Owner's Manual
WARNING
See the Important Safety and Product Information guide in the
product box for product warnings and other important
information.
Always consult your physician before you begin or modify any
exercise program.
Getting Started
When using your device for the first time, you should complete
these tasks to set up the device and learn about the basic
features.
1Go to www.garmin.com/wellness/start, and select your
company or vendor.
2Locate the serial number À on the back of the device.
3Follow the on-screen instructions to register the device with
your wellness partner site.
4Go to www.garminconnect.com/start, and follow the on-
screen instructions to register the device with Garmin
Connect™ (optional).
5Go to www.garmin.com/apps, and download the Garmin
Connect Mobile application (optional).
6Insert the device in the silicone clip, or carry the device in
your pocket (Wearing the Device).
7Go for a short walk (at least 1 minute).
8Check your progress toward your daily goal (Checking Your
Activity Progress).
Using Garmin Connect Mobile
Unlike other devices, your device must be paired
directly through the Garmin Connect Mobile application.
NOTE: Your mobile device must EHDEOHWRFRQHFWDQG
to pair with your device and synchronize data.
1From your mobile device, go to the Garmin Connect Mobile
application.
2Follow the on-screen instructions to pair the device and
update your preferences.
Wearing the Device
1Select an option:
• Carry the device in your pocket.
• Insert the device À into the flexible silicone clip Á by
stretching the clip material around the device.
2Attach the clip to your waistband or belt (optional).
3Carry or wear the device all day.
Checking Your Activity Progress
While you are wearing the device, it is active and sending data,
but no LEDs are showing.
• Double-tap the device.
Up to five green LEDs appear to indicate your daily progress.
LED State Description
Green Flashing Each flashing LED represents 10% of your
progress toward the daily goal.
Green Solid Each solid LED represents 20% of your progress
toward the daily goal.
Red Solid The battery level is low.
• Pair your device with the Garmin Connect Mobile application
to view your activity progress in real time (Using Garmin
Connect Mobile).
About the Step Goal
Your device has a default goal of steps per day. As you
begin your activity, the device records your progress toward the
daily goal.
You can turn on the auto goal feature or set a personalized step
goal on the Garmin Connect site. When you turn on the auto
goal feature, the device creates a daily step goal automatically,
based on your previous activity levels.
History
Your device keeps track of your daily steps, distance traveled,
calories burned, intensity, and very active minutes. This history
can be sent to your wellness partner site.
Your device stores your fitness activity data for up to 30 days.
When the data storage is full, the device deletes the oldest files
to make room for new data.
Sending Data to Your Wellness Partner Site
• Send data automatically to your wellness partner site by
passing within range of a wireless bridge.
• Send data manually to your wellness partner site by pairing
the device with the Garmin Connect Mobile application
(Using Garmin Connect Mobile).
Device Information
Specifications
Battery type User-replaceable CR2032 (3 volts)
Battery life Up to 6 months (typical use)
May 2014 190-01735-00_0A Printed in Taiwan
DRAFT
Operating temperature
range
-10°C to 50°C (from 14°F to 122°F)
Radio frequency/protocol 2.4 GHz wireless communications
protocol wireless technology
Water rating 1 ATM*
*The device withstands pressure equivalent to a depth of 10 m.
Device Care
NOTICE
Avoid extreme shock and harsh treatment, because it can
degrade the life of the product.
Do not use a sharp object to clean the device.
Avoid chemical cleaners, solvents, and insect repellents that
can damage plastic components and finishes.
Thoroughly rinse the device with fresh water after exposure to
chlorine, salt water, sunscreen, cosmetics, alcohol, or other
harsh chemicals. Prolonged exposure to these substances can
damage the case.
Do not store the device where prolonged exposure to extreme
temperatures can occur, because it can cause permanent
damage.
Replacing the Battery
WARNING
Do not use a sharp object to remove batteries.
Keep the battery away from children.
Never put batteries in mouth. If swallowed, contact your
physician or local poison control center.
Replaceable coin cell batteries may contain perchlorate
material. Special handling may apply. See
www.dtsc.ca.gov.hazardouswaste/perchlorate.
CAUTION
Contact your local waste disposal department to properly
recycle the batteries.
Before you can replace the battery, you must remove the
silicone clip.
1Locate the circular battery cover À on the back of the
sensor.
2Twist the cover counter-clockwise until it is loose enough to
remove.
3Remove the cover and the battery Á.
4Wait 30 seconds.
5Insert the new battery with the positive side facing up.
NOTE: Do not damage or lose the O-ring gasket.
6Replace the cover by aligning the dots and rotating
clockwise.
TIP: To confirm proper battery replacement, double-tap the
device.
The green LEDs flash. When no LEDs are showing, the
device is active and ready to send data.
2
DRAFT
The FCC ID is located in the battery compartment. The FCC ID is IPH-$2442.
