USERS MANUAL 2

Important Safety and product InformatIon
Refer to the applicable Pilot’s Guide and Installation Manual (available at www.garmin.com) for complete operating
and installation procedures.
The information provided in this document may not apply to all system configurations. It is the responsibility of the
Pilot to consult the appropriate Pilot’s Guide in determining applicability of the safety information to their specific
configuration.
WARNINGS, CAUTIONS, & NOTES
WARNING: Navigation and terrain separation must NOT be predicated upon the use of the terrain function.
The Terrain Proximity feature is NOT intended to be used as a primary reference for terrain avoidance and
does not relieve the pilot from the responsibility of being aware of surroundings during flight. The Terrain
Proximity feature is only to be used as an aid for terrain avoidance and is not certified for use in applications
requiring a certified terrain awareness system. Terrain data is obtained from third party sources. Garmin
is not able to independently verify the accuracy of the terrain data.
WARNING: The displayed minimum safe altitudes (MSAs) are only advisory in nature and should not
be relied upon as the sole source of obstacle and terrain avoidance information. Always refer to current
aeronautical charts for appropriate minimum clearance altitudes.
WARNING: The altitude calculated by the GPS receivers is geometric height above Mean Sea Level and
could vary significantly from the altitude displayed by pressure altimeters.
WARNING: Do not use outdated database information. Databases used must be updated regularly in order
to ensure that the information remains current. Pilots using any outdated database do so entirely at their
own risk.
WARNING: Do not use basemap (land and water data) information for primary navigation. Basemap data
is intended only to supplement other approved navigation data sources and should be considered as an
aid to enhance situational awareness.
WARNING: Do not rely solely upon the display of traffic information for collision avoidance maneuvering.
The traffic display does not provide collision avoidance resolution advisories and does not under any
circumstances or conditions relieve the pilot’s responsibility to see and avoid other aircraft.
WARNING: Do not rely solely upon the display of traffic information to accurately depict all of the traffic
within range of the aircraft. Due to lack of equipment, poor signal reception, and/or inaccurate information
from aircraft or ground stations, traffic may be present that is not represented on the display.
WARNING: Do not use data link weather information for maneuvering in, near or around areas of
hazardous weather. Information contained within data link weather products may not accurately depict
current weather conditions.
14
LIMITED WARRANTY
The Garmin LRU’s that comply with TSO (Technical Standard Order) requirements for certification (GMU 44 and GTP 59) are warranted
to be free from defects in materials or workmanship for two years from the date of purchase. The Garmin LRU’s that do not comply
with TSO requirements for certification (GDU 4XX) are warranted to be free from defects in materials or workmanship for one year from
the date of purchase. Within the specified period, Garmin will, at its sole option, repair or replace any components that fail in normal
use. Such repairs or replacement will be made at no charge to the customer for parts and labor, provided that the customer shall be
responsible for any transportation cost. This warranty does not cover failures due to abuse, misuse, accidents, or unauthorized altera-
tions or repairs.
THE WARRANTIES AND REMEDIES CONTAINED HEREIN ARE EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR
IMPLIED OR STATUTORY, INCLUDING ANY LIABILITY ARISING UNDER ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, STATUTORY OR OTHERWISE. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, WHICH MAY VARY FROM
STATE TO STATE.
IN NO EVENT SHALL GARMIN BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES, WHETHER
RESULTING FROM THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT OR FROM DEFECTS IN THE PRODUCT. Some states do not
allow the exclusion of incidental or consequential damages, so the above limitations may not apply to you.
Garmin retains the exclusive right to repair or replace the unit or software, or to offer a full refund of the purchase price, at its sole
discretion. SUCH REMEDY SHALL BE YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY BREACH OF WARRANTY.
Products sold through online auctions are not eligible for rebates or other special offers from Garmin. Online auction confirmations
are not accepted for warranty verification. To obtain warranty service, an original copy of the sales receipt from the original retailer is
required. Garmin will not replace missing components from any package purchased through an online auction.
To obtain warranty service, contact your local Garmin Authorized Service Center. For assistance in locating a Service Center, visit the
Garmin website at www.garmin.com or contact Garmin Customer Service at one of the numbers listed below.
Garmin International, Inc., 1200 East 151st Street, Olathe, Kansas 66062, U.S.A.
Toll free: 800/800.1020 Tel: 913/397.8200 Fax: 913/397.8282
Garmin AT, Inc., 2345 Turner Road SE, Salem, OR 97302, U.S.A.
Toll free: 800/525.6726 Tel: 503/391.3411 Fax: 503/364.2138
Garmin (Europe) Ltd. Liberty House, Hounsdown Business Park, Southampton, Hampshire SO40 9LR U.K.
Tel:44 (0) 23 8052 4000 Fax:44 (0) 23 8052 4004 Aviation Support:44 (0) 87 0850 1243
© Copyright 2013 Garmin Ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151st Street, Olathe, Kansas 66062, U.S.A.
Garmin (Europe) Ltd.
Liberty House, Hounsdown Business Park, Southampton, Hampshire SO40 9LR U.K.
Garmin (Asia) Corporation
No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan
www.garmin.com
Printed in Taiwan Part Number 190-00720-52 Rev. 1TP
32
WARNING: Do not use the indicated data link weather product age to determine the age of the weather
information shown by the data link weather product. Due to time delays inherent in gathering and processing
weather data for data link transmission, the weather information shown by the data link weather product
may be significantly older than the indicated weather product age.
WARNING: Because of variation in the earth’s magnetic field, operating the system within the following
areas could result in loss of reliable attitude and heading indications. North of 72° North latitude at all
longitudes. South of 70° South latitude at all longitudes. North of 65° North latitude between longitude
75° W and 120° W. (Northern Canada). North of 70° North latitude between longitude 70° W and 128° W.
(Northern Canada). North of 70° North latitude between longitude 85° E and 114° E. (Northern Russia).
South of 55° South latitude between longitude 120° E and 165° E. (Region south of Australia and New
Zealand).
WARNING: The system has a very high degree of functional integrity. However, the pilot must recognize
that providing monitoring and/or self-test capability for all conceivable system failures is not practical.
Although unlikely, it may be possible for erroneous operation to occur without a fault indication shown by
the system. It is thus the responsibility of the pilot to detect such an occurrence by means of cross-checking
with all redundant or correlated information available in the cockpit.
WARNING: The United States government operates the Global Positioning System and is solely responsible
for its accuracy and maintenance. The GPS system is subject to changes which could affect the accuracy and
performance of all GPS equipment. Portions of the system utilize GPS as a precision electronic NAVigation
AID (NAVAID). Therefore, as with all NAVAIDs, information presented by the system can be misused or
misinterpreted and, therefore, become unsafe.
WARNING: For safety reasons, operational procedures of the system must be learned on the ground.
WARNING: To reduce the risk of unsafe operation, carefully review and understand all aspects of the
applicable Pilot’s Guide documentation and the Pilot’s Operating Handbook of the aircraft. Thoroughly
practice basic operation prior to actual use. During flight operations, carefully compare indications from the
system to all available navigation sources, including the information from other NAVAIDs, visual sightings,
charts, etc. For safety purposes, always resolve any discrepancies before continuing navigation.
WARNING: The indicators represented on the Panel (GDU 4XX only) are based on GPS-derived data and
may differ from the instruments in the aircraft.
WARNING: The data contained in the terrain and obstacle databases comes from government agencies.
Garmin accurately processes and cross-validates the data, but cannot guarantee the accuracy and
completeness of the data.
CAUTION: The display uses a lens coated with a special anti-reflective coating that is very sensitive to skin
oils, waxes, and abrasive cleaners. CLEANERS CONTAINING AMMONIA WILL HARM THE ANTI-REFLECTIVE
COATING. It is very important to clean the lens using a clean, lint-free cloth and an eyeglass lens cleaner
that is specified as safe for anti-reflective coatings.
CAUTION: The system does not contain any user-serviceable parts. Repairs should only be made by an
authorized Garmin service center. Unauthorized repairs or modifications could void both the warranty and
the pilot’s authority to operate this device under FAA/FCC regulations.
NOTE: This product, its packaging, and its components contain chemicals known to the State of California
to cause cancer, birth defects, or reproductive harm. This notice is being provided in accordance with
California’s Proposition 65. If you have any questions or would like additional information, please refer
to our web site at www.garmin.com/prop65.
NOTE: Interference from GPS repeaters operating inside nearby hangars can cause an intermittent loss
of attitude and heading displays while the aircraft is on the ground. Moving the aircraft more than 100
yards away from the source of the interference should alleviate the condition.
NOTE: Use of polarized eyewear may cause the flight displays to appear dim or blank.
NOTE: Temporary Flight Restriction (TFR) data is provided by the FAA and may not be updated outside of
normal business hours. Confirm data currency through alternate sources and contact your local FSS for
interpretation of TFR data.
NOTE: Images provided on the Aux-Video page are for supplemental use only.
Product Environmental Programs
Information about Garmin’s product recycling program and WEEE, RoHS, REACH, and other compliance programs can
be found at www.garmin.com/aboutGarmin/environment.
Declaration of Conformity
Hereby, Garmin, declares that this product is in compliance with the essential requirements and other relevant provisions
of Directive 1999/5/EC. To view the full Declaration of Conformity, go to www.garmin.com/compliance.
Industry Canada Compliance
Category I radiocommunication devices comply with Industry Canada Standard RSS-210. Category II radiocommunication
devices comply with Industry Canada Standard RSS-310. This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of the device.
Radio Frequency Exposure
This device is a mobile transmitter and receiver that uses its antenna to send and receive low levels of radio frequency
(RF) energy for voice and/or data communications. The device emits RF energy below the published limits when operating
in its maximum output power mode and when used with Garmin authorized accessories. To comply with FCC RF
exposure compliance requirements, the device should be mounted per the installation instructions only. The device should
not be used in other congurations. The device must be mounted a minimum of 20 cm away from the body of the user.
This device must not be co-located or operated in conjunction with any other transmitter or antenna.
FCC Compliance
This product has been tested and found to comply with Part 15 of the FCC interference limits for Class B digital devices
FOR HOME OR OFFICE USE. These limits are designed to provide more reasonable protection against harmful
interference in a residential installation, and are more stringent than “outdoor” requirements.
Operation of this device is subject to the following conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
This equipment generates, uses, and can radiate radio frequency energy and may cause harmful interference to
radio communications if not installed and used in accordance with the instructions. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet that is on a different circuit from the GPS device.
• Consult the dealer or an experienced radio/TV technician for help.
This product does not contain any user-serviceable parts. Repairs should only be made by an authorized Garmin service
center. Unauthorized repairs or modications could result in permanent damage to the equipment, and void your warranty
and your authority to operate this device under Part 15 regulations.
