FTR-K1 SERIES
n FEATURES
l DPST/DPDT 8A
l Low prole power relay (height 16.5 mm) employing
unique construction
l High insulation by employing reinforced insulation
construction
Insulation distance: 8 mm (between coil and contact)
Dielectric strength: 5 kV (between coil and contact)
Surge strength: 10 kV (between coil and contact)
l Pin conguration compatible to VB
l UL, CSA, VDE, SEMKO, CQC recognized
l Flux proof sealing, RTII
l RoHS Compliant
Please see page 6 for more information
Actual marking does not carry the type name : "FTR"
E.g.: Ordering code: FTR-F1AL005R Actual marking: F1AL005R
POWER RELAY
2 POLES - 8A Low Prole Type
FTR-F1 R Series
(a) Relay type FTR-F1 : FTR-F1 Series
(b) Contact conguration A : 2 form A (SPST-NO)
C: : 2 form C (DPDT)
(c) Coil type L : High sensitive type (400mW)
(d) Coil rated voltage 005 : 3....48VDC
Coil rating table at page 3
(e) Contact rating R : 8A
(f) Special type RG : Transparent cover type
n PARTNUMBER INFORMATION
FTR-F1 A L 005 R - RG
[Example] (a) (b) (c) (d) (e) (f)
Note: Image of standard FTR-F1 relay
2
FTR-K1 SERIES
n SPECIFICATION
Item Standard type
F1 (A, C) L ( ) R
Transparent cover
F1 (A, C) L ( ) R - RG
Contact
Data
Conguration 2 form A (DPST-NO), 2 form C (DPDT)
Construction Single
Material Movable: gold plate silver tin oxide; Stationary: Silver tin
oxide
Resistance (initial) Max. 100mOhm at 1A, 6VDC
Contact rating 8A, 250VAC / 24VDC
Max. carrying current *18A
Max. switching voltage 400VAC/ 300VDC
Max. switching power 2,000VA, 192W
Min. switching load *210mA, 5VDC
Life Mechanical Min. 20x 106 operations
Electrical AC load Min. 50 x 103 operations
DC load Min. 50 x 103 operations
Coil Data Rated Power (at 20 ° C) 400mW
Operate Power (at 20 ° C) 225mW
Operating temperature range -40 to +75 °C (no frost) -40 to +70 °C (no frost)
Timing Data Operate (at nominal voltage) Max. 15ms (no diode, without bounce)
Release (at nominal voltage) Max. 5ms (no diode, without bounce)
Insulation Resistance (Initial) Min. 1,000MOhm at 500VDC
Dielectric strength
Open contacts 1,000VAC (50/60Hz) 1min.
Coil and contacts 5,000VAC (50/60Hz) 1min.
Adjacent contacts 3,000VAC (50/60Hz) 1 min.
Surge strength Coil and contacts 10.000V/ 1.2 x 50µs standard wave
Clearance 8 mm
Creepage 8 mm
EN61810-1, VDE0435 Voltage 250V
Pollution degree 3
Material group IIIa
Category C / 250V (reference voltage) (VDE0110b)
Other Vibration Resistance Misoperation 10 to 55Hz double amplitude 1.65mm
Endurance 10 to 55Hz double amplitude 3.3mm
Shock Misoperation Min. 100 m/s² (11 ± 1ms)
Endurance Min. 1,000 m/s² (6 ± 1ms)
Weight Approximately 13 g
Sealing Flux proof, RTII
FTR-F1 SERIES
*1 At carry currents > 10A PCB layout need to be considered.
*2 Minimum switching loads mentioned above are reference values. Please perform the conrmation test with actual
load before production since reference values may vary according to switching frequencies, environmental contions
and expected reliability levels.
3
FTR-K1 SERIES
n COIL RATING
Coil
Code
Rated Coil
Voltage
(VDC)
Coil Resistance
+/- 10% (Ohm)
Must Operate
Voltage
(VDC) *
Must Release
Voltage
(VDC) *
Max. Coil Voltage
(VDC)
Rated Power
(mW)
003 3 22.5 2.25 0.3 6
400
005 5 62 3.75 0.5 10
006 6 90 4.5 0.6 12
009 9 202 6.75 0.9 18
012 12 360 9 1.2 24
024 24 1,440 18 2.4 48
048 48 5,760 36 4.8 96
FTR-F1 SERIES
400mW type
Note: All values in the table are valid for 20°C and zero contact current.
* Specied operate values are valid for pulse wave voltage.
Type Compliance Contact rating
UL UL 508
E63614
Flammability: UL 94-V0 (plastics)
8A, 24VDC (resistive)
8A, 250 VAC (resistive)
1/6 HP, 125VAC
1/4 HP, 250VAC
Pilot duty: C300, R300
CSA C22.2 No. 14
LR 40304
VDE 0435, 0631, 0700, 0860
40013858
8A, 250 VAC (cosφ=1)
8 A 24VDC (0ms)
n SAFETY STANDARDS
Complies with BSI, IMC, CQC
4
FTR-K1 SERIES
FTR-F1 SERIES
n CHARACTERISTIC DATA
FTR-F1 SERIES
8A Rating type
5
FTR-K1 SERIES
FTR-F1 SERIES
n DIMENSIONS
l Dimensions l Schematics
(BOTTOM VIEW)
l PC board mounting
hole layout
(BOTTOM VIEW)
FTR-F1C type
Unit: mm
FTR-F1A type
6
FTR-K1 SERIES
1. General Information
l All signal and power relays produced by Fujitsu Components are compliant with RoHS directive 2002/95EC
including amendments.
l Cadmium as used in electrical contacts is exempted from the RoHS directives on October 21st, 2005.
(Amendment to Directive 2002/95/EC)
l All of our signal and power relays are lead-free. Please refer to Lead-Free Status Info for older date codes
at: http://www.fujitsu.com/us/downloads/MICRO/fcai/relays/lead-free-letter.pdf
l Lead free solder plating on relay terminals is Sn-3.0Ag-0.5Cu, unless otherwise specied.
This material has been veried to be compatible with PbSn assembly process.
2. Recommended Lead Free Solder Prole
l Recommended solder Sn-3.0Ag-0.5Cu.
RoHS Compliance and Lead Free Information
3. Moisture Sensitivity
l Moisture Sensitivity Level standard is not applicable to electromechanical relays, unless otherwise indicated.
4. Tin Whiskers
l Dipped SnAgCu solder is known as presenting a low risk to tin whisker development. No considerable length
whisker was found by our in house test.
We highly recommend that you conrm your actual solder conditions
Flow Solder condition:
Pre-heating: maximum 120˚C
Soldering: dip within 5 sec. at
260˚C solder bath
Solder by Soldering Iron:
Soldering Iron
Temperature: maximum 360˚C
Duration: maximum 3 sec.
FTR-F1 SERIES
7
FTR-K1 SERIES
