GOLD FINGERS TECHNOLOGY BTS22C Bluetooth Speaker User Manual BTS22Instructions
GOLD FINGERS TECHNOLOGY CO.,LTD Bluetooth Speaker BTS22Instructions
User Manual
1.Notice.............................................. ..................1
2.Performance characteristics.................................2
3.Operation instruction ...........................................2
4.Technical data.....................................................5
Contents
1. Notice
Do not keep the voice of speaker on the maximum
often, or it will hurt your hearing. We suggest you to
adjust the voice to 2/3 level of the maximum, this
operation can not only let you hear the perfect sound
of music , but also can extend speaker's service life
Avoid to storage at high temperatures such as in a hot
vehicle or in direct sunlight. (Storage at high
temperatures can damage performance and reduce
battery life).
Do not expose the speaker or any of its supplied parts
to rain or other liquids.
Always store the speaker with the power off and make
sure it is safely protected.
Please use 5V 1A charger to charge with the speaker,
charging time will be about 3-4 hours
If the LED indicator can not light on when turn on the
speaker, please charge with the speaker
2. Performance characteristics
1.The speaker is a Double channel Bluetooth Speaker with
independent output
2.The speaker adopts High fidelity design, make the sound
much more natural and exquisite
3.The Bluetooth speaker has built-in Lithium battery, and can
show power volume on iPhone
3. Operation instruction
Ⅰ. Function instruction
① Previous song/VOL-(Long press)
② Play/Pause/Answer Call(Bluetooth) / line in
③ Next song/VOL+(Long press)
④ 5V charging input port
⑤ Aux-in
⑥ Power switch
Ⅲ.Operation instruction
Connect speaker to cell phone/ mobile phone with Bluetooth
function Set your cell phone to discover the speaker by
following your phone’s guide .Your phone will find the
speaker (paring name of the speaker is: BTS22 and ask if
you want to pair with it .Confirm this by pressing the “Yes” or
“OK” key . you will hear a voice “paired”, it means your
phone has been connected with the speaker.
4. Technical data
Bluetooth Speaker:V4.0
Output: 3Wx2
Range: 10m
Play time: 5~6H
Standby time:350H
Product size: 168x39x50mm
Net weight: 298g
Ⅳ.Pairing
Your speaker uses a rechargeable battery. You must
charge the battery fully before using the speaker for the
first time .
Turn on the speaker, led light will be on blue in 1 second
,5 seconds later, the speaker will enter pairing mode
automatically. The led light will flash with red and blue.
enter pairing mode .
After paring ,short press“ ” to play/pause; short press “
+/ - ” to select songs; Long press “ + / - ” to adjust sound
volume.
Hands free function:
Answering a call: short Press“ ”when you receiving an
incoming call. Short press“ ” again to end the call. long
press“VOL+/VOL-” to adjust sound volume
Or
press and hold the “ ” button for about 2 seconds to BTS22
Bluetooth Speaker
User Manual
5V 1A Powe r ada pter
Conne ct US B port of PC, tabl et
or DVD pl aye r with USB ca ble
Conne ct th e audio out put i nterface of PC , tablet,
mobil e phone, Mp3, Mp 4, et c with line-in c able
.Connection diagram
TopBack
①
②
③
④⑤
⑥
FCC Warnings
Caution: The user is cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a C lass B digital
device, pursuant to Part 15 o f the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause h armful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and o n, the user is enc ouraged to try to correct the
interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to w hich the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
IC Warnings:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any i nterference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions suivantes :
(1) l’appareil ne doit pas produire de brouillage, et
(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
IC Radiation Exposure Statement:
This equipment complies with Canada radiation exposure limits set f orth for uncontrolled
environments.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Déclaration d’IC sur l’exposition aux radiations:
Cet équipement est conforme aux limites d’exposition aux radiations définies par le Canada pour
des environnements non contrôlés.
Cet émetteur ne doit pas être installé au même endroit ni utilisé avec une autre antenne ou un autre
émetteur.
