Gallagher Group 197800 125 Series Encoder Hardware User Manual Cardax 125 Encoder
Gallagher Group Ltd 125 Series Encoder Hardware Cardax 125 Encoder
Users Manual
Installation Note
Part number 3E0477 R2 1
March 2004
3E0477 R1
February 2004
Introduction
The Cardax 125 Encoder is used in conjunction with the Cardax Encoder III
software, for encoding and re-encoding Cardax 125 Series proximity cards.
Note:
The Cardax 125 Encoder will only operate correctly with the Cardax Encoder
III software installed.
Before you begin
Unpack the Cardax 125 Encoder and check the shipment contains the
following items:
• 1 x Cardax 125 Encoder
• 1 x Cardax 125 Encoder Installation Note (part number 3E0477)
• 1 x DB9 Female / Female cable
Power Supply Requirements
The Cardax 125 Encoder requires a supply of 13.6 V DC ± 15% with current at
200 mA per Encoder.
Cardax 125 Encoder
2 Part number 3E0477 R2
March 2004
Approvals and Standards
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Note: Changes or modifications not expressly approved by Cardax
(International) Ltd could void the user's authority to operate the
equipment.
ACN: 002132943
