GUARDIAN MTX01-CC Remote for Garage Door Opener User Manual B3F6B0E6CEEF32

GUARDIAN SHANGHAI CORP. Remote for Garage Door Opener B3F6B0E6CEEF32

Users Manual

Guardian Shanghai Corp. 368,MInShen Rd, Song Jiang, Shanghai, China,201612
To Program Transmitter(s):
1. Press/release the “LEARN” button on the rear control
panel, “OK” LED will glow and beep. The unit is now
ready to accept a transmitter in the next 30 seconds as
shown in Fig.2.
2. Press/release the large grey button on the Transmitter.
(Additional buttons used for multiple garage door openers)
3. The “OK” LED will flash twice indicating transmitter is
stored successfully.
Up to 20 Transmitters (including wireless keypad codes) can
be added to the unit by repeating the above procedures.
If more than 20 Transmitters are stored, the first stored
Transmitter will be replaced. (i.e. the 21st Transmitter
replaces the 1st stored Transmitter.)
Removing ALL Transmitters:
To remove ALL Transmitters from memory, press and hold
the “LEARN” button for 5 seconds. The “OK” LED will flash
and beep 2 times indicating ALL transmitters have been
removed from memory.
Replacing Transmitter Battery:
When the battery of the hand held Transmitter is low, the
indicator light will become dim and/or the range of the
Transmitter will decrease. To replace the battery, remove the
battery cover from the Transmitter as shown in Fig 3. Re-
place with a 23AE 12 volt alkaline battery with polarity shown
in Fig.3.
Fig.1
Fig.3
Signal and Bat-
tery Indicator
Visor Clip
Fig.2
LEARN
30
OK
1
2
23AE 12 Volt
OK
3
Flashes x2
This device complies FCC Rules for HOME OR OFFICE USE. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Any Changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate
equipment.
HomeLink® Compatible
This opener is compatible with HomeLink® in-vehicle systems.
Consult your vehicles owner’s manual for correct programming
instructions. NOTE: For all other in-vehicle remote systems, contact
the vehicle manufacturer for correct programming instructions.
