries" using the phone
number on the back of this manual.
ab
d
c
2.4FH1
F-09A.book Page 20 Thursday, March 5, 2009 11:37 AM
21
Easy Search/Contents/Precautions
F-09A_E1kou
◆
FeliCa reader/writer
・
FeliCa reader/writer function of FOMA terminal uses weak waves requiring no
licenses for radio stations.
・
It uses 13.56 MHz frequency band. When using other reader/writers in your
surroundings, keep FOMA terminal away sufficiently from them. Before using the
FeliCa reader/writer, confirm that there are no radio stations using the same
frequency band nearby.
◆
CAUTION
・
Do not use a remodeled FOMA terminal. Using a remodeled terminal violates the
Radio Law.
FOMA terminal is certified according to technical standard conformance of
specified wireless equipment based on the Radio Law, and as a proof of it, the
"Technical Compliance Mark " is depicted on the engraved sticker of FOMA
terminal.
If you remodel FOMA terminal by removing its screws, your certification of
technical standard conformance becomes invalid.
Do not use FOMA terminal with its certification of technical standard
conformance invalid as it violates the Radio Law.
・
Be careful when you use FOMA terminal while driving a car etc.
Using a mobile phone while driving is subject to penal regulations.
If you inevitably receive a call, tell the caller that you will "call back" by handsfree,
then park in a safe place and call back.
・
Use the Bluetooth function only in Japan.
The Bluetooth function of the FOMA terminal is compliant with wireless
standards and is authorized for use only in Japan.
If you use this function overseas, you may be punished.
・
Use FeliCa reader/writer function only in Japan.
FeliCa reader/writer function of FOMA terminal conforms to Japanese radio
standards.
If you use this function overseas, you may be punished.
F-09A.book Page 21 Thursday, March 5, 2009 11:37 AM
22 Easy Search/Contents/Precautions
F-09A_E1kou
Accessories and main options
Manual
F-09A
(including Back Cover F40 and the written warranty)
Instruction manual
CD-ROM for F-09A
* Quick Manual is appended
on PXXX.
* The PDF version of "Manual for PC Connection" and
"Kuten Code List" are contained in the CD-ROM.
<Basic package>
FOMA AC Adapter 01/02
(including written warranty and
operation manual)
<Optional accessories>
Desktop Holder F31
(including operation manual)
Battery Pack F10
Other optional accessories
→PXXX
F-09A.book Page 22 Thursday, March 5, 2009 11:37 AM
23
F-09A_E1kou
Before Using the Handset
Part names and functions ................................................................................................................................................... 24
Available FOMA terminal usage styles ............................................................................................................................. 28
Viewing display ................................................................................................................................................................... 30
Selecting functions from menu .......................................................................................................................................... 35
Selecting functions using touch operation ................................................................................................. Touch panel 39
Using fingerprint sensor for pointing operation .................................................................................. Pointing device 48
Using motion sensor ........................................................................................................................................................... 49
Using UIM (FOMA card) ...................................................................................................................................................... 50
Attaching/Removing battery pack .................................................................................................................................... 52
Charging ............................................................................................................................................................................... 54
Checking battery level .............................................................................................................. Remaining battery level 57
Checking deterioration of battery ................................................................................................................... Self-check 58
Turning power ON/OFF ........................................................................................................................... Power ON/OFF 58
Changing screen display to English ...................................................................................................... Select language 59
Setting date and time ................................................................................................................................... Date & time 60
Notifying the other party of your phone number ......................................................................... Caller ID notification 60
Checking your own phone number ..................................................................................................... User information 61
F-09A.book Page 23 Thursday, March 5, 2009 11:37 AM
24 Before Using the Handset
F-09A_E1kou
Part names and functions
<Using Earphone>
Connect an optional external connection jack
compatible earphone.
When using an earphone that is non-compliant to
external connection jack, connect an optional plug
adapter to use it.
a
b
c
e
d
f
g
i
j
k
h
a
b
c
d
f
e
g
t
m
n
o
p
r
q
l
s
o
d
p
n
h
l
m
k
i
j
External connection jack
Plug for the terminal
Flat-plug earphone jack
Connecting plug of Flat-plug
Earphone/Microphone with
Switch
Example of connecting Flat-plug Earphone/
Microphone with Switch (optional)
F-09A.book Page 24 Thursday, March 5, 2009 11:37 AM
