1
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
english
THANK YOU...................................................2
ABOUT YOUR JABRA BT8040 ..................................2
WHAT YOUR HEADSET CAN DO ...............................3
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
WEAR IT HOW YOU LIKE IT ....................................6
HOW TO ......................................................6
WHAT THE LIGHTS MEAN .....................................8
LISTENING TO MUSIC USING JABRA BT8040 . . . . . . . . . . . . . . . . . . . 9
USING JABRA BT8040 WITH 2 MOBILE PHONES. . . . . . . . . . . . . . . . 9
USING A JABRA BLUETOOTH HUB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
TROUBLESHOOTING & FAQ...................................10
NEED MORE HELP?...........................................12
TAKING CARE OF YOUR HEADSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
WARNING! ...................................................12
WARRANTY ..................................................13
CERTIFICATION AND SAFETY APPROVALS . . . . . . . . . . . . . . . . . . . . 15
GLOSSARY ...................................................17
2
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
Thank you
Thank you for purchasing the Jabra BT8040 Bluetooth® headset.
We hope you enjoy using it! This instruction manual will get you
up and running to make the most of your headset.
abouT your Jabra bT8040
1
Volume up, volume down
2
Charging socket
3
Answer/end button
Press and hold to turn headset on and o
• Tap to answer or end a call
3
2
1
3
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
WhaT your headseT can do
Your Jabra BT8040 lets you perform all of this:
• Answer calls
• End calls
• Reject calls*
• Voice dialing*
• Last number redialing*
• Call waiting*
• Put call on hold*
• Mute
• Multi-point - connected to two Bluetooth devices at the same
time
• Play music*
Specications
• Talk time up to 6 hours/standby time up to 200 hours
• Rechargeable battery with a charging option from an AC power
supply, a PC via USB cable, or a car charger (not included)
• Multi-colored light for status and battery indicator
• Quiet mode – turns light o after 1 minute
• Size: L 39 mm x W 18mm x D 12 mm
• (Weight) 10 grams
Digital sound enhancement via DSP technology
• Noise reduction for transmitting and receiving audio
• Noise dependent volume control*
• Automatic volume adjustment for receiving audio
• Acoustic shock protection
• Qualied for Bluetooth Specication version 2.0 + EDR (en-
hanced data rate), supporting Headset and Hands-free Proles
for phone conversations and Advanced Audio Distribution
Prole (A2DP) for streaming music
• e-SCO for enhanced audio quality
• 128 bit encryption
• Operating range up to 10 meters (approx. 33 feet)
* Phone dependent
4
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
geTTing sTarTed
The Jabra BT8040 is easy to operate. The answer/end button on
the headset performs various functions depending on how long
you press the button down.
Instruction Duration of press
Tap Press briefly
Double tap 2 quickly repeated taps
Press Approx: 1 seconds
Press and hold Approx: More than 3 seconds
1. Charge your headset
Ensure that your Jabra BT8040 headset is fully charged before you
start using it. Use the AC adaptor to charge the headset from a
power socket, or charge directly from your PC with the USB cable
that was provided. Your headset indicates the charging level while
charging:
What you see Charge level
Solid red Less than 70%
Solid yellow Between 70% and fully charged
Solid green Fully charged
Please note: The lifetime of the battery will be signicantly
reduced if your device is left uncharged for an extended period.
We therefore recommend that you recharge your device at least
once a month.
Turning your headset on and o
• Press and hold the answer/end button to turn on your headset.
The LED will show the battery level status to indicate that the
Jabra BT8040 is on.
• Press and hold the answer/end button until you see a burst of
red ashes in order to turn your headset o.
5
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
Pair it with your phone
Before you use your Jabra BT8040, you will need to pair it with
your mobile phone.
1. Your headset will automatically go into pairing mode when you
turn it on the rst time.
2. Set your Bluetooth phone to ‘discover’ the Jabra BT8040.
Follow your phone’s instructions. This usually involves going to a
‘setup’, ‘connect’, or ‘Bluetooth’ menu on your phone and selecting
the option to ‘discover’ or ‘add’ a Bluetooth device.*
BT8040
JABRA BT8040
JABRA BT8040
3. Your phone will nd the Jabra BT8040.
Your phone then asks you if you want to pair with it. Accept
this by pressing ‘Yes’ or ‘OK’ on the phone and conrm with the
passkey or PIN = 0000 (4 zeros). Your phone will conrm when the
pairing is complete.
In the case of an unsuccessful pairing, repeat steps 1 to 3.
Manual pairing
You can manually put your Jabra BT8040 into pairing mode, if you
want to pair with a second phone or Bluetooth device:
1. Ensure that the headset is o.
2. Press and hold the answer/end button for approx. 5 sec. until
the light turns solid Blue.
3. Set your Bluetooth phone to discover your headset as
described above.
6
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
Wear iT hoW you like iT
The Jabra BT8040 is ready to be worn. The ear gels can be used
for both left and right wearing. The BT8040 comes with a medium
sized ear-gel, but it can be replaced by a small or large one. You
can also twist the ear gel slightly to optimize the t and comfort.
For optimal performance, wear the Jabra BT8040 and your mobile
phone on the same side of your body or within your line of sight.
In general, you will get better performance when there are no
obstructions between your headset and your mobile phone.
hoW To
Answer a call
• Tap the answer/end button on your headset to answer a call.
End a call
• Tap the answer/end button to end an active call.
Make a call
• When you make a call from your mobile phone, the call will
(subject to phone settings) automatically transfer to your
headset. If your phone does not have this feature, tap on the
Jabra BT8040’s answer/end button to transfer the call with the
headset.
Reject a call*
• Press the answer/end button when the phone rings to reject an
incoming call. Depending on your phone settings, the person
who called you will either be forwarded to your voice mail or
you will hear a busy signal.
Activate voice dialing*
• Press the answer/end button. For best results, record the voice-
dialing tag through your headset. Please consult your phone’s
user manual for more information about using this feature.
Redial the last number*
• Double tap the answer/end button when the headset is on and
not being used.
Adjust the sound and volume*
• Tap the volume up or down to adjust the volume.
7
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
Mute on/Mute o
• To mute, press the volume up and down at the same time. A
low beep alert plays during a muted call.
• To turn the mute o, tap either of the volume buttons.
Call waiting and placing a call on hold*
This allows you to put a call on hold during a conversation and
answer an incoming call.
• Press the answer/end button once to put the active call on hold
and then answer the incoming call.
• Press the answer/end button to switch between the two calls.
• Tap the answer/end button to end the active conversation.
Battery Indicator
When the Jabra BT8040 is turned on or a button is pressed more
than 1 minute after the last button was pressed, the LED indicates
the battery level of the headset.
What you see Battery level/Talk time
2 Green ashes 1-5 hours talk time
2 Yellow ashes 10 min.-1 hour
2 Red ash 10 min.
* Phone dependent
8
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
WhaT The lighTs mean
Series of ashes See battery indicator
Flashing blue and green light Incoming call
Flashing blue light Flashing every three seconds:
In Standby mode and con-
nected to mobile phone
(only for 1 minute then o)
Flashing green light Flashing every three seconds:
In standby mode – not con-
nected
(only for 1 minute then o)
Flashing blue light Flashing every second:
active call
(only for 30 seconds then o)
Flashing red light Running low on battery
Flashing purple light Flashing every seconds: Con-
nected in A2DP streaming
music
(only for 30 seconds then o)
Solid blue light In pairing mode
Solid purple light Special music pairing mode
See chapter Troubleshooting
& FAQ - Frequently Asked
Questions
Solid green light Fully charged
Solid yellow light Charging level between 70%
and fully charged
Solid red light Charging level less than 70%
9
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
lisTening To music using Jabra bT8040
Jabra BT8040 is capable of streaming music over Bluetooth -
either from a mobile phone or any other Bluetooth device
supporting A2DP. Once you have paired your BT8040 with your
mobile phone or to the Bluetooth music player, use your phone or
music player to play, pause, stop, skip forward, or backward. When
you receive a call, the music will be automatically suspended and
you will be able to answer or reject a call through the headset.
Once you end a call, the music should restart. On some phones
and music devices you may have to press ‘play’ to restart the
music.
using Jabra bT8040 WiTh 2 mobile phones
Jabra BT8040 is capable of having two mobile phones (or Blue-
tooth devices) connected to the headset at the same time. This
will give you the freedom of having only one headset to operate
both of your mobile phones. Please note that Last Number Redial
will dial the number from the last outgoing call, independent of
the mobile phones, and the Voice Dialing function will only work
on the last paired mobile phone.
using a Jabra blueTooTh hub
The Jabra BT8040 can be used along with the Jabra Bluetooth Hub
(sold separately). This will enable you to use the headset with your
mobile and oce phones.
To pair the Jabra BT8040 with the Jabra Bluetooth Hub
The pairing process is a little dierent:
1. Put your Jabra BT8040 in pairing mode.
2. Put the Jabra Bluetooth Hub in pairing mode.
3. Place them close together. You do not need a dedicated
pin code to pair the two Jabra products. Consult the Jabra
Bluetooth Hub user manual for more information on how to
connect the Bluetooth hub to your oce phone.
The use of the Jabra BT8040 with the Jabra Bluetooth Hub is very
similar to using the headset with a mobile phone only. The only
dierence is in the transfer of a call to the headset from the oce
phone.
10
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
Transfer the call to the headset
• Tap the answer/end button to transfer the call from the oce
phone to the headset via the Jabra Bluetooth Hub
The answering of a call from the oce phone requires a hook lifter
in order to have the Jabra BT8040 answer the call automatically.
TroubleshooTing & FaQ
I hear crackling noises
• Bluetooth is a radio technology, which means it is sensitive to
objects between the headset and the connected device. It is
designed for the headset and the connected device to be used
within 33 feet (10 meters) of each other, with no major objects
in the way (walls, etc.).
I cannot hear anything in my headset
• Increase the volume in the headset
• Ensure that the headset is paired to a device that is playing
• Make sure your phone is connected to the headset by tapping
the Answer/End button.
I am having pairing problems
• You may have deleted your headset pairing connection in your
mobile phone.
Follow the pairing instructions.
I want to reset the headset
It is possible to reset and test the headset by ’Pressing and hold-
ing’ all three buttons at the same time. The red, blue, and green
lights will light up in a white light. In this mode, the pairing list is
reset, and you can test if the headset works, as you will be able to
hear audio in the speaker from the microphone.
The headset will automatically turn o after approx. 10 seconds.
The next time you power on, the headset will go into pairing
mode just like the rst time you powered on your new BT8040.
Will the Jabra BT8040 work with other Bluetooth equipment?
• The Jabra BT8040 is designed to work with Bluetooth mobile
phones. It can also work with other Bluetooth devices that are
compliant with Bluetooth version 1.1 or higher and that sup-
port a headset, hands-free, and/or advance audio distribution
prole.
11
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
I cannot use reject call, call on hold, redial, or voice dialing
These features are dependent on the ability of your phone to sup-
port a hands-free prole. Even if the hands-free prole is imple-
mented, the reject call, call hold, or voice dialing are all optional
features that are not supported by all devices. Please consult your
device manual for further details.
Please note that some features can only be operated from the
primary device e.g. voice dial using Jabra BT8040 with 2 mobile
phones.
The device does not connect to my headset in time to answer
an incoming call
If the headset is o and is turned on when a call is incoming, the
device and headset might not connect in time for the call to be
answered. In order to avoid such inconveniences please keep the
headset on, in range, and connected.
The music player starts playing when connecting to the
headset
Some phones may stat the music player once it connects to the
headset. Pair your headset again to the device in order to avoid
this behavior.
1. Ensure that the headset is o
2. Press and hold the answer/end button for approx. 5 sec. until
the light turns to solid blue
3. Continue to press and hold the answer/end button until the
solid blue light turns o
4. Continue to press and hold until a solid purple light turns on
Go through the regular steps in oairing the headset to a Bluetooth
device.
The music stream from my connected device is choppy or the
music pitch is changing
If you have connected two devices and move out of range of
one device while playing music from the connected device, the
headset will try to reconnect to the lost device. This can cause
the audio stream to be disrupted. For example, the music audio is
choppy or the audio pitch varies. In order to prevent this, do not
go out of range of your paired/connected devices.
12
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
need more help?
1. Web: www.jabra.com
(for the latest support info and online user manuals)
2. E-mail: Tech Support: techsupp@jabra.com
Information: info@jabra.com
3. Phone: 1 (800) 327-2230 (toll-free in USA)
(603) 579-5311 (Canada)
Taking care oF your headseT
• Always store the Jabra BT8030 with the power o and safely
protected.
• Avoid storage at extreme temperatures (above 45°C/113°F
– including direct sunlight – or below -10°C/14°F). This can
shorten the battery life and may aect its operation. High
temperatures may also degrade performance.
• Do not expose the Jabra BT8030 to rain or other liquids.
Warning!
Headsets are capable of delivering sounds at loud volumes and
high pitched tones. Exposure to such sounds can result in perma-
nent hearing loss. The volume level may vary based on conditions,
such as the phone that you are using, its reception and volume
settings, and the surrounding environment. Please read the safety
guidelines below befor using this headset.
Safety guidelines
1. Prior to using this product follow these steps
• before putting on the headset, turn the volume control to its
lowest level,
• put the headset on, and then
• slowly adjust the volume control to a comfortable level.
2. During the use of this product
• Keep the volume at the lowest level possible and avoid using
the headset in noisy environments where you may be inclined
to turn the volume up;
• If increasing the volume is necessary, adjust the volume control
slowly;
13
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
And
• If you experience discomfort or ringing in your ears, immedi-
ately discontinue using the headset and consult a physician.
With continued use at high volume, your ears may become accus-
tomed to the sound level, which may result in permanent damage
to your hearing without any noticeable discomfort.
Using the headset while operating a motor vehicle, motorcycle,
watercraft or bicycle may be dangerous, and is illegal in some
jurisdictions. Check your local laws. Use caution when using your
headset while engaging in any activity that requires your full at-
tention. While engaging in any such activity, remove the headset
from your ear area or turn your headset o in order to keep you
from being distracted so as to avoid an accident or injury.
3. Keep out of reach of children
The plastic bags that the product and its parts are wrapped in are
not toys for children. The bags themselves or the many small parts
that they contain may cause choking if ingested. Never try to take
the product apart yourself. None of the internal components can
be replaced or repaired by users.
Only authorized dealers or service centers are permitted to open
the product. If any parts of your product require replacement for
any reason, including normal wear and tear or breakage, contact
your dealer.
Avoid exposing the product to rain or other liquids.
4. ACA TS028 – Ignition of ammable substances
Do not use the Headset in environments where danger of ignition
of ammable gases is present.
WarranTy
Service and Warranty Information
Limited One (1) -Year Warranty GN US Inc., warrants this product
to be free from defects in materials and workmanship (subject to
the terms set forth below) for a period of one (1) year from the
date of purchase (“Warrenty Period”). During the Warranty Period,
GN will repair or replace (at GN’s discretion) this product or any
defective parts (“Warrenty Service”). If repair or replacement is
not commercially practicable or cannot be timely made, GN may
choose to refund to you the purchase price paid for the aected
product. Repair or replacement under the terms of this warranty
14
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
does not give right to any extension or a new beginning of the
period of warranty.
Claims under the Warranty
To obtain Warranty Service, please contact the GN dealer from
which you purchased this product or visit www.jabra.com for
further information about customer support.You will need to
return this Product to the dealer or ship it to the dealer or to GN (if
so indicated on www.jabra.com) in either its original packaging or
packaging aording an equal degree of protection.You will bear
the cost of shipping the product to GN. If the Product is covered
by the warranty, GN will bear the cost of shipping product back
to you after the completion of service under this warranty. Return
shipping will be charged to you for products not covered by the
warranty or requiring no warranty repair.
The Following information must be presented to obtain Warranty
Service: (a) the product, and (b) proof of purchase, which clearly
indicates the name and address of the seller, the date of purchase
and the product type, which is evidence that this product is
within the Warranty Period. Please further include (c) your return
address. (d) daytime telephone number, and (e) reason for return.
As part of GN/Jabra’s eorts to reduce environmental waste you
understand that the product may consist of reconditioned equip-
ment that contains used components, some of which have been
reworked. The used components all live up to GN/Jabra’s high
quality standards and comply with the GN product performance
and reliability specications. You understand that replaced parts
or components will become the property of GN.
Limitation of Warranty
This warranty is only valid for the original purchaser and will au-
tomatically terminate prior to expiration if this product is sold or
otherwise transferred to another party. The warranty provided by
GN in this statement applies only to products purchased for use,
and not for resale. It does not apply to open box purchases, which
are sold “as is” and without any warranty. Specically exempt from
warranty are limited-life consumable components subject to nor-
mal wear and tear, such as microphone windscreens, ear cushions,
modular plugs, ear tips, decorative nishes, batteries, and other
accessories. This warranty is invalid if the factory-applied serial
number, date code label, or product label has been altered or
removed from this product. This Warranty does not cover cosmetic
damage or damage due to misuse, abuse, negligence, Acts of
Nature, accident, disassembling or modication of, or to any part
15
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
of, the product. This Warranty does not cover damage due to im-
proper operation, maintenance or installation, or attempted repair
by anyone other than GN or a GN dealer which is authorized to do
GN warranty work. Any unauthorized repairs will void this
REPAIRS OR REPLACEMENTS AS PROVIDED UNDER THIS WAR-
RANTY ARE THE EXCLUSIVE REMEDY OF THE CONSUMER. GN
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY
ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY
LAW, THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER
EXPRESS AND IMPLIED WARRANTIES WHATSOEVER, INCLUDING
BUT NOT LIMITED TO THE WARRANTY OF MERCHANTABILITY AND
FITNESS FOR A PRACTICAL PURPOSE.
NOTE! This warranty gives you specic legal rights. You may
have other rights which vary from location to location. Some
jurisdictions do not allow the exclusion or limitation of incidental
or consequential damages or implied warranties, so the above
exclusions may not apply to you. This warranty does not aect
your legal (statutory) rights under your applicable national or local
laws.
cerTiFicaTion and saFeTy approvals
FCC
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Users are not permitted to make changes or modify the device
in any way. Changes or modications not expressly approved
by Jabra (GN US Inc.) will void the user’s authority to operate the
equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communi-
cations. However, there is no guarantee that interference will not
16
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
The device and its antenna must not be co-loaded or operating in
conjunction with any other antenna or transmitter.
Industry Canada
Operation is subject to the following two conditions: (1) This
device may not cause interference and (2) This device must accept
any interference, including interference that may cause undesired
operation of the device.
The term “IC:” before the certication/registration number only
signies that registration was performed based on a Declaration
of Conformity indicating that Industry Canada technical specica-
tions were met. It does not imply that Industry Canada approved
the equipment.
CE
This product is CE marked according to the provisions of the R &
TTE Directive (99/5/EC).
Hereby, GN A/S, declares that this product is in compliance with
the essential requirements and other relevant provisions of Direc-
tive 1999/5/EC.
For further information please consult http://www.jabra.com
Bluetooth
The Bluetooth® word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks by Jabra is under license. Other
trademarks and trade names are those of their respective owners.
17
english
JABRA BT8040 BLUETOOTH STEREO HEADSET
glossary
1. Bluetooth is a radio technology that connects devices, such
as mobile phones and headsets, without wires or cords over
a short distance (approx. 30 feet). Obtain more information at
www.bluetooth.com.
2. Bluetooth proles are the dierent ways that Bluetooth
devices communicate with other devices. Bluetooth phones
support either the headset prole, the hands-free prole, or
both. In order to support a certain prole, a phone manufac-
turer must implement certain mandatory features within the
phone’s software.
3. Pairing creates a unique and encrypted link between two
Bluetooth devices and lets them communicate with each other.
Bluetooth devices will not work if the devices have not been
paired.
4. A Passkey or PIN is a code that you enter on your mobile
phone to pair it with your Jabra BT8030. This makes your phone
and the Jabra BT8030 recognize each other and automatically
work together.
5. The Standby mode is when the Jabra BT8030 is passively wait-
ing for a call. When you ‘end’ a call on your mobile phone, the
headset goes into standby mode.
Dispose of the product according
to local standards and regulations.
www.jabra.com/weee
