user manual1

Rakuraku phone 7

INSTRUCTION MANUAL F-09B

ISSUE DATE:

NAME:

PHONE NUMBER:

MAIL ADDRESS:

‘10.7

・By "Voice reading function", you can perform

menu operation without depending on your

vision or you can use mail or i-mode.

・By "One-touch dial function", you can make

a call with one touch of a button.

To prevent damage to the environment,

bring used battery packs to a docomo

service counter, a docomo agent or a

recycle center.

(Business hours : 9:00 a.m. to 9:00 p.m.) (Business hours : 24 hours (open all year round))

(Business hours : 9:00 a.m. to 8:00 p.m. (open all year round))

Universal number

international prefix -8000120-0151*Universal number

international prefix -8005931-8600*

●

If you lose your FOMA terminal or have it stolen, immediately take the steps necessary for suspending the use of the FOMA terminal.

●

If the FOMA terminal you purchased is damaged, bring your FOMA terminal to a repair counter specified by DOCOMO after returning to Japan.

* Unavailable from land-line phones, etc.

Repairs

■

From DOCOMO mobile phones (In Japanese only)

■

From land-line phones (In Japanese only)

0120-800-000

(toll free)

(No prefix)

151

(toll free)

●

Please confirm the phone number before you dial.

●

For Applications or Repairs and After-Sales Service, please contact the above-mentioned information center or the docomo

shop etc. near you on the NTT DOCOMO website or the i-mode site.

NTT DOCOMO website http://www.nttdocomo.co.jp/english/

i-mode site iMenu⇒お客様サポート (user support)⇒ドコモショップ (docomo Shop) * In Japanese only

* Service available in: English, Portuguese, Chinese,

Spanish, Korean.

* Available from mobile phones and PHSs (including

non-DOCOMO phones).

General Inquiries <docomo Information Center>

0120-005-250 (toll free)

* You are charged a call fee to Japan when calling from a land-line

phone, etc.

※

If you use F-09B, you should dial the number ＋81-3-6832-6600

(to enter '＋', press and hold the '0' key for at least one second).

You are charged a call fee to Japan when calling from a land-line

phone, etc.

※

If you use F-09B, you should dial the number ＋81-3-6718-1414

(to enter '＋', press and hold the '0' key for at least one second).

Failures encountered overseas

Loss or theft of FOMA terminal or payment of cumulative

cost overseas <docomo Information Center>

(available 24 hours a day)

■

From DOCOMO mobile phones

(available 24 hours a day)

■

From DOCOMO mobile phones

International call access code for

the country you stay (table 1)

■

From land-line phones <Universal number>

You might be charged a domestic call fee according to the call rate

for the country you stay.

※

See page XXX for international call access codes for major countries

(table 1) and

universal number international prefix

(table 2).

■

From land-line phones <Universal number>

-81-3-6832-6600*

(toll free)

International call access code for

the country you stay (table 1)

-81-3-6718-1414*

(toll free)

You might be charged a domestic call fee according to the call rate

for the country you stay.

※

See page XXX for international call access codes for major countries

(table 1) and

universal number international prefix

(table 2).

■

From DOCOMO mobile phones (In Japanese only)

■

From land-line phones (In Japanese only)

0120-800-000

(toll free)

(No prefix)

113

(toll free)

* Unavailable from land-line phones, etc.

* Available from mobile phones and PHSs (including

non-DOCOMO phones).

* Available from mobile phones and PHSs (including

non-DOCOMO phones).

’10.7

INSTRUCTION MANUAL F-09B

Rakuraku phone 7

Easy Search/Contents/Precautions

Before Using the Handset

Voice/Videophone Calls

Phonebook

Sound/Screen/Light Settings

Security Settings

Voice calling/Voice reading

Mail

Camera

1Seg

i-αppli

Map/GPS Function

Data Management

Convenient Functions

Network Services

Character Entry/Voice Entry

PC Connection

Overseas Use

Appendix/Troubleshooting

Index

i-mode

i-motion/i-Channel/i-concier

ToruCa

* Unavailable from part of IP phones.

F-09B_EN_ninshou

DOCOMO W-CDMA, GSM/GPRS System

Thank you for selecting "Rakuraku phone 7 F-09B".

Both before and during use of your FOMA mobile terminal, be sure to thoroughly read this manual and

instruction manuals that come with other optional devices to ensure you are able to correctly use your FOMA

mobile terminal. For more information, you may contact us as mentioned on the back of this manual.

F-09B is your able partner. Please treat it with care and enjoy using it for years.

Before using your FOMA terminal

･

Because your FOMA terminal uses radio waves, it may not function in locations where it is difficult for radio

waves to penetrate, such as tunnels, underground passages and some buildings, in areas where radio wave

signals are weak, or out of service area. Even when you are high up in a tall building or condominium and

nothing blocks your view outside, your FOMA terminal may not be able to receive or transmit signals. Also,

communication may be interrupted even when the signal meter on your FOMA terminal indicates there is a

strong signal and you are not moving (traveling).

･

Use your FOMA terminal in a way that does not disturb others in public spaces, crowded locations or quiet

places.

･

Because your FOMA terminal uses radio waves to communicate, it is possible that a third party may attempt

to tap your calls. However, the W-CDMA, GSM/GPRS system automatically applies a confidential

communication function to all calls, so even if a third party could somehow tap a call, they only hear noise.

･

Your FOMA terminal encodes voice communication as digital data. When you are operating your FOMA

terminal while moving to a location subject to weaker radio wave signals, the transmitted digital data may

not be correctly decoded and as a result the decoded voice may differ somewhat from the actual voice.

･

Maintain a separate record of the data you register in your FOMA terminal. If the data should be deleted,

DOCOMO assumes no responsibility for the loss of any data.

･

You are recommended to save important data to microSD card. Using DOCOMO keitai datalink, you can

transfer and save phonebook, mail, schedule and other data to a PC.

･

The user hereby agrees that the user shall be solely responsible for the result of the use of SSL/TLS.

Neither DOCOMO nor the certifier as listed herein makes any representation and warranty as for the security

in the use of SSL/TLS. If the data should be erased, DOCOMO assumes no responsibility for the loss of any

data.

Certifier : VeriSign Japan K.K., Cybertrust Japan Co., Ltd., GlobalSign K.K., RSA Security Japan Ltd., SECOM

Trust Systems Co., Ltd., Comodo CA Ltd., Entrust, Inc.

･

This FOMA terminal supports FOMA Plus-Area and FOMA HIGH-SPEED Area.

･

The FOMA terminal can be used only via the FOMA network provided by DOCOMO and DOCOMO's roaming

area.

･

F-09B does not support the bilingual function.

When using FOMA terminal for the first time

When you are going to use FOMA terminal for the first time, please read this manual in the order below. You

will be able to understand an outline of the preparation for using FOMA terminal and basic operations.

1. Check "Precautions"

→

p.10

2. Attach and charge the battery pack

→

p.44, p.46

3. Turn the power ON, make initial settings and check your phone number

→

p.53, p.60

4. Check the functions of terminal keys

→

p.24

5. Check the definitions of icons appearing on the display

→

p.27

6. Check how to use the menus

→

p.34

7. Check how to make and receive calls

→

p.66, p.74

Latest information about this manual can be downloaded from NTT DOCOMO website (in Japanese only).

･

User's Manual Download

http://www.nttdocomo.co.jp/support/trouble/manual/download/index.html

* The URL and contents are subject to change without prior notice.

L01.fm Page 0 Thursday, May 27, 2010 2:16 PM

F-09B_EN_ninshou

How to use this manual

This manual provides the following methods to search for necessary functions easily.

Searching from Easy Search

p.4

Using friendly words, search for functions frequently used or convenient functions.

Searching from Menu list

p.490

Search from menu displayed on the display of F-09B.

Searching from thumb indices

Front cover

Use indices on the right of the front cover and turn the pages to search for functions.

See p.2–3 for examples.

Searching from CONTENTS

p.6

Use CONTENTS categorized into chapters based on purposes to search for items.

Searching from main functions

p.8

Functions can be searched from specific, convenient features of F-09B.

Searching from Index

p.531

Search from the function name, item keyword or service name.

･

In this "Manual for Rakuraku phone 7 F-09B", "F-09B" mobile terminal is referred to as "FOMA

terminal". Please be forewarned.

･

The screens and illustration shown here are examples. They may differ from those of actual FOMA

terminal.

･

This manual gives descriptions based mainly on the default settings. If settings are changed, the

displays or operations of FOMA terminal may differ from the ones described in this manual. For

default settings, see Menu list.

･

To make screens more visible, the screens in this manual are shown with stand-by display set to "

表示なし

(No icon)".

･

This manual uses examples based on the setting that the menu item is set to

リスト

(List). When

タイル

(Tile) is set, some menu item names may differ from those described in this manual, but the

dial buttons for operating them are the same.

･

Unauthorized copying of parts of or this entire manual is prohibited.

･

The contents of this manual are subject to change without prior notice.

L02.fm Page 1 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Easy Search

Use this to look up a frequently-used function or a convenient function by a simple word.

Convenient functions for calls

Showing/Hiding your phone number .................................

Caller ID notification

Putting the call on hold ................................................................................

On hold

Making the other party's voice more audible ......................................

Voice clear

Adjusting the other party's speaking speed ....................................

Voice slowing

Switching from voice call to videophone call .....

Switching to videophone call

Changing the volume of the other party's voice ............................

Listen volume

Making a call with one touch of a button .......................................

One-touch dial

109

When you cannot answer the call

Putting the call on hold when you cannot answer it immediately ...........

On hold

Notifying the caller that you have to refrain from talking

............................................................................................

Public mode (Drive mode)

..............................................................................................

Public mode (Power OFF)

Recording other party's message ................................................

Record message

Changing sound and vibration

Changing ring alert etc. by the group of the phonebook .......................................... 101

Changing ring alert ....................................................................................

Ring alert

120

Making vibration when there is an incoming call ...........................

Vibrate effect

124

Muting keypad sound .......................................................................

Keypad sound

125

Making terminal silent ..........................................................................

Silent mode

126

Changing displays

Meanings of icons on display .....................................................

Display overview

Changing stand-by display ..........................................................

Stand-by display

127

Changing display colors ...................................................................

Display colors

133

Changing font size of mail .........................................................................

Font size

235

Safety and security

Hiding contents of phonebook .....................................................

Secret attribute

109

Locking FOMA remotely in case of misplacement, etc.

...............................................................................................................

Omakase Lock

143

Rejecting calls from parties not saved in phonebook ...........

Unregistered caller

148

Rejecting calls with no caller IDs ...............................................

Anonymous caller

150

Saving phonebook and other data as a precaution against data loss

.................................................................................................

Data Security Service

152

L02.fm Page 4 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Mail

Listening the received mail by voice ...............................................

Voice reading

164

Starting the mail creation screen with two touches of buttons .

Two-touch mail

181

Sending images and/or melodies ..................................................

Attaching data

188

Sending voice message ..................................................................

Voice message

190

Camera

Saving shot photos to microSD card .......................................................................... 282

Shooting a photo with a frame .....................................................

Selecting frame

288

Changing the size of photo .....................................................................

Image size

289

Viewing shot photos .........................................................................

Display image

360

Watching 1Seg

Watching 1Seg ..................................................................................

Activate 1Seg

301

Reserving watching 1Seg ...................................................

Watching reservation

307

Changing settings of images and sounds ..........................................

User setting

309

Voice calling/Voice reading

Calling the phonebook by voice ...............................................................

Voice dial

160

Calling a function by voice ...................................................................

Voice menu

162

Reading the explanation of a function by voice ..............................

Voice reading

164

Other functions

Reading QR and/or bar code .........................................................

Bar code reader

293

Using pedometer/activity monitor .........................

Pedometer/Activity monitor

404

Using alarm clock ..................................................................................

Alarm clock

423

Sounding the large volume buzzer with one touch of a button

One-touch buzzer

435

Using calculator ........................................................................................

Calculator

439

Using a mobile phone overseas ........................................................

Overseas use

470

Updating software ........................................................................

Software update

549

Keeping security software updated .........................................

Scanning function

557

*1 This is charged service.

*2 This is an optional service to be charged requiring subscription.

●

For procedures to search for other functions, see "How to use this manual".

→

p.1

L02.fm Page 5 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

CONTENTS

■

Before using your FOMA terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . Inside of the front cover

■

How to use this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

■

Easy Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

■

Main functions of F-09B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

■

Precautions (ALWAYS FOLLOW THESE DIRECTIONS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

■

Handling precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

■

Waterproofness/Dustproofness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

■

Basic package and optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Before Using the Handset 23

Names and functions of parts Display overview Sub-display overview Operating menu Auto ro-

tation setting Using UIM (FOMA card) Installing/Removing battery pack Charging battery Battery

level Power ON/OFF Date & time Caller ID notification User information etc.

Voice/Videophone Calls 64

Making calls Voice memo Redial/Received calls Tone signal (DTMF) WORLD CALL Receiving

calls Any key answer Listen volume Alert volume Respond and hold Public mode Recorded

messages Voice call switching Switching videophone call function etc.

Phonebook 95

Phonebook new entry Group settings Searching phonebook Editing phonebook Deleting phone-

book Secret attribute One-touch dial Phonebook saving notice setting etc.

Sound/Screen/Light Settings 119

Select ring tone Vibrator setting Silent mode Stand-by display setting Sub-display setting Dis-

play colors setting Light setting Power saving mode Selecting fonts Clock format etc.

Security Settings 137

Security code Terminal security code change PIN code setting All lock Omakase Lock Self mode

Secret mode Call log display restriction User information display restriction Keypad dial lock

Lock on close Reject/Accept specified caller Unregistered caller Reset Delete all data Other "Se-

curity setting" etc.

Voice calling/Voice reading 159

Voice dial Voice menu registration Voice menu Voice reading settings Voice reading word reg-

istration

Mail 172

Easy mail creation/sending i-mode mail creation/sending Saving Unsent/Sent mail Check new

message Received mail Mail setting MessageR/F Early warning "Area Mail" SMS creation/send-

ing Managing mail etc.

i-mode 241

i-mode menu My menu i-mode password change Internet connection Bookmark Screen memo

Saving image i-melody Certificate download etc.

i-motion/i-Channel/i-concier 267

i-motion downloading i-motion setting i-Channel i-Channel setting i-concier Receiving informa-

tion etc.

L02.fm Page 6 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Camera 277

Before using the handset Photo shooting Magnifier Handwriting memo Video shooting Setting

for shooting Barcode reader

1Seg 297

Setting channels 1Seg watching Program guide i-

ppli Data broadcasting TV link User setting

etc.

ppli 313

Downloading Starting i-

ppli Sync i-

ppli start i-

ppli stand-by display Managing i-

ppli etc.

ToruCa 332

ToruCa Obtaining Displaying Managing etc.

Map/GPS Function 339

GPS Position location Navigation software Location request Notify location Loc. history Setting

GPS etc.

Data Management 358

Displaying image Playing moving pictures/i-motion Playing melody microSD card Infrared com-

munication Voice recorder etc.

Convenient Functions 403

Pedometer/Activity monitor Healthy life diary Multiaccess Auto power ON/OFF Notified time

auto power ON Countdown timer Alarm clock Scheduler Last call duration/Total calls duration

Last call cost/Total calls cost One-touch buzzer Calculator Earphone/Microphone with Switch etc.

Character Entry/Voice Entry 447

About character entry Character entry Enter pictogram/symbol/phrase Omakase pictogram Save

phrase Copy/Paste character Enter kuten code Save word Call phonebook Set character entry

method Voice input etc.

Network Services 461

Voice Mail service Call waiting Call forwarding service Nuisance call barring service Caller ID

request service Dual network service English guidance Service numbers Arrival call act Remote

control etc.

Overseas Use 469

Overview of international roaming service (WORLD WING) Services available Preparing and

checking for using FOMA terminal overseas Making/Receiving a call Network search mode

Roaming guidance Bar calls at roaming Services available overseas etc.

PC Connection 483

Data Communication DOCOMO keitai datalink etc.

Appendix/Troubleshooting 489

Menu list List of character assignments Combination of Multiaccess functions Options and relat-

ed devices Troubleshooting Error messages Warranty and After-Sales service Software update

Specifications SAR certification information Intellectual property rights etc.

Index 531

L02.fm Page 7 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Main functions of F-09B

Main features of F-09B

1Seg

You can watch "1Seg", a terrestrial digital TV

broadcast for mobile devices. You can also

communicate with a broadcasting station etc.

interactively and participate in quiz programs,

enjoy TV shopping etc.

→

p.298

i-mode mail, Easy Deco-mail

In addition to message text, you can attach

pictures, moving picture files, etc.

→

p.188

Moreover, as Deco-mail is available, you can

receive colorful and joyful mails, or send

decorated mails.

→

p.184

Voice entry message

This is a service that even a user who are not

good at operating keypads can enter characters

by voice and create mails.

After converting to texts, you can edit it manually

and add pictograms to it.

→

p.458

* This is an optional service to be charged

requiring subscription.

International Roaming

While staying overseas, you can use the same

FOMA terminal, phone number and mail address

as those used in Japan. You can use a voice/

videophone call, i-mode, i-mode mail, SMS and

network services.

→

p.470

GPS function

You can use radio waves transmitted from a GPS

satellite to obtain location information of FOMA

terminal. By using the information, you can check

the map of current location and peripheral

information, and you can attach the current location

to mail. You can also notify others of the location

information with a voice or mail during a call and

check the route to the destination.

→

p.340

DOCOMO community

DOCOMO community is a communication service

to share pictures, diaries and memos with

familiar people such as your family with no

additional monthly charge.

→

p.444

You can write a diary or send a picture in the way

you send mail, so you can easily update information.

* This is an optional service requiring

subscription.

Unique and convenient functions of F-09B

Voice recognition

You can easily call registered phonebook entries

or functions with your voice. Up to 100 functions

to be called can be registered. Depending on

usage frequency, the registered functions to be

called can be changed or added.

→

p.160, p.162

Voice reading

Read aloud the explanation of operation currently

shown on the display, or the contents of a

received mail or a site.

→

p.164

With FOMA terminal folded, if you press and hold

(

on the left side for 1 second or more, FOMA

terminal lets you know the current time by voice.

You can change the voice quality or speed of reading

to set the reading operation to be easy to hear.

Simple mail and voice message

You can easily create mail by following the

instruction on the screen. You can also attach

pictures and videos easily.

→

p.174

Moreover, you can record a message on the spot

and attach it to mail to send.

→

p.190

One-touch dial

Only by pressing the number buttons (One-touch

dial button) below the display, you can easily

make calls or send mails to registered parties.

You can also set ring alert or incoming call image

for the registered party.

→

p.116

Optical guide and guide functions

When there is an incoming voice call or videophone

call, a button blinks brightly to notify you how to

answer the call. This function allows you to see the

button to press next to shoot video or to fix the

setting. For a menu or function name that "

ガイド

(Guide)" is displayed at the bottom of the screen,

you can read the explanation.

→

p.30

, P999,

p.285

L02.fm Page 8 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Various security settings

Omakase Lock

Omakase Lock is a service that locks FOMA

terminal on request from the subscriber. Even if

the holder of FOMA terminal is different from its

subscriber, the terminal may be locked on

request from the subscriber.

→

p.143

* If you are the member of docomo Premier Club,

you can use the service any number of times

with no commission. If you are not the member

of docomo Premier Club, you are charged for

the service (however, you are not charged if

you subscribe to this service at the same time

as service interruption or during interruption.).

For precautions and detailed procedure for

using this service, refer to "Mobile Phone

User's Guide [i-mode] FOMA version".

Data Security Service

This is a service to back up the phonebook with

automatic update. This service allows you to

store phonebook, images or mails saved in FOMA

terminal to Data Center and restore the saved

data in case of misplacement of FOMA terminal

etc. You can also send broadcast notice when you

change your mail address. A PC (My docomo)

provides you with more convenient usage.

→

p.152

* This is an optional service to be charged

requiring subscription. For precautions and

detailed procedure for using this service, see

"Mobile Phone User's Guide [i-mode] FOMA

version".

Other convenient functions

Waterproofness/Dustproofness

FOMA terminal is provided with waterproofness

of IPX5 and IPX7 and dustproofness of IPX5 by

firmly closing the external connection jack cap

and installing the back cover in a locked state.

→

p.18

You can call or send/receive mail in the rain,

bathroom, etc. If the terminal is soiled with mud,

dirt, etc., you can wash it in tap water.

Omakase camera

Backlight, brightness, camera shake, skew, etc.

are corrected automatically. Also, a subject is

automatically focused according to its movement

so that you can easily shoot a clear picture using

macro shooting or normal shooting.

→

p.281

Super clear-voice 3 and Voice

slowing

"Super clear-voice 3 (

＝

Voice clear)" changes the

way to emphasize sound according to

surrounding noise to let you hear other party's

voice easily in various places. "Voice slowing"

also makes it easier to hear other party's voice by

adjusting the speed of other party's voice.

→

P999

Bar code reader and magnifier

Using macro shooting function, you can use

FOMA terminal as a bar code reader or magnifier.

Using bar code reader, you can obtain

information.

→

p.293

One-touch buzzer

By sounding a large-volume buzzer by using a

switch in emergency situation, you can notify the

people around you of your current location. Also,

by sounding the one-touch buzzer, you can

automatically make a voice call or use GPS

function to notify your current location.

→

p.435

Infrared communication

With devices that infrared communication

function is equipped, you can exchange

phonebook, photograph, etc.

→

p.396

Pedometer/Activity monitor

You can use FOMA terminal as a pedometer or

activity monitor to calculate the walked distance,

consumed calories, burnt fat, activity amount,

etc. In addition, you can automatically send

information in the pedometer/activity monitor to

the same destination on the same time every day

(Pedometer auto-send mail).

→

p.404

Healthy life diary

You can manage data obtained by a manometer

and body composition meter, and the data can be

graphed into a comprehensible chart. Also, by

using "

からだカルテ

(Medical body record)", you

can get advice about health from measured

result.

→

p.410

Omakase random stand-by screen

You can set a mail address and subject to a

distributor of a stand-by image so that the image

attached to mail is automatically saved and

displayed on the stand-by display when the

received mail matches the criteria.

→

p.127

L02.fm Page 9 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Precautions (ALWAYS

FOLLOW THESE DIREC-

TIONS)

・

Before using your FOMA terminal, or when

necessary, read the precautions below to

ensure safe use and handling. After reading

this manual, keep it carefully.

・

These precautions are intended to protect you

and others around you. Read and follow them

carefully to avoid injury, damage to the product

or damage to property.

・

The signs below differentiate between the

levels of danger that can occur if the product is

not used within the specified guidelines :

・

The symbols below show specific directions :

■

Precautions contain the description

below :

Handling FOMA terminal, battery pack, adapter, desktop

holder and UIM (Common)......................................... 10

Handling FOMA terminal ................................................ 11

Handling battery pack ..................................................... 12

Handling adapter and desktop holder ........................... 13

Handling UIM................................................................... 14

Handling mobile phones near electronic medical

equipment .................................................................... 14

Handling FOMA terminal, battery

pack, adapter, desktop holder and

UIM (Common)

DANGER

Do not use, store, or leave the equipment

in hot areas such as near flames or in

areas under strong direct sunlight such

as inside a vehicle.

May cause fire, burns or injuries.

Do not put the terminal into heating

cooking device such as microwave oven

or high-pressure container.

May cause fire, burns, injuries, electric shock.

Do not disassemble or remodel the

equipment.

May cause fire, burns, injuries, electric shock.

Do not let the terminal get wet with

water, drinking water, urine of pet

animals, etc.

May cause fire, burns, injuries, electric shock.

For FOMA terminal, use the battery pack

and adapter specified by NTT DOCOMO.

Failure to do so may cause fire, burns, injuries,

electric shock.

WARNING

Do not throw the equipment or give hard

shock to it.

May cause fire, burns, injuries, electric shock.

Keep conductive materials (metal pieces,

pencil lead, etc.) from coming in contact

with the charger terminal or external

connection jack. Do not put those

materials inside the terminal.

May cause fire, burns, injuries, electric shock.

Do not cover or wrap the terminal with a

blanket, etc while using or charging.

May cause fire or burns.

DANGER

This sign denotes that death

or serious injury may

directly result from

improper use.

WARNING

This sign denotes that death

or serious injury may result

from improper use.

CAUTION

This sign denotes that

bodily injury or damage to

property may result from

improper use.

This symbol denotes that the action is

prohibited.

This symbol denotes that disassembling

the phone or its components is not

allowed.

This symbol denotes that using the

phone or its components with wet hands

is not allowed.

This symbol denotes that using the

phone or its components in a bathroom

or other highly humid area is not

allowed.

This symbol denotes that an instruction

must be obeyed at all times.

This symbol denotes that the equipment

should be unplugged.

Don’t

No disassembly

No wet hands

No liquids

Unplug

Don’t

No disassembly

No liquids

Don’t

L02.fm Page 10 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Turn FOMA terminal OFF and stop

charging before entering a place such as

a gas station where flammable gases are

generated.

The gas may catch fire.

When using Osaifu-Keitai in a place as a gas

station, turn OFF the terminal before using it.

(When IC card lock is activated, deactivate it

before turning OFF the terminal.)

If the equipment starts giving off a

strange smell, overheats, becomes

discolored or deformed during use,

charging or in storage, immediately

perform the following operations :

･

Remove the power plug from the wall

outlet or cigarette lighter socket.

･

Turn FOMA terminal OFF.

･

Remove the battery pack from FOMA

terminal.

Failure to do so may cause fire, burns, injuries,

electric shock.

CAUTION

Do not leave the equipment on unstable

or sloping surfaces.

The terminal may fall and cause injuries.

Do not store the equipment in extremely

humid, dusty or hot areas.

May cause fire, burns, electric shock.

Children using the equipment should be

instructed in proper operation by an

adult. Do not allow them to use the

equipment without adult supervision.

May cause injuries.

Store the equipment out of reach of small

children.

The equipment can be accidentally swallowed

or cause injuries.

Be careful especially when using FOMA

terminal connected to the adapter

continuously for a long time.

If you use i-

ppli, videophone call, 1Seg

watching, etc. for a long time while charging,

FOMA terminal, battery pack and adapter may

be heated.

If directly touching the heated part for a long

time, you may have redness, itching, rash or

low-temperature burns depending on your

constitution or health condition.

Handling FOMA terminal

WARNING

Do not direct the infrared data port

toward your eye and transmit signals.

May cause harmful effect on eyes.

Do not direct the infrared data port

toward home electric appliances etc.

equipped with infrared device when

using infrared communication.

May cause an accident because of malfunction

of infrared device.

Do not put foreign objects such as liquid

like water, metal pieces or burnable

things into UIM or microSD card slot.

May cause fire, burns, injuries, electric shock.

Turn FOMA terminal OFF in areas where

use is prohibited, such as in airplanes and

hospitals.

May cause electronic equipment or electronic

medical equipment to fail or malfunction. If the

function which automatically turns on the

power is set, cancel the setting before turning

the power off.

When using the phone in a medical facility, be

sure to observe the regulations of the facility. If

you do prohibited act such as using the phone

in an airplane, you will be punished according

to law.

When you talk by setting handsfree or

ring alert is sounding, keep FOMA

terminal away from your ear.

And, when connecting the earphone/

microphone to FOMA terminal and play a

game or music, adjust the volume

moderately.

Too loud volume may cause a hearing loss.

And, if you cannot hear the sound around you

clearly, it may cause an accident.

If you have weak heart, be careful when

setting the Vibrate alert (vibration) or

alert volume setting.

May cause harmful effect on heart.

When you use electronic medical

equipment, check with the equipment

manufacturer to determine how the

device is affected by radio waves before

using.

May cause harmful effect on electronic medical

equipment etc.

Don’t

L02.fm Page 11 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Turn FOMA terminal OFF near high-

precision electronic control equipment or

electronic equipment using low-power

signals.

May cause the equipment to fail or malfunction.

* Examples of electronic equipment to avoid :

Hearing aids, implanted pacemakers or

defibrillators, other electrical medical

equipment, fire alarms, automatic doors,

other automatic control equipment, etc.

Users wearing implanted pacemakers or

defibrillators or other electrical medical

equipment should check with the

manufacturer or sales outlet about the effect

of radio frequencies on the equipment.

When the display or camera lens is

accidentally broken, be careful of broken

glass or exposed internal parts of FOMA

terminal.

Surfaces of display and camera lens are made

of plastic panels and they are structured for the

glass not to scatter, however, if you mistakenly

touch broken or exposed parts, you may be

injured.

When sounding one-touch buzzer,

always keep FOMA terminal away from

your ear.

Failure to do so may cause hearing defect.

CAUTION

Do not swing FOMA terminal by holding

its strap etc.

May cause accident such as injury to yourself or

others by hitting.

Do not use damaged FOMA terminal.

May cause fire, burns, injuries, electric shock.

If the display part is accidentally broken

and liquid crystal leaks out, do not make

the liquid contact with your skin of face

or hands.

May cause loss of sight or skin problems.

If the liquid gets into your eyes or mouth, rinse

it with clean water and see a doctor

immediately.

And, if the liquid adheres to skin or clothing, use

alcohol, etc. to wipe it off, then wash with soap.

To use the terminal in car, check with

automobile manufacturer or dealer to

determine how the device is affected by

radio waves before using.

In rare cases, using the phone in some vehicle

models can cause the vehicle's electronic

equipment to malfunction. In that case, stop

using the terminal immediately.

Mobile phones can give some users skin

problems such as itching, allergic

reactions or rashes. If you develop skin

problems, stop using the phone

immediately, and see a doctor.

→

"Material list (p.15)"

When opening or closing FOMA terminal,

take care not to have your fingers or strap

caught by the terminal.

May cause accident such as injuries.

When watching the display, take a

certain distance from the display in a fully

bright place.

Failure to do so may reduce visual acuity.

Handling battery pack

■

Check that the battery type matches the

type displayed on the battery pack label :

DANGER

Do not connect a wire or other metal

objects to the jack. And, do not carry or

store FOMA terminal with objects like a

metal necklace.

May cause battery pack to ignite, burst, heat or

leak.

Check the orientation of battery pack to

install it to FOMA terminal, and do not try

to force the battery pack onto FOMA

terminal if you are having trouble

installing it.

May cause battery pack to ignite, burst, heat or

leak.

Do not throw the battery pack into the

fire.

May cause battery pack to ignite, burst, heat or

leak.

Don’t

Display Battery type

Li-ion 00 Li-ion battery

Don’t

L02.fm Page 12 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Do not nail the battery pack, hit with a

hammer or step on it.

May cause battery pack to ignite, burst, heat or

leak.

If the battery pack's fluid contacts eyes,

immediately flush the eyes with clean

water and see a doctor immediately. Do

not rub the eyes.

Battery fluid in the eyes may cause blindness.

WARNING

If the battery pack seems to have

abnormalities such as deformation or

scratches due to falling, never use it.

May cause battery pack to ignite, burst, heat or

leak.

If the battery pack leaks or gives off a

strange smell, immediately remove it

from the vicinity of open flames.

The vapors from leaking battery pack fluid may

ignite or explode.

Be careful not to let your pet bite the

battery pack.

May cause battery pack to ignite, burst, heat or

leak.

CAUTION

Do not discard old battery packs together

with other garbage.

May cause igniting or environmental

destruction. Tape the terminals of old battery

packs to insulate them, and then bring them to

a sales outlet such as docomo Shop. If your

local municipality has a battery recycling

program, dispose of them as provided for.

Do not use or charge a wet battery pack.

May cause battery pack to ignite, burst, heat or

leak.

If fluid leaks out from battery pack, do not

make the fluid contact with your skin of

face or hands.

May cause loss of sight or skin problems.

If the fluid put into your eyes or mouth, or

contacts skin or clothes, immediately flush the

contacted area with clean water.

If the fluid put into the eyes or mouth,

immediately see a doctor after flushing.

Handling adapter and desktop

holder

WARNING

Do not use the adapter cord if it gets

damaged.

May cause fire, burns, electric shock.

Do not use the AC adapter or desktop

holder in a bathroom or other highly

humid area.

May cause fire, burns, electric shock.

Always use the DC adapter with a

negative-ground vehicle. Do not plug it

into a positive-ground vehicle.

May cause fire, burns, electric shock.

When it starts to thunder, do not touch

adapter.

May cause electric shock.

Do not short the charger terminal while it

is connected to the outlet or cigarette

lighter socket. Do not touch the charger

terminal with a part of your body such as

your hand or finger.

May cause fire, burns, electric shock.

Do not place heavy objects on the

adapter cord.

May cause fire, burns, electric shock.

When you insert and remove AC adapter

from power outlet, do not contact a

metal strap or other metal objects with

the jack.

May cause fire, burns, electric shock.

Do not touch the adapter cord or outlet

with wet hands.

May cause fire, burns, electric shock.

Only use with the specified power source

and voltage. When charging FOMA

terminal overseas, use AC Adapter for

global use.

If incorrect voltage is used, this may cause fire,

burns or electric shock.

AC Adapter : 100V AC

DC Adapter : DC 12V/24V (specific for negative

ground vehicle)

AC adapter for global use : Between 100V and

240V AC (Connect to the AC outlet for internal

household use)

Don’t

No wet hands

L02.fm Page 13 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

If the DC adapter's fuse blows, replace it

only with the specified fuse.

Failure to do so may cause fire, burns, electric

shock. For the specified fuse, refer to the

instruction manual that comes with the device.

Wipe off any dust that accumulates on

the power plug.

Failure to do so may cause fire, burns, electric

shock.

When you connect the AC adapter to an

outlet, firmly connect to the outlet.

Failure to do so may cause fire, burns, electric

shock.

When you disconnect the adapter from

the outlet or cigarette lighter socket, do

not pull the adapter cord with excessive

force. Instead, hold the power plug to

disconnect.

Failure to do so may cause fire, burns, electric

shock.

Always remove the power plug from the

outlet or cigarette lighter when not

using the adapter for an extended

period.

Failure to do so may cause fire, burns, electric

shock.

Immediately remove the power plug

from the outlet or cigarette lighter

socket if water or other fluids get into

the adapter.

Failure to do so may cause fire, burns, electric

shock.

Always remove the power plug from the

cigarette lighter socket when cleaning

the equipment.

Failure to do so may cause fire, burns, electric

shock.

Handling UIM

CAUTION

Be careful of the cut surface when

removing UIM.

May cause injuries.

Handling mobile phones near

electronic medical equipment

■

These precautions are based on the

guidelines produced at the

Electromagnetic Compatibility Conference

Japan, regarding the protection of

electronic medical equipment from radio

waves emitted by mobile phone units.

WARNING

Obey the following rules inside medical

facilities :

･

Do not bring FOMA terminal into operating

rooms (ORs), intensive care units (ICUs) or

coronary care units (CCUs).

･

Turn FOMA terminal OFF in hospital wards.

･

Turn FOMA terminal OFF in hospital lobbies

and corridors if electrical medical devices

could be nearby.

･

If the medical facility has specified zones

where use or possession of mobile devices is

prohibited, obey those instructions.

･

If the function to automatically turn on the

power is set, cancel the setting before turning

the power off.

Turn FOMA terminal OFF in crowded

trains or other public places where

pacemaker or defibrillator wearers could

be nearby.

FOMA terminal's signals may affect the

operation of implanted pacemakers or

defibrillators, and other devices.

Wearers of implanted pacemakers or

defibrillators must carry and use FOMA

terminal at least 22 cm away from the

implanted device.

FOMA terminal's signals may affect the

operation of implanted pacemakers or

defibrillators, and other devices.

When electrical medical devices other

than implanted pacemakers or

defibrillators are in use outside of

medical facilities (such as in home care

settings), check with the device

manufacturer to determine how the

device is affected by electrical signals.

FOMA terminal's signals may affect the

performance of electronic medical equipment.

Unplug

L02.fm Page 14 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Material list

Place of use Material Surface finishing

Exterior

case

Movable

part Sub-

display

PC+ABS resin UV hard coating

Movable

part

Display

PA-GF resin UV hard coating

Fixed part

Keypad

PA-GF resin UV hard coating

Fixed part

Battery

PC+ABS resin UV hard coating

Back

cover

PC+ABS resin UV hard coating

Back

cover lock

lever

POM resin None

Back

cover

inside

plate

Stainless

steel

None

Hinge

Movable

side

ABS resin UV hard coating

Hinge

Fixed side

ABS resin UV hard coating

Rear

screw cap

ABS resin UV hard coating

One-

touch

buzzer

switch

POM resin None

Display panel Acrylic resin UV hard coating

Sub-display panel Acrylic resin Acrylic hard

coating

Camera lens, Camera

panel

Acrylic resin UV hard coating

Side buttons PC resin UV hard coating

Operation buttons PC resin UV hard coating

Facing sheet around

keypad

PET resin None

One-touch buttons PC resin UV hard coating

Facing sheet around

one-touch buttons

PET resin None

Open assist button PC resin UV hard coating

Case pad Urethane

resin

None

External

connection

jack cap

Body PC+ABS resin UV hard coating

Bending

part

Elastomer

resin (TPE)

None

Water

stop part

PC+ABS resin None

D ring Synthetic

rubber

(EPDM)

None

External connection

jack

Stainless

steel

Tin plating

Battery

contacts

Battery

contacts

connector

body

PPS resin None

Battery

contacts

Beryllium

copper

Gold plating (Ni-

Pd plating based)

Screw (Battery install

recess)

Stainless

steel

None

Battery install recess

face

Printed circuit

board

Gold plating

Battery

pack

Battery

pack

PC resin None

Contacts Beryllium

copper

Gold plating

Battery

cover plate

(inner

cover)

Body Stainless

steel

None

Gasket Silicon rubber

(VMQ)

None

Charging

jack

Contacts Stainless

steel

Gold plating

Attaching

holder

section

LCP resin None

UIM card tray POM resin None

Place of use Material Surface finishing

L02.fm Page 15 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Handling precautions

General

・

F-09B is waterproof and dustproof, however, do not

allow water or dust to seep into FOMA terminal and do

not allow water or dust to adhere to accessories or

optional devices.

- FOMA terminal is provided with waterproofness of

IPX5 and IPX8 (a standard higher than IPX7) and

dustproofness of IPX5 by firmly closing the external

connection jack cap and installing the back cover in a

locked state, however, it is not completely

waterproof/dustproof. Do not install/remove the

battery pack or do not open/close the external

connection jack cap and back cover in the rain or with

waterdrop or dirt adhered to them. Water may seep

inside and cause corrosion or malfunction. Also,

accessories and optional devices are not waterproof/

dustproof. Malfunctions, which are determined to be

caused by water or dust as a result of inspections, are

not covered by the warrant. Since these conditions

are outside the scope of the warranty, a repair, if at

all possible, is charged.

・

Clean FOMA terminal with a dry soft cloth (such as a

cloth for eyeglasses).

- Rubbing it roughly with a dry cloth can scratch the

display.

- Drops of water or dirt left on the display may cause

stains.

- If FOMA terminal is wiped with alcohol, paint thinner,

benzine or detergent, the printing may disappear or

color may fade.

・

Clean the jack occasionally with a dry cotton swab etc.

- If the jack is soiled, connection gets worse and it may

cause power to be turned off or insufficient battery

charge, so clean the jack with a dry cotton swab etc.

Also, be careful never to damage the jack when

cleaning it.

・

Do not place FOMA terminal near an air-conditioner

outlet.

- The rapid change in temperature may cause

condensation, causing internal corrosion and

malfunction.

・

When using, be careful not to subject excessive force

to FOMA terminal or the battery.

- If FOMA terminal is crammed into a brimming bag or

placed in a pocket and sat on, the display, internal

PCBs, battery pack, etc. may be damaged or broken.

And, if external devices are plugged into the external

connection jack (earphone/microphone jack), the

breakage of the connector or malfunction may result.

・

Carefully read the separate instructions that come with

FOMA terminal and adapter.

・

Do not rub or scrape the display with a metal piece,

etc.

- It may scratch the display, causing malfunction or

damage.

FOMA terminal

・

Avoid extreme temperature.

- Use FOMA terminal where the temperature ranges

between 5 and 40

℃

(limited to the temporary use in

a bathroom etc. when temperature is above 36

℃

)

and humidity ranges between 45 and 85%.

・

FOMA terminal may affect land-line phones, TVs or

radios in use nearby, so use it as far as possible from

these appliances.

・

Maintain a separate record of the data you register in

your FOMA terminal.

- If the data should be deleted, DOCOMO assumes no

responsibility for the loss of any data.

・

Do not drop FOMA terminal or subject it to shocks.

- May cause malfunction or damage.

・

Do not plug external devices into the external

connection jack (earphone/microphone jack) at a slant,

or do not pull it while it is plugged.

- May cause malfunction or damage.

・

Do not fold FOMA terminal with the strap held inside.

- May cause malfunction or damage.

・

It is normal for FOMA terminal to become warm

during use or charging. Continue to use it.

・

Do not leave FOMA terminal with the camera in areas

under strong direct sunlight.

- May cause discoloring or burn-in of materials.

・

FOMA terminal should normally be used with the

external connection jack cap closed.

- Dust and/or water brought into FOMA terminal cause

troubles.

・

Do not use FOMA terminal with the back cover

removed.

- It may cause the battery to come off, or may cause a

malfunction or damage.

・

Do not put an extremely thick sticker, etc. on the

surface of display or keys.

- May cause malfunction or damage.

・

While using microSD card, do not remove microSD

card or turn OFF FOMA terminal.

- It may cause data loss or malfunction.

・

Do not place magnetic disks or cards with magnetic

stripes near FOMA terminal or place inside and fold

the terminal.

- Data stored on media such as cash cards, credit

cards, telephone cards and floppy disks may be

erased if the storage medium is placed near the

phone.

・

Do not bring magnetized objects close to FOMA

terminal.

- Bringing strong magnetism close may cause

malfunction.

L02.fm Page 16 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Battery pack

・

The battery pack is a consumable part.

- Replace the battery pack if FOMA terminal has

extremely short operation time on a full charge,

though it may vary by operating conditions.

Purchase a new battery pack of the specified type.

・

Charge the battery in an area within the proper

ambient temperature range (5-35

℃

・

The operation time provided by the battery pack varies

by the operating environment and battery pack's

deterioration.

・

The battery pack may swell out as it comes to near the

end of its lifetime depending on the usage conditions,

but it is not a problem.

・

Be careful about the following points when you keep

the battery pack.

- Keeping under the state of full charge (right after

charging ends)

- Keeping under the state of empty charge (too

exhausted to turn on FOMA terminal)

It may cause the battery pack performance to be

degraded or its lifetime to be shortened.

An appropriate battery level for storage is that the

battery icon is displayed with 2 cells.

Adapter

・

Charge the battery in an area within the proper

ambient temperature range (5-35

℃

・

Do not charge the battery in the areas below :

- In areas of excessive humidity, dust or vibrations

- Near land-line phones or TVs/radios

・

It is normal for the adapter to become warm while

charging. Continue to use it.

・

When using the DC adapter for charging, keep the

vehicle engine running.

- The vehicle's battery could become flat.

・

When using an outlet with a mechanism preventing

unplugging, follow the handling instructions for that

outlet.

・

Do not give hard shock to the adapter (including

battery charger). Do not deform the charger terminal.

- May cause malfunction.

UIM

・

Do not use excessive force to install/remove UIM.

・

Note that DOCOMO assumes no responsibility for

malfunctions occurring as the result of inserting and

using a UIM with another IC card reader/writer.

・

Always keep UIM ICs clean.

・

Clean the UIM with a soft, dry cloth (such as a cloth for

eyeglasses).

・

Maintain a separate record of the data you register on

the UIM.

- If the data should be deleted, DOCOMO assumes no

responsibility for the loss of any data.

・

To preserve the environment, bring the old UIM to a

sales outlet such as docomo Shop.

・

Take care not to scratch, touch accidentally or short IC.

- It may cause data loss or malfunction.

・

Do not drop the UIM or subject it to shocks.

- May cause malfunction.

・

Do not bend the UIM or place heavy objects on it.

- May cause malfunction.

・

Do not insert UIM into FOMA terminal with a label or

sticker put on UIM.

- May cause malfunction.

CAUTION

・

Do not use a remodeled FOMA terminal. Using a

remodeled terminal violates the Radio Law.

FOMA terminal is certified according to technical

standard conformance of specified wireless

equipment based on the Radio Law, and as a proof of

it, the "Technical Compliance Mark " is depicted on

the engraved sticker of FOMA terminal.

If you remodel FOMA terminal by removing its screws,

your certification of technical standard conformance

becomes invalid.

Do not use FOMA terminal with its certification of

technical standard conformance invalid as it violates

the Radio Law.

・

Be careful when you use FOMA terminal while driving

a car, etc.

Using a mobile phone while driving is subject to penal

regulations.

If you inevitably receive a call, tell the caller that you

will "call back" by handsfree, then park in a safe place

and call back.

L02.fm Page 17 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Waterproofness/Dust-

proofness

F-09B is provided with the following

waterproofness by firmly closing the external

connection jack cap, installing the back cover and

locking the cover.

・

IPX5 (Former JIS protection code 5)

・

IPX8

that is a higher standard than IPX7

(former JIS protection code 7)

Also, F-09B is dustproof to IP5X (former JIS

protection code 5)

if the external connection

jack cap is strictly closed as well as the back cover

is mounted and locked.

*1 Code IPX5 means that a phone keeps functioning

after directly applying a jet flow of 12.5 L/min. for at

least 3 minutes from a distance of 2.5-3 m on a

rotating turntable.

*2 Code IPX7 means that a phone keeps functioning

after it is slowly submerged to depth of 1 m in static

tap water at room temperature, left there for 30

minutes and then taken out.

*3 Code IPX8 means that it provides waterproofness

of which exceeds of IPX7 standard.

*4 Code IP5X means that a device is protected against

the ingress of dust specific to dustproof test (25

m or smaller in diameter), so that the ingress will

not interfere with predefined operation and safety

of the device.

F-09B provides the following waterproof

performances of IPX8.

･

F-09B keeps functioning after it is slowly

submerged to depth of 1.5 m in static tap water

at room temperature, left there for 30 minutes

and then taken out.

･

The mobile phone keeps shooting still images

or moving pictures in 30 minutes in static tap

water at room temperature.

・

You can talk or watch 1Seg programs without using an

umbrella in the rain (for rainfall of 20 mm or less per

hour).

- When your hands or FOMA terminal are wet, avoid

installing/removing the back cover or opening/

closing the external connection jack cap.

・

You can also shoot still images and moving pictures in

the pool depth of 1.5 m.

- Do not perform operations underwater except

shooting still images or moving pictures.

- If you put the terminal in water of swimming pool, be

sure to have it within 30 minutes.

- If FOMA terminal gets wet with water from the

swimming pool, wash it as predefined (

→

p.20).

・

You can use FOMA terminal in a bathroom.

- Do not put the terminal in the bathtub. Do not use the

terminal in hot water. May cause malfunction.

- Never put FOMA terminal in hot spring water or

water containing soap, detergent or bath powder.

To ensure waterproofness/

dustproofness

To avoid water and dust ingress, be sure to observe the

following points.

・

Do not throw any liquid other than room-temperature

tap water on FOMA terminal, or soak it in such liquid.

・

Open/close the external connection jack cap as

described below.

Place your finger at groove on the back cover side to

open the cap.

Close with the tab for the hinge at the rear side of the

cap fitted into the concave of the terminal. Make sure

that the cap is completely closed without slack.

What you can do with waterproofness and

dustproofness of F-09B

Groove on the back

cover side

Tab on the hinge side

L02.fm Page 18 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

・

Install the back cover as described below.

Fit 8 tabs of the back cover with concaves of FOMA

terminal. While pressing the back cover in the

direction of

so that there is no gap between FOMA

terminal and back cover, slide the back cover in the

direction of

to install, then slide the back cover lever

in the direction of

to lock.

* Make sure that the back cover is completely closed

without slack. Slide the lever on the back cover in

the direction of an engraved arrow, confirm that it

is firmly locked, then use the terminal.

・

Securely lock the back cover and firmly close the

external connection jack cap. Even a fine obstacle (one

hair, one grain of sand, tiny fiber, etc.) put between

contact surfaces may allow water to seep.

・

Do not poke the microphone, earpiece or speaker with

a swab or sharp object.

・

Do not drop FOMA terminal. It may become scratched

causing the waterproof/dustproof performance to

degrade.

・

The external connection jack cap and the rubber

packing of the inner lid play an important role for

keeping waterproof/dustproof performance. Do not

remove or scratch it. Also, prevent dust from adhering

to it.

To keep the FOMA terminal waterproof/

dustproof, replacement of parts is required every

2 years regardless of whether FOMA terminal

appears normal or abnormal. Replacement of

parts is charged and DOCOMO keeps your FOMA

terminal for the replacement. Bring the terminal

to a DOCOMO-specified repair office.

Important precautions

Do not perform actions shown in the illustrations below.

Observe the following precautions to use FOMA terminal

properly.

・

Accessories and optional devices are not waterproof/

dustproof. When watching 1Seg etc. with FOMA

terminal installed in the attached desktop holder, do

not use it in a bath room, shower room, kitchen or

lavatory even if it is not connected to the AC adapter.

・

Do not apply water flow stronger than allowed (

→

p.18) (e.g., such water flow that gives you pain when

applied to your skin directly from a faucet or shower).

F-09B provides the following waterproof

performances of IPX5. However, it causes malfunction.

・

If FOMA terminal should get wet with salt water,

seawater, soft drink or with mud or soil, flush away

immediately. When it dries out, it becomes harder to

get rid of, causing scratch or malfunction.

・

Do not put FOMA terminal in hot water, use it in a

sauna or apply hot airflow (from a hair dryer etc.) to it.

・

Do not move in water or slam the terminal against the

surface of water with FOMA terminal opened.

・

Do not soak the terminal in tap water or the pool for

more than 30 minutes.

・

When you use the terminal in swimming pool, obey

rules of the facility.

・

FOMA terminal does not float on water.

・

Do not leave water on FOMA terminal. May short-

circuit the power jacks, or in a cold region, water may

freeze causing malfunction.

・

Do not leave water on the microphone, earpiece or

speaker. It may cause a malfunction for calls.

・

If the back cover is damaged, replace it. Water may

enter inside from a damaged section causing troubles

such as electric shocks or corrosion of the battery.

Lever

Back cover

Washing with

laundry machine

Soaking in

Ocean water

Washing with

brush/sponge

Using soap/detergent/

bath powder

Using in

hot spring

Applying strong

water flow

L02.fm Page 19 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

・

If FOMA terminal gets wet with water or other liquids

with the external connection jack cap or back cover

open, the liquid may get inside the terminal causing

electric shocks or malfunction. Stop using FOMA

terminal, turn the power OFF, remove the battery pack

and contact a DOCOMO-specified repair office.

・

If rubber gasket on the external connection jack cap or

inner lid is damaged or deformed, replace it at

DOCOMO-specified repair office.

DOCOMO does not guarantee actual operations

under all states. Malfunctions deemed to be

caused by inappropriate operation by the

customer are not covered by the warranty.

Washing FOMA terminal

With holding the external connection jack cap not

to be opened, wash it with your hands not

scrubbing the terminal under tap water.

・

Do not apply water flow stronger than allowed (

→

p.18) (e.g., such water flow that gives you pain when

applied to your skin directly from a faucet or shower).

・

Install the back cover and with it locked, holding the

external connection jack cap not to be opened and

wash it with your hands not scrubbing under room-

temperature tap water.

・

Do not wash it by using a brush, sponge, soap,

detergent, etc.

・

When mud or soil is attached to FOMA terminal, do not

open or close the terminal. Instead, rinse the terminal

clean by shaking it several times in tap water in a

bucket, etc. and then flush away with running water.

・

After flushing away, wipe off water with a dry cloth,

drain as follows, and dry naturally.

Draining the water from FOMA

terminal

When FOMA terminal is wet, water may flow out after

wiping it off; drain the water in the following steps.

Wipe FOMA terminal surface with a dry, clean cloth

etc.

Shake FOMA terminal approximately 20 times, firmly

holding its hinge section, until there is no more water

splattering.

Press here

To d r ain water off the speaker, shake FOMA

terminal with the speaker upward

L02.fm Page 20 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Softly press dry, clean cloth etc., against FOMA

terminal to wipe off water remaining in the

microphone, earpiece, speaker, keys or hinges.

Remove the back cover and wipe off waterdrop

around the inner lid and the rear side of the back

cover. Never open the inner cover. After wiping off

the water, install and lock the back cover.

Removing back cover

→

p.44

■

Attaching

"Attaching/Removing battery pack"

Wipe off water drained from FOMA terminal with

dry, clean cloth etc., and dry naturally.

･

Water, if left in the terminal after wiping off, may

seep out.

･

Do not wipe off water remaining in a gap directly

with a cotton swab etc.

Charging

Be sure to check the following before and after charging.

・

Check that FOMA terminal is not wet when charging.

Never try to charge the battery pack when FOMA

terminal is wet.

・

Accessories and optional devices are not waterproof/

dustproof.

・

When charging the battery when or after FOMA

terminal is wet, adequately drain it and wipe off water

with a dry, clean cloth etc., and then insert into the

attached desktop holder or open the external

connection jack cap.

・

When the external connection jack cap is opened for

charging, close the cap firmly after charging. It is

recommended that the desktop holder be used for

charging to prevent water from seeping inside from

the external connection jack.

・

Do not use the AC adapter or desktop holder in a

bathroom, shower room, kitchen, lavatory or other

highly humid area. It may cause fire or electric shock.

・

Do not touch the AC adapter or desktop holder with

wet hands. May cause electric shock.

Rear side of the

back cover

Around the inner

cover

L02.fm Page 21 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Easy Search/CONTENTS/Handling instructions

Basic package and optional accessories

■

Basic package

■

Optional accessories

F-09B

(Including the Back Cover F51

and the written warranty)

らくらくホン7取扱説明書

(Rakuraku phone 7

Instruction manual)

CD-ROM for F-09B

PDF version "

パソコン

接続マニュアル

(Manual

for PC Connection)" and

区点コード一覧

(Kuten

Code List)" are included.

らくらくホン7

かんたん操作ガイド

(Rakuraku phone 7 Simple

guide)

らくらくホン7使いこなしDVD

(DVD for Rakuraku phone 7 Usage)

Battery Pack F17

FOMA AC Adapter 01/02

(including written warranty and operation manual)

Desktop Holder F30

Other optional accessories

→

p.XXX

Desktop Holder F30 is made of recycled ABS from

used products.

L02.fm Page 22 Thursday, May 27, 2010 2:15 PM

F-09B_EN_ninshou

Before Using the Handset

Names and functions of parts ....................................................................................................24

Opening FOMA terminal with button operation ..................................................................... 26

Display overview ......................................................................................................................... 27

Sub-display overview ................................................................................................................. 30

Operating menu .......................................................................................................................... 34

Selecting the way of closing notification screen ..................................................................... 38

Switching vertical and horizontal view automatically .................. <Auto rotation setting> 39

Using

使いかたガイド

(Operation guide) .................... <

使いかたガイド

(Operation guide)> 40

Using UIM (FOMA card) ............................................................................................................. 42

Installing/Removing battery pack ............................................................................................. 44

Charging ....................................................................................................................................... 46

Checking remaining battery level ................................................................... <Battery level> 51

Turning power ON/OFF .............................................................................. <Power ON/OFF> 53

Setting date and time .......................................................................... <Date & time setting> 57

Notifying your phone number to the other party ........................... <Caller ID notification> 59

Checking your own phone number ........................................... <User information display> 60

L03.fm Page 23 Thursday, May 27, 2010 3:44 PM

F-09B_EN_ninshou

Before Using the Handset

Names and functions of parts

Names of parts of F-09B and main functions assigned to buttons are explained below.

･

In the explanation of operations, the buttons described here are represented by graphical symbols.

Earpiece

Other party's voice is heard from here.

Light sensor

Use to adjust automatically the brightness of the

display.

* Blocking the light sensor may disable automatic

adjustment of light setting correctly.

Display

→

p.27

EQL

One-touch dial button 1/2/3

Pressing this button for 1 second or more allows you

to make a call to the registered party.

Menu button

Use to display menus or to perform the operation

shown on the left of the guide line.

Press for 1 second or more to use the voice menu.

Return/i-Channel button

Use to delete characters, return to the previous

screen, display i-Channel list.

Press for 1 second or more to delete the display of

arrival information.

Start/Character button

Use to make/receive voice calls, switch calls using a

speakerphone function or display character entry

modes or the font type list.

Press for 1 second or more to play the voice message

of Voice Mail.

Dial button

Use to enter phone numbers or text, or to select

menu items.

Press

for 1 second or more to check your

current location.

On stand-by display or the phone number entry

screen, press

for 1 second or more to enter

prefix "+" for International call.

*/Public mode (Drive mode) button

Use to enter " ", voiced sound mark or semi-voiced

sound mark.

Press for 1 second or more to start/cancel Public

mode (Drive mode).

Videophone/Lower case/

button

Use to make/receive videophone calls or to change

upper/lower case.

Press for 1 second or more to watch 1Seg.

Rakuraku Site button

Use to connect to Rakuraku net.

Press 1 second or more to activate Rakuraku search.

L03.fm Page 24 Thursday, May 27, 2010 3:44 PM

F-09B_EN_ninshou

Before Using the Handset

Microphone

Send your voice from here.

* If you cover the microphone, your voice may not

be heard clearly to the other party or the voice

may not be recorded correctly.

* Rear microphone does not pick up your voice

because it is to cut noise.

In Camera

Use to shoot the image of yourself or to send the

image of yourself over a videophone call.

Phonebook button

Use to display phonebook, to perform the operation

shown on the right of the guide line or to switch the

call by speakerphone function.

Press for 1 second or more to perform voice search

of the phonebook.

Multi-cursor button (Cross button)

Enter button

Use to perform selected operation or to display the

convenient tool menu. Display Information content

when it arrives. Display the i-Channel list for i-

Channel weather information.

Mail/Up button

Use to display mail menu screen, to move the cursor

upward, to adjust the volume (up) or to display the

mail list after receiving new mails.

Press for 1 second or more to display mail creation

screen.

i-mode/i-

ppli/Down button

Use to display i-mode menu, to move the cursor

downward, to adjust the volume (down) or to display

the message list after receiving MessageR/F.

Press for 1 second or more to display i-

ppli list.

Received calls/Left button

Use to display Received calls, to move the cursor left,

to switch screen or to adjust the volume (down).

Redial/Right button

Use to display Redial, to move the cursor right, to

switch screen or to adjust the volume (up).

End/Power button ( )

Use to terminate calling/operating function, on-hold,

or to cancel Secret mode.

Press for 2 seconds or more to turn ON/OFF the

power of FOMA terminal.

#/Line-feed/Silent mode button

Use to enter "

＃

", to insert a line feed or to switch a

macro mode for shooting an image.

Press for 1 second or more to start/cancel Silent

mode.

Camera/Camera switching/Voice

input button

Use to activate photo taking screen, to switch out/in

camera or voice input for creating mail.

Press for 1 second or more to display camera menu.

Sub-display

→

p.30

Light

Turn on/Blink when charging, incoming call,

receiving mail, activating camera, etc.

FOMA Antenna

* The terminal has a FOMA built-in antenna. To talk

in better conditions, do not cover the antenna with

your hand.

One-touch buzzer switch

Use to sound one-touch buzzer.

→

p.435

Infrared data port

Use to send or receive data via infrared

communication.

Shooting light

Turn on/Blink when Camera is activated.

Out camera

Use to take pictures or send the image over a

videophone call.

Speaker

Ring alert, voice of the other party using the

speakerphone or Voice reading, or one-touch buzzer

are heard from here.

Back cover

* Remove a back cover, open an inner cover, then

remove a battery pack to access a UIM card slot

and a microSD card slot.

→

p.384

Back cover lever

→

p.44

Charging jack

Open assist button

→

p.26

(

Voice reading button

Use to turn on the light of the sub-display, to switch

display, to set Voice slowing, Voice reading or to

terminate alarm clock sound or the voice for

notification of the schedule.

Volume button

Use to turn on the light of sub-display or to adjust the

volumes or brightness for shooting.

Strap opening

External connection jack

An integrated connection jack for charging,

connecting an earphone, etc.

→

p.50, p.441

* Available to connect an optional AC adapter, DC

adapter, FOMA USB Cable with Charge Function,

Earphone Plug Adapter for External connector

terminal, etc.

Connect an optional external connection jack

compatible earphone.

When using an earphone that is incompatible with an

external connection jack, connect an optional plug

adapter to use it.

L03.fm Page 25 Thursday, May 27, 2010 3:44 PM

F-09B_EN_ninshou

Before Using the Handset

<1Seg antenna>

The terminal has a built-in 1Seg antenna, and an

entire body of the terminal can work as an antenna.

To receive signals, minimize the covered part of

FOMA terminal when holding it with your hands to

watch 1Seg in better conditions.

→

p.299

Opening FOMA terminal with button

operation

You can easily open FOMA terminal by a button operation.

･

It can be opened with an easy and light operation even if you do not use Open assist button.

Press Open assist button

FOMA terminal opens.

INFORMATION

･

It is recommended that you hold FOMA terminal with your hand to operate it. Also, be careful not to hit your face,

other people or objects when opening FOMA terminal or not to drop FOMA terminal for a sudden movement when

opening it.

･

FOMA terminal may not be completely opened depending on the direction of FOMA terminal.

･

When folding FOMA terminal, do it with your hand. When FOMA terminal cannot be completely folded, once open

it completely, then fold it again.

Example of connecting Flat-plug Earphone/

Microphone with Switch (optional)

External connection jack

Plug for the terminalFlat-plug earphone jack

Connecting plug of

Flat-plug Earphone/

Microphone with Switch

L03.fm Page 26 Thursday, May 27, 2010 3:44 PM

F-09B_EN_ninshou

Before Using the Handset

Display overview

You can check current status by icons on the display screen, Information/Newly arrived information,

etc.

Displayed icons

Icons shown on the display are explained here.

: Display of remaining battery level

→

p.51

/ : Display of signal level

→

p.53

: Self mode ON

→

p.143

: Unavailable UIM inserted

: Data transfer mode ON

/DOCOMO

keitai datalink is in use

→

p.383, p.396, p.487

: In i-mode communication, accessing

→

p.242

: Displaying SSL page

→

p.243

/ : In Packet communication connected

with PC/Exchanging data

→

p.484

: Auto speakerphone ON

→

p.76

: In infrared communication

→

p.396

Using infrared remote control

→

p.400

: Secret mode ON

→

p.144

: During a voice call

: During a videophone call

→

p.67

: Switching between voice call and

videophone call

: Disconnecting a voice/videophone call

: In 64K data communication

→

p.484

: Voice reading available/Voice reading ON

→

p.164

: Unread Area Mail

→

p.219

: Unread i-mode mail and SMS are full and

SMS are full in UIM

→

p.194

(red) : Unread i-mode mail and SMS are full

→

p.194

(red) : SMS are full in UIM

→

p.225

(black) : Unread i-mode mail and SMS exist

→

p.194, p.225

/ : Running i-

ppli/i-

ppli DX

→

p.316

/ : Displaying i-

ppli/i-

ppli DX stand-by

display

→

p.326

/ : Activating from i-

ppli/i-

ppli DX

stand-by display

→

p.327

(3G is black)/ (3G is red)/ / : Status

display of network condition in use

(black)/

(red) : Unread MessageR

exits/full

→

p.214, p.215

(black)/

(red) : Unread MessageF

exits/full

→

p.214, p.215

: i-concier newly arrived information

exists

→

p.350

: Communication using USB handsfree

compatible device in progress

: One-touch buzzer ON

→

p.435

: In i-mode communication

→

p.242

: Obtaining i-motion data

→

p.268

: Positioning with GPS

→

p.340

/ / / / /

: Display input mode

→

p.449

j - r

bcdefghi

ひつじのしつじくん

® (Butler Sheep)"

NTT DOCOMO

L03.fm Page 27 Thursday, May 27, 2010 3:44 PM

F-09B_EN_ninshou

Before Using the Handset

: Silent mode ON

→

p.126

: Vibrator for voice call and mute of call

alert volume are set to ON at the same time

→

p.123, p.124

: Vibrator for a voice call ON

→

p.124

: Mute of call alert volume ON

→

p.123

: Receiving i-mode mail, SMS

→

p.194,

p.225

: In Public mode (Drive mode)

→

p.83

(black) : Reading UIM

→

p.53

: Receiving MessageR

→

p.213

: Receiving MessageF

→

p.213

(black) : Record message ON

: Unchecked recorded message exists

→

p.85

(red) : Recorded messages full

→

p.85

: Unchecked missed call exists

→

p.68

: Location request permitted

→

p.349

: Location request permitted and AUTO-

GPS ON

: AUTO-GPS ON

/ : Setting the usage of pedometer/

activity monitor/Setting the usage of

pedometer/activity monitor and auto-send

mail

→

p.404, p.407

(red) : i-mode mail and MessageR/F

storage are full or one of these spaces is full

and unreceived message exists

→

p.195,

p.214

/ / (all red) : i-mode mail or

MessageR/F storage is full

→

p.195, p.214

(black) : Unreceived i-mode mail and

MessageR/F exist

→

p.195, p.214

/ / (all black) : Unreceived i-mode

mail or MessageR/F exist in i-mode Center

→

p.195, p.214

: Unread ToruCa exists

→

p.303

: eco mode ON

→

p.134

: Reserving software update

→

p.555

: In microSD mode (USB connection with

microSD card installed)

→

p.395

: In microSD mode (USB connection with

microSD card not installed)

→

p.395

: In microSD mode (no USB connection

with microSD card installed)

→

p.395

: In microSD mode (no USB connection

with microSD card not installed)

→

p.395

: microSD card exists

→

p.384

: Connected to a PC etc. using FOMA USB

Cable

→

p.484

: Dial lock ON

→

p.146

: User information display restriction ON

→

p.145

: Alarm clock ON

→

p.423

: 1Seg watching reservation or schedule

notification is set

→

p.426

: Alarm clock, 1Seg watching reservation or

schedule notification is set

→

p.423, p.426

Machi-chara

→

p.133

Information/Newly arrived information

→

p.38

Pedometer/Activity monitor

→

p.370

i-Channel ticker

→

p.248

*1 The terminal is in the same state as out of ser-

vice area in data transfer mode.

*2 The current highest-priority item is displayed.

These icons are listed in descending order of the

priority from the top.

*3 Displayed in small icon when unread i-mode

mail exists.

*4 Time is displayed on other than stand-by dis-

play.

*5 Not displayed when the icon

is displayed.

*6 Not displayed when the microSD mode icon of

is displayed.

L03.fm Page 28 Thursday, May 27, 2010 3:44 PM

F-09B_EN_ninshou

Before Using the Handset

Display of information/arrival information

If there is a notification of failed auto-update of phonebook or saving phonebook, that of auto-update of

pattern definitions, etc., it is displayed as information on stand-by display. And, reception of mail or

MessageR/F, record of missed call, recorded message and voice message in Voice Mail service center

are notified as newly arrived information on the stand-by display.

: By pressing

, the following notifications appear

depending on the displayed icon.

/ / : Location request of GPS success/failure/end as unanswered

→

p.355

･

In All lock, Omakase Lock or Lock on close, if you press

, a message

indicating that the function is unavailable appears. Press

to return

to the stand-by display.

: Overwriting prediction icon

→

p.551

: Updating prediction icon

→

p.553

/ : A notification of auto-update of pattern definitions

→

p.558

: Updating Data Security Service failure

→

p.152

: i-

ppli auto-start failed

→

p.325

: Failed auto-send mail exists

→

p.180

: A notification of saving phonebook

→

p.117

: Auto-save of images failed

→

p.127

: Press

to display i-Channel list

→

p.347

: Press

to display a folder list of received mails

→

p.198

: Press

to display received calls screen

: Press

to display received calls screen and then press

to play recorded

messages

→

p.215

/ : Press

to display a list of MessageR or MessageF

: Press

for 1 second or more to display a confirmation screen asking for playing

recorded messages

→

p.462

･

Press

for 1 second or more : Clear the display of arrival information.

･

When FOMA terminal is folded, arrival information appears on the sub-display.

L03.fm Page 29 Thursday, May 27, 2010 3:44 PM

F-09B_EN_ninshou

Before Using the Handset

Displaying guide line

Operations that can be performed by pressing

are displayed on the guide line (the

displayed operations differ by the screen). Display locations and buttons correspond as shown in the

figure.

In this manual, the explanation of operations displayed on the guide line

is explained by corresponding buttons (

･

on the guide line corresponds with

udlr

of multi-

cursor button (cross button).

･

When "

ガイド

(Guide)" is displayed on the guide line, press

display the guide screen that explains the details of the function. Press

to end the guide screen.

INFORMATION

･

On the screen of i-

ppli, even if the operations corresponding to

gudlr

are not displayed on the

guide line, these buttons may be available.

Sub-display overview

Even when FOMA terminal is folded, set functions or various information can be checked

Icons displayed on sub-display

On sub-display, following icons appear to indicate the status.

: Display of remaining battery level

→

p.51

/ : Display of signal level

→

p.53

: Self mode ON

→

p.143

: Unavailable UIM inserted

: In Data transfer/Using DOCOMO keitai datalink

→

p.383, p.396, p.487

: In i-mode communication, accessing

→

p.242

/ : One-touch buzzer ON/OFF status

→

p.435, p.438

: Silent mode ON

→

p.126

: Voice reading available/Voice reading ON

→

p.164

: Failed auto-send mail or failed auto-send mail of pedometer/activity monitor exists

→

p.407

: Positioning with GPS

: In Public mode (Drive mode)

→

p.83

Guide line

a bc fghde

L03.fm Page 30 Monday, May 31, 2010 2:29 PM

Fujitsu F09B Mobile Phone User Manual L01

Fujitsu Limited Mobile Phone L01

Contents

user manual1

Navigation menu

Namespaces

Views

Navigation
