Frequency And Channel Usage
ii
TABLE OF CONTENTS
FOREWORD...........................................iii
SYSTEM CONFIGURATION...................v
PROGRAM NUMBER ............................vi
SYSTEM OVERVIEW............................vii
SPECIFICATIONS.............................SP-1
1 OPERATION ........................................1
1.1 Description of Controls ..........................1
1.2 Turning On and Off ................................2
1.3 Adjusting Display Brilliance and
Contrast ..................................................3
1.4 Menu Overview......................................4
1.4.1 Menu operating procedure .........4
1.4.2 Remarks on menu operation ......5
1.5 Setting Up for a Voyage.........................7
1.6 Setting CPA/TCPA .................................10
1.7 Plotter Display......................................11
1.8 Target Data Display .............................12
1.8.1 Normal target data....................12
1.8.2 Finding dangerous ship’s data..14
1.9 Own Ship’s Information........................15
1.9.1 Own static data.........................15
1.9.2 Own dynamic data....................17
1.10 Messages.............................................18
1.10.1 Sending a message..................18
1.10.2 Receiving messages ................20
1.10.3 Message logs ...........................21
1.11 Regional Operating Channels .............22
1.11.1 Viewing channels, Tx power.....22
1.11.2 Displaying, editing regional
operating area status ................23
1.12 Enabling/Disabling the Buzzer.............25
1.13 Long Range Mode ...............................26
2 MAINTENANCE,
TROUBLESHOOTING.......................27
2.1 Maintenance........................................ 27
2.2 Resetting the Breaker ......................... 28
2.3 Replacement of Battery....................... 28
2.4 Troubleshooting................................... 29
2.5 Diagnostics.......................................... 30
2.5.1 Displaying program number..... 30
2.5.2 Memory test ............................. 31
2.5.3 Keyboard test........................... 31
2.5.4 LCD test ................................... 32
2.5.5 On/off history............................ 32
2.5.6 GPS test................................... 33
2.6 Alarm Status........................................ 34
2.7 Error Messages................................... 35
2.8 GPS Monitor........................................ 36
2.9 Displaying Sensor Status .................... 37
2.10 Restoring Default Settings .................. 38
APPENDIX........................................ AP-1
Menu Tree ............................................... AP-1
Parts List.................................................. AP-3
Parts Location.......................................... AP-4
Digital Interface (IEC 61162-2) ................ AP-7
VHF Frequency List............................... AP-26
INDEX.................................................IN-1
Declaration of Conformity
APPENDIX
AP-26
VHF channel list
Ch No. Frequenc
y
Ch No. Frequenc
y
Ch No. Frequenc
y
Ch No. Frequenc
y
1001 156.05 1201 156.0625 2001 160.65 2201 160.6625
1002 156.1 1202 156.1125 2002 160.7 2202 160.7125
1003 156.15 1203 156.1625 2003 160.75 2203 160.7625
1004 156.2 1204 156.2125 2004 160.8 2204 160.8125
1005 156.25 1205 156.2625 2005 160.85 2205 160.8625
6 156.3 1206 156.3125 6 156.3 2206 160.9125
1007 156.35 1207 156.3625 2007 160.95 2207 160.9625
208 156.4125 8 156.4
209 156.4625 9 156.45
210 156.5125 10 156.5
211 156.5625 11 156.55
212 156.6125 12 156.6
213 156.6625 13 156.65
214 156.7125 14 156.7
215 156.7625 15 156.75
216 156.8125 16 156.8
217 156.8625 17 156.85
1018 156.9 1218 156.9125 2018 161.5 2218 161.5125
1019 156.95 1219 156.9625 2019 161.55 2219 161.5625
1020 157 1220 157.0125 2020 161.6 2220 161.6125
1021 157.05 1221 157.0625 2021 161.65 2221 161.6625
1022 157.1 1222 157.1125 2022 161.7 2222 161.7125
1023 157.15 1223 157.1625 2023 161.75 2223 161.7625
1024 157.2 1224 157.2125 2024 161.8 2224 161.8125
1025 157.25 1225 157.2625 2025 161.85 2225 161.8625
1026 157.3 1226 157.3125 2026 161.9125 2226 161.925
1027 157.35 1227 157.3625 2027 161.9625 2227 161.975
1028 157.4 1228 157.4125 2028 162 2228 162.0125
1060 156.025 1260 156.0375 2060 160.625 2260 160.6375
1061 156.075 1261 156.0875 2061 160.675 2261 160.6875
1062 156.125 1262 156.1375 2062 160.725 2262 160.7375
1063 156.175 1263 156.1875 2063 160.775 2263 160.7875
1064 156.225 1264 156.2375 2064 160.825 2264 160.8375
1065 156.275 1265 156.2875 2065 160.875 2265 160.8875
1066 156.325 1266 156.3375 2066 160.925 2266 160.9375
67 156.375 267 156.3875
68 156.425 268 156.4375
69 156.475 269 156.4875
70 156.525 270 156.5375
71 156.575 271 156.5875
72 156.625 272 156.6375
73 156.675 273 156.6875
74 156.725 274 156.7375
75 156.775 275 156.7875
76 156.825 276 156.8375
77 156.875 277 156.8875
1078 156.925 1278 156.9375 2078 161.525 2278 161.5375
1079 156.975 2079 161.575
1080 157.025 1280 157.0375 2080 161.625 2280 161.6375
1081 157.075 1281 157.0875 2081 161.675 2281 161.6875
1082 157.125 1282 157.1375 2082 161.725 2282 161.7375
APPENDIX
A
P-27
1083 157.175 1283 157.1875 2083 161.775 2283 161.7875
1084 157.225 1284 157.2375 2084 161.825 2284 161.8375
1085 157.275 1285 157.2875 2085 161.875 2285 161.8875
1086 157.325 1286 157.3375 2086 161.925 2286 161.9375
1087 157.375 1287 157.3875 2087 161.975 2287 161.9625
1088 157.425 1288 157.4125 2088 162.025 2288 162.0125
Note: Add 1000 for one-digit, two-digit, and three-digit channel numbers.
