Users Manual

www.philips.com/support

User manual

Always there to help you

Question?

Contact

Philips

1EN

Contents

1 Important 2

Important safety instructions 2

Care for your product 3

Care of the environment 3

Help and support 4

2 Your SoundBar 5

Main unit 5

Remote control 5

Wireless portable speakers 6

Wireless subwoofer 7

Connectors 7

3 Connect and set up 9

Charge portable speakers 9

Pair up with subwoofer/speakers 9

Place speakers 10

Connect audio from TV 10

Connect audio from other devices 12

Connect digital devices through HDMI 13

4 Spatial calibration 14

Step 1: calibrate the listening zone 14

Step 2: calibrate the surround speaker

position 14

5 Use your SoundBar 16

Adjust the volume 16

Choose your sound 16

MP3 player 17

Play music via Bluetooth 17

Connect Bluetooth via NFC 18

Auto standby 19

Set display brightness 19

Apply factory settings 19

6 Update software 20

Check software version 20

Update software via USB 20

7 Wall mount your SoundBar 21

Wall mount 21

 3URGXFWVSHFLÀFDWLRQV 22

9 Troubleshooting 23

10 Notice 25

Notice of compliance 25

Trademarks 25

2 3ENEN

• If you suspect that a battery has been

swallowed or placed inside any part of the

body, seek immediate medical attention.

• When you change the batteries, always

keep all new and used batteries out of

reach of children. Ensure that the battery

compartment is completely secure after

you replace the battery.

• If the battery compartment cannot be

completely secured, discontinue use of the

product. Keep out of reach of children and

contact the manufacturer.

• Apparatus shall not be exposed to

dripping or splashing.

• Do not place any sources of danger on

the apparatus IRUH[DPSOHOLTXLGÀOOHG

objects, lighted candles).

•This apparatus may contain lead and

mercury. Dispose according to local, State

or Federal laws. For disposal or recycling

information, please contact your local

authorities. For additional assistance on

recycling options, please contact www.

mygreenelectronics.com or www.eiae.org

or www.recycle.philips.com.

•Where the MAINS plug or an appliance

coupler is used as the disconnect device,

the disconnect device shall remain readily

operable.

•Do not place this apparatus on the

furniture that is capable of being tilted by a

child and an adult leaning, pulling, standing

or climbing on it. A falling apparatus can

cause serious injury or even death.

• This apparatus should not be placed in a

built-in installation such as a bookcase or

rack unless proper ventilation is provided.

Make sure to leave a space of 7.8 inches

(20cm) or more around this apparatus.

Class II equipment symbol

This symbol indicates that the unit has a double

insulation system.

This 'bolt of lightning' indicates uninsulated

material within your unit may cause an electrical

shock. For the safety of everyone in your

household, please do not remove product

covering.

The 'exclamation point' calls attention to

features for which you should read the enclosed

literature closely to prevent operating and

maintenance problems.

WARNING:7RUHGXFHWKHULVNRIÀUHRU

electric shock, this apparatus should not be

H[SRVHGWRUDLQRUPRLVWXUHDQGREMHFWVÀOOHG

with liquids, such as vases, should not be placed

on this apparatus.

CAUTION: To prevent electric shock, match

wide blade of plug to wide slot, fully insert.

Care for your product

8VHRQO\PLFURÀEHUFORWKWRFOHDQWKHSURGXFW

Care of the environment

Disposal of your old product and battery

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

This product may contain lead and mercury.

Disposal of these materials may be regulated

due to environmental considerations. For

disposal or recycling information, please contact

1 Important

Read and understand all instructions before you

use your product. If damage is caused by failure

to follow instructions, the warranty does not

apply.

Important safety instructions

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings.

Install in accordance with the

manufacturer's instructions.

• Do not install near any heat sources

such as radiators, heat registers, stoves, or

RWKHUDSSDUDWXVLQFOXGLQJDPSOLÀHUVWKDW

produce heat.

• Do not defeat the safety purpose of

the polarized or grounding-type plug. A

polarized plug has two blades with one

wider than the other. A grounding type

plug has two blades and a third grounding

prong. The wide blade or the third prong

are provided for your safety. If the provided

SOXJGRHVQRWÀWLQWR\RXURXWOHWFRQVXOW

an electrician for replacement of the

obsolete outlet.

• Protect the power cord from being

walked on or pinched, particularly at plugs,

convenience receptacles, and the point

where they exit from the apparatus.

• Only use attachments/accessories

VSHFLÀHGE\WKHPDQXIDFWXUHU

• Use only with the cart, stand, tripod,

EUDFNHWRUWDEOHVSHFLÀHGE\WKH

manufacturer or sold with the apparatus.

When a cart is used, use caution when

moving the cart/apparatus combination to

avoid injury from tip-over.

• Unplug this apparatus during lightning

storm or when unused for long periods of

time.

• Refer all servicing WRTXDOLÀHGVHUYLFH

personnel. Servicing is required when

the apparatus has been damaged in any

way, such as power-supply cord or plug

is damaged, liquid has been spilled or

objects have fallen into the apparatus, the

apparatus has been exposed to rain or

moisture, does not operate normally, or

has been dropped.

• Battery usage CAUTION - To prevent

battery leakage which may result in bodily

injury, property damage, or damage to the

unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove batteries when the unit is not

used for a long time.

• The batteries shall not be exposed to

H[FHVVLYHKHDWVXFKDVVXQVKLQHÀUHRU

the like.

• Perchlorate Material - special handling

may apply. See www.dtsc.ca.gov/

hazardouswaste/perchlorate.

• The product/remote control may contain

a coin/button type battery, which can be

swallowed. Keep the battery out of reach

of children at all times! If swallowed, the

battery can cause serious injury or death.

Severe internal burns can occur within two

hours of ingestion.

4 5ENEN

2 Your SoundBar

Congratulations on your purchase, and

ZHOFRPHWR3KLOLSV7RIXOO\EHQHÀWIURP

the support that Philips offers, register your

SoundBar at www.philips.com/welcome.

Main unit

This section includes an overview of the main

unit.

a Display panel

b (Standby-On/Standby indicator)

When the SoundBar is in standby, the

standby indicator turns red.

c NFC tag

ap the NFC-enabled device on the tag for

Bluetooth connection.

Remote control

This section includes an overview of the

remote control.

ab c

Switch the SoundBar on or to standby.

b Source buttons

• HDMI ARC: Switch your source to

HDMI ARC connection.

• HDMI 1: Switch your source to the

HDMI IN 1 connection.

• HDMI 2: Switch your source to the

HDMI IN 2 connection.

• COAX: Switch your audio source to

the coaxial connection.

• OPTICAL: Switch your audio source

to the optical connection.

• AUDIO IN: Switch your audio source

to the MP3 connection (3.5mm jack).

• : For Bluetooth on the main unit only:

Switch to Bluetooth mode.

• AUX: Switch your audio source to the

AUX connection.

your local authorities or visit www.recycle.

philips.com.

This product contains non-removable batteries:

• Do not incinerate. Batteries may explode if

overheated.

• For disposal or recycling information,

please contact your local authorities or visit

www.recycle.philips.com.

Help and support

For extensive online support, visit www.philips.

com/support to:

• download the user manual and the quick

start guide

• watch video tutorials (available only for

selected models)

• ÀQGDQVZHUVWRIUHTXHQWO\DQVZHUHG

questions (FAQs)

• email us a question

• chat with our support representative.

Follow the instructions on the website to select

your language, and then enter your product

model number.

Alternatively, you can contact Consumer Care

in your country. Before you contact, note down

the model number and serial number of your

SURGXFW<RXFDQÀQGWKLVLQIRUPDWLRQRQWKH

back or bottom of your product.

6 7ENEN

portable speakers docked into the

main unit).

d SURROUND ON DEMAND button/LED

• Press to switch the portable speaker

to SURROUND ON DEMAND

mode.

• The LED lights up white when the

portable speaker is switched to

SURROUND ON DEMAND mode.

e button/LED

• Press to switch the portable speaker

to Bluetooth mode.

• The LED blinks when you switch the

portable speaker to Bluetooth and no

Bluetooth devices are connected.

• The LED lights up when you switch

the portable speaker to Bluetooth and

Bluetooth devices are connected.

Note

• If you press the button on the portable speaker,

the portable speaker disconnects the main unit (or

SURROUND ON DEMAND mode switches off).

Wireless subwoofer

The SoundBar comes with a wireless subwoofer.

a CONNECT (connect)

Press to to enter the pairing mode for the

subwoofer.

b Subwoofer indicator

• When the power is turned on, the

indicator lights up.

• During wireless pairing between the

subwoofer and the main unit, the

indicator blinks white quickly.

• When the pairing succeeds, the

indicator lights up white.

• When the pairing fails, the indicator

blinks white slowly.

c AC MAINS~

Connect to the power supply.

Connectors

This section includes an overview of the

connectors available on your SoundBar.

a AUDIO-IN

Audio input from, for example, an MP3

player (3.5mm jack).

b AUX-AUDIO IN L/R

Connect to an analog audio output on the

TV or an analog device.

c DIGITAL IN-COAXIAL

Connect to a coaxial audio output on the

TV or a digital device.

d (SERVICE)

&RQQHFWD86%ÁDVKGULYHWRXSJUDGH

software of this product (not for media

play).

e DIGITAL IN-OPTICAL

a c d e g hb f

c /

For Bluetooth on the main unit only: skip

to the previous or next track.

For Bluetooth on the main unit only: play,

pause or resume.

e BASS +/-

Increase or decrease bass on the main unit.

f Volume control

• +/-: Increase or decrease volume.

• : Mute or restore volume.

g VOICE

• Press to select voice clarity sound

mode.

• Press and hold to toggle on or off

CLOSE TO ME (close to me) sound

mode.

h MUSIC

Select stereo sound mode.

i REAR VOL.+/-

Press to increase or decrease volume of

the portable left and right speakers (only

applicable when the portable left and

right speakers are wirelessly connected

to the main unit (or SURROUND ON

DEMAND mode switches on)).

j AUDIO SYNC +/-

Increase or decrease audio delay.

k NIGHT

Turn night mode on or off.

l AUTO VOL.

Turn auto volume on or off.

m CALIBRATION

• Press and hold to trigger calibration for

listening zone.

• Press three times to trigger calibration

for the portable left and right speakers

position.

n DIM

Set the brightness of SoundBar display

panel.

o MOVIE

Select surround sound mode.

p TREBLE +/-

Increase or decrease treble on the main

unit.

Wireless portable speakers

The SoundBar comes with two wireless

portable speakers (left and right).

* The illustration above is for overview of the

portable left speaker.

a Reset key

Press with a pin to reset the portable

speaker to the default settings.

b ON

• Press to turn on the portable speaker

if it automatically goes to standby.

• Press and hold to switch the portable

speaker to standby.

c Speaker LED

• Blinks in red and orange alternatively

if the portable speaker is not wirelessly

connected to the main unit.

• Lights up white when the portable

speaker is wirelessly connected to the

main unit, or when the battery capacity

is full or more than 30% remaining.

• Lights up red when the battery

capacity is less than 30% remaining .

• Blinks red when the battery capacity is

less than 10% remaining.

• Lights up orange when the portable

speaker is being charged (only for the

b ea dc

8 9ENEN

3 Connect and set

This section helps you connect your SoundBar

to a TV and other devices, and then set it up.

For information about the basic connections of

your SoundBar and accessories, see the quick

start guide.

Note

• )RULGHQWLÀFDWLRQDQGVXSSO\UDWLQJVVHHWKHW\SHSODWH

at the back or bottom of the product.

• Before you make or change any connections, make sure

that all devices are disconnected from the power outlet.

Charge portable speakers

If the portable left/right speaker is undocked

from the main unit, its battery level is indicated

by the LED on the speaker.

• Light up white: full battery or more than

30% capacity remaining

• Light up red: low battery level, less than

30% remaining

• Flash red: near empty, less than 10%

remaining

1 Dock your portable speakers into the main

unit to charge.

2 Turn on the main unit.

» During charging, the LED on the

portable speaker lights up orange.

» When fully charged, the LED on the

portable speaker lights up white for 10

seconds.

Note

• It may take around two hours to fully charge the

portable speakers.

• Battery performance varies due to many factors

including volume, sound setting and media played.

Pair up with subwoofer/

speakers

The wireless speakers and subwoofer

automatically pair up with the SoundBar for

wireless connection when you turn on the

SoundBar, the portable speakers and the

subwoofer.

If no audio from the wireless speakers and

subwoofer can be heard, manually pair up the

portable speakers and the subwoofer.

Pair up with the subwoofer

1 Turn on the SoundBar and the subwoofer.

» If the connection to the SoundBar is

lost, the indicator on the subwoofer

blinks white slowly.

2 Press the CONNECT (connect) button

on the subwoofer to enter the pairing

mode.

» The indicator on the subwoofer blinks

white quickly.

3 In OPTICAL mode (press OPTICAL) ,

within six seconds, on the remote control,

press twice then Volume + once, and

then hold down BASS +.

» If the pairing succeeds, the indicator on

the subwoofer lights up white.

» If the pairing fails, the indicator on the

subwoofer blinks white slowly.

Connect to an optical audio output on the

TV or a digital device.

f HDMI IN1 / HDMI IN2

Connect to the HDMI output on a digital

device.

g TO TV-HDMI OUT (ARC)

Connect to the HDMI (ARC) input on the

TV.

h AC MAINS~

Connect to the power supply.

10 11ENEN

What you need

• A High Speed HDMI Cable.

• Your TV supports both HDMI ARC and

HDMI-CEC (see the TV user manual for

details).

• For some TV models, enable the external

speaker output from the TV setting menu

(see the TV user manual for details).

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on this

product to the HDMI ARC connector on

the TV.

• The HDMI ARC connector on the TV

might be labeled differently. For details,

see the TV user manual.

2 On your TV, turn on HDMI-CEC

operations.

• For HDMI-CEC issues on your TV, see

the TV user manual to make sure that

the HDMI-CEC setup is correct, or

contact the TV manufacturer if needed.

3 Press HDMI ARC on the remote control

of this product to enable the HDMI ARC

connection.

Note

• 100% interoperability with all HDMI-CEC devices is not

guaranteed.

• If your TV is not HDMI ARC compliant, connect an

audio cable to hear the TV audio through this product.

Option 2: Connect to TV through

optical cable

Best quality audio

1 Using an optical cable, connect the

OPTICAL connector on this product to

the optical output on the TV.

• The digital optical output on the TV

might be labeled OPTICAL OUT,

SPDIF or SPDIF OUT.

2 Press OPTICAL on the remote control

of this product to enable the optical

connection.

Option 3: Connect to TV through

coaxial cable

Best quality audio

1 Using a coaxial cable, connect the

COAXIAL connector on this product to

the coaxial output on the TV.

• The digital coaxial output on the TV

might be labeled COAXIAL/DIGITAL

OUT or DIGITAL AUDIO OUT.

2 Press COAX on the remote control of this

product to enable the coaxial connection.

Option 4: Connect to TV through

analog audio cables

Basic quality audio

4 If the pairing fails, repeat the steps above.

Pair up with the speakers

1 Turn on the SoundBar and the portable

speakers.

» If the connection to the SoundBar is

lost, the LED on the portable blinks in

red and orange alternatively.

2 Dock the portable left and right speakers

into the main unit to pair up automatically.

3 If the pairing fails, re-dock the portable

speakers into the main unit.

Place speakers

For best sound effect, position all the speakers

towards the seating position and place them

close to your ear level (seated).

Note

• Surround sound depends on factors such as room

shape and size, type of wall and ceiling, windows nd

UHÁHFWLYHVXUIDFHVDQGVSHDNHUDFRXVWLFV([SHULPHQW

ZLWKWKHVSHDNHUSRVLWLRQVWRÀQGWKHRSWLPXPVHWWLQJ

for you.

SUB

WOOFER

REAR R

REAR L

Follow these general guidelines for speakers

placement.

1 Seating position:

This is the center of your listening area.

2 Place the SoundBar in front of the seating

position.

3 REAR L (rear left) and REAR R (rear right):

Place the portable speakers (surround)

to the left and right side of your seating

position, either in line with it or slightly

behind it.

4 SUBWOOFER (subwoofer):

Place the subwoofer at least one meter

to the left or right of the TV. Leave about

10-centimeter clearance from the wall.

Dock the portable speakers

You can also dock the portable left and right

speakers into the main unit to listen to audio,

for example, watching TV shows and news.

Connect audio from TV

Connect this product to a TV. You can listen to

audio from TV programs through the speakers

of this product.

Option 1: Connect to TV through

HDMI (ARC)

Best quality audio

This product supports HDMI with Audio

Return Channel (ARC). With the ARC feature,

you can hear the TV audio through this product

by using a single HDMI cable.

12 13ENEN

• The analog audio output on the

external device might be labeled

AUDIO OUT.

2 Press AUX on the remote control of

this product to enable the analog audio

connection.

Connect digital devices

through HDMI

Connect a digital device such as a set-top box,

DVD/Blu-ray player, or games console to this

product through a single HDMI connection.

When you connect the devices in this way and

SOD\DÀOHRUJDPHWKH

• video is automatically displayed on your

TV, and

• audio is automatically played on this

product.

1 Using a High Speed HDMI cable, connect

the HDMI OUT connector on your digital

device to the HDMI IN on this product.

2 Connect this product to TV through HDMI

OUT (ARC).

• If the TV is not HDMI CEC compliant,

select the correct video input on your

TV.

3 On the connected device, turn on HDMI-

CEC operations.

• For HDMI-CEC issues on your TV, see

the TV user manual and ensure the

HDMI-CEC setup is correct, or contact

the TV manufacturer if needed.

4 Press HDMI IN on the remote control

of this product to enable the HDMI IN

connection.

1 Using an analog audio cable, connect the

AUX connectors on this product to the

analog audio output on the TV.

• The analog audio output on the TV

might be labeled AUDIO OUT.

2 Press AUX on the remote control of

this product to enable the analog audio

connection.

Connect audio from other

devices

You may also play audio from other devices

through the speakers of this product.

Option 1: Connect to other device

through optical cable

Best quality audio

1 Using an optical cable, connect the

OPTICAL connector on this product to

the optical output on the external device.

• The digital optical output on the

external device might be labeled

OPTICAL OUT, SPDIF or SPDIF

OUT.

DVD

2 Press OPTICAL on the remote control

of this product to enable the optical

connection.

Option 2: Connect to other device

through coaxial cable

Best quality audio

1 Using a coaxial cable, connect the

COAXIAL connector on this product to

the coaxial output on the external device.

• The digital coaxial output on the

external device might be labeled

COAXIAL/DIGITAL OUT or

DIGITAL AUDIO OUT.

2 Press COAX on the remote control of this

product to enable the coaxial connection.

Option 3: Connect to other device

through analog audio cables

Basic quality audio

1 Using an analog audio cable, connect

the AUX connector on this product to

the analog audio output on the external

device.

14 15ENEN

• Make sure that the portable left and

right speakers are wirelessly connected

to the main unit (press SURROUND

ON DEMAND on the speaker).

2 Press CALIBRATION once to trigger

calibration.

• Press CALIBRATIONthree times to

trigger calibration if you re-locate the

portable left and right speakers and

skip Step 1 (calibrate the listening

zone) after you completed a round of

spatial calibration previously.

» You can hear the calibration tones

from the portable speakers.

3 Wait until the calibration tones end.

» If the calibration succeeds, DONE

(done) is displayed on the display

panel. And the new settings are stored.

Note

• Spatial calibration takes around three minutes.

• Surround sound improvement is only noticeable if

the portable left and right speakers (surround) were

improperly placed, or if there is strong surround effect

in the music you play.

• If the portable left and right speakers are swapped in

placement, during calibration L<->R is displayed for few

seconds, then the calibration completes.

• During calibration, you may press CALIBRATION

to cancel calibration, and the settings returns to the

default.

• If the spatial calibration fails, an error message is

displayed on the display panel, such as FAIL (fail), and

the settings returns to the default.

• If the spatial calibration fails, try the spatial calibration

again, and make sure that the calibration points

described at the beginning of this chapter are fully met.

4 Spatial

calibration

Spatial calibration is used to achieve the

following convenience, and simultaneously

optimizes surround sound experience for it.

• Have freedom to place the portable left

and right speakers (surround) according to

your need.

• Automatically balance the portable

speakers (surround) with respect to your

seating position.

The spatial calibration involves two steps.

• Step 1: calibrate the listening zone

• Step 2: calibrate the surround speaker

position

When to calibrate

• If you perform spatial calibration for the

ÀUVWWLPHSHUIRUPStep 1 and Step 2 in

sequence.

• If you re-design your seating layout,

perform Step 1 and Step 2 in sequence.

• If you re-locate the portable left and right

speakers (surround), perform Step 2

independently (Step 1 can be skipped).

Before you start

• Make sure that the room is fairly quiet.

• Place the portable left and right speakers

angled towards the main unit.

• Make sure that the main unit, the portable

left and right speakers can fully "see" each

other, no obstacle between them blocking

such view. Stand the portable speakers

upright if needed.

• The minimum distance between the

portable speakers and the main unit is

0.8m (2.6'), the maximum distance 6m

(20').

Step 1: calibrate the listening

zone

1 Place the portable left and right speakers

on two seating positions you prefer most

(such as on a sofa).

• Make sure that the portable left and

right speakers are wirelessly connected

to the main unit (press SURROUND

ON DEMAND on the speaker).

2 Press and hold CALIBRATION on the

remote control for three seconds to

trigger calibration.

» ZONE (zone) is displayed on the

display panel.

» You can hear the calibration tones

from the portable speakers.

3 Wait until the calibration tones end.

» ->SPKR (speaker) is displayed on the

display panel.

4 Then perform the following Step 2

(calibrate the surround speaker position)

to complete and store the new settings.

Step 2: calibrate the surround

speaker position

1 Place the portable left and right speakers

(surround) on the position you prefer.

16 17ENEN

It also compresses the sound dynamics,

increasing the volume for quiet scenes and

decreasing the volume for loud scenes.

1 Press AUTO VOL. to turn auto volume on

or off.

» When auto volume is turned on, ON

AUTO scrolls once on the display

panel.

» When auto volume is turned off, OFF

AUTO scrolls once on the display

panel.

Synchronize video and sound

If the audio and video are not synchronized,

delay the audio to match the video.

1 Press AUDIO SYNC +/- to synchronize

the audio with the video.

• AUDIO SYNC + increases the sound

delay, and AUDIO SYNC - decreases

the sound delay.

Night mode

For quiet listening, night mode decreases the

volume of loud sounds when audio is played.

Night mode is only available for Dolby Digital

soundtracks.

1 Press NIGHT to turn night mode on or

off.

» When night mode is turned on, ON

NIGHT scrolls once on the display

panel.

» When night mode is turned off, OFF

NIGHT scrolls once on the display

panel.

Note

• If auto volume is set to turned on, you cannot enable

the night mode.

MP3 player

Connect your MP3 player to play your audio

ÀOHVRUPXVLF

What you need

• An MP3 player.

• A 3.5mm stereo audio cable.

1 Using the 3.5mm stereo audio cable,

connect the MP3 player to the AUDIO IN

connector on your SoundBar.

2 Press AUDIO IN.

3 Press the buttons on the MP3 player to

VHOHFWDQGSOD\DXGLRÀOHVRUPXVLF

• On the MP3 player, it is recommended

to set the volume in the range of 80%

maximum volume.

Play music via Bluetooth

Through Bluetooth, connect the SoundBar with

your Bluetooth device (such as an iPad, iPhone,

iPod touch, Android phone, or laptop), and then

\RXFDQOLVWHQWRWKHDXGLRÀOHVVWRUHGRQWKH

device through your SoundBar speakers.

What you need

• A Bluetooth device which supports

%OXHWRRWKSURÀOH$'3DQGZLWK%OXHWRRWK

version as 2.1 + EDR.

• The maximum operational range between

the SoundBar and a Bluetooth device is

approximately 10 meters (30 feet).

Note

• The music streaming may be interrupted by obstacles

between the device and this product, such as wall,

metallic casing that covers the device, or other devices

nearby that operate in the same frequency.

• If you want to connect this product with another

Bluetooth device, break the current Bluetooth

connection.

5 Use your

SoundBar

This section helps you use the SoundBar to play

audio from connected devices.

Before you start

• Make the necessary connections described

in the quick start guide and the user

manual.

• Switch the SoundBar to the correct source

for other devices.

Adjust the volume

1 Press +/- (Volume) to increase or decrease

a volume level.

• To mute sound, press .

• To restore the sound, press again or

press +/- (Volume).

For the portable left and right speakers only

1 When the portable left and right speakers

are wirelessly connected to the main

unit (in SURROUND ON DEMAND

mode), press REAR VOL.+/- to increase or

decrease a volume level.

Choose your sound

This section helps you choose the ideal sound

for your video or music.

Surround sound mode

Experience an immersive audio experience with

surround sound modes.

• Press MOVIE to create a surround listening

experience. Ideal for watching movie.

• Press MUSIC to create stereo sound. Ideal

for listening to music.

Voice clarity

It makes human voice more clear and

outstanding for listening.

1 Press VOICE to switch to voice clarity.

» When voice clarity is turned on,

VOICE is displayed.

2 To exit this sound mode, press MOVIE or

MUSIC to select other sound mode.

CLOSE TO ME (close to me)

For ultimate clear sound without disturbing

your neighbors, place both the portable left and

right speakers close to you, and activate this

feature (to mute the main unit).

Note

• It is applicable only when the portable left and right

speakers are wirelessly connected to the main unit (or

SURROUND ON DEMAND mode switches on).

• If CLOSE TO ME (close to me) is turned on, the

functions for MOVIE and MUSIC buttons are disabled.

1 Press and hold VOICE for three seconds

to activate the feature.

» CLOSE TO ME (close to me) scrolls

once on the display panel.

» The main unit is muted.

2 To exit this sound mode, press and hold

VOICE again for three seconds.

» The previous sound mode switches in.

Equalizer

Change the high frequency (treble) and low

frequency (bass) settings of the SoundBar.

1 Press TREBLE +/- or BASS +/- to change

the frequency.

Auto volume

Turn the auto volume on to keep the volume

constant when you switch to a different source.

18 19ENEN

• For pairing, tap the NFC device on the

NFC tag of the main unit.

Note

• NFC feature is only available to the main unit, not

available to the portable left and right speakers.

1 Enable NFC on the Bluetooth device (see

the device' s user manual for details).

2 Tap the NFC device onto the NFC tag of

the main unit until the SoundBar beeps.

• )RUÀUVWWLPHFRQQHFWLRQRQVRPH

mobile devices prompt for pair-up

appears, select "YES" for connection.

» When the Bluetooth connection

succeeds, BT is displayed on the display

panel.

» If the connection fails, BT on the

display panel blinks continuously.

3 6HOHFWDQGSOD\DXGLRÀOHVRUPXVLFRQ

your NFC device.

• To break the connection, tap again the

NFC device onto the NFC tag on the

main unit.

Auto standby

When playing media from a connected device,

the SoundBar automatically switches to standby

if:

• no source button is pressed for 15

minutes, and

• no audio/video playback is detected from a

connected device.

Set display brightness

You can press DIM repeatedly to select a

different brightness level of the display panel on

this product.

• If you select DIM O (dim) on the display,

the display turns off after 10 seconds each

time you press a button on the remote

control.

Apply factory settings

You can reset this product to the default

settings programmed at the factory.

1 In AUX mode, on the remote control

press Volume -, BASS -, and TREBLE - in

sequence within three seconds.

» When the factory settings restore is

complete, the product automatically

switches off and restarts.

Bluetooth on the main unit

1 Press on the remote control to switch

the main unit to Bluetooth mode.

» BT on the display blinks.

2 On the Bluetooth device, switch on

Bluetooth, search for and select Fidelio B5

to start connection (see the user manual

of the Bluetooth device on how to enable

Bluetooth).

» During connection, BT on the display

blinks.

3 Wait until BT on the display lights up.

» If the connection succeeds, BT on the

display lights up.

» If the connection fails, BT on the

display blinks.

4 6HOHFWDQGSOD\DXGLRÀOHVRUPXVLFRQ

your Bluetooth device.

• During play, if a call is coming, music

play is paused.

• If music streaming is interrupted, place

the Bluetooth device closer to the

main unit.

5 To exit Bluetooth, select other source.

» When you switch back to Bluetooth

mode, Bluetooth connection resumes.

• To break the current Bluetooth

connection, press and hold on the

remote control.

Bluetooth on a single speaker

You can use the portable left or the portable

right speaker as a standalone Bluetooth speaker,

independently from the main unit.

1 Press the button on the left or right

speaker to switch to Bluetooth mode.

» The LED on the left or right speaker

blinks.

2 On the Bluetooth device, switch on

Bluetooth, search for and select the

name of the left or right speaker to start

connection (see the user manual of the

Bluetooth device on how to enable

Bluetooth).

• B5 -L portable stands for the portable

left speaker, B5 -R portable for the

portable right speaker.

» During connection, the LED on the

left or right speaker blinks.

3 Wait until the LED on the portable

speaker lights up.

» If the connection succeeds, connection

tone is heard, and the LED on the

portable speaker lights up.

» If the connection fails, the LED on

the portable speaker blinks.

4 6HOHFWDQGSOD\DXGLRÀOHVRUPXVLFRQ

your Bluetooth device.

• During play, if a call is coming, music

play is paused.

• If music streaming is interrupted, place

the Bluetooth device closer to the

main unit.

5 To exit Bluetooth, press the SURROUND

ON DEMAND button on the speaker.

» When you switch back to Bluetooth

mode, Bluetooth connection resumes.

• To break the current Bluetooth

connection, press and hold the

button on the speaker.

Note

• The function of the remote control is not available to

a standalone Bluetooth speaker (the portable left or

right speaker).

Connect Bluetooth via NFC

NFC (Near Field Communication) is a

technology that enables short-range wireless

communication between NFC-enabled devices,

such as mobile phones.

What you need

• A Bluetooth device with NFC function.

20 21ENEN

7 Wall mount

your SoundBar

Before you mount your SoundBar on the wall,

read all safety precautions.

Wall mount

Note

• You must detach the portable speakers from the main

unit before wall mounting or un-mounting.

• Improper wall mounting may result in accident, injury or

damage. If you have any query, contact Consumer Care

in your country.

• Secure the wall mount to a wall that can support the

combined weight of the product and the wall mount.

• Before wall mount, you need not remove the four

rubber feet at the bottom of the soundbar, otherwise

WKHUXEEHUIHHWFDQQRWEHÀ[HGEDFN

Screw length/diameter

Depend on the type of wall mounting this wall

mount bracket, make sure that you use screws

of a suitable length and diameter.

See the illustration on the separate wall mount

sheet on how to wall mount the SoundBar.

1) Drill holes on the wall.

2) Secure the wall bracket on the wall with the

dowels and screws.

3) Hang the SoundBar on the wall bracket.

> 25mm

3 - 3.5mm

6 Update software

To get the best features and support, update

your product with the latest software.

What you need

• $86%ÁDVKGULYHWKDWLV)$7IRUPDWWHG

Do not use a USB hard drive.

• A computer with Internet access.

• $QDUFKLYHXWLOLW\WKDWVXSSRUWVWKH=,3ÀOH

format.

Check software version

In HDMI ARC source, on the remote control

press TREBLE -, BASS -, and Volume - in

sequence within three seconds.

» The software version number is

displayed on the display panel.

Update software via USB

1 Check the latest software version on www.

philips.com/support.

• Search for your model and click on

"Software and drivers".

2 'RZQORDGWKHVRIWZDUHLQWRD86%ÁDVK

drive.

a Unzip the download if zipped, and

make sure that the unzipped folder is

named "UPG".

b Put the "UPG" folder in the root

directory.

3 &RQQHFWWKH86%ÁDVKGULYHWRWKH

(SERVICE) connector on this product.

4 Switch this product to HDMI ARC source

(press HDMI ARC).

5 On the remote control, within 6 seconds

press twice then Volume + once, and

then hold down MOVIE.

» Then "UPG" (upgrade) is displayed on

the display panel.

6 Wait until the upgrade is completed.

» If the upgrade is complete, this product

automatically turns off and on again.

Caution

• 'RQRWWXUQRIIWKHSRZHURUUHPRYHWKH86%ÁDVK

drive when the software update is in progress because

you might damage this product.

• The upgrade time may take around eight minutes.

22 23ENEN

9 Troubleshooting

Warning

• Risk of electric shock. Never remove the casing of the

product.

To keep the warranty valid, never try to repair

the product yourself.

If you have problems using this product, check

the following points before you request service.

If you still have a problem, get support at www.

philips.com/support.

Sound

No sound from the speakers of this product.

• Connect the audio cable from this product

to your TV or other devices. However, you

do not need a separate audio connection

when:

• This product and

TV are connected

through HDMI ARC connection, or

• a device is connected to the HDMI IN

connector on this product.

• Make sure that you connect the audio

input on this product to the audio output

on your TV or other devices.

• On the remote control, select the correct

audio input.

• Reset this product to its factory settings.

• Make sure that this product is not muted.

No sound from the wireless portable

speakers.

• Make sure that the wireless portable

speaker is turned on. Press ON on the

bottom of the wireless portable speaker.

• Dock the wireless portable speakers into

the main unit to charge the battery.

• If you intend the wireless portable speaker

to wirelessly connect to the main unit,

make sure that you press the SURROUND

ON DEMAND button on the wireless

portable speaker.

• If you intend the wireless portable speaker

to be a standalone Bluetooth speaker,

make sure that you connect the portable

left or right speaker to a Bluetooth device

(see 'Bluetooth on a single speaker' on

page 18).

No sound from the wireless subwoofer.

• Wirelessly connect the subwoofer to the

main unit.

Distorted sound or echo.

• If you play audio from the TV through the

SoundBar, make sure that the TV is muted.

Audio and video are not synchronized.

• Press AUDIO SYNC +/- to synchronize

the audio with the video.

Bluetooth

A device cannot connect with the SoundBar.

• The device does not support the

FRPSDWLEOHSURÀOHVUHTXLUHGIRUWKH

SoundBar.

• You have not enabled the Bluetooth

function of the device. See the user manual

of the device on how to enable the

function.

• The device is not correctly connected.

Connect the device correctly.

• The SoundBar is already connected with

another Bluetooth device. Disconnect the

connected device, then try again.

Quality of audio play from a connected

Bluetooth device is poor.

• The Bluetooth reception is poor. Move the

device closer to the SoundBar, or remove

any obstacle between the device and the

SoundBar.

The connected Bluetooth device connects and

disconnects constantly.

• The Bluetooth reception is poor. Move the

device closer to the SoundBar, or remove

any obstacle between the device and the

SoundBar.

• Turn off Wi-Fi function on the Bluetooth

device to avoid interference.

• For some Bluetooth, the Bluetooth

connection can be deactivated

8 Product

specifications

Note

• 6SHFLÀFDWLRQVDQGGHVLJQDUHVXEMHFWWRFKDQJHZLWKRXW

notice.

$PSOLÀHU

• FTC total output power: 66W

• Front Left + Right: 16W (1%THD,

8ohm, 150Hz-20kHz)

• Surround Left + Right: 20W (1%THD,

8ohm, 150Hz-20kHz)

• Subwoofer: 30W (1%THD, 4ohm,

30Hz-140Hz)

• Total output power: 210W RMS (+/- 0.5

dB, 30% THD) / 168W RMS (+/- 0.5 dB,

10% THD)

• Frequency response: 20 Hz-20 kHz / ±3

• Signal-to-noise ratio: > 65 dB (CCIR) /

(A-weighted)

• Input sensitivity:

• AUX: 750 mV

• AUDIO IN: 400 mV

Audio

• S/PDIF Digital audio input:

• Coaxial: IEC 60958-3

• Optical: TOSLINK

Bluetooth

•%OXHWRRWKSURÀOHV$'3

•Bluetooth version: 2.1 + EDR

Main unit

•Power supply: 110-240 V~, 50-60 Hz

•Power consumption: 50 W

•6WDQGE\SRZHUFRQVXPSWLRQ:

•Dimensions (WxHxD): 1035 x 73 x 156

mm (with portable left and right speakers

attached)

•Weight: 4.4 kg

• Built-in speakers

• 2 x woofer (76 mm/3", 8 ohm)

• 2 x tweeter (25.4 mm/1", 8 ohm)

Portable speakers

• Speaker impedance: 8 ohm

• Speaker drivers: 2 x 76 mm (3") full range

• Dimensions (WxHxD): 191 x 73 x 156

• Weight: 0.86 kg/each

Subwoofer

• Power supply: 110-240 V~, 50-60 Hz

• Power consumption: 30 W

• 6WDQGE\SRZHUFRQVXPSWLRQ:

• Impedance: 4 ohm

• Speaker drivers: 1 x 165 mm (6.5") woofer

• Dimensions (WxHxD): 200 x 510 x 201

• Weight: 4.9 kg

Wall mount

•Dimensions (WxHxD): 40 x 100 x 26.5

•Weight: 0.1 kg/each

Remote control batteries

• 2 x AAA-R03-1.5 V

24 25ENEN

10 Notice

This section contains the legal and trademark

notices.

Notice of compliance

The device complies with the FCC rules, Part

15. Operation is subject to the following two

conditions:

a This device may not cause harmful

interference, and

b This device must accept any interference

received, including interference that may

cause undesired operation.

FCC rules

This equipment has been tested and found

to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference in a

residential installation. This equipment generates,

uses and can radiate radio frequency energy

and, if not installed and used in accordance

with the instruction manual, may cause harmful

interference to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception,

which can be determined by turning the

equipment off and on, the user is encouraged

to try to correct the interference by one or

more of the following measures:

• Relocate the receiving antenna.

• Increase the separation between

equipment and receiver.

• Connect the equipment into an outlet on

a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced

radio/TV technician for help.

FCC Radiation Exposure Statement:This

equipment complies with FCC radiation

exposure limits set forth for an uncontrolled

environment. This equipment should be installed

and operated with a minimum distance of

20cm between the radiator and your body.

This transmitter must not be co-located or

operated in conjunction with any other antenna

or transmitter.

Warning:$Q\FKDQJHVRUPRGLÀFDWLRQVPDGH

to this device that are not expressly approved

by Gibson Innovations may void the user’s

authority to operate the equipment.

Model number: B5/37

Trade Name: Philips

Responsible Party:P&F USA, Inc. PO Box 2248

Alpharetta, GA 30023-2248; 1-866-226-6074

Canada:

CAN ICES-3(B)/NMB-3(B)

This device complies with Industry Canada

licence-exempt RSS standard(s). Operation is

subject to the following Two conditions: (1) this

device may not cause harmful interference, and

(2) this device must accept any interference

received, including interference that may cause

undesired operation.

Trademarks

For DTS patents, see http://patents.dts.com.

Manufactured under license from DTS Licensing

Limited. DTS, the Symbol, & DTS and the

Symbol together are registered trademarks, and

DTS Digital Surround is a trademark of DTS,

Manufactured under license from Dolby

Laboratories. Dolby, Pro Logic, and the

double-D symbol are trademarks of Dolby

Laboratories.

automatically to save power. This does not

indicate any malfunction of the SoundBar.

Spatial calibration

Why spatial calibration is needed?

•Spatial calibration optimizes surround

sound experience if your portable left and

right speakers (surround) are not properly

placed.

Improvement in surround sound is not

noticeable after successful spatial calibration.

• Surround sound improvement is only

noticeable if the portable left and right

speakers (surround) were improperly

placed, or if there is strong surround effect

in the music you play.

Error message is displayed on the display

panel.

• If spatial calibration fails, one of the

following error message is displayed. Refer

to the fourth chapter (Spatial calibration)

for details to re-calibrate.

•FAIL (fail): indicates that the

portable left/right speaker is not in

SURROUND ON DEMAND mode

or out of calibration range, or there is

some obstacle by which the main unit,

the portable left and right speakers

cannot completely "see" each other.

•BATT LOW (battery low): indicates

that the portable left/right speaker has

low battery.

•ERR1 (error): indicates that the

portable left and right speakers are not

detached from the main unit.

Wireless Speaker Model number: WSB5

26 EN

7KHWHUPV+'0,DQG+'0,+LJK'HÀQLWLRQ

Multimedia Interface, and the HDMI Logo are

trademarks or registered trademarks of HDMI

Licensing LLC in the United States and other

countries.

The Bluetooth word mark and logos are

registered trademarks owned by Bluetooth

SIG, Inc. and any use of such marks by Gibson

Innovations Limited is under license. Other

trademarks and trade names are those of their

respective owners.

The N Mark is a trademark or registered

trademark of NFC Forum, Inc. in the United

States and in other countries.

The aptX® mark and the aptX logo are

trade marks of CSR plc or one of its group

companies and may be registered in one or

more jurisdictions.

Philips and the Philips’ Shield Emblem are registered

trademarks of Koninklijke Philips N.V. and are used

by WOOX Innovations Limited under license from

Koninklijke Philips N.V.

000000000000

English

Important

Read and understand all instructions before you use your product. If damage is caused by failure to

follow instructions, the warranty does not apply.

Help and support

For extensive online support, visit www.philips.com/support to:

• download the user manual and the quick start guide

• watch video tutorials (available only for selected models)

• Ànd answers to frequently answered questions (F$4s)

• email us a question

• chat with our support representative.

Follow the instructions on the website to select your language, and then enter your product model number.

$lternatively, you can contact &onsumer &are in your country. %efore you contact, note down the

model number and serial number of your product. <ou can Ànd this information on the back or

bottom of your product.

Important safety instructions

• Read these instructions.

• Keep these instructions.

• Heed all warnings.

• Follow all instructions.

• Do not use this apparatus near water.

• Clean only with dry cloth.

• Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus

(including ampliÀers) that produce heat.

• Do not defeat the safety purpose of the polarized or grounding-type

plug. $ polarized plug has two blades with one wider than the other. $

grounding type plug has two blades and a third grounding prong. The wide

blade or the third prong are provided for your safety. If the provided plug

does not Àt into your outlet, consult an electrician for replacement of the obsolete outlet.

• Protect the power cord from being walked on or pinched, particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

• Only use attachments/accessories speciÀed by the manufacturer.

•Use only with the cart, stand, tripod, bracket or table speciÀed by the

manufacturer or sold with the apparatus. When a cart is used, use caution when

moving the cart/apparatus combination to avoid injury from tip-over.

• Unplug this apparatus during lightning storm or when unused for long periods of time.

• Refer all servicing to qualiÀed service personnel. 6ervicing is required when the

apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid

has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

• Battery usage CAUTION - To prevent battery leakage which may result in bodily injury,

property damage, or damage to the unit:

• Install all batteries correctly, + and - as marked on the unit.

• Do not mix batteries (old and new or carbon and alkaline, etc.).

• Remove batteries when the unit is not used for a long time.

• The batteries shall not be exposed to excessive heat such as sunshine, Àre or the like.

• 3erchlorate 0aterial - special handling may apply. 6ee www.dtsc.ca.gov/hazardouswaste/

perchlorate.

• The product/remote control may contain a coin/button type battery, which can be swallowed.

Keep the battery out of reach of children at all times! If swallowed, the battery can cause

serious injury or death. 6evere internal burns can occur within two hours of ingestion.

• If you suspect that a battery has been swallowed or placed inside any part of the body, seek

immediate medical attention.

• When you change the batteries, always keep all new and used batteries out of reach of children.

Ensure that the battery compartment is completely secure after you replace the battery.

• If the battery compartment cannot be completely secured, discontinue use of the product.

Keep out of reach of children and contact the manufacturer.

• Apparatus shall not be exposed to dripping or splashing.

• Do not place any sources of danger on the apparatus (for example. liquid Àlled objects, lighted

candles).

•This apparatus may contain lead and mercury. Dispose according to local, 6tate or Federal

laws. For disposal or recycling information, please contact your local authorities. For additional

assistance on recycling options, please contact www.mygreenelectronics.com or www.eiae.org

or www.recycle.philips.com.

•Where the 0$I16 plug or an appliance coupler is used as the disconnect device, the

disconnect device shall remain readily operable.

•Do not place this apparatus on the furniture that is capable of being tilted by a child and an adult

leaning, pulling, standing or climbing on it. $ falling apparatus can cause serious injury or even death.

•

This apparatus should not be placed in a built-in installation such as a bookcase or rack unless proper

ventilation is provided. Make sure to leave a space of 7.8 inches (20cm) or more around this apparatus.

Class II equipment symbol

This symbol indicates that the unit has a double insulation system.

This ‘bolt of lightning’ indicates uninsulated material within your unit may cause an

electrical shock. For the safety of everyone in your household, please do not remove

product covering.

The ‘exclamation point’ calls attention to features for which you should read the

enclosed literature closely to prevent operating and maintenance problems.

WARNING: To reduce the risk of Àre or electric shock, this apparatus should not be exposed to rain

or moisture and objects Àlled with liquids, such as vases, should not be placed on this apparatus.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.

Care for your product

8se only microÀber cloth to clean the product.

Care of the environment

Disposal of your old product and battery

Your product is designed and manufactured with high quality materials and components, which can be

recycled and reused.

This product may contain lead and mercury. Disposal of these materials may be regulated due to

environmental considerations. For disposal or recycling information, please contact your local authorities.

This product contains batteries:

• Dispose of batteries properly. Do not incinerate. %atteries may explode if overheated.

• Do not wrap in metal or aluminum foil. Wrap in newspaper before discarding.

• It is suggested that you contact your local town or city to determine proper battery redemption

site(s) in your area.

• Please visit www.call2recycle.org for additional information on a recycling center in your area for

rechargeable batteries.

Notice of compliance

The device complies with the F&& rules, Part . 2peration is subject to the following two conditions:

a This device may not cause harmful interference, and

b This device must accept any interference received, including interference that may cause

undesired operation.

FCC rules

This equipment has been tested and found to comply with the limits for a &lass % digital device,

pursuant to part  of the F&& Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception, which can be determined

by turning the equipment off and on, the user is encouraged to try to correct the interference by one

or more of the following measures:

• Relocate the receiving antenna.

• Increase the separation between equipment and receiver.

•

&onnect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• &onsult the dealer or an experienced radio/T9 technician for help.

FCC Radiation Exposure Statement:This equipment complies with F&& radiation exposure limits

set forth for an uncontrolled environment. This equipment should be installed and operated with a

minimum distance of 20cm between the radiator and your body. This transmitter must not be co-

located or operated in conjunction with any other antenna or transmitter.

Warning: $ny changes or modiÀcations made to this device that are not expressly approved by

Gibson Innovations may void the user’s authority to operate the equipment.

Model 1umber : #

Trade 1ame: Philips

Responsible Party:PF 86$, Inc. P2 %ox 228 $lpharetta, G$ 002-228  (8) 22-07

Canada:

&$1 I&E6-(%)/1M%-(%)

This device complies with Industry &anada licence-exempt R66s. 2peration is subject to the

following Two conditions: () this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired operation.

Español

Importante

Lea y asegúrese de comprender todas las instrucciones antes de usar el producto. La garantía no

cubre los daños producidos por no haber seguido las instrucciones.

Ayuda y asistencia técnica

Para obtener una amplia asistencia en línea, visite www.philips.com/support para:

• descargar el manual de usuario y la guía de inicio rápido

• ver tutoriales de video (solo disponible para modelos seleccionados)

• buscar respuestas a preguntas frecuentes (F$4)

• enviarnos un correo electrónico con una pregunta

• chatear con nuestro representante de soporte.

6iga las instrucciones del sitio web para seleccionar su idioma e ingrese el número de modelo de su

producto.

Ta m b i pn puede ponerse en contacto con el servicio de atención al cliente de su país. $ntes

de ponerse en contacto, anote el modelo y número de serie del producto. Puede buscar esta

información en la parte posterior o inferior del producto.

Instrucciones de seguridad importantes

• Lea estas instrucciones.

• Conserve estas instrucciones.

• Preste atención a todas las advertencias.

• Siga todas las instrucciones.

• No utilice este aparato cerca del agua.

• Utilice únicamente un paño seco para la limpieza.

• No bloquee las aperturas de ventilación. Realice la instalación de acuerdo con las

indicaciones del fabricante.

• No realice la instalación cerca de fuentes de calor como radiadores, rejillas de calefacción,

estufas u otros equipos que produzcan calor (incluso ampliÀcadores).

•Utilice el conector polarizado o con conexión a tierra de conformidad

con las normas de seguridad. Un enchufe polarizado cuenta con dos

álabes, uno más ancho que el otro. Los conectores a tierra tienen dos

conductores y una tercera terminal de contacto para la conexión a tierra.

El conductor ancho o la tercera terminal de contacto con conexión a tierra se proveen para

mayor seguridad. 6i el enchufe suministrado no encaja correctamente en el tomacorriente,

consulte a un electricista para reemplazar la toma.

• Proteja el cable de alimentación. Evite pisar o doblar el cable, en particular a la altura del

conector y las terminales de contacto del aparato.

• Utilice sólo los accesorios que especiÀca el fabricante.

• Utilice sólo el carrito, el soporte, el trípode y la mesa que indica el fabricante y

los que incluye el equipo. Tenga cuidado cuando transpor te el equipo en el carrito

para evitar caídas y posibles lesiones.

• Desenchufe el equipo durante tormentas eléctricas o cuando no se utilice por un

período prolongado.

• Todos los trabajos de servicio técnico deben ser realizados por personal de servicio

caliÀcado. 6olicite el servicio de asistencia técnica cuando, por ejemplo, el cable de alimentación

o el conector están dañados, si se derramó líquido o cayeron objetos dentro del aparato, si el

equipo estuvo expuesto a la lluvia o humedad, si no funciona normalmente o si se cayó.

• PRECAUCIÓN: para evitar que las baterías se sulfaten y puedan ocasionar lesiones, daños

materiales o en la unidad:

• Instale todas las baterías de forma correcta, de acuerdo con los signos + y - marcados en

la unidad.

• 1o utilice baterías de distintas clases (nuevas y usadas o de carbono y alcalinas, etc.).

• Extraiga las pilas cuando no utilice la unidad durante un período prolongado.

• 1o exponga las baterías a temperaturas altas como las que emiten la luz solar, el fuego u

otros elementos similares.

• Este producto contiene perclorato y puede requerir un método de manipulación especial.

9isite www.dtsc.ca.gov/hazardouswaste/perchlorate.

• El producto/control remoto puede contener una batería tipo botón o moneda fácil de tragar.

6iempre mantenga las baterías lejos del alcance de los niños. En caso de ingestión la batería

podría causar lesiones graves o la muerte. Puede haber quemaduras internas graves en un plazo

de dos horas tras la ingestión.

• 6i sospecha que una batería se ha ingerido o introducido en cualquier parte del cuerpo,

consulte inmediatamente a un médico.

•

$l cambiar las baterías, mantenga siempre las baterías nuevas y usadas lejos del alcance de los niños.

9eriÀque que el compartimiento de la batería esté bien cerrado luego de reemplazar la batería.

• 6i el compartimiento de la batería no puede cerrarse, discontinúe el uso del producto.

Manténgalo lejos del alcance de los niños y comuníquese con el fabricante.

• No exponga el equipo a goteos ni salpicaduras.

• No coloque el aparato cerca de fuentes de peligro (por ejemplo, objetos que contengan

líquidos o velas encendidas).

•Este aparato puede contener plomo y mercurio. &umpla con la normativa local, estatal o

nacional sobre eliminación de productos. &omuníquese con las autoridades locales para solicitar

información sobre la eliminación o el reciclaje de productos. Para obtener más información

sobre las opciones de reciclaje disponibles, ingrese en cualquiera de los siguientes sitios web:

www.mygreenelectronics.com, www.eiae.org, www.recycle.philips.com.

•6i el conector de alimentación u otro conector se utilizan como dispositivos de desconexión,

deben estar accesible y fáciles de operar.

•1o coloque este aparato sobre muebles que adultos o niños puedan tirar, inclinar o utilizar para

subirse sobre ellos. 6i el aparato se cae, puede causar heridas graves o incluso la muerte.

• Este aparato no debe ubicarse en una instalación cerrada como una estantería o un rack, a

menos que esté adecuadamente ventilada. 9eriÀque que haya un espacio mínimo de 20 cm

(7,8 pulg) alrededor del aparato.

Símbolo de equipo de Clase II

Este símbolo indica que la unidad tiene un sistema de doble aislamiento.

Conozca estos símbolos de seguridad

El símbolo del rayo indica que los componentes sin aislamiento dentro de la unidad

pueden generar descargas eléctricas. Para la seguridad de todas las personas de su

hogar, no retire la cubierta del producto.

El signo de exclamación indica las características del producto que pueden provocar

problemas de funcionamiento y mantenimiento. Por eso, se recomienda leer el manual

de instrucciones.

ADVERTENCIA: Para reducir el riesgo de incendios o descargas eléctricas, no exponga el aparato a la

lluvia ni a la humedad, ni coloque sobre él objetos que contengan líquidos (por ejemplo, jarrones).

PRECAUCIÓN: Para evitar descargas eléctricas, el conductor ancho debe introducirse por completo

en la ranura adecuada.

Protección del producto

Utilice únicamente un paño de microÀbra para limpiar el producto.

Cuidado del medio ambiente

Desecho del producto y de las pilas usadas

El producto ha sido diseñado y fabricado con materiales y componentes de alta calidad que pueden

reciclarse y reutilizarse.

Este producto puede contener plomo y mercurio. Es posible que la eliminación de estos materiales

se encuentre bajo regulación debido a causas medioambientales. Para obtener información sobre la

eliminación o el reciclaje, póngase en contacto con las autoridades locales.

Este producto contiene pilas:

• Deseche las pilas correctamente. 1o las arroje al fuego. Las pilas pueden explotar si se

sobrecalientan.

• 1o la envuelva en papel de aluminio o metal. Envuélvala en papel de periódico antes de

deshacerse de ella.

• Le sugerimos que se informe acerca de los puntos de recogida de pilas de su ciudad.

• 9isite www.call2recycle.org para obtener más información sobre centros de reciclaje para pilas

recargables de su zona.

Aviso de cumplimiento

El dispositivo cumple con los reglamentos de la F&&, apartado . El funcionamiento está sujeto a las

siguientes condiciones:

a El dispositivo no debe causar interferencias nocivas y

b debe recibir todo tipo de interferencias, incluso las que originan un funcionamiento

indeseado.

Normas de la Comisión Federal de Comunicaciones (FCC)

Este equipo se ha probado y se ha determinado que cumple con los límites para un dispositivo digital

clase %, de acuerdo con el apartado  de las normativas de la F&&. Estos límites están destinados a

ofrecer una protección razonable contra interferencias dañinas dentro de una instalación residencial.

Este equipo genera, utiliza y puede emitir energía de radiofrecuencia. 6i no se instala y utiliza de

conformidad con el manual de instrucciones, puede ocasionar interferencias perjudiciales en las

comunicaciones de radio.

6in embargo, no existe garantía de que no se producirá interferencia en una instalación en particular.

6i este equipo provoca interferencias perjudiciales en la recepción de radio o televisión, lo que

puede determinarse al encender y apagar el equipo, se recomienda al usuario intentar corregir la

interferencia mediante una o varias de las siguientes medidas:

• &ambie la posición de la antena receptora.

• $umente la distancia entre el equipo y el receptor.

• &onecte el equipo a un tomacorriente de un circuito diferente al que está conectado el

receptor.

• Para obtener ayuda, comuníquese con el distribuidor o con un técnico de radio o televisión

caliÀcado.

Normas sobre la exposición a campos de radiación de la FCC: este equipo cumple con la normativa

que regula los límites de exposición a la radiación de F&& para ambientes no controlados. Este

equipo debe instalarse y utilizarse con una distancia mínima de 20 cm entre el radiador y el cuerpo.

1o coloque este aparato cerca de otros transmisores o antenas, ni lo utilice con este tipo de

dispositivos.

Advertencia: &ualquier alteración o modiÀcación a este dispositivo, que no cuente con la autorización

expresa de Gibson Innovations, puede anular el derecho del usuario para utilizar el equipo.

1umero de modelo: %/7

1ombre comercial: Philips

Parte responsable: PF U6$, Inc. P2 %ox 228 $lpharetta, G$ 002-228  (8) 22-07

Canadá:

&$1 I&E6-(%)/1M%-(%)

Este dispositivo cumple con los estándares R66 exentos de licencia de Industry &anada. El

funcionamiento queda sujeto a las siguientes condiciones: () este dispositivo no debe producir

interferencias dañinas, y (2) debe soportar cualquier interferencia, incluso aquéllas que pueden causar

un funcionamiento no deseado.

México:

La operación de este equipo está sujeta a las siguientes dos condiciones: () es posible que este

equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar

cualquier interferencia, incluyendo la que pueda causar su operación no deseada.

P&F USA Inc. PO Box 2248 Al

haretta

GA 30023-2248

ONE (1) YEAR LIMITED WARRANTY

WARRANTY COVERAGE:

This warranty obligation is limited to the terms set forth

below.

WHO IS COVERED:

This product is warranted to the original purchaser or the per-

son receiving the product as a gift against defects in materials and

workmanship as based on the date of original purchase

(“Warranty Period”) from an Authorized Dealer. The original

sales receipt showing the product name and the purchase date

from an authorized retailer is considered such proof.

WHAT IS COVERED:

This warranty covers new products if a defect in material

or workmanship occurs and a valid claim is received within

the Warranty Period. At its option, the company will either (1)

repair the product at no charge, using new or refurbished

replacement parts, or (2) exchange the product with a product

that is new or which has been manufactured from new, or ser-

viceable used parts and is at least functionally equivalent or most

comparable to the original product in current inventory,

or (3) refund the original purchase price of the product.

The company warrants replacement products or parts provided

under this warranty against defects in materials and workmanship

from the date of the replacement or repair for ninety (90) days

or for the remaining portion of the original product’s warranty,

whichever provides longer coverage for you. When a product or

part is exchanged, any replacement item becomes your property

and the replaced item becomes the company property. When a

refund is given, your product becomes the company property.

Note: Any product sold and identified as refurbished or

renewed carries a ninety (90) day limited warranty.

Replacement product can only be sent if all warranty

requirements are met. Failure to follow all requirements

can result in delay.

WHAT IS NOT COVERED - EXCLUSIONS AND LIMI-

TATIONS:

This Limited Warranty applies only to the new products that

can be identified by the trademark, trade name, or logo affixed

to it. This Limited Warranty does not apply to any non-Philips

hardware product or any software, even if packaged or sold

with the product. Non-Philips manufacturers, suppliers, or

publishers may provide a separate warranty for their own

products packaged with the bundled product.

The company is not liable for any damage to or loss of any ,

programs data, or other information stored on any media

contained within the product, or any non-Philips product or part

not covered by this warranty. Recovery or reinstallation of

programs, data or other information is not covered under this

Limited Warranty.

This warranty does not apply (a) to damage caused by accident,

abuse, misuse, neglect, misapplication, or non-Philips product, (b)

to damage caused by service performed by anyone other than

an Authorized Service Location, (c) to a product or

a part that has been modified without written permission,

or (d) if any serial number has been removed or defaced,

or (e) product, accessories or consumables sold “AS IS”

without warranty of any kind by including refurbished Philips

product sold “AS IS” by some retailers.

This Limited Warranty does not cover:

sShipping charges to return defective product.

sLabor charges for installation or setup of the product, adjust-

ment of customer controls on the product, and installation or

repair of antenna/signal source systems outside of the product.

sProduct repair and/or part replacement because of improper

installation or maintenance, connections to improper voltage

supply, power line surge, lightning damage, retained images or

screen markings resulting from viewing fixed stationary con-

tent for extended periods, product cosmetic appearance items

due to normal wear and tear, unauthorized repair or other

cause not within the control of the company.

sDamage or claims for products not being available for use, or

for lost data or lost software.

sDamage from mishandled shipments or transit accidents when

returning product.

sA product that requires modification or adaptation to enable

it to operate in any country other than the country for which

it was designed, manufactured, approved and/or authorized, or

repair of products damaged by these modifications.

sA product used for commercial or institutional purposes

(including but not limited to rental purposes).

sProduct lost in shipment and no signature verification receipt

can be provided.

sFailure to operate per Owner’s Manual.

TO OBTAIN ASSISTANCE IN THE U.S.A., CANADA,

PUERTO RICO, OR U.S. VIRGIN ISLANDS…

Contact Customer Care Center at:

1 (866) 226-6074

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS

WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CON-

SUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDEN-

TAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF

ANY EXPRESS OR IMPLIED WARRANTY ON THIS PROD-

UCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE

LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR

FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT

IS LIMITED IN DURATION TO THE DURATION OF THIS

WARRANTY.

Some states do not allow the exclusions or limitation of inciden-

tal or consequential damages, or allow limitations on how long an

implied warranty lasts, so the above limitations or exclusions may

not apply to you.

This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.

B5/37_Safety_V1.0.indd 1 6/17/2015 5:46:41 PM

Le dispositif rencontre l'exemption des limites courantes d'evaluation dans la section 2.5 de RSS 102 et

la conformite a l'exposition de rf, utilisateurs peut obtenir l'information canadienne sur l'exposition

RSS-102

la conformite de rf.

The device meets the exemption from the routine evaluation

limits in section 2.5 of RSS 102 and compliance with RSS-102

RF exposure, users can obtain Canadian information on RF

exposure and compliance.

Français

1 Important

Lisez attentivement toutes les instructions avant d’utiliser le téléviseur. 6i des dommages sont causés

par le non-respect des instructions, la garantie ne sera pas applicable.

Aide et soutien

Pour un service complet à la clientèle en ligne, visitez le site www.philips.com/support pour effectuer

les opérations suivantes :

• télécharger le manuel d’utilisation et le guide de démarrage rapide

• regarder des didacticiels vidéo (pour certains modèles seulement)

• trouver des réponses aux questions les plus fréquentes (F$4)

• nous envoyer une question par courriel

• clavarder avec un de nos représentants du service à la clientèle

6uivez les instructions sur le site Web pour sélectionner votre langue, ensuite entrez le numéro de

modèle de votre produit.

9ous pouvez également communiquer avec le service à la clientèle dans votre pays. 1otez auparavant

le numéro de modèle et le numéro de série de votre produit. 9ous pouvez trouver cette information

à l’arrière de votre appareil.

Consignes de sécurité importantes

• Lisez ces instructions.

• Conservez ces instructions.

• Tenez compte de tous les avertissements.

• Suivez toutes les instructions.

• N’utilisez pas cet appareil près de l’eau.

• Nettoyez l’appareil avec un chiffon sec seulement.

• N’obstruez aucune prise de ventilation. Installez l’appareil en conformité avec les instructions

du fabricant.

• N’installez pas l’appareil près d’une source de chaleur comme un radiateur, un registre de

chaleur ou un autre appareil (incluant les ampliÀcateurs) qui produit de la chaleur.

• Ne passez pas outre les instructions de sécurité concernant la Àche

polarisée ou la Àche de mise à la terre. Une Àche polarisée est composée

de deux broches dont l’une est plus large que l’autre. Une Àche de mise

à la terre est composée de deux broches et d’une broche de masse. La

broche plus large et la broche de masse visent à assurer votre sécurité. 6i la Àche fournie ne

peut être insérée dans la prise, consultez un électricien pour qu’il remplace votre prise désuète.

• Protégez le cordon d’alimentation de faoon à ce qu’il ne puisse pas être écrasé ou pincé

vériÀez particulièrement les Àches, les prises et la sortie du Àl dans l’appareil.

• Utilisez seulement les accessoires spéciÀés par le fabricant.

• Utilisez seulement le chariot, le support, le trépied ou la table spéciÀés par

le fabricant ou vendu avec l’appareil. 6i vous utilisez un chariot, faites attention

lorsque vous le déplacez aÀn d’éviter de vous blesser en cas de renversement de

l’appareil.

• Débranchez cet appareil pendant les orages avec éclairs ou s’il n’est pas utilisé

pendant de longues périodes.

• Toute réparation doit être faite par un technicien qualiÀé. Une réparation est nécessaire quand

l’appareil a été endommagé, par exemple, quand le cordon ou la Àche d’alimentation ont été

endommagés, quand un objet a été introduit dans l’appareil ou quand l’appareil a été mouillé,

exposé à la pluie ou à l’humidité, qu’il ne fonctionne pas correctement ou qu’il a été échappé.

• AVERTISSEMENT relatif à l’utilisation de piles ² $Àn d’éviter une fuite des piles pouvant

entraîner des blessures ou des dommages matériels :

• Installez toutes les piles correctement en alignant les pôles + et - tel qu’indiqué sur

l’appareil.

• 1e combinez pas des piles différentes (neuves et usagées, au carbone et alcalines, etc.).

• Retirez les piles lorsque l’appareil n’est pas utilisé pendant une longue période.

• Les piles intégrées ne doivent pas être exposées à une chaleur excessive, comme les

rayons du soleil ou le feu.

• Produits contenant du perchlorate : une manipulation particulière peut être requise.

&onsulter www.dtsc.ca.gov/hazardouswaste/perchlorate.

• L’appareil ou sa télécommande peuvent contenir une pile bouton qu’un enfant pourrait avaler.

Gardez ce type de pile hors de portée des enfants à tout moment! En cas d’ingestion, la pile

peut provoquer des blessures sérieuses voire la mort. De graves brûlures internes peuvent

survenir dans les deux heures suivant l’ingestion.

• 6i vous croyez qu’une pile a été ingérée ou introduite dans le corps de quelqu’un, consultez

immédiatement votre médecin.

• Lorsque vous changez les piles, assurez-vous que les piles neuves et usagées sont hors

de portée des enfants. Une fois le changement de pile effectué, assurez-vous que son

compartiment est bien fermé et sécurisé.

• 6i vous ne parvenez pas à sécuriser le compartiment de la pile, cessez d’utiliser l’appareil.

Gardez l’appareil hors de portée des enfants et communiquez avec le fabricant.

• N’exposez pas l’appareil aux éclaboussures, ni aux déversements.

• Ne placez aucune source de danger sur l’appareil (par exemple des objets remplis de liquide

ou des bougies allumées).

•&et appareil peut contenir du plomb et du mercure. Mettez l’appareil au rebut conformément

aux lois municipales, provinciales ou fédérales. Pour en savoir plus sur la mise au rebut ou sur le

recyclage, veuillez communiquer avec les autorités locales. Pour de plus amples renseignements

sur les diverses possibilités de recyclage, visitez les sites www.mygreenelectronics.com, www.

eiae.org ou www.recycle.philips.com.

•6i la Àche d’alimentation ou un coupleur d’appareil est utilisé comme dispositif de découplage,

celui-ci doit rester facilement accessible.

•1e placez pas cet appareil sur un meuble qu’un enfant pourrait faire basculer ou qu’un adulte

pourrait renverser involontairement en s’appuyant ou en grimpant dessus ou encore en le

tirant. La chute d’un appareil peut provoquer des blessures graves, voire la mort.

• &et appareil ne doit pas être placé dans un meuble encastré comme une bibliothèque ou une

étagère, à moins que l’emplacement offre une ventilation sufÀsante. 9eillez à garder un espace

dégagé d’au moins 20 cm (7,8») autour de cet appareil.

Symbole d’équipement de classe II

&e symbole signiÀe que l’appareil sur lequel il est apposé est doté d’une double isolation.

Sachez reconnaître ces symboles de sécurité

et pouvant causer un choc électrique. Pour assurer la sécurité des membres de votre

famille, veuillez ne pas enlever le couvercle du produit.

caractéristiques à propos desquelles vous devez lire attentivement la documentation

accompagnant l’appareil aÀn d’éviter tout problème de fonctionnement et d’entretien.

AVERTISSEMENT : aÀn de réduire les risques d’incendie ou de choc électrique, n’exposez pas cet

appareil à la pluie ou à l’humidité. 1e posez pas dessus d’objets remplis de liquides, tels que des vases.

ATTENTION : pour éviter les chocs électriques, introduisez la broche la plus large de la Àche dans la

borne correspondante de la prise et poussez à fond.

Précautions d’utilisation de votre appareil

Utilisez seulement un chiffon en microÀbre pour nettoyer l’appareil.

Respect de l’environnement

0LVHDXUHEXWGHYRWUHSURGXLWHWGHODSLOHHQÀQGHYLH

&et appareil a été conou et fabriqué avec des matériaux et des composants de haute qualité pouvant

être recyclés et réutilisés.

&e produit peut contenir du plomb et du mercure. La mise au rebut de ces substances peut

être réglementée aÀn de préserver l’environnement. &ontactez les autorités locales pour toute

information concernant la mise au rebut ou le recyclage.

&e produit est doté de piles :

• Mettez les piles au rebut de manière adéquate. 1e les incinérez pas. Les piles peuvent exploser

en cas de surchauffe.

• 1e les enroulez pas dans une feuille métallique ou d’aluminium. Enroulez-les dans du papier

journal avant de les jeter.

• 1ous vous recommandons de contacter l’administration de votre ville pour connaître le(s)

site(s) de recyclage de piles de votre zone.

• Rendez-vous sur www.call2recycle.org pour plus d’informations sur les centres de recyclage

dans votre région pour les piles rechargeables.

Avis de conformité

&e dispositif est conforme aux règlements de la F&&, partie . Le fonctionnement est assujetti aux

deux conditions suivantes :

a Cet appareil ne doit pas causer d’interférence préjudiciable et

b l’appareil doit accepter toute interférence reçue, y compris les interférences qui peuvent

causer un fonctionnement non désiré.

Règlement de la FCC

&et équipement a été testé et jugé compatible avec les limites s’appliquant aux appareils numériques

de la classe %, conformément à l’article  du règlement de la F&&. &es limites ont été déÀnies pour

fournir une protection raisonnable contre les interférences nuisibles dans le cadre d’une installation

résidentielle. &et équipement génère, utilise et peut émettre de l’énergie radiofréquence et, s’il n’est

pas installé ni utilisé conformément aux instructions, peut causer des interférences gênantes pour les

communications radio.

Rien ne garantit toutefois que des interférences ne surviendront pas dans une installation particulière.

6i cet équipement cause des interférences nuisibles pour la réception de la radio ou de la télévision,

ce qui peut être déterminé en mettant l’équipement hors tension puis sous tension, l’utilisateur devra

essayer de corriger ces interférences en effectuant une ou plusieurs des opérations suivantes :

• Déplacez l’antenne de réception.

• $ugmentez la distance entre l’équipement et le récepteur.

• %ranchez l’équipement à une prise d’un circuit autre que celui sur lequel le récepteur est

branché.

• &onsultez le détaillant ou un technicien de radiotélévision expérimenté.

Énoncé de la FCC sur l’exposition aux rayonnements radioélectriques : cet appareil est conforme

aux limites d’exposition aux rayonnements radioélectriques de la F&& pour un environnement

non contrôlé. &et appareil doit être installé et utilisé en conservant une distance minimale de

20 centimètres entre le radiateur et votre corps. &et émetteur ne doit pas être installé au même

endroit qu’une autre antenne ou un autre émetteur, ni utilisé avec un tel dispositif.

Avertissement : Tout changement ou toute modiÀcation apporté à cet appareil sans l’autorisation

expresse de Gibson Innovations peut annuler le droit de l’utilisateur à utiliser l’équipement.

1uméro de modèle

Marque : Philips

Partie responsable : PF U6$, Inc. P2 %ox 228 $lpharetta, G$ 002-228  (8) 22-07

Canada :

&$1 I&E6-(%)/1M%-(%)

&et appareil est conforme aux normes R66 sans licence d’Industrie &anada. 6on fonctionnement

est assujetti aux deux conditions suivantes : () l’appareil ne doit pas causer d’interférences nuisibles

(2) l’appareil doit accepter toute interférence reçue, y compris les interférences qui peuvent causer un

fonctionnement non désiré.

Specifications are subject to change without notice

This product has been manufactured by, and is sold under the responsibility of

Gibson Innovations Ltd., and Gibson Innovations Ltd. is the warrantor in relation

to this product. Philips and the Philips Shield Emblem are registered trademarks of

Koninklijke Philips N.V. and are used under license from Koninklijke Philips N.V.

HTL2140B_F7_Safety_V1.0

P&F USA Inc. PO Box 2248 Alpharetta, GA 30023-2248

GARANTÍA LIMITADA DE UN (1) AÑO

COBERTURA DE GARANTÍA:

La obligación de esta garantía se limita a los términos establecidos a

continuación.

QUIÉNES ESTÁN CUBIERTOS:

Este producto está garantizado al comprador original o a lapersonaque lo

recibe como regalo contra defectos en los materiales y en la mano de

obra, a partir de la fecha de la compra original ("períododegarantía")en el

distribuidor autorizado.El recibo de ventas,donde aparecen el nombre del

producto y la fecha de la compra en un distribuidor autorizado, se

considerará comprobante de esta fecha.

LOQUEESTÁCUBIERTO:

Esta garantía cubre productos nuevos si se produce algún defecto enel

material o la mano de obra y se recibe un reclamo válido dentrodel

período de garantía. A su propia discreción, la compañía dentrodel

período de garantía. A su propia discreción, la compañía nuevas o

reacondicionadas;(2)cambiará el producto por uno nuevo o que se ha

fabricado con piezas nuevas o usadas utilizables, y que sea al menos

funcionalmente equivalente o lo más parecido al producto original del

inventario actual; o (3) reembolsará el precio de compra original del

producto. La compañía garantiza productos o piezas de repuesto

proporcionados bajo esta garantía contra defectos en los materiales y en

la mano de obra durante noventa (90) días o por el resto de la garantía

del producto original, lo que le promocione más cobertura. Cuando se

cambia un producto o una pieza, el artículo que usted recibe pasa a ser

de su propiedad y el que se le entrega pasa a ser propiedad de la

compañía.Cuando se proporcione un reembolso, su producto pasa a ser

propiedad la compañía.

Nota: Cualquier producto que se venda y que esté identi

como reacondicionado o renovado tiene una garantía limitada

de noventa (90) días.

El producto de reemplazo sólo se puede enviar si se cumplen

todos los requisitos de la garantía. El incumplimiento de tales

requisitos puede ocasionar un retardo.

LO QUE NO SE CUBRE: EXCLUSIONES Y LIMITACIONES:

Esta garantía limitada se aplica sólo a los productos nuevos que se pueden

identificar por la marca registrada, el nombre comercial o por tener el

logotipo correspondiente. Esta garantía limitada no se aplica a ningún

producto de hardware ni de software que no sea Philips, incluso si viene

empacado con el producto o si se vende junto con éste. Los fabricantes,

proveedores o editores que no sean Philips pueden proporcionar una

garantía por separado para sus propios productos empacados con el

producto Philips.

La compañía no es responsable por ningún daño o pérdida de programas,

datos u otra información almacenados en algún medio contenido en el

producto, ni por ningún producto o pieza que no sea Philips que no esté

cubierta por esta garantía. La recuperación o la reinstalación de

programas, datos u otra información no está cubierta por esta garantía

limitada.

Esta garantía no se aplica (a) a daños causados por accidente, abuso, mal

uso, negligencia, mala aplicación o a productos que no sean Philips;

(b) a daño provocado por servicio realizado por

Esta garant

a le otorga derechos legales espec

ficos. Usted puede tener otros derechos que var

an entre los diferentes estados y provincias.

cualquier persona distinta de un establecimiento de servicio autorizado;

escrito; (d) si se ha retirado o desfigurado cualquier número de serie; y

tampoco se aplica la garantía a (e)productos, accesorios o insumos

vendidos TAL COMO ESTÁN sin garantía de ningún tipo, lo que incluye

productos Philips vendidos TAL COMO ESTÁN por algunos

distribuidores.

Esta garantía limitada no cubre:

s Los costos de envío al devolver el producto defectuoso.

sLos costos de mano de obra por la instalacion o configuración del

producto, el ajuste de controles del cliente en el producto y la

instalación o reparación de sistemas de antena o fuente de señal

externos al producto.

s La reparación del producto o el reemplazo de piezas debido a

instalación o mantenimiento inadecuada, a conexiones hechas a un

suministro de voltaje inadecuado, sobrevoltaje de la línea de

alimentación, daño causado por relámpagos, imágenes retenidas o

marcas en la pantalla producto de la visualización de contenido fijo

durante periodos prolongados, reparaciones cosméticas debido al

desgaste normal, reparaciones no autorizadas u otras causas que no

se encuentren bajo el control de la compañía.

s Daños o reclamos por productos que no están disponibles para su

uso, por datos perdidos o por pérdida de software.

s Daños debido a mala manipulación en el transporte o accidentes de

envío al devolver el producto.

sUn producto que requiera modificacion o adaptacion para permitir su

funcionamiento en algún país que no sea el país para el que se diseñó,

fabricó, aprobó y/o autorizó o la reparación de productos dañados

por estas modificaciones.

s Un producto que se use para propósitos comerciales o institucionales

(lo que incluye, entre otros, los de alquiler).

s La pérdida del producto en el envío y cuando no se pueda

proporcionar una firma que verifique el recibo.

s No operar según el Manual del propietario.

PARA OBTENER AYUDA EN LOS EE.UU., EN CANADÁ,

PUERTO RICO O EN LAS ISLAS VIRGENES DE LOS EE.UU...

Comuníquese con el Centro de Atención al Cliente al:

1 (866) 226-6074

LA REPARACIÓN O EL REEMPLAZO, SEGÚN LO DISPONE

ESTA GARANTÍA, ES LA SOLUCIÓN EXCLUSIVA PARA EL

CLIENTE. PHILIPS NO SERÁ RESPONSABLE DE LOS DAÑOS

INCIDENTALES O INDIRECTOS QUE INFRINJAN ALGUNA

GARANTÍA EXPRESA O IMPLÍCITA SOBRE ESTE PRODUCTO.

CON EXCEPCIÓN DE LO QUE PROHÍBA LA LEY VIGENTE,

TODA GARANTÍA IMPLÍCITA DE COMERCIABILIDAD Y

ADECUACIÓN PARA UN PROPÓSITO PARTICULAR EN ESTE

PRODUCTO ESTÁ LIMITADA EN DURACIÓN A LO QUE

ESPECIFIQUE ESTA GARANTÍA.

Algunos estados no permiten las exclusiones ni la limitación de

los daños incidentales o indirectos, ni permiten limitaciones sobre

la duración de la garantía implícita, de modo que las limitaciones

o exclusiones anteriores pueden no aplicarse a usted.

P&F USA Inc. PO Box 2248 Alpharetta, GA 30023-2248

OGARANTIE LIMITÉE DE UN (1) AN

COUVERTURE DE GARANTIE:

Cette provision pour garantie est limitée aux conditions établies

ci-dessous.

QUI EST COUVERT?

La garantie du présent produit couvre l’acheteur original ou toute

personne recevant le produit en cadeau contre tout défaut de matière ou

de main d’œuvre conformément à la date originale d’achat (« Période de

garantie ») auprès d’un distributeur agréé. Le reçu de vente original

indiquant le nom du produit ainsi que la date d’achat d’un détaillant

agréé est considéré comme une preuve d’achat.

QU'EST-CE QUI EST COUVERT?

Cette garantie couvre les nouveaux produits dans le cas où un défaut

de matière ou de main d’ uvre se présenterait et une réclamation valide

était présentée dans la période de garantie.La société pourra, à sa seule

discrétion: (1)réparer le produit gratuitement avecdes pièces de rechange

neuves ou remises à neuf; ou (2) échanger le produit pour un produit

neuf ou ayant été fabriqué à partir de pièces neuvesou usagées en bon

état et au moins fonctionnellement équivalent ou comparable au produit

d’origine actuellement en inventaire; ou (3) rembourser le prix d’achat

initial du produit. La société garantit les produits ou pièces de

remplacement prévus sous cette garantie contre tout défaut de matière

ou de mai d’œuvre à n partir de la date de remplacement ou de

réparation, pour une période de quatre-vingt-dix (90) jours ou pour la

portion restante de la garantie du produit d’origine, la plus longue de ces

couvertures étant à retenir. Lorsqu’un produit ou une pièce est échangé,

tout article de rechanged evient votre propriété et l’article remplacé

devient la propriété de la société. Lorsqu’un remboursement est effectué,

votre produit devient la propriété de la société.

Remarque : tout produit vendu et identifié comme étant remis

à neuf ou rénové porte une garantie limitée de quatre-vingt-dix

(90) jours.

Un produit de remplacement ne pourra être envoyé que si

toutes les exigences de la garantie ont été respectées. Tout

manquement de répondre à toutes les exigences pourra

entraîner un délai.

CE QUI N’EST PAS COUVERT - EXCLUSIONS ET

LIMITATIONS:

Cette garantie limitée ne s’applique qu’aux nouveaux produits pouvant

être identifiés par la marque de commerce, le nom commercial ou le logo

qui y sont apposés.Cette garantielimitée ne s’applique à aucun produit

matérielou logiciel non Philips,même si celui-ci est incorporé au produit ou

venduavec celui-ci.Les fabricants, fournisseurs ou éditeurs non-Philips

peuvent fournir une garantie séparée pour leurs propres produits intégrés

au produit fourni.

La société ne saurait être tenue pour responsable de tout dommage ou

perte de programmes, données ou autres informations mis en mémoire

dans tous les médias contenus dans le produit ou de tout produit ou pièce

non-Philips non couvert par cette garantie. La récupération ou réinstallation

des programmes, données ou autres informations n’est pas couverte par

cette garantie limitée. Cette garantie ne s’applique pas (a) aux dommages

causés par un accident, un abus, un mauvais usage une négligence, une

mauvaise application ou à un produit non-Philips, (b) aux dommages causés

par un service réalisé par quiconque autre qu’un centre de service agréé,

(c)à un produit ou pièce ayant été modifié sans permission écrite, ou

(d) si tout numéro de série a été supprimé ou défiguré, ou (e) à un

ette garantie vous donne des droits légaux spécifiques. Il est possible que vous bénéficiiez de droits supplémentaires variant d'un État/Province à l'autre.

produit, accessoire ou produit non durable vendu « TEL QUEL » sans

garantie de quelque description que ce soit par l’inclusion de produits

remis à neuf Philips vendu « TEL QUEL » par certains détaillants.

Cette garantie limitée ne couvre pas:

s les frais d’expédition pour le renvoi du produit défectueux.

s les frais de main-d’œuvre pour l’installation ou la configuration du

produit, le réglage des commandes sur le produit du client ainsi que

l’installation ou la réparation du système d’antenne/source sonor

externe au produit.

s la réparation du produit et/ou le remplacement des pièces à cause

d’une mauvaise installation ou d’un mauvais entretien, d’un raccorde-

ment à une alimentation électrique incorrecte, d’une surtension

temporaire, de dommages occasionnés par la foudre, d’une

rémanence de l’image ou de marques à l’écran résultant de l’affichage

d’un contenu stationnaire fixe pour une période de temps prolongée,

de l’aspect esthétique du produit causé par une usure normale, d’une

réparation non autorisée ou de toute autre cause non contrôlable par

la société.

s tout dommage ou réclamation pour des produits non disponibles

à l’utilisation ou pour des données perdues ou logiciel perdu.

s tout dommage causé par un mauvais acheminement du produit

ou par un accident encouru lors du renvoi du produit.

s un produit nécessitant une modification ou adaptation afin de

permettre l’utilisation dans tout pays autre que celui pour lequel il

était désigné, fabriqué, approuvé et/ou autorisé ou toute réparation

du produit endommagé par ces modifications.

s un produit utilisé à des fins commerciales ou institutionnelles (y

compris mais non de façon limitative les fins de location).

s un produit perdu lors de l’expédition sans preuve signée de la

réception.

s tout manquement d’exploiter le produit selon le manuel de

l’utilisateur.

POUR OBTENIR DE L’AIDE AUX ÉTATS-UNIS, AU

CANADA,

À PUERTO RICO OU AUX ÎLES VIERGES

AMÈRICAINES …

Communiquez avec le centre de service à la clientèle au:

1 (866) 226-6074

LA RÉPARATION OU LE REMPLACEMENT CONFORMÉMENT À

CETTE GARANTIE CONSTITUE LE SEUL REMÈDE POUR LE

CONSOMMATEUR. PHILIPS N’EST AUCUNEMENT RESPONSABLE

DE TOUT DOMMAGE ACCESSOIRE OU INDIRECT RÉSULTANT DE

LA VIOLATION DE TOUTE GARANTIE EXPRESSE OU IMPLICITE

SUR CE PRODUIT. SAUF DANS LAMESURE INTERDITE PAR LES

LOIS APPLICABLES, TOUTEGARANTIE IMPLICITE DE QUALITÉ

LOYALE ET MARCHANDEOU D’UTILITÉ PARTICULIÈRE DU

PRODUIT EST LIMITÉE DANSLE TEMPS À LA DURÉE DE CETTE

GARANTIE.

Certains états ne reconnaissent pas l’exclusion ou la limitation de la

responsabilité pour dommages indirects ou accessoires, ou autorisent

des limitations sur la durée d’une garantie implicite, il est donc possible

que les limitations ou exclusions mentionnées cidessus soient sans effet

dans votre cas.

12 meses.- Televisores con y sin reproductor de video digital DVD, reproductores de discos de video digital DVD, reproductores de disco de video digital

BLUE-RAY, grabadores reproductores de discos de video digital DVD, sistemas de cine en casa, radiograbadoras con y sin reproductor de disco compacto, video

proyector (excepto la lámpara), mini sistemas de audio, equipos modulares, antenas de recepción de satélite, teléfonos, teléfonos inalámbricos, auto estéreos,

tabletas electrónicas, Base para Ipod y bocinas inalámbricas (bluetooth).

6 meses.- Radio relojes, radios A.M. /F.M, batería recargables y reproductores de audio digital MP3 (internet).

24 meses.- Televisores Hoteleros LCD y ITV.

90 días.- Accesorios, controles remotos, bocinas, micrófonos, audífonos y aparatos reconstruidos de LCD TV, DVD, Blue-Ray, Barras de audio y Sistemas

de Teatro en casa.

B5/37_Safety_V1.0.indd 2 6/17/2015 5:46:43 PM

2015.6.17

Gibson Innovations B5 Soundbar Speaker User Manual 13

Gibson Innovations Limited Soundbar Speaker 13

Users Manual

Navigation menu

Namespaces

Views

Navigation
