Garmin 01653 Marine VHF Radio User Manual

Garmin International Inc Marine VHF Radio

Contents

Quick Start Guide

A01653
Quick Start Manual................................................................................................................... 2
Manuel de démarrage rapide....................................................................................................7
Manuale di avvio rapido.......................................................................................................... 13
Schnellstartanleitung.............................................................................................................. 18
Guía de inicio rápido............................................................................................................... 24
September 2016 Printed in China 190-02061-92_0A
A01653 Series Quick Start Manual
Introduction
WARNING
See the Important Safety and Product Information guide in the product box for
product warnings and other important information.
Device Overview
A01653
A01653
Item Key Description
ÀDISTRESS Lift the door and select to send a DSC distress call with a
programmed MMSI number.
ÁVOL/SQ Press to switch between volume or squelch.
Rotate to adjust the volume or squelch level.
ÂSelect the key that corresponds to the on-screen item to select
the item.
ÃSELECT On the home screen, rotate to change the channel.
On the home screen, press to toggle weather channels.
Rotate to highlight an item in a list.
Press to select an item.
PWR
North America:
16/9
International: 16+
Hold to turn the radio on and off.
Select to toggle between preset channels.
DSC Select to view a menu of DSC options.
HI/LO Select to change the transmission mode and power settings.
CLEAR Select to return to the previous menu option.
Select to cancel or mute an incoming DSC call.
MENU From the home screen, select to view configuration options.
From a menu, select to return to the home screen.
2 Quick Start Manual
Handset Overview
ÀPTT Hold to broadcast.
Á or Select to change the channel on the radio.
ÂNorth America: 16/9
International: 16+
Select to toggle between preset channels.
Home Screen
ÀCurrent radio system status, settings, and alerts.
ÁCurrent international, Canadian, or U.S. frequency band
Â*Current latitude
Ã*Current longitude
Ä*Current time
Å**Current speed over ground (SOG) or course over ground (COG)
ÆSoft-key functions change depending on your current activity
ÇCurrent working channel
*The current latitude, longitude, and time appear when the transceiver is
connected to a GPS device. You can enter data manually when the transceiver is
not connected to a GPS device.
** The current SOG and COG appear when the transceiver is connected to a
GPS device, and the option is enabled in the menu.
System Status Icons
Icon Status
Receiving an incoming signal
Transmitting
Transmitting at 25 W
Transmitting at 1 W
Saved channel
Local receiver mode, often used in areas with radio frequency interference (harbors)
ATIS enabled
Position tracking enabled
Auto channel changing disabled
Quick Start Manual 3
Icon Status
Incoming or missed DSC call
Weather alert
External GPS connected
Basic Operation
Turning On and Off the Device
Hold PWR.
Adjusting the Radio Volume
1Set the squelch level to MIN before you adjust the radio volume (optional).
2Turn the VOL/SQ dial to increase or decrease the radio volume.
Adjusting the Squelch Level
You can adjust the sensitivity level of the squelch to filter out background noise.
When you increase the squelch level, you hear fewer weak background signals
when you are receiving.
1Press the VOL/SQ dial.
SQUELCH appears on the screen.
2Turn the VOL/SQ dial counter-clockwise until you hear audio.
3Turn the VOL/SQ dial clockwise until there is no background noise.
Selecting the Frequency Band
You can switch between the USA, International, or Canadian frequency bands.
NOTE: Not all frequency bands are available on all device models.
1Select MENU > CHANNEL > Frequency band.
2Select a frequency band.
Selecting a Channel
You can select an international, Canadian, or USA channel (page 4).
Select an option:
To select a channel on the device, turn Channel clockwise or counter-
clockwise.
To select a channel on the handset, select or .
Transmitting with the Radio or Handset
1Select an appropriate channel.
2Ensure the channel is clear.
NOTE: You cannot obstruct the communications of other people due to
Federal Communications Commission (FCC) and international guidelines.
3Select PTT on the handset.
appears at the top of the screen.
4Speak into the handset.
NOTE: Five minutes is the maximum time allowed for transmission. After five
minutes of transmitting, PTT is disabled until you release PTT.
5Release PTT.
Setting the Receiving Sensitivity
You can control the receiving sensitivity of the device. When you have noise in
high-traffic areas or areas with electromagnetic interference, such as near cell-
phone towers, you can set the receiving sensitivity to LOC to decrease receiver
sensitivity. In remote areas and on open water, you can set the receiving
sensitivity to DIST to ensure that you use the maximum range of the receiver.
1Select HI/LO.
2Select an option:
Select LOC to enable local sensitivity.
Select DIST to enable distant sensitivity.
4 Quick Start Manual
Switching Between 1 W and 25 W Transmitting Modes
You can control the transmitting power of the radio. LO (1 W) is used for local
transmissions, and HI (25 W) is used for distance and distress transmissions.
When two signals broadcast on the same frequency, a VHF radio receives only
the stronger of the two signals. You should transmit calls other than distress calls
using the lowest power setting that allows you to communicate, to reduce the
possibility that your transmissions interfere with the transmissions of others.
In the USA frequency band, transmissions on channels 13 and 67 must be low
(1 W) by default.
1Select HI/LO.
2Select 1W or 25W.
Digital Selective Calling
Digital Selective Calling
NOTE: Before you can use DSC capabilities, you must enter a Mobile Marine
Safety Identity (MMSI) number. An MMSI number identifies each DSC radio, like
a telephone number.
Digital Selective Calling (DSC) is a key component of the Global Maritime
Distress and Safety System (GMDSS). DSC enables VHF radios to place and
receive digital calls directly with other vessels and shore stations, including the
USA and Canadian Coast Guards. Your radio includes full Class-D DSC
capabilities.
For more information about DSC on your device, including using DSC for distress
calls, see the online owner's manual (page 7).
NOTE: The device disables DSC automatically when you turn on ATIS
(page 6).
Entering Your MMSI Number
NOTICE
You can enter your MMSI number only once. If you must change your MMSI
number after entering it, you must take your radio to your Garmin® dealer for
reprogramming.
The Mobile Marine Safety Identity (MMSI) number is a nine-digit code that acts
as a DSC self-identification number, and it is required in order to use the DSC
capabilities of your device. You can obtain an MMSI number from the
telecommunications authority or ship registry for your country. In the USA, you
can obtain an MMSI number from these sources.
Federal Communications Commission (FCC): assignments are recognized
internationally
• BoatU.S.®, Sea Tow®, or United States Power Squadrons®: assignments are
for USA waters only
1Select MENU > DSC > MY MMSI.
2Turn SELECT clockwise or counter-clockwise to increase or decrease the
number.
3Press SELECT to accept the number.
4Repeat steps 2 and 3 for each number in the sequence.
5Select ACCEPT.
The device prompts you to confirm your identity.
6Enter your MMSI number again, and select ACCEPT.
If the MMSI numbers you entered do not match, a message appears.
7If necessary, select RETRY and enter the number again.
Quick Start Manual 5
Automatic Transmitter Identification System
Automatic Transmitter Identification System (ATIS) is a vessel identification
system used on certain inland waterways in some European countries. See your
Garmin dealer to program your VHF radio if you plan to use your radio on
waterways that are within the bounds of the Regional Arrangement Concerning
the Radiotelephone Service on Inland Waterways (the Basel Agreement). ATIS is
prohibited outside the European inland waterways that are covered by the Basel
Agreement.
When you enable ATIS, your radio sends a data signal identifying your station at
the end of every transmission. Data identifying your position is not sent, but your
position is calculated through the method of triangulation by coastal stations that
receive your transmissions.
To enable ATIS, you must enter your ATIS identification number (page 6), and
turn on ATIS. See your Garmin dealer to determine your ATIS identification
number and to learn about ATIS requirements for your region.
Your radio disables these functions when you enable ATIS.
Digital Selective Calling (DSC)
Dual watch and Tri watch
Channel scanning
International channels 6, 8, 10, 11, 12, 13, 14, 71, 72, 74, and 77 restrict
transmitting to low-power (1 W) when you enable ATIS.
Entering Your ATIS Identification Number
NOTICE
You can enter your ATIS identification number only once. If you must change
your ATIS identification number after entering it, you must take your radio to your
Garmin dealer for reprogramming.
1Select MENU > ATIS > MY ATIS ID.
2Turn SELECT clockwise or counter-clockwise to increase or decrease the
number.
3Press SELECT to accept the number.
4Repeat steps 2 and 3 for each number in the sequence.
5Select ACCEPT.
The device prompts you to reenter your number.
6Enter your ATIS number again, and select ACCEPT.
If the ATIS numbers you entered do not match, a message appears.
7If necessary, select RETRY and enter the number again.
Turning On and Off ATIS
1Select MENU > ATIS > ATIS.
2Select ON or OFF.
appears on the screen when ATIS is enabled.
3Select an option:
To save your changes and return to the home screen, select OK.
To return to the home screen without saving your changes, select MENU.
Appendix
Contacting Garmin Product Support
Go to www.garmin.com/support for in-country support information.
In the USA, call 913-397-8200 or 1-800-800-1020.
6 Quick Start Manual
In the UK, call 0808 238 0000.
In Europe, call +44 (0) 870 850 1241.
Cleaning the Outer Casing
NOTICE
Avoid chemical cleaners and solvents that can damage plastic components.
1Clean the outer casing of the device (not the screen) using a cloth dampened
with a mild detergent solution.
2Wipe the device dry.
Cleaning the Screen
NOTICE
Cleaners containing ammonia will harm the anti-reflective coating.
The device is coated with a special anti-reflective coating which is very sensitive
to waxes and abrasive cleaners.
1Apply an eyeglass lens cleaner specified as safe for anti-reflective coatings to
the cloth.
2Gently wipe the screen with a soft, clean, lint-free cloth.
Getting the Owner's Manual
Go to www.garmin.com/manuals/A01653.
