GEMMY 113341 Orchestra of Lights-Lightshow Tree and Speaker User Manual
GEMMY INDUSTRIES (HK)LIMITED BVI Orchestra of Lights-Lightshow Tree and Speaker
GEMMY >
User manual
1
WARNING: READ AND UNDERSTAND ALL
INSTRUCTIONS.
Failure to follow all instructions listed below may result in electric shock, re and/or serious
personal injury.
WARNING:
ELECTRIC PRODUCT. Keep away from children. Not recommended for children
under 3 years of age. As with all electrical products, precautions should be observed during handling
and use to reduce the risk of electric shock. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied persons in order to avoid a hazard. To avoid
the risk of electrical shock, always make sure the gure is unplugged from the electrical outlet before
assembling, disassembling, or relocating.
WARNING:
This product is to be assembled by adults only.
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
When using electrical products, basic precautions should always be followed, including the following:
• This is an electrical product - not a toy! To avoid risk of fire, burns, personal injury, and electric
shock, it should not be played with or placed where small children can reach it.
• Do not use seasonal products outdoors unless marked suitable for indoor and outdoor use. When
products are used in outdoor applications, connect the product to a Ground Fault Circuit Interrupting
(GFCI) outlet. If one is not provided, contact a qualied electrician for proper installation.
• This seasonal use product is not intended for permanent installation or use.
• Do not mount or place near gas or electric heaters, replaces, candles, or other similar sources of
heat.
• Do not secure product wiring with staples or nails or place on sharp hooks or nails.
• Do not let lamps rest on the supply cord or on any wire.
• Unplug the product when leaving the house, when retiring for the night, or if left unattended.
• Do not use this product for other than its intended purpose.
• Do not hang ornaments or other objects from cord, wire, or light string.
• Do not close doors or windows on the product, or extension cords, as this may damage the wire
insulation.
• Do not cover the product with a cloth, paper, or any material not part of the product when in use.
• Do not place the product against carpeting, furniture, or any other fabric when in use.
• Read and follow all instructions that are on the product or provided with the product.
SAVE THESE INSTRUCTIONS
SAFETY INFORMATION
Orchestra of Lights-
Lightshow Tree and Speaker
2
SAFETY INFORMATION
CAUTION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
CAUTION:
compliance could void the user’s authority to operate the equipment.
NOTE:
This equipment has been t ested and f ound t o comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. T
hese limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses, and c an r adiate radio frequency energy and, if n ot i nstalled and u sed in
accordance w ith the instructions, may cause harmful interference to r adio communications.
However, there is n o guarantee that i nterference will not o ccur in a particular i nstallation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and o n, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list. If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 15-20 minutes.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
3
PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY
A Base 2
B Support Rings 8
C Controller 1
D Plastic covers 7
E Base Connector ring 2
F/G Star Topper with Light Strings 1
H Speaker stake 1
I Speaker 1
J UL-listed Adaptor
1
K Metal stakes 8
L Poles 3
PACKAGE CONTENTS
K
F I
HJ
G
AD
CE
B
L
4
1. Set bases (A) out in a clear and at area. Unfold each base (A)
to allow it to stand up.
2. Attach support rings (B) on each base (A).
3.Use controller ( C ) for the larger tree and begin attaching the
plastic covers (D) and place over base (A). Attach plastic covers
(D) for the smaller tree and place over base (A).
4. Attach base connector ring ( E ) over the top of the assembled
base.
ASSEMBLY INSTRUCTIONS
1
2
4
5
5. Assemble 2 support poles (L) for the larger tree and 1 support
pole (L) for the smaller tree.
6. Begin staking each tree into ground using the metal stakes (K).
7. Take the Star Topper marked “F” and place on the taller
support pole (L). Take the Star Topper marked “G” and place
on the shorter support pole (L).
8. Carefully drape light strings down toward the ground based
on their number order in a clockwise direction. Use the plastic
clip to secure the light strings to the arched areas along the
support ring (B), being careful to secure them in a clockwise
numbered order. Tighten each with the cinch clip until taught.
6
F
7
8
ASSEMBLY INSTRUCTIONS
5
6
ASSEMBLY INSTRUCTIONS
8
9
9. Connect the two trees together by attaching the cables.
10. Connect the UL listed adapter (J) to the main control box.
8
10
11. Connect the speaker wire to the control box.
8
12
12. Slide stake into the bottom of the speaker and insert into
ground.
8
11
7
CARE AND MAINTENANCE
• When the product is placed on a live tree, the tree should be well-maintained and fresh. Do not
place on live trees in which the needles are brown or break off easily. Keep the tree holder lled
with water.
• If the product is placed on a tree, the tree should be well-secured and stable.
• Before using and reusing, inspect the product carefully. Discard any products that have cut,
damaged or frayed wire insulation cords, cracks, lamp holders or enclosures, loose connections, or
exposed copper wire.
• When storing the product, carefully remove the product from wherever it is placed, including trees,
branches, or bushes, to avoid any undue strain or stress on the product conductors, connections
and wires.
• When not in use, store neatly in a cool, dry location protected from sunlight.
• Do not discard box as it should be used for storage.
• Return all parts to the original packaging, if possible.
• The remote control is not weatherproof. Please operate and store in a dry environment.
TROUBLESHOOTING
If you have any questions regarding the product, please call customer service at 1-877-250-9032,
9 a.m. - 5 p.m., CST, Monday-Friday.
The product is
not operating
properly.
1. The power source may
be disabled or the cord is
unplugged.
1. Check all power cords to ensure that they
are properly connected.
THESE INSTRUCTIONS ARE FOR THESE ITEM NUMBERS
1133 41
QD ID：912 74
Visit WWW.GEMMY.COM for more information.
©2018 GEMMY INDUSTRIES CORP.
117 WRANGLER DRIVE. SUITE 100
COPPELL, TX 75019 U.S.A.
1 (877) 250-9032
MADE IN CHINA / PRINTED IN CHINA
