GE Appliances

164D4290P005 49-80034 7-00 JR

JKP18

JTP18

JKP56

JTP56

JK910

JK950

JT910

JT950

Owner’s Manual

Safety Information . . . . . . . . .3–5

Operating Instructions

Clock and Timer . . . . . . . . . . . . .12

Gourmet Shelf and

Baking Stones . . . . . . . . . . . . . . . .21

Oven Thermostat . . . . . . . . . . . . .22

Proofing . . . . . . . . . . . . . . . . . . . .20

Sabbath Feature . . . . . . . . . . . . . . .9

Timed Baking

and Roasting . . . . . . . . . .13, 18, 19

Using the Oven . . . . . . . . . . . .6–24

Care and Cleaning

Baking Stones . . . . . . . . . . . . . . . .27

Broiler Pan and Grid . . . . . . . . . .26

Control Panel . . . . . . . . . . . . . . . .26

Lift-Off Oven Door . . . . . . . . . . .25

Oven Floor . . . . . . . . . . . . . . . . . .26

Oven Light Bulb . . . . . . . . . . . . . .28

Probe . . . . . . . . . . . . . . . . . . . . . . .27

Stainless Steel Surfaces . . . . . . . .29

Self-Cleaning Oven . . . . . . . .23, 24

Shelves . . . . . . . . . . . . . . . . . . . . . .27

Troubleshooting Tips . . . .30–32

Customer Services

Service telephone

numbers . . . . . . . . . . . .Back Cover

Product registration . . . . .2, 33, 34

Warranty . . . . . . . . . . . . . . . . . . . .35

www.geappliances.com

Built-In Oven

Electric Convection

Inside you will find many helpful hints on how to use and maintain your oven properly. Just a little

preventive care on your part can save you a great deal of time and money over the life of your oven.

READ THIS MANUAL

GE & You, A Service Partnership.

FOR YOUR RECORDS

Write the model and serial numbers here:

#

#

You can find them on a label on the front of the oven behind the oven door on single oven models,

or the front of the lower oven behind the oven door on double oven models.

Staple sales slip or cancelled check here.

Proof of the original purchase date is needed to obtain service under the warranty.

IMPORTANT!

Fill out the Consumer Product Registration Card.

Two easy ways to register your appliance!

■Through the internet at www.geappliances.com

■Complete and mail the enclosed Product Registration Card

You’ll find many answers to common problems in the

Before You Call For Service

section. If you

review our chart of

Troubleshooting Tips

first, you may not need to call for service at all.

If you do need service, you can relax knowing help is only a phone call away. A list of toll-free

customer service numbers is included in the back section of this manual.

OR

Visit our Website at:

www.geappliances.com

IF YOU NEED SERVICE

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

2

3

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be followed to minimize the risk of fire or

explosion, electric shock, or to prevent property damage, personal injury, or loss of life.

IMPORTANT SAFETY NOTICE

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to

publish a list of substances known to the state to cause cancer, birth defects or other reproductive

harm, and requires businesses to warn customers of potential exposure to such substances.

The fiberglass insulation in self-clean ovens gives off a very small amount of carbon monoxide during

the cleaning cycle. Exposure can be minimized by venting with an open window or using a ventilation

fan or hood.

When using electrical appliances, basic safety precautions should be followed, including the

following:

■Use this appliance only for its intended

purpose as described in this Owner’s

Manual.

■Be sure your appliance is properly installed

and grounded by a qualified technician in

accordance with the provided installation

instructions.

■ Do not attempt to repair or replace any

part of your oven unless it is specifically

recommended in this manual. All other

servicing should be referred to a qualified

technician.

■ Have the installer show you the location of

the circuit breaker or fuse. Mark it for easy

reference.

■ Before performing any service, disconnect

the oven power supply at the household

distribution panel by removing the fuse or

switching off the circuit breaker.

■ Do not leave children alone—children

should not be left alone or unattended in

an area where an appliance is in use. They

should never be allowed to sit or stand on

any part of the appliance.

■ Do not allow anyone to climb, stand or

hang on the door. They could damage the

oven, or cause severe personal injury.

■ Be sure the oven is securely installed in a

cabinet that is firmly attached to the house

structure. Never allow anyone to climb, sit,

stand or hang on the oven door.

■ Never leave the oven door open when you

are not watching the oven.

■ Always keep combustible wall covering,

curtains or drapes a safe distance from

your oven.

■ Always keep dish towels, dish cloths, pot

holders and other linens a safe distance

from your oven.

■ Always keep wooden and plastic utensils

and canned food a safe distance away from

your oven.

■ Teach children not to play with the

controls or any other part of the oven.

SAFETY PRECAUTIONS

4

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

■ Do not store flammable materials in an

oven.

■

CAUTION

:

Items of interest to

children should not be stored in cabinets

above an oven; children climbing on the

oven to reach items could be seriously

injured.

■ Never wear loose-fitting or hanging

garments while using the appliance. Be

careful when reaching for items stored in

cabinets over the oven. Flammable material

could be ignited if brought in contact with

hot surfaces or heating elements and may

cause severe burns.

■ Use only dry pot holders—moist or damp

pot holders on hot surfaces may result in

burns from steam. Do not let pot holders

touch hot heating elements. Do not use a

towel or other bulky cloth.

■ For your safety, never use your appliance

for warming or heating the room.

■ Do not let cooking grease or other

flammable materials accumulate in or near

the oven.

■ Do not use water on grease fires. Never pick

up a flaming pan. Turn the controls off.

■Flame in the oven can be smothered

completely by closing the oven door and

turning the oven off or by using a multi-

purpose dry chemical or foam-type fire

extinguisher.

■ Do not touch the heating elements or the

interior surface of the oven. These surfaces

may be hot enough to burn even though

they are dark in color. During and after use,

do not touch, or let clothing or other

flammable materials contact any interior

area of the oven; allow sufficient time for

cooling first.

■Potentially hot surfaces include oven vent

openings, surfaces near the openings,

crevices around the oven door, the edges

of the window and metal trim parts above

the door.

■

REMEMBER:

The inside surface of the oven

may be hot when the door is opened.

■ Never leave jars or cans of fat drippings in

or near your oven.

■ Do not store or use combustible materials,

gasoline or other flammable vapors and

liquids in the vicinity of this or any other

appliance.

■ Stand away from the oven when opening

the oven door. Hot air or steam which

escapes can cause burns to hands, face

and/or eyes.

■ Do not heat unopened food containers.

Pressure could build up and the container

could burst, causing an injury.

■ Keep the oven vent unobstructed.

■ Keep the oven free from grease buildup.

■ Place the oven shelf in the desired position

while the oven is cool. If shelves must be

handled when hot, do not let pot holder

contact the heating elements.

■ When using cooking or roasting bags in the

oven, follow the manufacturer’s directions.

■ Pulling out the shelf to the stop-lock is a

convenience in lifting heavy foods. It is also

a precaution against burns from touching

hot surfaces of the door or oven walls.

■ Do not use the oven to dry newspapers.

If overheated, they can catch on fire.

■ Do not use the oven for a storage area.

Items stored in an oven can ignite.

■ Do not leave paper products, cooking

utensils or food in the oven when not in use.

■ After broiling, always take the broiler pan

out of the oven and clean it. Leftover grease

in the broiler pan can catch fire next time

you use the pan.

■ Clean only parts listed in this Use and

Care Manual.

■ Do not use aluminum foil to line oven

bottoms, except as suggested in this

manual. Improper installation of

aluminum foil may result in a risk

of electric shock or fire.

WARNING!

SAFETY PRECAUTIONS

5

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 160°F. and poultry

to at least an INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against

foodborne illness.

COOK MEAT AND POULTRY THOROUGHLY…

■Do not clean the door gasket. The door

gasket is essential for a good seal. Care

should be taken not to rub, damage or

move the gasket.

■Do not use oven cleaners. No commercial

oven cleaner or oven liner protective

coating of any kind should be used in or

around any part of the oven. Residue from

oven cleaners will damage the inside of the

oven when the self-clean cycle is used.

■Before self-cleaning the oven, remove the

broiler pan, grid and other cookware.

■Be sure to wipe up excess spillage before

starting the self-cleaning operation.

■If the self-cleaning mode malfunctions,

turn the oven off and disconnect the power

supply. Have it serviced by a qualified

technician.

SELF-CLEANING OVEN

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

SAVE THESE INSTRUCTIONS

6

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Using the oven controls.

Throughout this manual, features and appearance may vary from your model.

Oven Control, Clock and Timer Features and Settings

BAKE Pad

Press this pad to select the bake function.

BROIL HI/LO Pad

Press this pad to select the broil function.

CONVECTION BAKE Pad

Press this pad to select baking with the

convection function.

CONVECTION ROAST Pad

Press this pad to select roasting with the

convection function.

PROOF Pad (on some models)

Press this pad to select a warm environment

useful for rising yeast-leavened products.

START Pad

Must be pressed to start any cooking or

cleaning function.

Display

Shows the time of day, oven temperature,

whether the oven is in the bake, broil or

self-cleaning mode and the times set for

the timer or automatic oven operations.

If “F– and a number or letter” flash in the display and

the oven control signals, this indicates a function

error code. Press the CLEAR/OFF pad. Allow the oven to

cool for one hour. Put the oven back into operation. If the

function error code repeats, disconnect the power to the

oven and call for service.

If your oven was set for a timed oven operation

and a power outage occurred, the clock and all

programmed functions must be reset.

The time of day will flash in the display when there

has been a power outage.

SELF CLEAN Pad

Press this pad to select the self-cleaning

function. See the

Using the self-cleaning

oven

section.

OVEN LIGHT Pad

Press this pad to turn the oven light

on or off.

DELAY START Pad

Use along with

COOKING TIME

or

SELF

CLEAN

pads to set the oven to start and

stop automatically at a time you set.

COOKING TIME Pad

Press this pad and then press the number

pads to set the amount of time you want

your food to cook. The oven will shut off

when the cooking time has run out.

CLEAR/OFF Pad

Press this pad to cancel

ALL

oven

operations except the clock and timer.

CLOCK Pad

Press this pad before setting the clock.

Number Pads

Use to set any function requiring numbers

such as the time of day on the clock, the

timer, the oven temperature, the internal

food temperature, the start time and

length of operation for timed baking

and self-cleaning.

KITCHEN TIMER ON/OFF Pad

Press this pad to select the timer feature.

PROBE Pad

Press this pad when using the probe to

cook food.

Double oven control shown.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Special features of your oven control.

Your new touch pad control has additional features that you may choose to use. The following are the

features and how you may activate them.

The special feature modes can only be activated while the display is showing the time of day. They remain

in the control’s memory until the steps are repeated.

When the display shows your choice, press the START pad. The special features will remain in memory

after a power failure, except for the Sabbath feature, which will have to be reset.

12 Hour Shut-Off

With this feature, should you forget and leave the

oven on, the control will automatically turn off the

oven after 12 hours during baking functions or

after 3 hours during a broil function.

If you wish to turn

OFF

this feature, follow

the steps below.

Press the

BAKE

and

BROIL HI/LO

pads (on double oven models use

the

upper

oven controls) at the same

time for 3 seconds until the display

shows

SF.

Press the

DELAY START

pad. The

display will show

12 shdn

(12 hour

shut-off). Press the

DELAY START

pad again and the display will show

no shdn

(no shut-off).

Press the

START

pad to activate the

no shut-off and leave the control set

in this special features mode.

NOTE: On double oven models this activates this

special feature for both ovens.

Control Lockout

Your control will allow you to lock down the touch

pads so they cannot be activated when pressed.

Press the

BAKE

and

BROIL HI/LO

pads (on double oven models use

the

upper

oven controls) at the same

time for 3 seconds until the display

shows

SF.

Press the

SELF CLEAN

pad. The

display will show

LOC OFF.

Press the

SELF CLEAN

pad again.

The display will show

LOC ON.

Press the

START

pad to activate

the control lockout feature and

leave the control set in this special

features mode.

When this feature is on and the touch

pads are pressed the control will beep

and the display will show

LOC.

NOTE:

■

The control lockout mode will not affect the

CLOCK, KITCHEN TIMER ON/OFF and OVEN

LIGHT ON/OFF touch pads.

■

On double oven models this activates this

special feature for both ovens.

7

12 Hour, 24 Hour or Clock Black-Out

Your control is set to use a 12 hour clock.

If you would prefer to have a 24 hour

military time clock or black-out the clock

display, follow the steps below.

Press the

BAKE

and

BROIL HI/LO

pads (on double oven models use

the

upper

oven controls) at the same

time for 3 seconds until the display

shows

SF.

Press the

CLOCK

pad once. The

display will show

12 hr.

If this is

the choice you want, press the

START

pad.

Press the

CLOCK

pad again to change

to the 24 hour military time clock.

The display will show

24 hr.

If this

is the choice you want, press the

START

pad.

Press the

CLOCK

pad again to black-

out the clock display. The display

will show

OFF.

If this is the choice

you want, press the

START

pad.

NOTE: If the clock is in the black-out mode you

will not be able to use the Delay Start function.

Cook and Hold

Your new control has a cook and hold feature that

keeps cooked foods warm for up to 3 hours after

the cooking function is finished.

To activate this feature, follow the steps

below.

On double oven models both ovens

follow the same step 1. Then proceed

with steps 2 through 3, using the pads for

the upper or lower oven.

Press the

BAKE

and

BROIL HI/LO

pads (on double oven models use

the

upper

oven controls) at the same

time for 3 seconds until the display

shows

SF.

Press the

COOKING TIME

pad. The

display will show

Hld OFF.

Press the

COOKING TIME

pad again to

activate the feature. The display will

show

Hld ON.

Press the

START

pad to activate the

cook and hold feature and leave the

control set in this special features

mode.

Using Convection Conversion

By using the Convection Conversion feature you

can automatically convert the oven temperature

from regular baking to Convection Bake

temperatures.

To convert the oven temperature for

convection baking, follow the steps below.

Press and hold the

CONVECTION

BAKE

pad for 4 to 5 seconds.

CON Con Bake

will show in the display.

Using the number pads, enter

the temperature recommended

in the recipe.

Press the

START

pad.

The display shows the converted

(reduced) temperature. For

example, if you entered a recipe

temperature of 350°F., the display

will show

325°F.

when it is converted.

Press the

CLEAR/OFF

pad when

baking is finished.

NOTE: Conversion must be set each time you

want to use it. It is not held in memory.

8

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Special features of your oven control.

Tones at the End of a Timed Cycle

At the end of a timed cycle, 3 short beeps will

sound followed by one beep every 6 seconds until

the CLEAR/OFF pad is pressed. This continuous 6

second beep may be canceled.

To cancel the 6 second beep:

Press the

BAKE

and

BROIL HI/LO

pads (on double oven models use

the

upper

oven controls) at the same

time for 3 seconds until the display

shows

SF.

Press the

KITCHEN TIMER ON/OFF

pad. The display shows

CON BEEP

(continuous beep). Press the

KITCHEN TIMER ON/OFF

pad

again. The display shows

BEEP.

(This cancels the one beep every

6 seconds.)

Press the

START

pad.

NOTE: On double oven models this cancels the

end of cycle tone for both ovens.

Fahrenheit or Celsius Temperature Selection

Your oven control is set to use the Fahrenheit

temperature selections but you may change this

to use the Celsius selections.

Press the

BAKE

and

BROIL HI/LO

pads (on double oven models use

the

upper

oven controls) at the same

time for 3 seconds until the display

shows

SF.

Press the

BROIL HI/LO

pad. The

display will show

F

(Fahrenheit).

Press the

BROIL HI/LO

pad again. The

display will show

C

(Celsius).

Press the

START

pad.

NOTE: On double oven models the new setting

will be displayed for both ovens.

9

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Using the Sabbath Feature.

(Designed for use on the Jewish Sabbath and Holidays.)

(On some models)

The Sabbath feature can be used for baking/roasting only. It cannot be used for convection, broiling, self-cleaning, or

Delay Start cooking.

NOTE: The oven light comes on automatically (on some models) when the door is opened and goes off when the door is closed.

The bulb may be removed. See the Oven Light Replacement section. On models with a light switch on the control panel, the oven

light may be turned on and left on.

How to Set for Regular Baking/Roasting

Make sure the clock shows the correct time of day.

Press and hold

both

the

BAKE

and

BROIL

HI/LO

pads,

at the same time

, until the

display shows

SF.

NOTE:

If bake or broil appears in the

display, the

BAKE

and

BROIL HI/LO

pads

were not touched at the same time.

Touch the

CLEAR/OFF

pad and begin

again.

Tap the

DELAY START

pad until

SAb bAtH

appears in the display.

Touch the

START

pad and ⊃will appear

in the display.

Touch the

BAKE

pad. No signal will

be given.

Using the number pads, enter the desired

temperature between 170° and 550°.

No signal or temperature will be given.

Touch the

START

pad.

After a random delay period of

approximately 30 seconds to 1 minute,

⊃will appear in the display indicating

that the oven is

baking/roasting.

If ⊃

doesn’t appear in the display, start

again at Step 4.

To adjust the oven temperature, touch the

BAKE

pad, enter the new temperature using

the number pads, and touch the

START

pad.

NOTE:

The

CLEAR/OFF

and

COOKING TIME

pads

are active during the Sabbath feature.

⊃⊃

How to Set for Timed Baking/Roasting–Immediate Start and Automatic Stop

Make sure the clock shows the correct time of day.

Press and hold

both

the

BAKE

and

BROIL

HI/LO

pads,

at the same time

, until the

display shows

SF.

NOTE:

If bake or broil appears in the

display, the

BAKE

and

BROIL HI/LO

pads

were not touched at the same time.

Touch the

CLEAR/OFF

pad and begin

again.

Tap the

DELAY START

pad until

SAb bAtH

appears in the display.

Touch the

START

pad and ⊃will appear

in the display.

Touch the

COOKING TIME

pad.

Touch the number pads to set the

desired length of cooking time between

1 minute and 9 hours and 99 minutes.

The cooking time that you entered will

be displayed.

Touch the

START

pad.

Touch the

BAKE

pad. No signal will be

given.

Using the number pads, enter the desired

temperature. No signal or temperature

will be given.

Touch the

START

pad.

After a random delay period of

approximately 30 seconds to 1 minute,

⊃will appear in the display indicating

that the oven is

baking/roasting.

If ⊃

doesn’t appear in the display, start

again at Step 7.

To adjust the oven temperature, touch the

BAKE

pad, enter the new temperature using

the number pads, and touch the

START

pad.

When cooking is finished, the display will

change from ⊃to ⊃and

0:00

will appear,

indicating that the oven has turned

OFF

but is still set in Sabbath. Remove

the cooked food.

⊃

⊃⊃

How to Exit the Sabbath Feature

Touch the

CLEAR/OFF

pad.

If the oven is cooking, wait for a random

delay period of approximately 30

seconds to 1 minute, until only ⊃is

in the display.

Press and hold

both

the

BAKE

and

BROIL

HI/LO

pads,

at the same time

, until the

display shows

SF.

Tap the

DELAY START

pad until

12 shdn

or

no shdn

appears in the display.

12 shdn

indicates that the oven will automatically

turn off after 12 hours.

no shdn

indicates

that the oven will not automatically

turn off.

Touch the

START

pad.

NOTE:

If a power outage occurred while

the oven was in Sabbath, the oven will

automatically turn off and stay off even

when the power returns. The oven

control must be reset.

When the display shows

⊃

the

oven is set in Sabbath. When the

display shows

⊃

the oven is

baking/roasting.

⊃

When the display shows

⊃

the

oven is set in Sabbath. When the

display shows

⊃

the oven is

baking/roasting.

⊃

10

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Using the oven.

To avoid possible burns, place the shelves in the desired position before you turn the oven on.

Before you begin…

The shelves have stop-locks, so that when

placed correctly on the supports, they will

stop before coming completely out, and

will not tilt.

When placing and removing cookware,

pull the shelf out to the bump on the

shelf support.

To remove a shelf,

pull it toward you, tilt

the front end up and pull it out.

To replace,

place the end of the shelf

(stop-locks) on the support, tilt up the

front and push the shelf in.

30

″

ovens (shown) have 7 shelf

positions.

27

″

ovens have 4 shelf positions.

How to Set the Oven for Baking or Roasting

Press the

BAKE

pad.

Press the number pads to set the

desired temperature.

Press the

START

pad.

Check food for doneness at

minimum time on recipe. Cook

longer if necessary.

Press the

CLEAR/OFF

pad when

cooking is complete.

NOTE: A cooling fan may automatically turn on

and off to cool internal parts. This is normal, and

the fan may continue to run even after the oven is

turned off.

Shelf Position

Type of Food 27” Oven 30” Oven

Frozen pies B or C C or D

(on cookie sheet)

Angel food cake, A B

bundt or pound cakes

Biscuits, muffins, B or C C or D

brownies, cookies,

cupcakes, layer

cakes, pies

Casseroles B or C C or D

Preheating and Pan Placement

Preheat the oven if the recipe calls for it.

To preheat, set the oven at the correct

temperature. Preheating is necessary for

good results when baking cakes, cookies,

pastry and breads.

For ovens without a preheat indicator light or

tone, preheat 10 minutes.

Baking results will be better if baking pans

are centered in the oven as much as

possible. Pans should not touch each

other or the walls of the oven. If you need

to use two shelves, stagger the pans so one

is not directly above the other, and leave

approximately 11⁄2″between pans, from

the front, back and sides of the wall.

Aluminum Foil

You can use aluminum foil to line the

broiler pan and broiler grid. However,

you must mold the foil tightly to the grid

and cut slits in it just like the grid.

Aluminum foil may also be used to catch a

spillover.

Never entirely cover a shelf with

aluminum foil. This will disturb the heat

circulation and result in poor baking.

A smaller sheet of foil may be used to

catch a spillover by placing it on a lower

shelf several inches below the food.

Cut slits in the foil just like the grid.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

How to Set the Oven for Broiling

Place the meat or fish on the broiler

grid in the broiler pan.

Follow suggested shelf positions in

the

Broiling Guide.

If your oven is connected to 208 volts, rare steaks

may be broiled by preheating the broiler and

positioning the oven shelf one position higher.

Press the

BROIL HI/LO

pad once for

HI Broil.

To change to

LO Broil,

press the

BROIL HI/LO

pad again.

Press the

START

pad.

When broiling is finished, press the

CLEAR/OFF

pad.

NOTE: Broil will not work if the temperature

probe is plugged in.

Leave the door open to the broil

stop position. The door stays open

by itself, yet the proper temperature

is maintained in the oven.

Broiling Guide

27” Ovens 27” Ovens 27” Ovens 30” Ovens 30” Ovens 30” Ovens

Quantity and/ Shelf First Side Second Side Shelf First Side Second Side

Food or Thickness Position Time (min.) Time (min.) Position Time (min.) Time (min.) Comments

Ground Beef 1 lb. (4 patties) C 10 7 E 10 7 Space evenly. Up

Well Done 1/2 to 3/4″thick E 10 9 to 8 patties take

about the same

time.

Beef Steaks

Rare 1″thick C 6 5 E 8 6 Steaks less than

Medium 1 to 11⁄2lbs. C 8 6 E 10 8 1″thick cook

Well Done C 12 11 E 12 10 through before

browning.

Rare 11⁄2″thick C 10 7–8 E 10 8 Pan frying is

Medium 2 to 21⁄2lbs. C 15 14–16 E 15 14–16 recommended.

Well Done C 25 20–25 E 25 20–25 Slash fat.

Chicken 1 whole A 35 10–15 C 25 10 Reduce time about

2 to 21⁄2lbs., 5 to 10 minutes

split lengthwise per side for cut-up

chicken. Brush

each side with

melted butter.

Broil skin-side-

down first.

Lobster Tails 2–4 B 13–16 Do not C 13–16 Do not Cut through back of

6 to 8 oz. each turn over. turn over. shell. Spread open.

Brush with melted

butter before

broiling and after

half of broiling

time.

Fish Fillets 1/4 to 1/2″thick C 5 5 E 5 5 Handle and turn

very carefully.

Brush with lemon

butter before and

during cooking, if

desired. Preheat

broiler to increase

browning.

Ham Slices 1″thick B 8 8 D 8 8 Increase time 5 to

(precooked) 10 minutes per

side for 11⁄2″thick

or home-cured ham.

Pork Chops 2 (1/2″thick) C 10 10 E 10 10 Slash fat.

Well Done 2 (1″thick) about 1 lb. B 13 13 D 15 15

Lamb Chops

Medium 2 (1″thick) about 10 C 10 9 E 10 9 Slash fat.

Well Done to 12 oz. C 12 10 E 12 10

Medium 2 (11⁄2″thick) about 1 lb. C 14 12 E 14 12

Well Done B 17 12–14 E 17 12–14 11

12

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Using the clock and timer.

To Set the Clock

The clock must be set to the correct time

of day for the automatic oven timing

functions to work properly. The time of

day cannot be changed during a timed

baking or self-cleaning cycle.

Press the

CLOCK

pad.

Press the number pads.

Press the

START

pad.

Make sure the clock is set to the

correct time of day.

To Set the Timer

Press the

KITCHEN TIMER ON/OFF

pad.

Press the number pads until the

amount of time you want shows in

the display. For example, to set 2

hours and 45 minutes, press

2, 4

and

5

in that order. If you make a mistake

press the

KITCHEN TIMER ON/OFF

pad and begin again.

Press the

START

pad.

When the timer reaches

:00

,

the control will beep 3 times

followed by one beep every 6

seconds until the

KITCHEN TIMER

ON/OFF

pad is pressed.

The 6 second tone can be canceled by

following the steps in the

Special features

of your oven control

section under

Tones at

the End of a Timed Cycle.

NOTE: On some models the time counts down

immediately when the START pad is pressed. The

timer is actually counting down in seconds that

are not shown on the display until the last minute.

The timer is a minute timer only.

The timer does not control oven

operations. The maximum setting on

the timer is 9 hours and 59 minutes.

To Reset the Timer

If the display is still showing the time

remaining, you may change it by pressing

the

KITCHEN TIMER ON/OFF

pad, then

press the number pads until the time you

want appears in the display.

If the remaining time is not in the display

(clock, delay start or cooking time are in

the display), recall the remaining time by

pressing the

KITCHEN TIMER ON/OFF

pad

and then pressing the number pads to

enter the new time you want.

To Cancel the Timer

Press the

KITCHEN TIMER ON/OFF

pad twice.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Using the timed baking and roasting features.

On double oven models, you can use timed baking in one oven while using self-clean in the other; you can also use

timed baking in both ovens at the same time.

NOTE: Foods that spoil easily–such as milk, eggs, fish, stuffings, poultry and pork–should not be allowed to sit for

more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that

the oven light is off because heat from the bulb will speed harmful bacteria growth.

How to Set an Immediate Start and Automatic Stop

The oven will turn on immediately and cook for a

selected length of time. At the end of the cooking

time the oven will turn off automatically.

Make sure the clock shows the correct

time of day.

Press the

BAKE

pad.

Using the number pads, enter the

desired temperature.

Press the

COOKING TIME

pad.

NOTE: If your recipe requires preheating, you

may need to add additional time to the length of

the cooking time.

Using the number pads, enter the

desired baking time. The oven

temperature and the cooking time

that you entered will be displayed.

Press the

START

pad.

The display shows the oven temperature

that you set and the cooking time

countdown. The display starts changing

once the temperature reaches 100°F.

NOTE: On double oven models when using both

ovens at the same time, the times showing in the

display will be for the last oven set. To display the

time set for the first oven set, press the COOKING

TIME pad for that oven.

The oven will continue to cook for

the programmed amount of time,

then shut off automatically.

Press the

CLEAR/OFF

pad to clear

the display.

How to Set a Delayed Start and Automatic Stop

You can set the oven control to delay-start the

oven, cook for a specific length of time and then

turn off automatically.

Make sure the clock shows the correct

time of day.

Press the

BAKE

pad.

Using the number pads, enter the

desired temperature.

Press the

COOKING TIME

pad.

NOTE: If your recipe requires preheating, you

may need to add additional time to the length of

the cooking time.

Using the number pads, enter the

desired baking time.

Press the

DELAY START

pad.

Using the number pads, enter the

time of day you want the oven to turn

on and start cooking.

Press the

START

pad.

NOTE: An attention tone will sound if you are

using timed baking and do not press the START

pad after entering the baking temperature.

If you would like to check the times you

have set, press the

DELAY START

pad to

check the start time you have set or press

the

COOKING TIME

pad to check the

length of cooking time you have set.

When the oven turns on at the time

of day you have set, the display will

show the changing temperature

(starting at 100°F.) and the cooking

time countdown.

NOTE: On double oven models when using both

ovens at the same time, the times showing in the

display will be for the last oven set. To display the

time set for the first oven set, press the DELAY

START or the COOKING TIME pad for that oven.

At the end of timed baking, the oven

will turn off. The end of cycle tone

will sound.

Press the

CLEAR/OFF

pad to clear

the display.

13

14

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Using the probe.

For many foods, especially roasts and poultry, internal food temperature is the best test for doneness. The

temperature probe takes the guesswork out of roasting by cooking foods to the exact doneness you want.

NOTE: Double oven models have a probe in the

upper oven only.

Use of probes other than the one

provided with this product may result in

damage to the probe.

Use the handles of the probe and plug

when inserting and removing them from

the meat and outlet.

■

To avoid damaging your probe, do not use

tongs to pull on the cable when removing it.

■

To avoid breaking the probe, make sure food is

completely defrosted before inserting.

■

To prevent possible burns, do not unplug

the probe from the outlet until the oven

has cooled.

■

Never leave your probe inside the oven during

a self-cleaning cycle.

■

Do not store the probe in the oven.

The temperature probe has a

skewer-like probe at one end and a

plug at the other end that goes into

the outlet in the oven.

After preparing the meat and placing it

on a trivet or on the broiler pan grid,

follow these directions for proper probe

placement.

Lay the probe on the outside of the

meat along the top or side and mark

with your finger where the edge of

the meat comes to on the probe. The

point should rest in the center of the

thickest meaty part of the roast.

Insert the probe completely into the

meat. It should not touch the bone,

fat or gristle.

For roasts with no bone, insert the probe

into the meatiest part of the roast. For

bone-in ham or lamb, insert the probe

into the center of the lowest large muscle

or joint.

Insert the probe into the center of dishes

such as meat loaf or casseroles. When

cooking fish, insert the probe from just

above the gill into the meatiest area,

parallel to the backbone.

Insert the probe into the meatiest part of

the inner thigh from below and parallel

to the leg of a whole turkey.

How to Set the Oven For Roasting When Using the Probe

Insert the probe into the meat.

Plug the probe into the outlet in the

oven. Make sure it’s pushed all the

way in. Close the oven door.

Press the

PROBE

pad.

Press the number pads to set the

desired internal food or meat

temperature.

Press the

BAKE

pad.

Press the number pads to set the

desired oven temperature.

Press the

START

pad.

The display will flash if the probe is inserted into

the outlet and you have not set a probe

temperature and pressed the START pad.

When the oven starts to heat, the word

LO

will be in the display.

After the internal temperature of the

meat reaches 100°F., the changing

internal temperature will be shown

in the display.

When the internal temperature of

the meat reaches the number you

have set, the probe and the oven

turn off and the oven control signals.

To stop the signal, press the

CLEAR/OFF

pad. Use hot pads to

remove the probe from the food.

Do not use tongs to pull on it—they

might damage it.

To change the oven temperature during

the Roast cycle, press the

BAKE

pad and

then the number pads to set the new

temperature.

■

If the probe is removed from the food before

the final temperature is reached, a tone will

sound and the display will flash until the probe

is removed from the oven.

■

You can use the timer even though you cannot

use timed oven operations.

Cable

Handles

Probe

Plug

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Using the convection oven.

The convection oven fan shuts off when the oven door is opened. DO NOT leave the door open for long periods of

time while using convection cooking or you may shorten the life of the convection heating element.

Adapting Recipes…

You can use your favorite recipes in the

convection oven.

When baking, reduce baking

temperature by 25°F.

No need to preheat when cooking longer

than 15 minutes.

■

For more information on adapting recipes, see

the Convection Cookbook.

■

Use pan size recommended.

■

Some package instructions for frozen

casseroles or main dishes have been

developed using commercial convection ovens.

For best results in this oven, preheat the oven

and use the temperature on the package.

To help you understand the difference

between convection bake and roast and

traditional bake and roast, here are some

general guidelines.

Convection Bake

■

Ideal for evenly browned baked foods cooked

on multiple shelves.

■

Good for large quantities of baked foods.

■

Good results with cookies, biscuits, muffins,

brownies, cupcakes, cream puffs, sweet rolls,

angel food cake and bread.

Heat comes from the heating element in

the rear of the oven. The convection fan

circulates the heated air evenly over and

around the food. Preheating is not

necessary with foods having a bake time

of over 15 minutes.

Convection Roast

■

Good for large tender cuts of meat, uncovered.

Heat comes from the top heating

element. The convection fan circulates

the heated air evenly over and around the

food. Meat and poultry are browned on

all sides as if they were cooked on a

rotisserie. Using the roasting rack

provided, heated air will be circulated

over, under and around the food being

roasted. The heated air seals in juices

quickly for a moist and tender product

while, at the same time, creating a rich

golden brown exterior.

Roasts or poultry should be cooked on a shelf (on

27” models use the offset shelf) in the lowest

shelf position (A).

When you are convection roasting it is

important that you use the broiler pan

and grid and the special roasting rack for

best convection roasting results. The pan

is used to catch grease spills and the grid

is used to prevent grease spatters.

Place the meat on the special roasting

rack. The rack holds the meat. The rack

allows the heated air to circulate under

the meat and increase browning on the

underside of the meat or poultry.

■Place the shelf (on 27″models use

the offset shelf) in the lowest shelf

position (A).

■Place the grid on the broiler pan and

put the roasting rack over them making

sure the posts on the roasting rack fit

into the holes in the broiler pan.

CAUTION: When you are using the offset shelf

(on 27” models) in the lowest position (A), you

will need to use caution when pulling the shelf

out. We recommend that you pull the shelf out

several inches and then, using two pot holders,

pull the shelf out by holding the sides of it. The

offset shelf is low and you could be burned if you

place your hand in the middle of the shelf and

pull all the way out. Be very careful not to burn

your hand on the door when using a shelf in the

lowest position (A).

In a convection oven, a fan

circulates hot air over, under and

around the food.

This circulating hot air is evenly

distributed throughout the oven

cavity. As a result, foods are evenly

cooked and browned—often in less

time with convection heat.

(appearance may vary)

Roasting rack

Grid

Post

Broiler pan

Offset shelf (27″models only)

15

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Using the convection oven.

Cookware for Convection Cooking

Before using your convection oven, check

to see if your cookware leaves room for air

circulation in the oven. If you are baking

with several pans, leave space between

them. Also, be sure the pans do not touch

each other or the walls of the oven.

Paper and Plastic

Heat-resistant paper and plastic

containers that are recommended for use

in regular ovens can be used in

convection ovens. Plastic cookware that

is heat-resistant to temperatures of

400°F. can also be used.

Metal and Glass

Any type of cookware will work in your

convection oven. However, metal pans

heat the fastest and are recommended for

convection baking.

■

Darkened or matte-finished pans will bake

faster than shiny pans.

■

Glass or ceramic pans cook more slowly.

When baking cookies, you will get the

best results if you use a flat cookie sheet

instead of a pan with low sides.

For recipes like oven-baked chicken,

use a pan with low sides. Hot air cannot

circulate well around food in a pan with

high sides.

How to Set the Oven for Convection Baking or Roasting

Press the

CONVECTION BAKE

or

CONVECTION ROAST

pad.

Press the number pads to set the

desired oven temperature.

Press the

START

pad.

To change the oven temperature, press

the

CONVECTION BAKE

or

CONVECTION

ROAST

pad and then the number pads to

set the new temperature.

When the oven starts to heat the changing

temperature, starting at 100°F., will be

displayed. When the oven reaches the

temperature you set, 3 beeps will sound.

Press the

CLEAR/OFF

pad when

finished.

NOTE:

■

You will hear a fan while cooking with

convection. The fan will stop when the door is

opened but the heat will not turn off.

■

You may hear the oven clicking during baking.

This is normal.

Multi-Shelf Baking

When convection baking with only 1 shelf, follow

the shelf positions recommended in the Using the

oven section.

Because heated air is circulated evenly

throughout the oven, foods can be

baked with excellent results using

multiple shelves.

Multi-shelf baking may increase cook times

slightly for some foods but the overall

result is time saved. Cookies, muffins,

biscuits, and other quickbreads give very

good results with multi-shelf baking.

30” Ovens

When baking on 3 shelves, place one

shelf in the bottom (A) position, one on

the third (C) position and one in the 5th

(E) position.

27” Ovens

When baking on 3 shelves, divide the

oven into thirds by placing the offset shelf

in the third (C) shelf position and the

straight shelves in first (A) and fourth (D)

shelf positions.

For two-shelf baking, place the offset shelf

in the bottom (A) shelf position. Place

the straight shelf in the third (C) shelf

position.

CAUTION: When you are using the offset shelf

(on 27” models) in the lowest position (A), you

will need to use caution when pulling the shelf

out. We recommend that you pull the shelf out

several inches and then, using two pot holders,

pull the shelf out by holding the sides of it. The

offset shelf is low and you could be burned if you

place your hand in the middle of the shelf and

pull all the way out. Be very careful not to burn

your hand on the door when using a shelf in the

lowest position (A).

Multi-shelf position 30

″

oven

Multi-shelf position 27

″

oven

16

or

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

How to Set the Oven for Convection Roasting when Using the Probe

The display will flash

PROBE

and the oven

control will signal if the probe is inserted

into the outlet, and you have not set a

probe temperature and pressed the

START

pad.

Place the shelf (on 27″models use

the offset shelf) in the lowest

position (A). Insert the probe into

the meat.

Plug the probe into the outlet in the

oven. Make sure it is pushed all the

way in. Close the oven door.

Press the

CONVECTION ROAST

pad.

Press the number pads to set the

desired oven temperature.

Press the

PROBE

pad.

Press the number pads to set the

desired internal meat temperature.

Press the

START

pad.

When the oven starts to heat, the word

LO

will be in the display.

After the internal temperature of the meat

reaches 100°F., the changing internal

temperature will be shown in the display.

When the internal temperature of

the meat reaches the number you

have set, the probe and the oven

turn off and the oven control signals.

To stop the signal, press the

CLEAR/OFF

pad. Use hot pads to

remove the probe from the food. Do

not use tongs to pull on it—they

might damage it.

CAUTION: To prevent possible burns, do not

unplug the probe from the oven outlet until the

oven has cooled. Do not store the probe in the

oven.

NOTE:

■

If the probe is removed from the food before

the final temperature is reached, a tone will

sound and the display will flash until the probe

is removed from the oven.

■

You will hear a fan while cooking with this

feature. The fan will stop when the door is

opened but the heat will not turn off.

■

You can use the timer even though you cannot

use timed oven operations.

■

On double oven models, you will not be able to

use the probe in the upper oven during timed

oven operations. This is because with the

probe you are cooking by temperature rather

than time.

For best results when roasting large

turkeys and roasts, we recommend

using the probe included in the

convection oven.

To change the oven temperature

during the Convection Roast cycle,

press the CONVECTION ROAST pad

and then press the number pads to

set the new desired temperature.

Convection Roasting Guide

Meats Minutes/Lb. Oven Temp. Internal Temp.

Beef Rib, Boneless Rib, Rare 20–24 325°F. 140°F.†

Top Sirloin Medium 24–28 325°F. 160°F.

(3 to 5 lbs.) Well 28–32 325°F. 170°F.

Beef Tenderloin Rare 10–14 325°F. 140°F.†

Medium 14–18 325°F. 160°F.

Pork Bone-in, Boneless (3 to 5 lbs.) 23–27 325°F. 170°F.

Chops (1/2 to 1″thick) 2 chops 30–35 total 325°F. 170°F.

4 chops 35–40 total 325°F. 170°F.

6 chops 40–45 total 325°F. 170°F.

Ham Canned, Butt, Shank (3 to 5 lbs. fully cooked) 14–18 325°F. 140°F.

Lamb Bone-in, Boneless (3 to 5 lbs.) Medium 17–20 325°F. 160°F.

Well 20–24 325°F. 170°F.

Seafood Fish, whole (3 to 5 lbs.) 30–40 total 400°F.

Lobster Tails (6 to 8 oz. each) 20–25 total 350°F.

Poultry Whole Chicken (21⁄2to 31⁄2lbs.) 24–26 350°F. 180°–185°F.

Cornish Hens Unstuffed (1 to 11⁄2lbs.) 50–55 total 350°F. 180°–185°F.

Stuffed (1 to 11⁄2lbs.) 55–60 total 350°F. 180°–185°F.

Duckling (4 to 5 lbs.) 24–26 325°F. 180°–185°F.

Turkey, whole*

Unstuffed (10 to 16 lbs.) 8–11 325°F. 180°–185°F.

Unstuffed (18 to 24 lbs.) 7–10 325°F. 180°–185°F.

Turkey Breast (4 to 6 lbs.) 16–19 325°F. 170°F.

*Stuffed birds generally require 30–45 minutes additional roasting time. Shield legs and breast with foil to prevent over-

browning and drying of skin.

†The U.S. Department of Agriculture says “Rare beef is popular, but you should know that cooking it to only 140°F. means

some food poisoning organisms may survive.” (Source: Safe Food Book. Your Kitchen Guide. USDA Rev. June 1985.) 17

18

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Using the timed features for convection baking.

On double oven models, you can use timed baking in one oven while using self-clean in the other; you can also use

timed baking in both ovens at the same time.

You will hear a fan while cooking with this feature. The fan will stop when the door is opened but the heat will not

turn off.

NOTE: Foods that spoil easily–such as milk, eggs, fish, stuffings, poultry and pork–should not be allowed to sit for

more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure

that the oven light is off because heat from the bulb will speed harmful bacteria growth.

How to Set an Immediate Start and Automatic Stop

The oven will turn on immediately and cook for a

selected length of time. At the end of the cooking

time the oven will turn off automatically.

Make sure the clock shows the correct

time of day.

Press the

CONVECTION BAKE

pad.

Press the number pads to set the

desired oven temperature.

Press the

COOKING TIME

pad.

NOTE: If your recipe requires preheating, you

may need to add additional time to the length of

the cooking time.

Press the number pads to set the

desired length of cooking time. The

minimum cooking time you can set

is 1 minute. The oven temperature

that you set and the cooking time

that you entered will be in the display.

Press the

START

pad.

The display shows the oven temperature

that you set and the cooking time

countdown. The display starts changing

once the temperature reaches 100°F.

NOTE: On double oven models when using both

ovens at the same time, the times showing in the

display will be for the last oven set. To display the

time set for the first oven set, press the COOKING

TIME pad for that oven.

At the end of timed convection bake

the oven will turn off. The end of

cycle tone will sound. Press the

CLEAR/OFF

pad to clear the display

if necessary.

Remove the food from the oven.

Remember, foods that are left in the

oven continue cooking after the

controls are off.

19

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

How to Set a Delayed Start and Automatic Stop

You can set the oven control to delay-start the

oven, cook for a specific length of time and then

turn off automatically.

Make sure the clock shows the correct

time of day.

Press the

CONVECTION BAKE

pad.

Press the number pads to set the

desired oven temperature.

Press the

COOKING TIME

pad.

NOTE: If your recipe requires preheating, you

may need to add additional time to the length of

the cooking time.

Press the number pads to set the

desired cooking time.

Press the

DELAY START

pad.

Press the number pads to set the

time of day you want the oven to turn

on and start cooking.

If you would like to check the times you have set,

press the DELAY START pad to check the start time

you have set or press the COOKING TIME pad to

check the length of cooking time you have set.

Press the

START

pad.

NOTE: An attention tone will sound if you are

using timed baking and do not press the START

pad after entering the baking temperature.

When the oven turns on at the time

of day you have set, the display will

show the changing temperature

(starting at 100°F.) and the cooking

time countdown.

NOTE: On double oven models when using both

ovens at the same time, the times showing in the

display will be for the last oven set. To display the

time set for the first oven set, press the DELAY

START or COOKING TIME pad for that oven.

At the end of timed convection bake the

oven will turn off. The end of cycle tone

will sound.

Press the

CLEAR/OFF

pad to clear the

display if necessary. When baking is

finished, remove the food from the

oven. Remember, even though the

oven shuts off automatically, foods

continue cooking after the controls

are off.

Using the proofing feature

(on some models)

The proofing feature maintains a warm environment useful for rising yeast-leavened products.

How to Set the Oven For Proofing

Place the covered dough in a dish in

the oven on shelf B or C.

NOTE: For best results, cover the dough with a

cloth or with greased plastic wrap (the plastic

may need to be anchored underneath the

container so the oven fan will not blow it off).

Press the

PROOF

pad and then the

START

pad.

The display will read

BRD

(bread).

The oven interior light turns on and

remains on during proofing.

The proofing feature automatically

provides the optimum temperature for

the proofing process and therefore does

not have a temperature adjustment.

Set the

KITCHEN TIMER

for the

minimum proof time.

When proofing is finished, press

the

CLEAR/OFF

pad.

■

To avoid lowering the oven temperature

and lengthening proofing time, do not

open the oven door unnecessarily.

■

Check bread products early to avoid

over-proofing.

NOTE:

■

Do not use the proofing mode for warming

food or keeping food hot. The proofing oven

temperature is not hot enough to hold foods

at safe temperatures.

■

Proofing feature on upper oven only.

■

Proofing will not operate when oven is above

150 degrees. “HOT” will show in the display.

20

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

21

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Using the gourmet shelf and baking stones

(on some models)

The gourmet shelf and baking stones are excellent for baking bread and pizza.

■The shelf should be placed in the

second rack position from the bottom

and the stones carefully placed on it.

Preheat to the desired baking

temperature.

■Always preheat the stones before using

them. For best results do not use baking

stones with rising crust pizzas.

When using the gourmet shelf bake at the same

temperature and for the same time that you

would normally.

■Use a pizza peel (special wood paddle)

to place pizza on or off the baking

stones. Sprinkle corn meal on the

baking stones and the peel to prevent

sticking.

■The baking stones become very hot in

the oven. Allow the stones to cool

before removing them from the oven.

Always use a heavy potholder or oven

glove when handling the baking stones.

■The stones are made of a porous

ceramic material and it is normal for

the stones to accumulate stains with

use. This will not affect their baking

capabilities in any way.

Avoid sudden temperature changes. Don’t place

the heated stones on a cold surface or immerse

them in water.

■Do not leave the stones in your oven

when they are not being used. Baking

times and browning may be affected.

Carefully place the stones on the

offset rack.

Do not drop the stones onto the

rack or chipping may occur.

To remove the stones place a hand

under the rack and push up on the

stones.

22

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Adjust the oven thermostat—Do it yourself!

You may find that your new oven cooks differently than the one it replaced. Use your new oven for a few

weeks to become more familiar with it. If you still think your new oven is too hot or too cold, you can adjust

the thermostat yourself.

Do not use thermometers, such as those found in grocery stores, to check the temperature setting of your oven.

These thermometers may vary 20–40 degrees.

NOTE: This adjustment will not affect the broiling or the self-cleaning temperatures. The adjustment will be

retained in memory after a power failure.

To Adjust the Thermostat

Press the

BAKE

and

BROIL HI/LO

pads

at the same time for 3 seconds until

the display shows

SF.

Press the

BAKE

pad for the oven

which you want to use. A two digit

number shows in the display.

Press

BAKE

again to alternate between

increasing and decreasing the oven

temperature.

The oven temperature can be

adjusted up to (+) 35°F. hotter or (-)

35°F. cooler. Press the number pads

the same way you read them. For

example, to change the oven

temperature 15°F., press

1

and

5.

When you have made the

adjustment, press the

START

pad to go back to the time of

day display. Use your oven as

you would normally.

The type of margarine will affect baking performance!

Most recipes for baking have been developed using high fat products such as butter or margarine (80% fat). If you

decrease the fat, the recipe may not give the same results as with a higher fat product.

Recipe failure can result if cakes, pies, pastries, cookies or candies are made with low fat spreads. The lower the fat

content of a spread product, the more noticeable these differences become.

Federal standards require products labeled “margarine” to contain at least 80% fat by weight. Low fat spreads, on the

other hand, contain less fat and more water. The high moisture content of these spreads affect the texture and flavor of

baked goods. For best results with your old favorite recipes, use margarine, butter or stick spreads containing at least

70% vegetable oil.

23

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Using the self-cleaning oven.

The oven door must be closed and all controls must be set correctly for the cycle to work properly.

Before a Clean Cycle

The oven must be cool in order to set the self-

clean cycle.

We recommend venting your kitchen

with an open window or using a

ventilation fan or hood during the first

self-clean cycle.

Remove the broiler pan, broiler grid,

probe, all cookware and any aluminum

foil from the oven.

The oven shelves and convection roasting

rack can be self-cleaned, but they will

darken, lose their luster and become

hard to slide.

Do not use abrasives or oven cleaners.

Clean the top, sides and outside of the

oven door with soap and water.

Make sure the oven light bulb cover

(on some models) is in place and the

oven light is off.

IMPORTANT:

The health of some birds

is extremely sensitive to the fumes given

off during the self-cleaning cycle of any

oven. Move birds to another well

ventilated room.

■On double oven models, you can

set a clean cycle in both ovens at the

same time. The last oven set will

automatically delay its start until the

end of the first oven’s clean cycle.

■On double oven models, you can use

timed baking in one oven and self-clean

the other at the same time.

Wipe up heavy soil on the oven

bottom. (appearance may vary)

How to Set the Oven for Cleaning

Press the

SELF CLEAN

pad.

Using the number pads, enter the

desired clean time, if a time other

than 4 hours is needed.

Clean cycle time is normally 4 hours. You

can change the clean time to any time

between 3 hours and 5 hours, depending

on how dirty your oven is.

Press the

START

pad.

The door locks automatically. The display

will show the clean time remaining. It will

not be possible to open the oven door

until the temperature drops below the

lock temperature and the

LOCKED DOOR

light goes off.

When the

LOCKED DOOR

light is off, open

the door.

■The words

LOCK DOOR

will flash and

the oven control will signal if you set

the clean cycle and forget to close the

oven door.

■To stop a clean cycle, press the

CLEAR/OFF

pad. When the

LOCKED

DOOR

light goes off indicating the

oven has cooled below the locking

temperature, open the door.

24

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Using the self-cleaning oven.

The oven door must be closed and all controls must be set correctly for the cycle to work properly.

How to Delay the Start of Cleaning

Press the

SELF CLEAN

pad.

Using the number pads, enter the

desired clean time.

Press the

DELAY START

pad.

Using the number pads, enter the

time of day you want the clean cycle

to start.

Press the

START

pad.

The door locks automatically. The display

will show the start time. It will not be

possible to open the oven door until

the temperature drops below the lock

temperature and the

LOCKED DOOR

light goes off.

When the

LOCKED DOOR

light is off, open

the door.

NOTE: On double oven models, you can set a

delay clean in both ovens at the same time.

The second oven set will automatically delay

the start of cleaning until the end of the first

oven’s clean cycle.

To recall the start time of the second oven set,

press the DELAY START pad on the controls for

the second oven.

After a Clean Cycle

You may notice some white ash in the

oven. Wipe it up with a damp cloth after

the oven cools.

If white spots remain, remove them with a soap-

filled steel wool pad and rinse thoroughly with a

vinegar and water mixture.

These deposits are usually a salt residue

that cannot be removed by the clean cycle.

If the oven is not clean after one clean

cycle, repeat the cycle.

■You cannot set the oven for cooking

until the oven is cool enough for the

door to unlock.

■ While the oven is self-cleaning, you

can press the

CLOCK

pad to display

the time of day. To return to the

clean countdown, press the

SELF

CLEAN

pad.

■ If the shelves become hard to slide, wipe

the shelf supports with cooking oil.

25

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Care and cleaning of the oven.

Be sure electrical power is off and all surfaces are cool before cleaning any part of the oven.

How to Remove Packaging Tape

To assure no damage is done to the finish

of the product, the safest way to remove

the adhesive left from packaging tape on

new appliances is an application of a

household liquid dishwashing detergent,

mineral oil or cooking oil.

Apply with a soft cloth and allow to soak.

Wipe dry and then apply an appliance

polish to thoroughly clean and protect

the surface.

NOTE: The plastic tape must be removed from all

chrome trim. It cannot be removed if it is baked on.

Lift the door straight up and off

the hinges.

The gasket is designed with a gap at

the bottom to allow for proper air

circulation.

Do not rub or clean the door gasket—

it has an extremely low resistance to

abrasion.

If you notice the gasket becoming

worn, frayed or damaged in any way

or if it has become displaced on the

door, you should have it replaced.

Lift-Off Oven Door

The oven door is removable for easier

access to the light bulb.

Do not lift the door by the handle.

To remove the door,

open it to the broil

stop position. Grasp firmly on each side

and lift the door straight up and off the

hinges.

Do not place hands between the hinge and the

oven door frame.

To replace the door,

make sure the hinges

are in the broil stop position. Position the

slots in the bottom of the door squarely

over the hinges and slowly lower it over

both hinges.

To clean the inside of the door:

■ Because the area inside the gasket is

cleaned during the self-clean cycle, you

do not need to clean this by hand.

■ The area outside the gasket and the

front frame can be cleaned with a soap-

filled steel wool or plastic pad, hot

water and detergent. Rinse well with a

vinegar and water solution.

To clean the outside of the door:

■ Use soap and water to thoroughly clean

the top, sides and front of the oven

door. Rinse well. You may also use a

glass cleaner to clean the glass on the

outside of the door. Do not let water

drip into the vent openings.

■ Spillage of marinades, fruit juices,

tomato sauces and basting materials

containing acids may cause

discoloration and should be wiped up

immediately. When surface is cool,

clean and rinse.

■ Do not use oven cleaners, cleaning

powders or harsh abrasives on the

outside of the door.

Press down and pull out.

Removable Oven Floor

To remove the oven floor:

Remove the oven door using the

instructions in the

Lift-Off Oven Door

section of this manual.

Press down and pull out the

removable oven floor.

Clean the oven floor with warm

soapy water.

When re-installing the oven floor be

sure to slide it all the way to the back

of the oven.

IMPORTANT:

Always replace the

removable floor before the next use.

26

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Care and cleaning of the oven.

Control Panel

It’s a good idea to wipe the control

panel after each use. Clean with mild

soap and water or vinegar and water,

rinse with clean water and polish dry

with a soft cloth.

Do not use abrasive cleansers, strong

liquid cleansers, plastic scouring pads or

oven cleansers on the control panel—they

will damage the finish. A 50/50 solution

of vinegar and hot water works well.

Broiler Pan & Grid

Do not clean the broiler pan or grid in a self-

cleaning oven.

After broiling, remove the broiler pan

from the oven. Remove the grid from the

pan. Carefully pour out the grease from

the pan into a proper container.

Wash and rinse the broiler pan and grid

in hot water with a soap-filled or plastic

scouring pad.

If food has burned on, sprinkle the grid

with detergent while hot and cover with

wet paper towels or a dishcloth. Soaking

the pan will remove burned-on foods.

Both the broiler pan and grid may be

cleaned with a commercial oven cleaner.

Both the broiler pan and grid can also be

cleaned in a dishwasher.

Do not store a soiled broiler pan and grid

anywhere in the oven.

After broiling, remove the broiler

pan from the oven.

27

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Oven Shelves and Convection Roasting Rack

Clean the oven shelves (including the

offset shelf) and the convection roasting

rack with an abrasive cleanser or steel

wool. After cleaning, rinse the shelves

and rack with clean water and dry with a

clean cloth.

NOTE: The oven shelves and convection roasting

rack may be cleaned in the self-cleaning oven.

However, the shelves will darken in color, lose

their luster and become hard to slide if cleaned

during the self-cleaning cycle. You can wipe the

shelf supports with cooking oil after self-cleaning

to make the shelves slide more easily.

Roasting rack

Oven shelf

Offset shelf (27″models only)

Probe

The temperature probe may be cleaned

with soap and water or a soap-filled

scouring pad. Cool the temperature

probe before cleaning. Scour stubborn

spots with a soap-filled scouring pad,

rinse and dry.

■

Do not immerse the temperature probe

in water.

■

Do not store the temperature probe in

the oven.

Baking Stones

(on some models)

The baking stones are made of a porous

ceramic material and it is normal for

them to accumulate stains with use.

If you must clean them, allow then to

cool. Scrape off soil and rinse well in

warm water.

■

Do not wash with soaps and detergents as

they may be absorbed by the stones and may

transfer an unwanted taste.

■

Do not wash in an automatic dishwasher.

■

Allow the stones to cool completely before

cleaning.

■

Do not put hot stones into water.

■

Make sure that the stones are thoroughly dry

before baking.

■

Do not wash in an automatic dishwasher.

Wire cover holder

Oven Light Bulb

(on some models)

NOTE: The glass cover (on some

models) should be removed only when

cold. Wearing latex gloves may offer a

better grip.

Before replacing the bulb, disconnect

electrical power to the oven at the main

fuse or circuit breaker panel. Let the bulb

cool completely before removing it. For

your safety, do not touch a hot bulb with a

damp cloth. If you do, the bulb will break.

To remove:

Turn the glass cover counterclockwise

1/4 turn until the tabs of the glass cover

clear the grooves of the socket. Remove

the bulb.

To replace:

Put in a new 40-watt appliance bulb.

Place the tabs of the glass cover into the

grooves of the socket. Turn the glass

cover clockwise 1/4 turn.

NOTE:

■

A 40-watt appliance bulb is smaller than a

standard 40-watt household bulb.

■

Reconnect electrical power to the oven.

■

For improved lighting inside the oven, clean

the glass cover frequently using a wet cloth.

This should be done when the oven is

completely cool.

Bulb

Socket

Tab

Maximum

length

31⁄2”

Glass cover

Oven Light Bulb

(on some models)

CAUTION: Before replacing your oven

light bulb, disconnect the electrical

power to the oven at the main fuse or

circuit breaker panel.

Be sure to let the light cover and bulb

cool completely.

To remove the cover:

Hold a hand under the cover so it

doesn’t fall when released. With

fingers of the same hand, firmly

push back the wire cover holder.

Lift off the cover.

Do not remove any screws to remove

the cover.

Replace bulb with a 40-watt

appliance bulb.

To replace the cover:

Place it into groove of the light

receptacle. Pull wire forward to

the center of the cover until it

snaps into place.

Connect electrical power to

the oven.

28

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Care and cleaning of the oven.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Oven Heating Elements

Do not clean the broil element. Any soil

will burn off when the element is heated.

The bake element is not exposed and is

under the removable oven floor. If

spillovers, residue or ash accumulate on

the removable oven floor, wipe up before

self-cleaning.

To clean the oven floor, take out the

removable floor and gently lift the bake

element. Clean with warm soapy water.

Always replace the removable floor

before next use.

Stainless Steel

(on some models)

Do not use a steel-wool pad; it will

scratch the surface.

To clean stainless steel surfaces, use a

hot, damp cloth with a mild detergent

suitable for stainless steel surfaces. Use

a clean, hot, damp cloth to remove

soap. Dry with a dry, clean cloth.

If food soil remains, try a general

kitchen cleaner, such as Fantastik®,

Simple Green®, or Formula 409®.

For hard-to-clean soil, use a

standard stainless-steel cleaner,

such as Bon-Ami® or Cameo®.

Apply cleaner with a damp sponge.

Use a clean, hot, damp cloth to remove

cleaner. Dry with a dry, clean cloth.

Always scrub lightly in the direction of

the grain.

After cleaning, use a stainless-steel

polish, such as Stainless Steel Magic®,

Revere Copper and Stainless Steel

Cleaner®, or Wenol All Purpose

Metal Polish®. Follow the product

instructions for cleaning the stainless-

steel surface.

29

30

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Before You Call For Service…

Troubleshooting Tips

Save time and money! Review the charts on the following

pages first and you may not need to call for service.

Problem Possible Causes What To Do

Control signals after

You forgot to enter a bake •Press the

BAKE

pad and desired temperature or the

entering cooking time

temperature or cleaning

SELF CLEAN

pad and desired clean time.

or delay start

time.

Food does not bake

Oven controls improperly set. •See the

Using the oven

section.

or roast properly

Shelf position is incorrect •See the

Using the oven

section.

or the shelf is not level.

Incorrect cookware or •See the

Using the oven

section.

cookware of improper size

being used.

Oven floor not in place. •Replace the oven floor.

Oven thermostat needs •See the

Adjust the oven thermostat—Do it yourself!

adjustment. section.

Food does not

Door not open to the •See the

Using the oven

section.

broil properly

broil stop position as

recommended.

Oven controls improperly set. •Make sure you press the

BROIL HI/LO

pad.

Improper shelf position •See the

Broiling Guide.

being used.

Food being cooked •Use the broiling pan and grid that came with your oven.

in a hot pan. Make sure it is cool.

Cookware not suited •Use the broiling pan and grid that came with your oven.

for broiling.

The probe is plugged into the •Unplug and remove the probe from the oven.

outlet in the oven.

Aluminum foil used on the •See the

Using the oven

section.

broiling pan and grid has

not been fitted properly and

slit as recommended.

In some areas the power •Preheat the broil element for 10 minutes.

(voltage) may be low.

•Broil for the longest period of time recommended in

the

Broiling Guide.

Clock and timer

A fuse in your home may be •Replace the fuse or reset the circuit breaker.

do not work

blown or the circuit breaker

tripped.

Oven controls improperly set. •See the

Using the clock and timer

section.

Oven light does

Light bulb is loose or defective. •Tighten or replace the bulb.

not work

Pad operating light is broken. •Call for service.

31

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

Problem Possible Causes What To Do

Oven temperature too

Oven thermostat •See the

Adjust the oven thermostat—Do it yourself!

hot or too cold

needs adjustment. section.

Oven will not work

A fuse in your home may •Replace the fuse or reset the circuit breaker.

be blown or the circuit

breaker tripped.

Oven controls improperly set. •See the

Using the oven

section.

Oven will not self-clean

The oven temperature •Allow the oven to cool to room temperature and reset

is too high to set a the controls.

self-clean operation.

Oven controls improperly set. •See the

Using the self-cleaning oven

section.

The probe is plugged into •Remove the probe from the oven.

the outlet in the oven.

“Crackling” or

This is the sound of the •This is normal.

“popping” sound

metal heating and cooling

during both the cooking and

cleaning functions.

Excessive smoking

Excessive soil. •Press the

CLEAR/OFF

pad. Open the windows to rid

during clean cycle

the room of smoke. Wait until the

LOCKED DOOR

light goes off. Wipe up the excess soil and reset the

clean cycle.

Oven door will not

Oven too hot. •Allow the oven to cool below locking temperature.

open after a

clean cycle

Oven not clean after a

Oven controls not properly set. •See the

Using the self-cleaning oven

section.

clean cycle

Oven was heavily soiled. •Clean up heavy spillovers before starting the clean

cycle. Heavily soiled ovens may need to self-clean

again or for a longer period of time.

“LOCK DOOR” flashes

The self-clean cycle has •Close the oven door.

in the display

been selected but the

door is not closed.

LOCKED DOOR light

The oven door is locked •Press the

CLEAR/OFF

pad. Allow the oven to cool.

is on when you want

because the temperature

to cook

inside the oven has not

dropped below the

locking temperature.

32

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Before You Call For Service…

Troubleshooting Tips

Problem Possible Causes What To Do

“F— and a number

You have a function •Press the

CLEAR/OFF

pad. Allow the oven to cool for

or letter” flash

error code. one hour. Put the oven back into operation.

in the display

If the function code repeats. •Disconnect all power to the oven for at least 30

seconds and then reconnect power. If the function

error code repeats, call for service.

Display goes blank

A fuse in your home may •Replace the fuse or reset the circuit breaker.

be blown or the circuit

breaker tripped.

The clock is in the •See the

Special features of your oven control

section.

black-out mode.

Display flashes

Power failure. •Reset the clock.

Unable to get the

Oven control pads were •The

BAKE

and

BROIL HI/LO

pads (on double oven

display to show “SF”

not pressed properly. models use the upper oven controls) must be pressed

at the same time and held for 3 seconds.

“Probe” appears in

This is reminding you to •Enter a probe temperature.

the display

enter a probe temperature

after plugging in the probe.

Power outage,

Power outage or surge. •Reset the clock. If the oven was in use, you must reset

clock flashes

it by pressing the

CLEAR/OFF

pad, setting the clock

and resetting any cooking function.

Steam from the vent

When using the convection •This is normal.

feature, it is normal to see

steam coming out of the

oven vent. As the number

of shelves or amount of

food being cooked increases,

the amount of visible steam

will increase.

“Burning” or “oily”

This is normal in a new oven •To speed the process, set a self-clean cycle for a

odor emitting from

and will disappear in time. minimum of 3 hours. See the

Using the self-cleaning

the vent oven

section.

Strong odor

An odor from the insulation •This is temporary.

around the inside of the

oven is normal for the first

few times the oven is used.

Fan noise

A cooling fan or a convection •This is normal. The cooling fan will turn off and on.

fan (depending on the The convection fan will run until the function is

function you are using) over or the door is opened.

may automatically turn on

and off to cool internal parts.

33

General Electric Company

Warranty Registration Department

P.O. Box 32150

Louisville, KY 40232-2150

GE Service Protection Plus™

GE, a name recognized worldwide for quality and dependability, offers you

Service Protection Plus™—comprehensive protection on all your appliances—

No Matter What Brand!

Benefits Include:

•Backed by GE

•All brands covered

•Unlimited service calls

•All parts and labor costs included

•No out-of-pocket expenses

•No hidden deductibles

•One 800 number to call

You will be completely satisfied with our service protection or you may request your money back

on the remaining value of your contract. No questions asked. It’s that simple.

Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more—any brand!

Plus there’s no extra charge for emergency service and low monthly financing is available. Even icemaker

coverage and food spoilage protection is offered. You can rest easy, knowing that all your valuable

household products are protected against expensive repairs.

Place your confidence in GE and call us in the U.S. toll-free at 800-626-2224

for more information.

*All brands covered, up to 20 years old, in the continental U.S.

We’ll Cover Any Appliance.

Anywhere. Anytime.*

Please place in envelope and mail to:

✁Cut here

34

Consumer Product Ownership Registration

Important

Mail

Today!

First

Name

Mr. ■■Ms. ■■Mrs. ■■Miss ■■

Street

Address

City State

Date Placed

In Use

Month Day Year

Zip

Code

Apt. #

Last

Name

Phone

Number __

Consumer Product Ownership Registration

Dear Customer:

Thank you for purchasing our product and thank you for placing your confidence in us.

We are proud to have you as a customer!

Follow these three steps to protect your new appliance investment:

Important: If you did not get a registration card with your

product, detach and return the form below to

ensure that your product is registered, or register

online at www.geappliances.com.

123

Model Number Serial Number

✁Cut here

Complete and mail

your Consumer

Product Ownership

Registration today.

Have the peace of

mind of knowing we

can contact you in

the

unlikely event of

a

safety modification.

After mailing the

registration below,

store this document

in a safe place. It

contains information

you will need should

you require service.

Our service number is

800 GE CARES

(800-432-2737).

Read your Owner’s

Manual carefully.

It will help you

operate your new

appliance properly.

Model Number Serial Number

E-mail Address

Occasionally, we may allow selected companies to send you information.

■■ Check here if you do not want this information.

35

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Customer Service

GE Built-In Electric Oven Warranty

All warranty service provided by our Factory Service Centers

or an authorized Customer Care®technician. For service,

call 800-GE-CARES.

For The Period Of: GE Will Replace:

One Year Any part

of the oven which fails due to a defect in materials or workmanship.

From the date of the

During this

full one-year warranty,

GE will also provide,

free of charge,

all labor

original purchase

and in-home service to replace the defective part.

■Service trips to your home to teach you how to use

the product.

■Improper installation.

■Failure of the product if it is abused, misused, or used

for other than the intended purpose or used

commercially.

■Replacement of house fuses or resetting of circuit

breakers.

■Damage to the product caused by accident, fire, floods

or acts of God.

■Incidental or consequential damage caused by

possible defects with this appliance.

What GE Will Not Cover:

This warranty is extended to the original purchaser and any succeeding owner for products purchased for

home use within the USA. In Alaska, the warranty excludes the cost of shipping or service calls to your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty

gives you specific legal rights, and you may also have other rights which vary from state to state. To know

what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.

Warrantor: General Electric Company. Louisville, KY 40225

36

Safety InstructionsOperating InstructionsCare and CleaningTroubleshooting TipsCustomer Service

Printed in LaFayette, GA

Service Telephone Numbers.

GE Answer Center

®

800.626.2000

The GE Answer Center® is open 24 hours a day, 7 days a week.

OR

Visit our Website at:

www.geappliances.com

In-Home Repair Service

800-GE-CARES (800-432-2737)

Expert GE repair service is only a phone call away.

Special Needs Service

800.626.2000

800-TDD-GEAC (800-833-4322)

GE offers, free of charge, a brochure to assist in planning a barrier-free kitchen for persons

with limited mobility.

Service Contracts

800-626-2224

Purchase a GE service contract while your warranty is still in effect and you’ll receive a

substantial discount. GE Consumer Service will still be there after your warranty expires.

Parts and Accessories

800-626-2002

Individuals qualified to service their own appliances can have parts or accessories sent directly

to their homes (VISA, MasterCard and Discover cards are accepted).

Instructions contained in this manual cover procedures to be performed by any user. Other servicing

generally should be referred to qualified service personnel. Caution must be exercised, since

improper servicing may cause unsafe operation.

Service Satisfaction

If you are not satisfied with the service you receive from GE:

First,

contact the people who serviced your appliance.

Next,

if you are still not pleased, write all the details—including your phone number—to: Manager,

Customer Relations, GE Appliances, Appliance Park, Louisville, KY 40225.
