GNT™ 10 Installation
Instructions
The GNT 10 extends the range of Garmin® wireless
marine devices, such as a remote control or wireless
mouse, and adds additional capabilities to more
feature-rich wireless devices, such as the quatix™
watch. The GNT 10 connects to an existing NMEA
2000® network on your boat. Additional GNT 10
devices can be installed on your NMEA 2000
network to provide a larger coverage area on your
boat.
Important Safety Information
CAUTION
Always wear safety goggles, ear protection, and a
dust mask when drilling, cutting, or sanding.
NOTICE
When drilling or cutting, always check what is on the
opposite side of the surface.
Contacting Garmin Product Support
• Go to www.garmin.com/support and click
Contact Support for in-country support
information.
• In the USA, call (913) 397.8200 or (800)
800.1020.
• In the UK, call 0808 2380000.
• In Europe, call +44 (0) 870.8501241.
Mounting Considerations
NOTICE
This device should be mounted in a location that is
not exposed to extreme temperatures or conditions.
The temperature range for this device is listed in the
product specifications. Extended exposure to
temperatures exceeding the specified temperature
range, in storage or operating conditions, may cause
device failure. Extreme-temperature-induced
damage and related consequences are not covered
by the warranty.
When selecting a mounting location, observe these
considerations.
• Metal and other dense materials may inhibit
communication between this device and Garmin
wireless marine devices. The intended mounting
location must be tested to make sure this device
reliably communicates with your wireless devices
everywhere you plan to use them on the boat.
• You can use the included screws to mount the
device on your boat. If the included screws are
not appropriate for the mounting surface, suitable
hardware must be purchased separately.
Mounting the Device
1Determine the mounting location.
2Using the device as a template, mark the two
pilot hole locations on the mounting surface.
3Using a 1/8 in. (3 mm) bit, drill the pilot holes.
4Use the included screws to attach the device to
the mounting surface.
NMEA 2000 Connection
Considerations
• This device connects to an existing NMEA 2000
network on your boat.
• If you are unfamiliar with NMEA 2000, you
should read the “NMEA 2000 Network
Fundamentals” chapter of the Technical
Reference for NMEA 2000 Products, available on
the Garmin web site. Click the “Manuals” link on
the product page for your device at
www.garmin.com.
• If the cable connected to the device is not long
enough to reach your NMEA 2000 network, an
extension of up to 16.5 ft. (5 m) can be used,
according to the NMEA 2000 guidelines.
Item Description
ÀGNT 10 device
ÁNMEA 2000 power cable (existing; not included)
ÂIgnition or in-line switch (existing; not included)
Ã12 Vdc power source
ÄNMEA 2000 terminator or backbone cable (existing;
not included)
ÅNMEA 2000 T-connector (included)
About the Status LED
The device has a two-color LED that you can use to
troubleshoot problems, if necessary. The LED is
labeled STATUS on the device.
Color State Status
Green Flashing The device is working correctly.
Solid The device software is being updated
Red Flashing
slowly
The device is starting up. If the LED
does not change to flashing green
after a short time, the device may not
be not working correctly. A software
update using a Garmin chartplotter
connected to the same NMEA 2000
network may correct the problem.
Flashing
quickly
The device is not receiving NMEA
2000 data. The NMEA 2000 network
should be checked for proper
installation and operation.
Auto MOB
When paired with a Garmin quatix watch, this device
is capable of triggering an automatic man overboard
(MOB) event.
A Garmin quatix watch must be paired with this
device for the auto MOB feature to work properly.
The owner's manual provided with your watch
contains detailed instructions on pairing and auto
MOB setup.
After auto MOB is enabled on a paired watch, this
device monitors the connection with the watch.
When the connection to the watch is lost for ten
seconds, this device triggers a system-wide MOB
event. During an MOB event, an MOB waypoint and
alert appear on all connected Garmin chartplotters.
The owner's manual provided with your Garmin
chartplotter contains additional information on MOB
features and actions.
February 2013 190-01576-90_01 Printed in Taiwan
Specifications
Specification Measurement
Dimensions
(W×H×D)
55/16 × 251/64 × 111/16 in. (135 × 71
× 26 mm)
Weight 6.63 oz. (188 g)
Temperature range From 5° to 158°F (from -15° to
70°C)
Material Fully gasketed, high-impact plastic,
waterproof to IEC 60529 IPX7
standards
Compass-safe
distance
131/32 in. (50 mm)
NMEA 2000 LEN 1
NMEA 2000 PGN Information
Type PGN Description
Transmit and
receive
059392 ISO acknowledgment
060928 ISO address claim
126208 NMEA®: Command, request,
and acknowledge group
function
Transmit 126464 Transmit PGN list group
function
126996 Product information
Type PGN Description
Receive 059904 ISO request
127250 Vessel heading
127258 Magnetic variance
127488 Engine parameters: Rapid
update
127489 Engine parameters: Dynamic
127505 Fluid level
127508 Battery status
128259 Speed: Water referenced
128267 Water depth
129025 Position: Rapid update
129026 COG and SOG : Rapid update
129029 GNSS position data
129283 Cross track error
129284 Navigation data
129285 Navigation route and waypoint
info
130306 Wind data
130312 Temperature
130314 Actual pressure
Garmin International, Inc.
1200 East 151st Street
Olathe, Kansas 66062, USA
Garmin (Europe) Ltd.
Liberty House, Hounsdown Business Park
Southampton, Hampshire, SO40 9LR UK
Garmin Corporation
No. 68, Zhangshu 2nd Road, Xizhi Dist.
New Taipei City, 221, Taiwan (R.O.C.)
Garmin® and the Garmin logo are trademarks of Garmin Ltd. or
its subsidiaries, registered in the USA and other countries.
GNT™ and quatix™ are trademarks of Garmin Ltd. or its
subsidiaries. These trademarks may not be used without the
express permission of Garmin.
NMEA 2000® and the NMEA 2000 logo are registered
trademarks of the National Marine Electronics Association.
© 2013 Garmin Ltd. or its subsidiaries www.garmin.com/support
