User Manual
GDL 82
Pilot's Quick Start Guide
© 2017
Garmin International, Inc., or its subsidiaries
All Rights Reserved
Except as expressly provided herein, no part of this guide may
be reproduced, copied, transmitted, disseminated,
downloaded or stored in any storage medium, for any
purpose without the express prior written consent of
Garmin.
Garmin hereby grants permission to download a single copy
of this guide and of any revision to this guide onto a hard
drive or other electronic storage medium to be viewed and to
print one copy of this guide or of any revision hereto,
provided that such electronic or printed copy of this guide or
revision must contain the complete text of this copyright
notice and provided further that any unauthorized
commercial distribution of this guide or any revision hereto is
strictly prohibited.
For warranty information, visit:
garmin.com/en-US/legal/aviation-limited-warranty
For aviation product support, visit:
flyGarmin.com
For ADS-B informational videos, visit:
garmin.com/en-US/learning-center/ads-b
190-01810-03 Rev. A
Made in the U.S.A.
Resize.fm Page 1 Thursday, September 21, 2017 10:12 AM
12
NOTE
When the aircraft is on any airport movement area, the
transponder should be in Altitude Reporting (ALT) mode.
NOTE
If filing a flight plan or requesting ATC services, do not
use Anonymous Mode.
TRANSPONDER
OPERATING MODE
GDL 82 OPERATION
ADS-B OUT MESSAGES
OFF - Turned off or no power Do not transmit.
STBY (standby) Do not transmit.
ON - Non-altitude reporting Do not provide pressure
altitude information.
ALT (altitude reporting) Provide all required
information.
ENABLE ANONYMOUS MODE
1. Set the Anonymous Mode switch to the enabled position.
2. Set the transponder to squawk VFR code 1200.
OPTIONAL ADS-B OUT FAIL ANNUNCIATOR
An illuminated annunciator lamp indicates the unit is not
transmitting ADS-B Out messages. Or, messages do not
contain all required information.
GDL 82 SYSTEM
The GDL 82 is a UAT ADS-B transmitter that integrates with the
aircraft’s existing transponder, creating an ADS-B Out compliant
solution for flight in the U.S. below 18,000 feet.
GDL 82 SYSTEM FEATURES
GDL 82 Series
•Transmits ADS-B Out messages to ATC and
other aircraft
•Interrogates the interfaced transponder to
obtain squawk codes, IDENT status, and
pressure altitude
•Optional Anonymous Mode
•Optional ADS-B Out Fail Annunciator
GDL 82 w/ GPS/SBAS
•Unit functions as its own position source for
ADS-B Out messages
