Garmin 02556 Low Power Transmitter 2402-2480 MHz User Manual

Garmin International Inc Low Power Transmitter 2402-2480 MHz

Contents

User Manual

Quick Start Manual
Introduction
WARNING
See the Important Safety and Product
Information guide in the product box for product
warnings and other important information.
Always consult your physician befo e you begin
or modify any exercise program.
Keys
ÀHold to turn the device on and off.
Select to turn the backlight on and
off.
ÁSelect to start and stop the timer.
Select to choose the highlighted
menu item.
DRAFT
ÂSelect to scroll through the data
screens, options, and settings.
ÃSelect to return to the previous
screen.
Select to scroll through display
screen options.
Select to mark a new lap, when lap
key function is enabled.
Turning on Activity Tracker
The activity tracking feature records your daily
step count, step goal, distance traveled, and
calories burned for each recorded day. Your
calories burned includes your base metabolism
plus activity calories.
Activity tracking can be enabled during the
initial device setup, or at any ime.
Select > Settings > Activity Tracking >
Turn On.
Your step count does not appear until the
device acquir s GPS signals and sets the
tim automatically. The device may need a
clear view of the sky to acquire GPS
signals.
Your total number of steps taken during the day
appears beneath the time of day. The step
count is updated periodically.
TIP: You can select to scroll through your
activity tracking data.
Going for a Run
The device comes partially charged. You may
need to charge the device (page 4) before
going for a run.
2
DRAFT
1Hold to turn on the device.
2Select .
3Go outside, and wait while the device
locates GPS signal.
It may take a few minutes to locate GPS
signals. When GPS is located,
appears solid.
4Select to start the timer.
5Go for a run.
6After you complete your run, select to
stop the timer.
7Select an option:
• Select Resume to restart the timer.
NOTE: After a few sec nds, a
summary appears.
• Select Save to save the run and reset
the timer. A summary appears.
NOTE: Y u c n now upload your run to
Garmin Connect™
.
• Select Discard to delete the run.
Putting On the Optional Heart Rate
Monitor
You should wear the heart rate monitor directly
on your skin, just below your sternum. It should
be snug enough to stay in place during your
activity.
1Push one tab À of the strap through the
slot Á in the heart rate monitor module.
3
DRAFT
2Press the tab down.
3Wet the electrodes  on the back of the
module to create a strong connection
between your chest and the heart rate
monitor module.
4Wrap the strap around your chest and
attach it to the other side of the heart rate
monitor module.
The Garmin® logo should be right-side up.
5Bring the device within 3 m (10 ft.) of the
heart rate monitor.
After you put on the heart rate monitor, it is
active and sending data.
Charging the Device
WARNING
This device contains a lithium-ion battery. See
the Important Safety and Product Information
guide in the product box for product warnings
and other important information.
NOTICE
To prevent corrosion, thoroughly clean and dry
the contacts and the surrounding area before
charging or connecting to a computer. Refer to
the cleaning instructions in the owner's manual.
4
DRAFT
1Plug the USB cable into a USB port on
your computer.
2Align the charger posts with the contacts
on the back of the device, and press the
charger À until it clicks.
3Charge the device completely.
Using Garmin Connec
You can upload all of your ac vity data to
Garmin Connect for compr hensive analysis.
With Garmin Conn ct, you can view a map of
your activity, nd share your activities with
friends.
1C nnect the device to your computer using
the USB cable.
2Go to www.garminconnect.com/start.
3Follow the on-screen instructions.
Device Information
More Information
Your owner's manual contains details about
additional features. Go to
www.garmin.com/manuals/.
• Bluetooth® notifications from your
smartphone
•Pairing ANT+® sensors
5
DRAFT
• Training options
• Customizing your device
Temperature Specifications
Operating temperature range:
From -15º to 60ºC (from 5º to 140ºF)
Charging temperature range:
From 0º to 45ºC (from 32º to 113ºF)
Heart rate monitor operating temperature
range: From -10 to 50 C (from 14 to
122 F)
6
DRAFT
DRAFT
Garmin®, the Garmin logo, ANT+® are
trademarks of Garmin Ltd. or its subsidiaries, registered in
the USA and other countries. Garmin Connect™
is a
trademark of Garmin Ltd. or its subsidiaries. These
trademarks may not be used without the express
permission of Garmin.
The Bluetooth® word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Garmin
is under license.
M/N: A02556
© 2015 Garmin Ltd. or its subsidiaries
www.garmin.com/support
Printed in Taiwan
June 2015 190-01902-90_0A
