G Tech Technology A21G 2.4GHz Wireless Mouse User Manual A21
G.Tech Technology Ltd. 2.4GHz Wireless Mouse A21
Users Manaual
A21G
2.4G low power wireless mouse
User Guide
Wireless RF mouse
USB nano receiver
1xAAA battery
User guide
Thanks for buying Fuhlen products, please read this user guide carefully before use.
Package Contents:
Frequency band: 2402MHz ~ 2479MHz
Power supply: 1.5V
Operation current: ≤10mA(1.5V)
Resolution: 1000 DPI
Operation distance: up to 10m
The above technical data is for reference only, Fuhlen could update it without prior notification.
ON/OFF switch
On the bottom of the mouse, there is a ON/OFF switch.
When you are traveling or on a plane or stop using it for a
long time, please switch it to OFF to save power. Switch it
to ON, you can reuse the mouse.
Battery Disposal
Don’t throw away the batteries into the fire.
After replace the batteries, put them to the right place for recycling.
Technical data
Insert one AA battery as the diagram
on the battery tray indicates.Close
the battery cover.
A
Switch the ON OFF button to ON./
Set Wireless Connection
The A21G mouse and USB receiver is pre-paired before packing.
you can use it after installing the battery.
1. Turn on the computer.
2. Plug the USB receiver into an available USB port on your computer.
3. Install the battery into the mouse. Press any key to start.
If your wireless mouse will not pair with the USB receiver,
you will need to download the Pairing Software tool to your computer from
the Fuhlen website: http://www.fuhlenstyle.com/download.jsp, and pair
the mouse and receiver according to the instruction.
Finished setting the wireless connection of the mouse, you can enjoy the wireless freedom.
Switch the ON/OFF button to
OFF and open the battery cover.
Installation
Mouse Feature
Receiver Build-in design
The mouse is with build-in design, when
you stop using the nano USB receiver,
it can be stored in the bottom of mouse.
It is more convenient for storing.
Plug the USB receiver into an
available USB port on your
computer. Press any key to start.
Federal Communications Commission (FCC) Notice:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired
operation.
FCC Notice English - 13
