Manual
Bluetooth music adapter
User manual
www.jabra.com
© 2006 Jabra, GN Mobile A/S (GN Netcom A/S). All rights
reserved. Jabra® is a registered trademark of GN Mobile A/S
(GN Netcom A/S). All other trademarks included herein are
the property of their respective owners. The Bluetooth®
word mark and logos are owned by the Bluetooth SIG, Inc.
and any use of such marks by GN Mobile A/S (GN Netcom
A/S) is under license.
(Design and specifications subject to change without notice)
Made in China
PART NUMBER
Phone Number: 0800 0327026
Email Address: support.uk@jabra.com
Customer Contact Details:
RELEASE YOUR JABRA
2RELEASE YOUR JABRA
3
Jabra A125s Bluetooth music adapter
1. Thank you
Thank you for purchasing the Jabra A125s Bluetooth® Music Adapter designed
for most iPods. We hope you enjoy it! You will discover a new way of enjoying
your music – wirelessly!
This instruction manual will get you started and ready to make the most of
your adapter.
When the Jabra A125s is connected to the iPod, handle your iPod and Jabra
A125s with care.
2. About your Jabra A125s
1. Light indicator (LED) and multi-function button
2. Charging socket
3. Dock connector for iPod
Fig 1
3. What your Jabra A125s can do
Your Jabra A125s is designed to work with any Jabra Bluetooth stereo headset
such as the Jabra BT620s. The adapter connects with most iPods, iPod Minis
and Nanos via iPod dock connector.
Specifications:
• Up to 10 hours of music - standby time up to 250 hours
•
Rechargeable battery with charging option from PC via USB cable, AC power
supply (not included in the pack), or car charger (not included)
• Weight 22 grams (¾ oz)
• Operating range up to 10 metres (33 feet)
• Advanced Audio (A2DP), Remote Control (AVRCP) (see glossary page 9)
• Bluetooth specification 1.2 (see glossary page 9)
1. Thank you . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2. About your Jabra A125s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. What your Jabra A125s can do . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
4. Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5. Charging your Jabra A125s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
6. Turning on your Jabra A125s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
7. Pairing with a headset or other device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
8. Using the Jabra A125s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
9. What the lights mean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
10. Troubleshooting & FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
11. Need more help? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
12. Certification and safety approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
13. Taking care of your music adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
14. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
15. Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1
3
2
4RELEASE YOUR JABRA
5
Jabra A125s Bluetooth music adapter
4. Your Jabra A125s will find and connect to the headset
•
Within 1 minute the headset LED will start to flash and the adapter will start to
flash slowly. Press play on your audio device. Sound will start to play in the headset
If the headset LED is still solid blue after 1 minute repeat sections 2 and 3.
NOTE: If you have a Jabra Bluetooth headset such as the Jabra BT620s, you can
connect your mobile phone and your ipod simultaneously.
To pair two devices, first pair and connect your headset with your mobile
phone (follow the instructions from your headset) and then pair your headset
with the Jabra A125s as instructed above.
8. Using the Jabra A125s
Start playing music
• Make sure that your headset is turned on before turning on the music
adapter. The music adapter will then connect automatically to your headset.
• Tap the button on the music adapter or use your headset play/pause button*
to play or pause the music
Other music features supported by your Jabra A125s*
Playing music from your Bluetooth stereo headset such as the Jabra BT620s
• The prominent center button on the right side of the device is the play
button. On the top there are the skip forward and skip back buttons.
To start play*
•
Tap the play button once.
To pause*
•
Tap the play button – tap again to resume playing.
Answer a call when playing music*
•
Tap
the answer/end button to pause the music and the call will be
connected. The music will resume after the call has ended (depending on the
device supporting this feature).
Skip one track forward*
•
Tap the skip forward button - continue tapping to skip several tracks forward.
Skip one track back*
•
Tap the skip back button - continue tapping to skip several tracks backward.
Fast forward*
•
Press and hold the skip forward button.
Fast rewind*
•
Press and hold the skip back button.
* Device dependent -
These features will work when the headset you are
connected to supports Bluetooth remote control (AVRCP) profile. Many
headsets like the Jabra BT620s support this feature.
Connect to the headset manually
•
Tap the button on the music adapter. (Make sure that the headset is switched on)
What’s in the pack?
• Jabra A125s Bluetooth music adapter
• USB charger for charging from any PC or laptop
• User manual
4. Getting started
The Jabra A125s is easy to operate. The multi-function button performs
different functions depending on how long you press them:
Instruction: Duration of press:
Tap Press briefly and let go
Press Approx: 1 second
Press and hold Approx: 5 seconds
5. Charging your Jabra A125s
Make sure that your Jabra A125s is fully charged for up to 6 hours before you
start using it. Only use the chargers provided in the box or Jabra approved
chargers such as the Jabra BT 620s AC charger – do not use chargers from any
other devices as this might damage your Jabra A125s.
Connect the USB charger to your Jabra A125s charging socket (see fig 1)
When the LED is solid red, your music adapter is charging. When the light turns
to green, the adapter is fully charged.
6. Turning on your Jabra A125s
• Press the multi-function button to turn on your Jabra A125s – when the
adapter is on the LED will flash
• Press and hold the button to turn the device off.
7. Pairing with a headset or other device
Before you use your Jabra A125s you must pair it with a Bluetooth
headset or headphone
• Make sure the headset and Jabra A125s are turned off
1. Put the headset into pairing mode:
Refer to your headset’s manual for pairing mode instructions, if you are pairing
with the Jabra BT620s:
• Press and hold the answer/end button until the LED is solid blue.
2. Put your Jabra A125s in pairing mode
• Press and hold the multi-function button until the LED light is solid blue
3. Connect your Jabra A125s to your iPod via the dock connector
6RELEASE YOUR JABRA
7
Jabra A125s Bluetooth music adapter
uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The user must place the base 8” (20cm) or more from any personnel in order to
comply with FCC RF exposure requirements.
CE
This product is CE marked according to the provisions of the R & TTE Directive
(99/5/EC).
Hereby, GN Netcom, declares that this product is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
For further information please consult http://www.jabra.com
Within the EU this device is intended to be used in Austria, Belgium, Cyprus,
Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary,
Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Poland, Portugal, Slovakia,
Slovenia, Spain, Sweden, The Netherlands, United Kingdom, and within EFTA in
Iceland, Norway and Switzerland
Bluetooth
The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and
any use of such marks by GN Netcom is under license. Other trademarks and
trade names are those of their respective owners.
13. Taking care of your music adapter
• Always store the Jabra A125s with the power off and safely protected.
• Avoid storage at extreme temperatures (above 45°C/113°F – including direct
sunlight – or below -10°C/14°F). This can shorten battery life and may affect
operation. High temperatures may also degrade performance.
• Do not expose the Jabra A125s to rain or other liquids.
9. What the lights mean
What you see Status
Solid red Charging
Flashing red Low battery
Solid green Fully charged
Solid blue Pairing mode
Soft flashing blue (every 3 sec) Streaming connection is established
Flashing rapidly blue Searching for devices
10. Troubleshooting and FAQ
Please see the headset’s manual for further information regarding the
headset.
I hear crackling noises
Bluetooth is a radio technology which means it is sensitive to objects
between the headset and the device it is connected to. You should be able to
have 10 metres (33 feet) of distance between the headset and the connected
device when there are no major objects in the way (Walls etc.)
I cannot hear anything in the headset
Increase the volume in the headset and on the music player. Ensure that the
headset is paired to a device that is playing. Make sure that music is playing
on the audio device.
I have pairing problems
Ensure that both devices are fully charged and repeat all mentioned steps
under pairing.
11. Need more help?
Jabra offers customer support online at www.jabra.com or you can see the
inside cover for the support details for your country.
12. Certification and safety approvals
FCC
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Users are not
permitted to make changes or modify the device in any way. Changes or
modifications not expressly approved by Jabra will void the user’s authority
to operate the equipment. This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates,
x
8RELEASE YOUR JABRA
9
Jabra A125s Bluetooth music adapter
14. Warranty
Jabra (GN Netcom) warrants this product against all defects in material and
workmanship for a period of two years from the date of original purchase. The
conditions of this warranty and our responsibilities under this warranty are as
follows:
• The warranty is limited to the original purchaser
• A copy of your receipt or other proof of purchase is required.
• The warranty is void if the serial number, date code label or product label
is removed, or if the product has been subject to physical abuse, improper
installation, modification, or repair by unauthorized third parties
• The responsibility of Jabra (GN Netcom) products shall be limited to the
repair or replacement of the product at its sole discretion
• Any implied warranty on Jabra (GN Netcom) products is limited to two years
from the date of purchase on all parts, including any cords and connectors
•
Specifically exempt from any warranty are limited-life consumable
components subject to normal wear and tear, such as microphone
windscreens, ear cushions, decorative finishes, batteries, and other accessories
• Jabra (GN Netcom) is not liable for any incidental or consequential damages
arising from the use or misuse of any Jabra (GN Netcom) product
• This warranty gives you specific rights and you may have other rights which
vary from area to area
• Unless otherwise instructed in the User Manual, the user may not, under
any circumstances, attempt to perform service, adjustments or repairs on
this unit, whether in or out of warranty. It must be returned to the purchase
point, factory or authorized service agency for all such work
• Jabra (GN Netcom) will not assume any responsibility for any loss or damage
incurred in shipping. Any repair work on Jabra (GN Netcom) products by
unauthorized third parties voids any warranty
WARNING: Improper connection, modifications, alterations, unauthorized
repairs, dropping, hitting and other misuse or abuse of the product could
damage the product and your iPod. Jabra shall have no liability for such damage.
15. Glossary
Bluetooth is a radio technology that connects devices, such as mobile phones
and headsets, without wires or cords over a short distance (approx. 10 metres).
Get more information at www.bluetooth.com
Bluetooth profiles are the different ways that Bluetooth devices communicate
with other devices. Bluetooth phones support either the headset profile,the
hands-free profile or both. In order to support a certain profile, a phone
manufacturer must implement certain mandatory features within the phone’s
software. Dispose of the product
according to local
standards and regulations.
www.jabra.com/weee
Pairing creates a unique and encrypted link between two Bluetooth devices
and lets them communicate with each other. Bluetooth devices will not work if
the devices have not been paired.
Standby mode is when the Jabra A125s is on but not connected to a headset.
A2DP (Advanced Audio Distribution Profile) is a Bluetooth Profile that
enables stereo sound. Both the adapter and the device it connects to must
support A2DP in order to hear A2DP sound in the headset.
AVRCP (Audio Video Remote Control Profile) is a Bluetooth profile that
enables remote control of the device that the headset is connected to. Both
the headset and the device it connects to must support AVRCP in order for
AVRCP to work.
