Gigaset Communications 5505H Portable Part User Manual AS18H 28H

Gigaset Communications GmbH Portable Part AS18H 28H

UserManual.wiki >

Gigaset Communications >

5505H User Manual HTML Version

User Manual

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / Overview.fm / 19.01.2011

Mitel 5505H handset

11.12. 11:56

INT MENU

1Charge status of

the batteries

2Display keys

3Message key

Flashes: new messages

received

4 Handsfree key

5 Control key (u)

6 Talk key

7Directory key

(press down)

8End call and

On/Off key

9 Ringer on/off

(press and hold

in idle status)

10 Keypad lock on/off

(press and hold)

11 Recall key

- Consultation call

(flash)

- Dialling pause

(press and hold)

12 Microphone

13 "Microphone off" key

Display keys on handset:

Pressing a key launches the function that

appears above that key in the display.

Display

icon

Function when pressed

INT Call other registered handsets

¢ page 7.

MENU Open main/submenu (see

Menu tree ¢ page 16).

“ Go back one menu level.

UScroll up/down or adjust

volume with u.

T Move cursor to left/right

with u.

˜Backspace deletes one charac-

ter at a time from right to left.

OK Confirm menu function or save

entry.

ECO DECT

You are helping to protect the environment with your Mitel 5505H.

Reduced energy consumption

Your telephone has a power-saving adapter plug and uses less power.

Reduced transmission power (depending on the base station)

The transmission power can only be reduced if your base station supports this function.

The transmission power of your telephone is reduced automatically:

◆The handset's transmission power is reduced depending on the distance to the base station.

◆The transmission power on the base station is reduced to virtually zero when only one handset is regis-

tered and the handset is in the base station.

You can reduce the transmission power of the handset and base station even more by using Eco Mode/Eco

Mode+. For further information, please see your phone's user guide.

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / Overview.fm / 19.01.2011

Safety precautions

Emergency numbers cannot be dialled if the keypad lock

(¢ page 1) is activated!

Not all of the functions described in this user guide are avail-

able in all countries.

Care

Wipe the charging cradle and the handset with a

damp cloth (do not use solvent) or an antistatic cloth.

Never use a dry cloth. This can cause static.

Contact with liquid

If the handset should come into contact with liquid:

◆Switch the handset off and remove the batteries

immediately.

◆Allow the liquid to drain from the handset.

◆Pat all parts dry, then place the handset with the

battery compartment open and the keypad facing

down in a dry, warm place for at least 72 hours

(not in a microwave, oven etc.).

◆Do not switch on the handset again until it is

completely dry.

When it has fully dried out, you will normally be able

to use it again.

Read this user guide and the safety precautions carefully

before use. Explain their content and the potential hazards

associated with using the telephone to your children.

Only use the mains adapter supplied.

Fit only the recommended, rechargeable

batteries (¢ page 9), i.e. never use any other

battery type or non-rechargeable batteries as this

could result in significant health risks and personal

injury.

The operation of medical appliances may be

affected. Be aware of the technical conditions in

your particular environment, e.g. doctor's surgery.

Do not hold the rear of the handset to your ear

when it is ringing. Otherwise you risk serious and

permanent damage to your hearing.

The handset may cause an unpleasant humming

noise in hearing aids.

Do not install the phone in a bathroom or shower

room. The phone is not splashproof.

Do not use your phone in environments with a

potential explosion hazard, e.g. paint shops.

If you give your phone to someone else, make sure

you also give them the user guide.

Disposal

Batteries should not be disposed of in general

household waste. Observe the local waste dis-

posal regulations, details of which can be obtained

from your local authority or the dealer you pur-

chased the product from.

All electrical and electronic equipment must be

disposed of separately from general household

waste using the sites designated by local authori-

ties.

If a product displays this symbol of a crossed-out

rubbish bin, the product is subject to European

Directive 2002/96/EC.

The appropriate disposal and separate collection

of used equipment serve to prevent potential

harm to the environment and to health. They are a

precondition for the re-use and recycling of used

electrical and electronic equipment.

For further information on disposing of your used

equipment, please contact your local authority,

your refuse collection service or the dealer you

purchased the product from.

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / starting.fm / 19.01.2011

First steps

Check the pack contents

◆one Mitel 5505H handset,

◆one charging cradle,

◆one mains adapter,

◆two batteries,

◆one battery cover,

◆one user guide.

Setting up the charging cradle

The charging cradle is designed to be operated in enclosed, dry areas at temperatures ranging

from +5°C to +45°C.

¤Place the charging cradle on a level, non-slip surface.

The phone's feet do not usually leave any marks on surfaces. However, due to the multitude of

different varnishes and polishes used on today's furnishings, the occurrence of marks on the

surfaces cannot be completely ruled out.

You can also mount the charging cradle on the wall.

Please note:

◆Never expose the telephone to the influence of heat sources, direct sunlight or other elec-

trical devices.

◆Protect your Mitel from moisture, dust, corrosive liquids and vapours.

Connecting the charging cradle

Please note

Pay attention to the range of the base station.

This is up to 300 m in unobstructed outdoor areas and up to 50 m inside buildings. The

range is reduced when Eco Mode (¢ page 1) is activated.

¤Connect the flat plug from the power supply 1.

¤Plug the mains adapter into the plug socket 2.

If you need to disconnect the plug from the charging cradle,

press the release button 1 and disconnect the plug 2.

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / starting.fm / 19.01.2011

Setting up the handset for use

The display is protected by a plastic film.

Please remove the protective film!

Inserting the batteries and closing the battery cover

Warning

Use only the rechargeable batteries (¢ page 9) recommended by Gigaset Communications

GmbH . Never use conventional (non-rechargeable) batteries, as this could result in signifi-

cant health risks and damage to property. For example, the outer casing of the batteries

could be destroyed or the batteries could explode. The phone could also malfunction or

be damaged as a result of using batteries that are not of the recommended type.

¤Insert the batteries the right way

round.

The polarity is indicated in/on

the battery compartment.

¤Slide the battery cover back into the

main casing until it clicks into place.

If you need to open the battery cover,

for instance to replace the batteries, place

your fingertip in the grooved area on the

Directory

To open the directory: press h.

You can save up to 80 phone numbers

(max. 32 digits) with corresponding names

(max. 14 characters). Enter letters/characters

¢ page 9.

Saving the first number in the directory

h ¢ New Entry? ¢ OK

¢ ~ (enter number) ¢ OK

¢ ~ (enter name) ¢ OK

Storing a number in the directory

h ¢ MENU ¢ New Entry ¢ OK

¢ ~ (enter number) ¢ OK

¢ ~ (enter name) ¢ OK

Selecting a directory entry

Open the directory with h. You have the following

options:

◆Use u to scroll through the entries until the

required name is selected.

◆Enter the first character of the name and scroll to

the entry with u, if required.

Dialling with the directory

h ¢ u (select entry) ¢ c

Using other functions

h ¢ u (select entry) ¢ MENU

The following functions can be selected with u:

Using shortcut keys

You can assign directory entries to the keys 0 and 2–9:

h ¢ u (select entry) ¢ MENU ¢ Shortcut ¢ OK

¢ ~ (press the key you want to assign the entry to)

New Entry Save new phone number.

Show Number Display the phone number.

Use Number Edit or add to the number.

Then dial or select other

functions from the MENU.

Edit Entry Edit selected entry.

Delete Entry Delete selected entry.

Send Entry Send a single entry to another

handset (¢ page 8).

Delete List Delete all directory entries.

Send List Send the complete list to another

handset (¢ page 8).

Shortcut For shortcuts, assign the current

entry to a key.

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / main.fm / 19.01.2011

To dial, press and hold the required shortcut key.

Transferring the directory to another handset

Requirements:

◆The sending and receiving handsets must both be

registered to the same base station.

◆The other handset and the base station can send

and receive directory entries.

h ¢ u (select entry) ¢ MENU ¢ Send Entry /

Send List ¢ OK ¢ ~ (enter the internal number of

the receiving handset) ¢ OK

Last number redial list

This list contains the ten last dialled numbers.

Dialling from the last number redial list

c (press briefly) ¢ u (select entry) ¢ c

Managing entries in the last number redial list

c (press briefly) ¢ u (select entry) ¢ MENU

You can select the following settings:

Opening lists with the message key

An advisory tone sounds and the message key

flashes as soon as a new entry appears in the list. A

message appears in the display.

If you press the message key f, you will see all lists

that contain new messages. If only one list contains

new messages, this will be opened automatically.

Setting the alarm clock

Activating/deactivating the alarm clock

MENU ¢ Alarm Clock ¢ OK ¢ Activation

¢ OK (‰ = on)

When activated:

¢ Set the wake-up time ¢ OK

When the alarm clock rings, press any key to switch it

off for 24 hours. If the alarm clock is set, the wake-up

icon l will appear on the screen and the wake-up

time will be displayed instead of the date.

Setting the wake-up time

MENU ¢ Alarm Clock ¢ OK ¢ Wake-up time

¢ OK

Enter the wake-up time in hours and minutes, then

press OK.

Phone settings

For details on how to set audio settings, see Menu

tree ¢ page 16.

Changing the display language

MENU ¢ Settings ¢ OK ¢ Handset ¢ OK

¢ Language ¢ OK ¢ select the language ¢ OK

The current language is indicated by ‰.

If you accidentally choose a language you do not

understand:

MENU ¢ 4 2 1 (press the keys one after the other)

Select the correct language with u and press OK.

Resetting the handset

You can reset individual settings and changes that

you have made. Entries in the directory, the calls list

and the handset's registration to the base station will

be retained.

MENU ¢ Settings ¢ OK ¢ Handset ¢ OK

¢ Reset Handset ¢ OK

Cancel the reset with a.

Use Number Edit or add to the number.

Then dial or select other

functions from the MENU.

Copy to Dir. Copy an entry to the directory.

Delete Entry Delete selected entry.

Delete List Delete all entries.

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / main.fm / 19.01.2011

Appendix

Entering letters/characters

Press the relevant key the number of times indicated.

Briefly press the hash key # to switch from "Abc" to

"123" mode, from "123" to "abc" mode and from "abc"

to "Abc" mode.

Standard characters

1) Space

Specifications

Recommended batteries

Technology: Nickel-metal-hydride (NiMH)

Size: AAA (Micro, HR03)

Voltage: 1.2 V

Capacity: 400–800 mAh

We recommend the following types of battery:

◆GP 550/700 mAh

◆Yuasa Phone 700/800 mAh

◆Peacebay 550/650 mAh

(Valid at the time of going to press)

The handset is supplied with recommended batter-

ies.

General specifications

Questions and answers

If you have any queries about the use of your tele-

phone, visit our website at

www.gigaset.com/customercare

for assistance 24/7. The table below contains a list of

common problems and possible solutions.

1x 2x 3x 4x 5x 6x 7x 8x 9x 10x11x12x13x14x

11£$¥¤

2a b c 2 ä á à â ã ç

Id e f 3 ë é è ê

4gh i 4 ï í ì î

5j k l 5

Lm n o 6 ö ñ ó ò ô õ

Mp q r s 7 ß

Nt u v 8 ü ú ù û

Ow x y z 9 ÿ ý æ ø å

Q. , ? ! 0 + - : ¿ ¡ " ’ ; _

P * / ( ) < = > %

# Abc

-->

123

-->

abc # @ \ & §

DECT standard is supported

GAP standard is supported

Range up to 300 m outdoors

up to 50 m indoors

Environmental conditions

in operation

+5°C to +45°C, 20% to

75% relative humidity

Problem Cause Solution

Nothing

appears in

the display.

The handset is

not switched on.

The batteries

are flat.

Press the end call

key a for approx.

5 seconds or place the

handset in the base

station.

Charge or replace

the batteries.

No wireless

connection

to the base sta-

tion,

Base flashes in

the display.

The handset is out-

side the range of

the base station.

The handset is

not registered.

The base station

is not turned on.

Move the handset

closer to the base sta-

tion.

¢ page 5.

Check the mains plug

on the base station.

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / main.fm / 19.01.2011

Industry Canada Certification

Operation is subject to the following two conditions

(1) this device may not cause interference, and (2) this

device must accept any interference, including inter-

ference that may cause undesired operation of the

device.

NOTICE: The Industry Canada label identifies certified

equipment. This certification means that the equip-

ment meets certain telecommunications network,

protective, operational and safety requirements as

prescribed in the appropriate Terminal Equipment

Technical Requirements document(s). The Depart-

ment does not guarantee the equipment will operate

to the user’s satisfaction.

Before installing this equipment, users should ensure

that it is permissible to be connected to the facilities

of the local telecommunications company. The

equipment must also be installed using an accepta-

ble method of connection. The customer should be

aware that compliance with the above conditions

may not prevent degradation of service in some situ-

ations.

Repairs to certified equipment should be coordinated

by a representative designated by the supplier.

Any repairs or alterations made by the user to this

equipment, or equipment malfunctions, may give the

telecommunications company cause to request the

user to disconnect the equipment.

Users should ensure for their own protection that

the electrical ground connections of the power util-

ity, telephone lines and internal metallic water pipe

system, if present, are connected together.

This precaution may be particularly important in rural

areas

NOTE: Users should not attempt to make such con-

nections themselves, but should contact the appro-

priate electric inspection authority, or electrician, as

appropriate.

This product meets the applicable Industry Canada

technical specifications.

The Ringer Equivalence Number is an indication of

the maximum number of devices allowed to be con-

nected to a telephone interface. The termination of

an interface may consist of any combination of

devices subject only to the requirement that the sum

of the RENs of all devices does not exceed five.

This Class B digital apparatus complies with Canadian

ICES-003.

Cet appareil numérique de la classe B est conforme à

la norme NMB-003 du Canada.

FCC / ACTA Information

Warning: Changes or modifications to this unit not

expressly approved by Gigaset Communications USA

LLC could void the FCC authority to operate the

equipment. This includes the addition of any external

antenna device.

This equipment complies with Part 68 of the FCC rules

and the requirements adopted by the ACTA. On the

bottom of the base station is a label that contains,

among other information, a product identifier in the

format US:AAAEQ##TXXXX. If requested, this number

must be provided to the telephone company.

A plug and jack used to connect this equipment to

the premises wiring and telephone network must

comply with the applicable FCC Part 68 rules and

requirements adopted by the ACTA. A compliant tele-

phone cord and modular plug is provided with this

product. It is designed to be connected to a compati-

ble modular jack that is also compliant. See installa-

tion instructions for details.

The REN is used to determine the number of devices

that may be connected to a telephone line. Excessive

RENs on a telephone line may result in the devices not

ringing in response to an incoming call. In most but

not all areas, the sum of RENs should not exceed five

(5.0). To be certain of the number of devices that may

be connected to a line, as determined by the total

RENs, contact the local telephone company.

For products approved after July 23, 2001, the REN for

this product is part of the product identifier that has

the format US:AAAEQ##TXXXX. The digits repre-

sented by ## are the REN without a decimal point

(e.g., 03 is a REN of 0.3). For earlier products, the REN is

separately shown on the label.

A copy of the supplier's Declaration of Conformity

(SDoC) is available at this Internet address:

www.gigaset.com/docs.

If this equipment causes harm to the telephone

network, the telephone company will notify you

advance, that temporary discontinuance of service

may be required. But if advance notice isn’t practical,

the telephone company will notify the customer as

soon as possible. Also, you will be advised of your

right to file a complaint with the FCC if you believe it

is necessary.

The telephone company may make changes in its

facilities, equipment, operations or procedures that

could affect the operation of the equipment. If this

happens the telephone company will provide

advance notice in order for you to make necessary

modifications to maintain uninterrupted service. If

you experience trouble with this telephone system,

disconnect it from the network until the problem has

been corrected or until you are sure that the equip-

ment is not malfunctioning.

If trouble is experienced with this equipment, for

repair or warranty information, please contact Sup-

port at 1-866 247-8758. If the equipment is causing

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / main.fm / 19.01.2011

harm to the telephone network, the telephone com-

pany may request that you disconnect the equip-

ment until the problem is resolved. This equipment is

of a type that is not intended to be repaired by the

Customer (user).

This telephone system may not be used on coin serv-

ice provided by the telephone company. Connection

to party line service is subject to state tariffs. Contact

the state public utility commission, public service

commission or corporation commission for informa-

tion. Privacy of communications may not be ensured

when using this phone.

If your home has specially wired alarm equipment

connected to the telephone line, ensure the installa-

tion of this equipment does not disable your alarm

equipment. If you have questions about what will

disable alarm equipment, consult your telephone

company or a qualified installer.

This telephone system equipment has been tested

and found to comply with the limits for Class B digital

device, pursuant to Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference,

and (2) This device must accept any interference

received, including interference that may cause

undesired operation. These limits are designed to

provide reasonable protection against harmful inter-

ference in a residential installation. Some cordless tel-

ephones operate at frequencies that may cause inter-

ference to nearby TV’s and VCR’s; to minimize or pre-

vent such interference, the system base should not be

placed near or on top of a TV or VCR; and, if interfer-

ence is experienced, moving the base farther away

from the TV or VCR will often reduce or eliminate

the interference.

However, there is no guarantee that interference will

not occur in a particular installation. If this telephone

system does cause harmful interference to radio or

television reception, which can be determined by

turning the system off and on, the user is encouraged

to try to correct the interference by one or more of the

following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the base station

and receiver.

3. Connect the base station into an outlet on a circuit

different from that to which the receiver is connected.

4. Consult the dealer or an experienced radio TV

technician for help.

Notice for Direct Inward Dialing ("DID")

ALLOWING THIS EQUIPMENT TO BE OPERATED IN

SUCH A MANNER AS TO NOT PROVIDE FOR PROPER

ANSWER SUPERVISION IS A VIOLATION OF PART 68 OF

THE FCC‘S RULES.

Notice to Hearing Aid Wearers:

This phone system is compatible with inductively

coupled hearing aids.

Power Outage:

In the event of a power outage, your cordless

telephone will not operate. The cordless telephone

requires electricity for operation. You should have a

telephone that does not require electricity available

for use during power outages.

Notice:

The installation of the base unit should allow at least

8 inches between the base and persons to be in

compliance with FCC RF exposure guidelines.

For body worn operation, the portable part (handset)

has been tested and meets FCC RF exposure guide-

lines. Use with an accessory that contains metal parts

may not ensure compliance with FCC RF exposure

guidelines.

Notice to telephone company service:

If you need service from your telephone company,

please provide them with the information

– Facility interface Code (FIC)

– Service Order Code (SOC)

– Universal Service Order Code (USOC)

as indicated on the label on the bottom side of the

base station.

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / main.fm / 19.01.2011

Safety precautions

Before using your telephone equipment, basic safety

instructions should always be followed to reduce the

risk of fire, electric shock and injury to persons.

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on the

product.

3. Unplug this product from the wall telephone jack

and power outlet before cleaning. Do not use liquid

cleaners or aerosol cleaners. Use damp cloth for

cleaning.

4. Do not use this product near water, for example,

near a bathtub, wash bowl, kitchen sink, or laundry

tub, in a wet basement or near a swimming pool.

5. Place this product securely on a stable surface. Seri-

ous damage and/or injury may result if the unit falls.

6. Slots or openings in the cabinet and the back and

bottom are provided for ventilation, to protect it from

overheating. These openings must not be blocked or

covered. This product should never be placed near or

over a radiator or heat register, or in a place where

proper ventilation is not provided.

7. This product should be operated only from the type

of power source indicated on the marking label. If you

are not sure of the type of AC line power to your

home, consult your dealer or local power company.

8. Do not place objects on the power cord. Install the

unit where no one can step or trip on the cord.

9. Do not overload wall outlets and extension cords as

this can result in the risk of fire or electric shock.

10. Never push objects of any kind into this product

through cabinet slots as they may touch dangerous

voltage points or short out parts that could result in

the risk of fire or electric shock. Never spill liquid of

any kind on this product.

11. To reduce the risk of electric shock or burns, do not

disassemble this product. Take it to a qualified service

center when service is required. Opening or removing

covers may expose you to dangerous voltages, dan-

gerous electrical current or other risks. Incorrect reas-

sembly can cause electric shock when the appliance

is subsequently used. Disconnect TNV circuit connec-

tor before removing cover.

12. Unplug the product from the wall outlet and refer

servicing to qualified service personnel under the fol-

lowing conditions:

a.) When the power cord is damaged or frayed.

b.) If liquid has been spilled into the product.

c.) If the product has been exposed to rain or water.

d.) If the product does not operate normally by fol-

low

ing the operating instructions. Adjust only those

controls

that are covered by the operating instruc-

tions because improper adjustment of other controls

may result in damage and may require extensive

work by a qualified technician to restore the product

to normal operation.

e.) If the product has been dropped or physically has

been damaged.

f.) If the product exhibits a distinct change in perform-

ance.

13. Avoid using a telephone (other than a cordless

type) during a thunderstorm. There may be a remote

risk of electrical shock from lightning. Therefore we

suggest a surge arrestor.

14. Do not use the telephone to report a gas leak in

the vicinity of the leak.

15. Emergency/911 numbers may not be dialed if the

keypad is locked.

16. Minimum No. 26 AWG telecommunication line

cord must be used with this phone.

BATTERY SAFETY PRECAUTIONS

To reduce the risk of fire, injury or electric shock, and

to properly dispose of batteries, please read and

understand the following instructions.

CONTAINS NICKEL METAL HYDRIDE BATTERY. BAT-

TERY MUST BE RECYCLED OR DISPOSED OF PROP-

ERLY. DO NOT DISPOSE OF IN MUNICIPAL WASTE.

1. Only use the batteries specified for use with this

product.

2. DO NOT USE NICKEL CADMIUM OR LITHIUM BAT-

TERIES, or mix batteries of different sizes or from dif-

ferent manufacturers in this product. DO NOT USE

NONRECHARGEABLE BATTERIES.

3. Do not dispose of the batteries in a fire; the cells

may explode. Do not expose batteries to water. Check

with local codes for special disposal instructions.

4. Do not open or mutilate the batteries. Released

electrolyte is corrosive and may cause damage to the

eyes or skin. The electrolyte may be toxic if swal-

lowed.

5. Exercise care in handling the batteries in order not

to short the batteries with conducting materials such

as rings, bracelets, and keys. The batteries or conduct-

ing material may overheat and cause burns or fire.

6. Charge the batteries provided with, or identified for

use with, this product only in accordance with the

instructions and limitations specified in the user’s

manual. Do not attempt to charge the batteries with

any means other than that specified in the users

manual.

7. Periodically clean the charge contacts on both the

charger and handset.

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / main.fm / 19.01.2011

Service (Customer Care)

Customer Care Warranty for Cordless Products

To obtain Customer Care Warranty service,

product operation information, or for problem resolution, call:

Toll Free: 1-866 247-8758

End-user limited warranty

This product is covered by a one year limited war-

ranty. Any repair replacement or warranty service,

and all questions about this product should be

directed to: 1-866 247-8758.

This limited, non-transferable warranty is provided to

the original buyer/end-consumer ("you") for systems,

handsets and accessories (collectively, "Product") pro-

vided by Gigaset Communications USA LLC or

Gigaset Communications Canada Inc. (collectively

"Gigaset NAM"). Gigaset NAM warrants to you that at

the date of purchase, the Product is free of defects in

workmanship and materials and the software

included in the Product will perform in substantial

compliance to its program specifications.

1. WARRANTY PERIOD

The Product warranty period is one (1) year from the

original date of purchase by you. Proof of purchase

(e.g., sales slip or invoice) must be provided with any

Product returned during the warranty period. Batter-

ies supplied with the Products are warranted to be

free from defects at the time of purchase only.

2. EXCLUSIVE REMEDY

Gigaset NAM's entire liability and your exclusive rem-

edy if the Product is defective in materials or work-

manship during the warranty period and is returned

shall be that the Product will be repaired or replaced

as set forth in Section 4 below. Reconditioned

replacement components, parts or materials may be

used in the replacement or repair. Data in the mem-

ory of the Product may be lost during repair.

3. THIS LIMITED WARRANTY DOES NOT

COVER AND IS VOID WITH RESPECT TO

THE FOLLOWING:

– Cosmetic damage, physical damage to the surface

of the Product, including, without limitation,

breakage, cracks, dents, scratches or adhesive

marks on the LCD screen or outside casing of the

Product.

– Products which have been repaired, maintained

or modified (including the antenna) by anyone

other than Gigaset NAM or a Gigaset NAM-

approved repair facility, or that have been improp-

erly installed.

– Cost of installation, removal or reinstallation.

– Damage due to any telephone, electronic, hard-

ware or software program, network, Internet or

computer malfunctions, failures, or difficulties of

any kind, including without limitation, server fail-

ure or incomplete, incorrect, garbled or delayed

computer transmissions.

– Equipment and components not manufactured,

supplied or authorized by Gigaset NAM.

– Modification of the Product's components, or

operation of the Product in an unsuitable environ-

ment or in a manner for which it is not intended,

including but not limited to failures or defects

caused by misuse, abuse, accidents, physical dam-

age, abnormal operation, improper handling or

storage, neglect, alterations, unauthorized instal-

lation, removal or repairs, failure to follow instruc-

tions, problems caused by the carrier's network

coverage, exposure to fire, water or excessive

moisture or dampness, floods, or extreme

changes in climate or temperature, acts of God,

riots, acts of terrorism, spills of food or liquids,

viruses or other software flaws introduced into the

Product or other acts which are not the fault of

Gigaset NAM and which the Product is not speci-

fied to tolerate, including damage caused by mis-

handling or blown fuses.

– Products which have had warranty stickers, elec-

tronic serial number and/or serial number label

removed, altered, rendered illegible or fraudu-

lently applied to other equipment.

– Signal reception problems (unless caused by

defect in material or workmanship in the Product).

– Products operated outside published maximum

ratings.

– Performance of the Products when used in combi-

nation with other products or equipment not

manufactured, supplied or authorized by Gigaset

NAM.

– Consumables (such as batteries and fuses).

– Payments for labor or service to representatives or

service centers not authorized to perform product

maintenance by Gigaset NAM.

– Loss of data.

– Testing and examination discloses that the

alleged defect or malfunction in the Product does

not exist.

This warranty does not cover customer education,

instruction, installation or removal, set up adjust-

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / main.fm / 19.01.2011

ments, problems related to service(s) provided by a

carrier or other service provider, and/or signal recep-

tion problems. Gigaset NAM shall not be responsible

for software, firmware, information, or memory data

contained in, stored on, or integrated with any Prod-

ucts returned for repair, whether under warranty or

not. This warranty is valid only in the country in which

it is purchased (i.e., the United States of America or

Canada respectively, but not both).

USE WITH ACCESSORIES NOT SUPPLIED BY

GIGASET NAM OR NOT OTHERWISE EXPRESSLY

AUTHORIZED BY GIGASET NAM MAY VOID WAR-

RANTY.

4. WARRANTY CLAIM PROCEDURE

All warranty claims must be made by notifying

Gigaset NAM prior to the expiration of the warranty

period. Gigaset NAM's obligation to provide warranty

support shall not extend past the end of the warranty

period, except that any product repaired or replaced

during the warranty period shall continue to be war-

ranted for the balance of such warranty period or

thirty (30) days, whichever is greater.

Support service will be provided for you by accessing

the toll free customer service number:

1-866 247-8758

5. LIMITATION OF WARRANTY

Gigaset NAM makes no warranty or representation

that the software in the Products will meet your

requirements or will work in combination with any

hardware or applications software products provided

by third parties, that the operation of the software

will be uninterrupted or error free, or that all defects

in the software products will be corrected.

6. LIMITATION ON REMEDIES; NO

CONSEQUENTIAL OR OTHER DAMAGES

Your exclusive remedy for any breach of this limited

warranty is as set forth above. Except for any refund

elected by Gigaset NAM, YOU ARE NOT ENTITLED

TO ANY DAMAGES, INCLUDING BUT NOT LIMITED

TO CONSEQUENTIAL DAMAGES, if the Product does

not meet the limited warranty , and, to the maximum

extent allowed by applicable law, even if any remedy

fails of its essential purpose. The terms below ("Exclu-

sion of Incidental, Consequential and Certain Other

Damages") are also incorporated into this limited

warranty . Some states/jurisdictions/provinces do not

allow the exclusion or limitation of incidental or con-

sequential damages, so the above limitation or exclu-

sion may not apply to you. This limited warranty gives

you specific legal rights. You may have others which

vary from state/jurisdiction/province to state/juris-

diction/province.

7. DISCLAIMER OF WARRANTIES

GIGASET NAM AND ITS SUPPLIERS PROVIDE THE

PRODUCT AND SUPPORT SERVICES (IF ANY) AS IS

AND WITH ALL FAULTS. THE LIMITED WARRANTY IS IN

LIEU OF ANY OTHER EXPRESS WARRANTIES (IF ANY)

CREATED BY ANY DOCUMENTATION OR PACKAGING

EXCEPT FOR THE LIMITED WARRANTY, AND TO THE

MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW

IS IN LIEU OF ANY IMPLIED OR STATUTORY WARRAN-

TIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED

WARRANTIES OF MERCHANTABILITY AND FITNESS

FOR A PARTICULAR PURPOSE, OF ACCURACY OR

COMPLETENESS OR RESPONSES, OF RESULTS, OF

WORKMANLIKE EFFORT, OF LACK OF VIRUSES AND

OF LACK OF NEGLIGENCE, ALL WITH REGARD TO THE

PRODUCT, AND THE PROVISION OF OR FAILURE TO

PROVIDE SUPPORT SERVICES. ALSO, THERE IS NO

WARRANTY OR CONDITION OF TITLE, QUIET ENJOY-

MENT, QUIET POSSESSION, OR CORRESPONDENCE TO

DESCRIPTION OR NONINFRINGEMENT WITH REGARD

TO THE PRODUCT. Some states/jurisdictions/prov-

inces do not allow limitations on how long an implied

warranty lasts or the exclusion or limitation of inci-

dental or consequential damages, so the above exclu-

sions or limitations may not apply to you. If an implied

warranty or condition is created by your state/prov-

ince and federal or state/provincial law prohibits dis-

claimer of it, you also have an implied warranty or

condition, BUT ONLY AS TO DEFECTS DISCOVERED

DURING THE PERIOD OF THIS LIMITED WARRANTY

(ONE YEAR). AS TO ANY DEFECTS DISCOVERED AFTER

THE ONE YEAR PERIOD, THERE IS NO WARRANTY OR

CONDITION OF ANY KIND.

This limited warranty gives you specific legal rights,

and you may also have other rights which vary from

state to state/province to province. In no event shall

Gigaset NAM's liability exceed the cost of repairing or

replacing defective Products as provided herein, and

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / main.fm / 19.01.2011

any such liabilities will terminate upon expiration of

the warranty period.

Any supplements or updates to the Product or the

software in the Product, including without limitation,

any (if any) software fixes or upgrades or bug fixes

provided to you after the expiration of the one year

limited warranty period are not covered by any war-

ranty or condition, express, implied or statutory.

8. EXCLUSION OF INCIDENTAL,

CONSEQUENTIAL AND CERTAIN OTHER

DAMAGES

TO THE MAXIMUM EXTENT PERMITTED BY APPLICA-

BLE LAW, IN NO EVENT SHALL GIGASET NAM, SELLER

OR THEIR SUPPLIERS BE LIABLE FOR ANY SPECIAL,

INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAM-

AGES WHATSOEVER (INCLUDING, BUT NOT LIMITED

TO, DAMAGES FOR LOSS OF PROFITS OR CONFIDEN-

TIAL OR OTHER INFORMATION, FOR BUSINESS INTER-

RUPTION, FOR PERSONAL INJURY, FOR LOSS OF PRI-

VACY, FOR FAILURE TO MEET ANY DUTY INCLUDING

OF GOOD FAITH OR OF REASONABLE CARE, FOR NEG-

LIGENCE, AND FOR ANY OTHER PECUNIARY OR

OTHER LOSS WHATSOEVER) ARISING OUT OF OR IN

ANY WAY RELATED TO THE USE OF OR INABILITY TO

USE THE PRODUCT, THE PROVISION OF OR FAILURE

TO PROVIDE SUPPORT SERVICES, OR OTHERWISE

UNDER OR IN CONNECTION WITH ANY PROVISION OF

THIS LIMITED WARRANTY, EVEN IN THE EVENT OF THE

FAULT, TORT (INCLUDING NEGLIGENCE), STRICT LIA-

BILITY, BREACH OF CONTRACT OR BREACH OF WAR-

RANTY OF GIGASET NAM OR SELLER OR ANY SUP-

PLIER, AND EVEN IF GIGASET NAM OR SELLER OR ANY

SUPPLIER HAS BEEN ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. REPAIR OR REPLACEMENT, AS PRO-

VIDED UNDER THE WARRANTY, IS YOUR SOLE AND

EXCLUSIVE REMEDY FOR BREACH OF THE LIMITED

WARRANTY.

9. LIMITATION OF LIABILITY AND

REMEDIES

NOTWITHSTANDING ANY DAMAGES THAT YOU

MIGHT INCUR FOR ANY REASON WHATSOEVER

(INCLUDING, WITHOUT LIMITATION, ALL DAMAGES

REFERENCED ABOVE AND ALL DIRECT OR GENERAL

DAMAGES), THE ENTIRE LIABILITY OF GIGASET NAM,

SELLER AND ANY OF THEIR SUPPLIERS UNDER ANY

PROVISION OF THIS LIMITED WARRANTY AND YOUR

EXCLUSIVE REMEDY FOR ALL OF THE FOREGOING

(EXCEPT FOR ANY REMEDY OF REPAIR OR REPLACE-

MENT ELECTED BY GIGASET NAM OR SELLER OR SUP-

PLIER WITH RESPECT TO ANY BREACH OF THE LIM-

ITED WARRANTY) SHALL BE LIMITED TO THE GREATER

OF THE AMOUNT ACTUALLY PAID BY YOU FOR THE

PRODUCT OR FIVE DOLLARS ($5.00 USD/CAN). THE

FOREGOING LIMITATIONS, EXCLUSIONS AND DIS-

CLAIMERS SHALL APPLY TO THE MAXIMUM EXTENT

PERMITTED BY APPLICABLE LAW, EVEN IF ANY REM-

EDY FAILS ITS ESSENTIAL PURPOSE.

10. GOVERNING LAW

If this Product was purchased in the United States of

America this limited warranty will be governed by the

laws of Texas, and exclude the United Nations Con-

vention on Contracts for the International Sale of

Goods. If this Product was purchased in Canada this

limited warranty will be governed by the laws of the

Province of Ontario and the federal laws of Canada

applicable therein, and exclude the United Nations

Convention on Contracts for the

International Sale of Goods.

If you want to learn more about Gigaset Service or for

Support on your Gigaset phone, visit our web site at

http://www.gigaset.com or please call

1-866 247-8758.

Issued by

Gigaset Communications GmbH

Frankenstr. 2a, D-46395 Bocholt

Manufactured by Gigaset Communications GmbH

under trademark license of Siemens AG.

Subject to availability. Rights of modifications

reserved.

Product attributes subject to change.

We reserve the right, to make changes without notice

in equipment design and/or components.

Part Number:

AS18X/AS28X / en master / A31008-M2001-B101-1-19 / main.fm / 19.01.2011

Menu tree

Your phone has an extensive range of features. These

are offered in the form of menus.

To select a function while the phone is in idle status,

press MENU (open menu), use the t and v keys to

scroll to the function you require and press OK to con-

firm.

To return to idle status: press and hold the a key.

As an alternative to selecting functions using the t

and v keys, you can also enter the digit combination

that is in front of the function in the menu tree.

For setting the time and date, for example:

MENU ¢ 4 1 ¢ OK

Issued by

Gigaset Communications GmbH

Frankenstrasse 2a, 46395 Bocholt

Gigaset Communications GmbH is a trademark licen-

see of Siemens AG

Subject to availability.

Rights of modifications reserved.

www.gigaset.com

This user guide is made from 100% recycled paper.

1Alarm Clock

1-1 Activation Activating/deactivating the alarm clock

1-2 Wake-up time Input format: HHMM

2Audio Settings

2-1 Handset Volume 2-1-1 Earpiece Can be set to one of 3 levels

2-1-2 Speaker Can be set to one of 5 levels

2-2 Ringer Volume 5 levels + "crescendo" available

2-3 Ringer Melody 2-3-1 External Calls 10 ringer melodies available for external calls

2-3-2 Internal Calls 10 ringer melodies available for internal calls

2-3-3 Alarm Clock 10 ringer melodies available for alarm clock

2-4 Advis. Tones Activate/deactivate

2-5 Battery Low 2-5-1 Off Warning tone to indicate battery

is almost flat:

never

2-5-2 On always

2-5-3 During Call only during a call

3Voice Mail (Menu dependent on base station)

4Settings

4-1 Date/Time Enter date (DDMMYY format), then time (HHMM format)

4-2 Handset 4-2-1 Language Set the display language ¢ page 8

4-2-2 Auto Answer Automatically activate/deactivate auto answer ¢ page 7

4-2-3 Register HS Manually register the handset ¢ page 5

4-2-4 Reset Handset Reset the handset ¢ page 8

4-3 Base (Menu dependent on base station)

Gigaset Communications 5505H Portable Part User Manual AS18H 28H

Gigaset Communications GmbH Portable Part AS18H 28H

User Manual

Navigation menu

Namespaces

Views

Navigation
