GemTek Technology DPH153AT Small Cell SC-DPH153-LA, Dual Band 1 port User Manual

Gemtek Technology Co., Ltd. Small Cell SC-DPH153-LA, Dual Band 1 port

Contents

User Manual Part 1

Cisco Systems, Inc. 678 277-1120
5030 Sugarloaf Parkway, Box 465447 770 722-2009
Lawrenceville, GA 30042 www.cisco.com
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its a liates in the U.S. and other
countries. To view a list of Cisco trademarks, go to this URL: www.cisco.com/go/trademarks.
Other third party trademarks mentioned are the property of their respective owners.
The use of the word partner does not imply a partnership relationship between Cisco and any other company. (1110R)
© 2012 Cisco and/or its a liates. All rights reserved.
October 2012 Printed in United States of America Part Number 78-4071002-01
DPH153 3G Small Cell
Power
Ethernet
Location
3G
Quick Reference Guide
Activate Your Device
To activate your device, follow your service provider-speci c instructions.
Con rm Your Success
Your device is con gured and working properly when:
• The 3G light on your DPH153 3G Small Cell is solid green.
• You are able to place a phone call using your DPH153 3G Small Cell.
Contact your service provider for additional details.
Having Trouble?
1. Is your Internet connection up and running and connected?
2. Is your DPH153 3G Small Cell indicator solid green?
3. Contact your service provider if you need help.
Power On Your Device
Connect your DPH153 3G Small Cell to a
power outlet with the AC power adapter.
The Power light on the front of the device will
come on immediately.
Package Contents
• DPH153 3G Small Cell • AC power adapter • User Guide
• Yellow ethernet cable • Quick Reference Guide
Front Panel Back Panel
Before You Begin
• Plan your installation location – your device should be:
- At least one foot away from other wireless broadcasting devices to avoid possible
interference.
- Where you can connect your DPH153 3G Small Cell to your Internet equipment.
• Equipment and setup time may vary. Contact your service provider for instructions.
Connect Your Device
to the Internet
Connect the yellow ethernet cable from the
“Ethernet” port on your DPH153 3G Small
Cell to your router.
Serial # (S/N)
Serial Number (S/N) Tip
Write down your DPH153 3G Small Cell’s serial number; you’ll need it for online activation and
future reference. It can be found on the bottom of the device or on the box label.
Reset
Ethernet
Power
Back of Router
T15587
Reset
Ethernet
Power
To Wall Outlet
T15588
Ethernet
Power
Reset
Ethernet
Power
Reset
Ethernet
Power
Reset
T15583
Ethernet
Reset
Power
Power
Ethernet
Location
3G
T15582
Power
Ethernet
Location
3G
T15586
Model: DPH153
P/N: 74-11121-01
CSN: 123456789
FCC ID: MXF-DPH153AT
HW Version: 1.0
Rating: 12V 0.8A
Tested To Comply
With FCC Standards
For Home or Office Use
LISTED
I.T.E.
E218211
S/N: FFAA11-123456789C
MAC: XXXXXXXXXXXX
Date Code: 07/08
Factory ID: ks001
MADE IN CHINA
Serial Number
