Global Traffic Technologies OPTICOMGPS2 Opticom Radio Transceiver User Manual RF Module Serial Protocol

79-1000-0772-0

Revision A

OPTICOMGPS2 Radio Transceiver Module

User Manual

Page 2 of 31

Ownership Disclaimer

This document contains confidential information that is the sole property of Global Traffic

Technologies (GTT) and is intended for use by their employees and designees. The user shall keep

the contents of this document confidential and protect it from disclosure to outside parties. Any

copying, distribution, or re-use, either in part or in whole, without the express written consent of

Global Traffic Technologies is prohibited.

Trademark Conventions

The following is the list of registered trademarks of Global Traffic Technologies:

• Opticom™

All instances of Opticom, Opticom Infrared and Opticom GPS contained within this document are understood

to reference these trademarks without repeating the ™ symbol.

Page 3 of 31

Table of Contents

1. INTRODUCTION ........................................................................................................................... 4

1.1 Scope .......................................................................................................................................................................................... 4

1.2 Definitions, Acronyms, and Abbreviations ....................................................................................................................... 4

2. PROTOCOL SPECIFICATION ...................................................................................................... 5

2.1 Roles ............................................................................................................................................................................................ 5

2.2 Error Detection & Recovery................................................................................................................................................... 5

2.3 Flow Control .............................................................................................................................................................................. 5

2.4 Character Format ..................................................................................................................................................................... 5

2.5 Supported Data Types ............................................................................................................................................................ 6

2.6 Message Format ....................................................................................................................................................................... 6

3. SETUP AND CONFIGURATION MESSAGES .............................................................................. 8

3.1 Set Mode (M) .............................................................................................................................................................................. 8

3.2 Set Framing Configuration (F) .............................................................................................................................................. 9

3.3 Hop Table Configuration (H) ............................................................................................................................................... 10

3.4 Hop Table Row Index (I) ....................................................................................................................................................... 14

3.5 Transmit Slot Data (T) ........................................................................................................................................................... 15

3.6 Receive Slot Data (r) .............................................................................................................................................................. 16

3.7 Broken Mode Report (b) ....................................................................................................................................................... 17

3.8 Signal Strength Report (s) ................................................................................................................................................... 17

3.9 Set Serial Number (N) ............................................................................................................................................................ 18

3.10 Set Attenuation Level (G) ......................................................................................................................................................... 19

3.11 Erase Faults (J) ......................................................................................................................................................................... 20

4. QUERY MESSAGES ................................................................................................................... 21

4.1 Module Identity Query (D) .................................................................................................................................................... 21

4.2 Mode Query (Q) ....................................................................................................................................................................... 22

4.3 Framing Configuration Query (C) ...................................................................................................................................... 23

4.4 Hop Table Configuration Query (A) ................................................................................................................................... 24

4.5 Broken Mode (B) ..................................................................................................................................................................... 25

5. HARDWARE INTERFACE .......................................................................................................... 26

6. AGENCY STATEMENTS ............................................................................................................ 27

7. REVISION HISTORY ................................................................................................................... 31

Page 4 of 31

1. Introduction

1.1 Scope

This specification defines and controls the serial communications interface between the Global Traffic Technologies

(GTT) Radio Module controller and the RF module controller through which the configuration and control of the RF

module is performed.

1.2 Definitions, Acronyms, and Abbreviations

This section contains descriptions of terms, acronyms, and abbreviations that are used throughout this document.

3D – Three dimensional

RF – Radio Frequency

PPS – Pulse Per Second

Page 5 of 31

2. Protocol Specification

The following subsections detail the structure of the protocol. Individual message types are defined in the next major

section.

2.1 Roles

This protocol is intended to be used in a point-to-point mode only meaning one GTT controller to one RF module. The

devices act as near peers in that the GTT device assumes the role of a master device in order to perform

configuration of the RF module. However, once operations have begun, the RF module autonomously reports inbound

data as it occurs while the GTT controller periodically sends content to be transmitted and the time index to be used

in frequency hopping.

2.2 Error Detection & Recovery

All devices are expected to detect framing, checksum and overflow errors. If a device detects a communication error

such as these, the device will not send a response to the received message. It is the sender’s responsibility to detect

the lack of response from the receiving device and resend the command if it so chooses. During configuration, the

GTT controller will perform retries to ensure that the RF module is fully configured prior to enabling over-the-air

operation.

If a device receives a message without error, but the message contains invalid data, or the requested operation

cannot be performed due to the current context of the receiving device, then the device is expected to provide

information in the response to the sender that it could not carry out the command.

Under operational conditions (i.e. over-the-air), the messages are transfers of data, not diagnostics or configuration.

Failure of a transfer (See annotations in the message section) shall not require a retry since loss of a single data is

non-critical (i.e. either repeated or new data will be arriving momentarily).

2.3 Flow Control

No flow control shall be supported by this protocol.

2.4 Character Format

The supported binary character format is the following:

Start bits: 1

Data bits: 8

Stop bits: 1

Parity: None

Page 6 of 31

2.5 Supported Data Types

In order to specify the message formats, the following data type definitions are necessary:

Type Size Range

UCHAR 8 bits 0..255

CHAR 8 bits -128..127

USHORT 16 bits 0..65535

SHORT 16 bits -32768..32767

ULONG 32 bits 0..4,294,967,295

LONG 32 bits -2,147,483,648..2,147,483,647

Each byte (where a byte is 8 bits in size) of these data types is serial transmitted least-significant bit first, most-

significant bit last. Multi-byte data types are transmitted least-significant byte first, most significant byte last. For

example, an unsigned short with value 1234H would be transmitted as a byte with value 34H followed by a byte with

value 12H (i.e. little endian).

2.6 Message Format

Messages are sent from the host to the radio in multiple of 8 bytes. For messages that are not even multiples of 8

bytes, the remaining package is padded with trailing zeros (0).

Messages have the following structure:

with the fields further defined below:

The <Header> shall be a single UCHAR with a value 0x02 representing an STX.

A message receiver begins assembling a new incoming message when it receives a <Header> meeting this

specification.

16 bit value specifying the number of bytes to follow including the checksum.

The <Command> is composed of a single ASCII CHAR. Commands are defined in section 5. Commands that are

initiated by the host are always an uppercase character. Commands that initiated by the RF module or responses

to host commands are always a lowercase character.

<Data>

Page 7 of 31

The <Data> field is an optional, variable length field which has a format that is context dependent for each

<Message ID>. The maximum length for this field is not limited by the protocol.

The <Checksum> field is a single USHORT field which is the 16-bit sum (sum modulo 216) of all the bytes in the

message prior to this field. This sum includes the <Header>,<Length>,<Command>, and <Data> fields.

Page 8 of 31

3. Setup and Configuration Messages

3.1 Set Mode (M)

Used by the host to change the operational mode of RF module. Offline mode is an idle mode where operational

setup occurs. Online mode is an active operations mode where normal transmit and receive functions are performed.

Tests modes are receive test mode and transmit test mode. RF Module responds with the new active mode or a

Broken Mode status.

Offline Mode is characterized by no RF activity (transmitter off, receiver off) and no frequency hopping.

Online Mode is possible when the RF module has been completely configured.

Note: When enabled, programming mode may use a different protocol

Sent by Host:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 4

for this message.

Command UCHAR 1

Single ASCII character ‘M’ for mode.

Mode UCHAR 1

Values are :

0 – Offline Mode

1 – Online Mode

2 – Transmit Test Mode

3 – Programming

Sent by RF Module:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 5

for this message.

Command UCHAR 1

Single ASCII character ‘m’ mode acknowledge.

Status UCHAR 1

Values are:

0 – Accepted

1 – Invalid mode

2 – Cannot change mode, insufficient information or

setup

Current Mode UCHAR 1

Values are :

0 – Offline Mode

1 – Online Mode

2 – Transmit Test Mode

3 – Programming

4 – Broken Mode

Page 9 of 31

3.2 Set Framing Configuration (F)

Used by the host to configure the number of slots to occur in each frequency hop, number of data slots, and the

individual slot configurations. All slots are assumed to be receive slots until configured otherwise.

Note: the first one or more slots of a frame may not be useable if the transmission time is less than 3.167 msec. This

time is needed by the radio to tune to the new frequency.

Sent by Host:

Data Element

Base Type

Instances

Description

Length USHORT 1

Number of bytes to follow including checksum.

Value is 4 + (number of slots * 2).

Command UCHAR 1

Single ASCII character ‘F’ for framing configuration.

Number of

slots/hop UCHAR 1

Number of slots to follow. Maximum of 255 slots. Default

is 186.

For

each

slot

Slot

Size USHORT 1

Number of bytes in this slot. Maximum size is dictated

by the number of slots. Total number of bytes sent per

frame cannot exceed 16,000.

Note: Slot sizes must be even number of bytes.

Sent by RF Module:

Data Element

Base Type

Instances

Description

Length USHORT 1

Number of bytes to follow including checksum. Always 4

for this message.

Command UCHAR 1

Single ASCII character ‘f’ for framing configuration

acknowledge.

Status UCHAR 1

Values are:

0 – Accepted

1 – Invalid number of slots

2 – Invalid size

3 - Exceeds maximum byte total

Page 10 of 31

3.3 Hop Table Configuration (H)

Used by the host to specify the set of frequencies to be used in the hopping sequence. Frequencies are specified in

rows and columns. Each row is indexed by the seconds since midnight calculated from the UTC time reported by the

GPS receiver modulo the number of rows. The host will calculate the seconds since midnight and row index each

second.

Sent by Host:

Data Element Base

Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Value is

5 + (number of row * number of columns)

Command UCHAR 1

Single ASCII character ‘H’ for hop table configuration.

Number of rows UCHAR 1

Number of seconds before repeating. Maximum of 25

rows. Default is 25.

Number of columns UCHAR 1

Number of frequency changes per second. Maximum of

5 columns. Default is 3.

Note: rows * columns MUST be less than or equal to 75.

For

each

row

Channel 1 UCHAR 1

Receive channel for 1st hop in this second. Integer

channel value. Valid range is 1 to 81.

Channel 2 UCHAR 1

Receive channel for 2nd hop second.

Channel 3 UCHAR 1

Receive channel for 3rd hop in this second.

Channel n UCHAR 1

Receive channel for nth hop in this second.

Sent by RF Module:

Data Element Base

Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always

4for this message.

Command UCHAR 1

Single ASCII character ‘h’ for hop table configuration

acknowledge.

Status UCHAR 1

Values are:

0 – Accepted

1 – Invalid channel

2 – Invalid size

3 – Invalid channel sequence

Possible Hop Table Channels and Associated Frequencies:

Channel

Receive Frequency

Page 11 of 31

Number

1

2401024

2

2402048

3

2403072

4

2403096

5

2494120

6

2495144

7

2407168

8

2408192

9

2409216

10

2410240

11

2411264

12

2412288

13

2413312

14

2414336

15

2415360

16

2416384

17

2417408

18

2418432

19

2419456

20

2420480

21

2421504

22

2422528

23

2423552

24

2424576

25

2425600

26

2426624

27

2427648

28

2428672

29

2429696

30

2430720

31

2431744

32

2432768

33

2433792

34

2434816

35

2435840

36

2436864

37

2437888

38

2438912

39

2439936

40

2440960

41

2441984

42

2443008

43

2444032

44

2445056

45

2446080

46

2447104

47

2448128

48

2449152

49

2450176

50

2451200

51

2452224

52

2453248

53

2454272

54

2455296

Page 12 of 31

55

2456320

56

2457344

57

2458368

58

2459392

59

2460824

60

2461848

61

2462872

62

2463896

63

2464920

64

2465536

65

2466560

66

2467584

67

2468608

68

2469632

69

2470656

70

2471680

71

2472704

72

2473728

73

2474752

74

2475776

75

2476800

76

2477824

77

2478848

78

2479872

79

2480896

80

2481920

81

2482944

Default Hop Table Channels:

Row Column Channel

Number

1

2

57

3

54

2

1

4

2

50

3

58

3

1

8

2

52

3

6

4

1

48

2

60

3

10

5

1

46

2

42

3

12

6

1

62

2

44

3

40

7

1

14

2

38

3

64

8

1

18

2

16

Page 13 of 31

3

66

9

1

68

2

32

3

20

10

1

72

2

70

3

30

11

1

34

2

78

3

74

12

1

28

2

76

3

24

13

1

81

2

26

3

14

1

55

2

53

3

5

15

1

49

2

59

3

9

16

1

51

2

7

3

47

17

1

61

2

11

3

45

18

1

41

2

13

3

63

19

1

43

2

39

3

15

20

1

37

2

65

3

19

21

1

17

2

67

3

69

22

1

31

2

21

3

73

23

1

71

2

29

3

33

24

1

79

2

75

3

27

25

1

77

2

25

3

23

Page 14 of 31

3.4 Hop Table Row Index (I)

Defines the transmit and receive frequencies for the next 1 second interval by specifying the row index into the Hop

Table.

Sent by Host:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 4

for this message.

Command UCHAR 1

Single ASCII character ‘I’ for hop table row index.

Hop Table Index UCHAR 1

Index into the Hop table configured at startup. Indexed

by seconds since midnight modulo number of rows in

Hop Table.

Sent by RF Module:

Data Element

Base Type

Instances

Description

Length USHORT 1

Number of bytes to follow including checksum. Always 4

for this message.

Command UCHAR 1

Single ASCII character ‘i’ for hop table row index.

Status UCHAR 1

Values are:

0 – Accepted

4 – Invalid Index

Page 15 of 31

3.5 Transmit Slot Data (T)

The Transmit Slot Data message is used by the host to instruct the RF module on which slot of the slots defined in the

Framing Configuration to broadcast the supplied data. The slot, number of bytes and the data are specified. Data is

only broadcast for the next time period as defined by the framing configuration.

Data must be received by the radio no later than 50 msec prior to the 1PPS.

Only 1 TX slot per unit is allowed (i.e. no multiple broadcasts within a single frame).

Sent by Host:

Data

Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Value is

6 + value of Size)

Command UCHAR 1

Single ASCII character ‘T’ for Transmit Slot Data.

Slot UCHAR 1

Must be one of the slots defined in the framing

configuration. Range of values is 1 to Number of slots. A

value of 0 is not used.

Size USHORT 1

Number of bytes to be broadcast. Length is limited by

the size of the slot defined in the framing configuration

and the maximum size for a single transmission.

The size will be the width of the slot. If the data

Data UCHAR[Size] 1

Data to be broadcast. First byte [index 0] is first to be

broadcast over the air.

Sent by RF Module:

Data

Element

Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 4

for this message.

Command UCHAR 1

Single ASCII character ‘t’ for Transmit Slot Data

acknowledgement.

Status UCHAR 1

Values are:

0 – Accepted

1 – Invalid slot

2 – Invalid size

Page 16 of 31

3.6 Receive Slot Data (r)

A Receive Slot Data message is sent at the conclusion of each slot regardless of whether data was received or not.

If no data was received, then the Size field specifies 0, the data field is omitted, the received CRC is 0, the calculated

CRC is 0, and the RSSI is the valued that was sampled during the slot.

Sent by RF Module:

Data

Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Value is

12 + value of Size).

Command UCHAR 1

Single ASCII character ‘r’ for Receive Slot Data.

Slot UCHAR 1

Must be one of the slots defined in the framing

configuration.

Size USHORT 1

Number of bytes received. Length is limited by the size

of the slot defined in the framing configuration.

Data UCHAR[Size] 1

Data received. . First byte [index 0] is first to be received

over the air. Field is omitted if length is 0.

TX CRC USHORT 1

Transmitted CRC. Calculated by transmitter.

RX CRC USHORT 1

Calculated CRC on the receive side.

RSSI UCHAR 1

Received Signal strength indicator.

SNR UCHAR 1

Approximation of Signal to noise ration 0-255

representing 0-25.5 dB. At 10 dB, running at .01 BER.

Sent by Host:

No acknowledgement. Assumed that new data will with the next frequency hop.

Page 17 of 31

3.7 Broken Mode Report (b)

A Broken Mode Report message is sent to the GTT controller whenever a failure is detected.

Sent by RF Module:

Data

Element

Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Value is

4 + number of failures).

Command UCHAR 1

Single ASCII character ‘b’ for Broken Mode Report.

Number of

Failures UCHAR 1

Count of failure codes to follow.

Failure UCHAR

Number of

failures

Active failure indications.

1 – No 1 PPS detected

2 – VSWR fault

Sent by Host:

No acknowledgement.

3.8 Signal Strength Report (s)

The Signal Strength Report message is sent to the GTT controller at the end of every frame. There is an RSSI value

for each slot in the frame. The report is sent even if none of the slots had data in them.

Sent by RF Module:

Data Element Base

Type Instance

s Description

Length USHORT 1

Number of bytes to follow including checksum.

Value is 3 + number of slots).

Command UCHAR 1

Single ASCII character ‘s’ for Signal Strength

Report.

For

each

slot

RSSI UCHAR Number

of slots in

the frame

The RSSI for each slot defined in the framing

configuration.

Sent by Host:

No acknowledgement.

Page 18 of 31

3.9 Set Serial Number (N)

Used by the host controller to set the radio module’s serial number.

Sent by Host:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 13

for this message.

Command UCHAR 1

Single ASCII character ‘N’ for Set Serial Number.

Serial Number UCHAR[10] 1

Format is: RAyywwssss where

RA denotes RF module with OMAP processor (dual core)

yy demotes the last two digits of the year and ww is the

week since the beginning of the year and

ssss is the sequence number as labeled on the radio

board.

RByywwssss denotes RF module with TMS processor

(single core).The yy, ww and ssss fields are the same.

Sent by RF Module:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 3

for this message.

Command UCHAR 1

Single ASCII character ‘n’ for Set Serial Number

acknowledge.

Page 19 of 31

3.10 Set Attenuation Level (G)

Used by the host controller to set the radio module’s transmit attenuation level.

Sent by Host:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 4

for this message.

Command UCHAR 1

Single ASCII character ‘G’ for Set Attenuation Level.

Attenuation

Level UCHAR 1

Valid range of values is 0-15.A value of 0 is no

attenuation and a value of 15 is maximum attenuation.

Sent by RF Module:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 4

for this message.

Command UCHAR 1

Single ASCII character ‘g’ for Set Attenuation Level

Acknowledge.

Status UCHAR 1

Values are:

0 – Accepted

5 – Invalid attentuation

Page 20 of 31

3.11 Erase Faults (J)

Used by the host controller to clear any existing fault indicators.

Sent by Host:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always

43for this message.

Command UCHAR 1

Single ASCII character ‘J’ for Erase Faults.

Sent by RF Module:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 3

for this message.

Command UCHAR 1

Single ASCII character ‘j’ for Erase Faults acknowledge.

Page 21 of 31

4. Query Messages

4.1 Module Identity Query (D)

Used by the host controller to query the make/model and firmware revision of the unit.

Sent by Host:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 3

for this message.

Command UCHAR 1

Single ASCII character ‘D’ for Query Identity.

Sent by RF Module:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 22

for this message.

Command UCHAR 1

Single ASCII character ‘d’ for Identity acknowledge.

Serial Number UCHAR[10] 1

Format is: RMssssssss where

RM denotes RF module and

ssssssss is the sequence number as labeled on the

radio board.

Refer to GTT Serial Number Format specification 79-

1000-0205-0

Firmware

Revision UCHAR[9] 1

ASCII string representing the revision string.

Format is: XX.XX .XXX Leading zeros to be supplied if

single digit version number.

Page 22 of 31

4.2 Mode Query (Q)

Used by the host controller to query the current operating mode of the unit.

Sent by Host:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 3

for this message.

Command UCHAR 1

Single ASCII character ‘Q’ for query mode.

Sent by RF Module:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always 4

for this message.

Command UCHAR 1

Single ASCII character ‘q’ for Mode Acknowledge

Current Mode UCHAR 1

Values are :

0 – Offline Mode

1 – Online Mode

2 – Transmit Test Mode

3 – Programming

4 – Broken Mode

Page 23 of 31

4.3 Framing Configuration Query (C)

Used by the host controller to query the current framing configuration of the unit.

Sent by Host:

Data Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Always

3for this message.

Command UCHAR 1

Single ASCII character ‘C’ for Query Framing

Configuration.

Sent by RF Module:

Data Element

Base Type

Instances

Description

Length USHORT 1

Number of bytes to follow including checksum. Value is 4

+ (Number of slots * 2).

Command UCHAR 1

Single ASCII character ‘c’ for Framing Configuration

acknowledge.

Number of

slots/hop UCHAR 1

Number of slots to follow. Maximum of 255 slots. Default

is 186.

For

each

slot

Slot

Size USHORT 1

Number of bytes in this slot. Maximum size is dictated by

the number of slots. Total number of bytes sent per frame

cannot exceed 16,000.

Page 24 of 31

4.4 Hop Table Configuration Query (A)

Used by the host controller to query the Hop Table Configuration of the unit.

Sent by Host:

Data Element

Base Type

Instances

Description

Length USHORT 1

Number of bytes to follow including checksum. Always 3

for this message.

Command UCHAR 1

Single ASCII character ‘A’ for query Hop Table

Configuration.

Sent by RF Module:

Data Element Base

Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Value is

5 + (number of rows * number of columns)

Command UCHAR 1

Single ASCII character ‘a’ for Hop Table Configuration

acknowledge.

Number of rows UCHAR 1

Number of seconds before repeating. Maximum of 25 rows.

Default is 25.

Number of columns UCHAR 1

Number of frequency changes per second. Maximum

of 5 columns. Default is 3.

Note: rows * columns MUST be less than or equal to

75.

For

each

row

Channel 1 UCHAR 1

Receive channel for 1st hop in this second.

Channel 2 UCHAR 1

Receive channel for 2nd hop second.

Channel 3 UCHAR 1

Receive channel for 3rd hop in this second.

Channel n UCHAR 1

Receive channel for nth hop in this second.

Page 25 of 31

4.5 Broken Mode (B)

Used by the Host to query the reasons behind a Broken Mode report.

Sent by Host:

Data Element

Base Type

Instances

Description

Length USHORT 1

Number of bytes to follow including checksum. Always 3

for this message.

Command UCHAR 1

Single ASCII character ‘‘B’ for Query Broken Mode

Report.

Sent by RF Module:

Data

Element Base Type Instances Description

Length USHORT 1

Number of bytes to follow including checksum. Value is

4 + Number of failures)

Command UCHAR 1

Single ASCII character ‘b’ for Broken Mode Report.

Number of

Failures UCHAR 1

Count of failure codes to follow.

Failure UCHAR

Number of

failures

Active failure indications.

1 – No 1 PPS detected

2 – VSWR fault

Page 26 of 31

5. Hardware Interface

The following table provides the signal interface to the 20 pin interface connector

Pin Number

Signal Name

Description

1 GND Signal/Power Ground

2 5V 5VDC Input

3 NC

4 NC

5 RXD UART Receive Data Input

6 TXD UART Transmit Data Output

7 J4.7 General Purpose Input/Output

8 GPIO2 General Purpose Input/Output 2

9 RESET Reset Input – Active High

10 STATUS Status Output

11 BOOT Boot Mode Select – Active High

12 1PPS 1 Pulse Per Second Input

13 GND Signal/Power Ground

14 3.3V 3.3VDC Input

15 NC

16 NC

17 GPIO4 General Purpose Input/Output 4

18 GPIO2 General Purpose Input/Output 2

19 GPIO3 General Purpose Input/Output 3

20 GPIO1 General Purpose Input/Output 1

Page 27 of 31

6. Agency Statements

FCC Statements

Compliance Statement (Part 15.19)

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause undesired operation.

Warning (Part 15.21)

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the

equipment.

FCC Interference Statement (Part 15.105 (b)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment

generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment

off and on, the user is encouraged to try to correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

- Consult the dealer or an experienced radio/TV technician for help.

RF Exposure (OET Bulletin 65)

To comply with FCC/IC RF exposure requirements for mobile transmitting devices, this transmitter should only be used or

installed at locations where there is at least 20cm separation distance between the antenna and all persons.

To comply with FCC/IC RF exposure limits for general population / uncontrolled exposure, the antenna(s)

used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons

and must not be co-located or operating in conjunction with any other antenna or transmitter.

Page 28 of 31

Industry Canada Statements

Section 7.1.2 of RSS-GEN

Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or

lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the

antenna type and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than

that necessary for successful communication.

User manuals for transmitters equipped with detachable antennas shall also contain the following notice in a

conspicuous location:

This radio transmitter IC7275A-OPTICOM2 has been approved by Industry Canada to operate with the antenna types

listed

below with the maximum permissible gain and required antenna impedance for each antenna

type indicated. Antenna types not included in this list, having a gain greater than the maximum

gain indicated for that type, are strictly prohibited for use with this device.

This device has been designed to operate with the antenna(s) listed below, and having a maximum gain of 3.5 dB.

Antennas not included in this list or having a gain greater than 3.5 dB are strictly prohibited for use with this device. The

required antenna impedance is 50 ohms.

List of all Antennas Acceptable for use with the Transmitter

Laird # MAF94192

HOW TSEN # S-001-1

Mobile Mark # DM2-2400/1575

Section 7.1.3 of RSS-GEN

This Device complies with Industry Canada License-exempt RSS standard(s). Operation is subject to the following two

conditions: 1) this device may not cause interference, and 2) this device must accept any interference, including

interference that may cause undesired operation of the device.

Industrie Canada déclarations

Section 7.1.2 du RSS-GEN

Aux termes des règlements de l'industrie du Canada, cet émetteur radio peut fonctionner uniquement à l'aide d'une

antenne d'un type et un maximum (ou moins) de gain approuvé pour l'émetteur par Industrie Canada. Pour réduire le

risque d'interférence aux autres utilisateurs, le type d'antenne et son gain doivent être choisis afin que la puissance

isotrope rayonnée équivalente (e.i.r.p.) ne dépasse pas ce qui est nécessaire pour une communication réussie.

Page 29 of 31

Les manuels d'utilisation pour des émetteurs équipés des antennes détachables contiendront également la

notification suivante dans un endroit remarquable

Cet émetteur radio IC7275A-OPTICOM2 a été approuvé par Industrie Canada pour fonctionner avec les types d'antennes

énumérées ci-dessous avec le gain maximal admissible et l'impédance d'antenne requise pour chaque antenne type

indiqué. Types d'antenne non inclus dans cette liste, ayant un gain supérieur au maximum gagner indiqué pour ce type,

sont strictement interdites pour une utilisation avec cet appareil.

Ce dispositif a été conçu pour fonctionner avec l'antenne (s) ci-dessous, et ayant un gain maximum de 3,5 dB. Antennes

pas inclus dans cette liste ou ayant un gain supérieur à 3,5 dB sont strictement interdites pour une utilisation avec cet

appareil. L'impédance d'antenne requise est de 50 ohms.

Liste de toutes les antennes acceptables pour une utilisation avec l'émetteur

Laird # MAF94192

HOW TSEN # S-001-1

Mobile Mark # DM2-2400/1575

Section 7.1.3 du RSS-GEN

Cet appareil est conforme avec Industrie Canada norme exempte de licence RSS (s). Son fonctionnement est soumis aux

deux conditions suivantes: 1) cette appareil peut ne pas causer l'interférence et 2) cet appareil doit accepter toute

interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil.

OEM Responsibilities to comply with FCC and Industry Canada Regulations

The OPTICOMGPS2 Module has been certified for integration into products only by

OEM integrators under the

following conditions:

1. The antenna(s) must be installed such that a minimum separation distance of 20cm is maintained

between the radiator (antenna) and all persons at all times.

2. The transmitter module must not be co-located or operating in conjunction with any other antenna or

transmitter.

As long as the two conditions above are met, further transmitter testing will not be required. However, the OEM

integrator is still responsible for testing their end-product for any additional compliance requirements required

with this module installed (for example, digital device emissions, PC peripheral requirements, etc.).

IMPORTANT NOTE: In the event that these conditions cannot be met (for certain configurations or co-location with

another transmitter), then the FCC and Industry Canada authorizations are no longer considered valid and the FCC ID

and IC Certification Number cannot be used on the final product. In these circumstances, the OEM integrator will be

Page 30 of 31

responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC and Industry

Canada authorization.

End Product Labeling

The OPTICOMGPS2

Module is labeled with its own FCC ID and IC Certification Number. If the FCC ID and IC

Certification Number are not visible when the module is installed inside another device, then the outside of the device

into which the module is installed must also display a label referring to the enclosed module. In that case, the final

end product must be labeled in a visible area with the following:

“Contains Transmitter Module FCC ID: VJB-OPTICOMGPS2”

“Contains Transmitter Module IC: 7275A-OPTICOM2”

or

“Contains FCC ID: VJB-OPTICOMGPS2”

“Contains IC: 7275A-OPTICOM2”

The OEM of the OPTICOMGPS2 Module must only use the approved antenna(s) listed above, which have been certified with

this module.

The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF

module or change RF related parameters in the user manual of the end product.

To comply with FCC and Industry Canada RF radiation exposure limits for general population, the antenna(s)

used for this transmitter must be installed such that a minimum separation distance of 20cm is maintained

between the radiator (antenna) and all persons at all times and must not be co-located or operating in

conjunction with any other antenna or transmitter.

Page 31 of 31

7. Revision History

Date Revision Status Description of Changes

March 15, 2012 A Active Initial release

Global Traffic Technologies OPTICOMGPS2 Opticom Radio Transceiver User Manual RF Module Serial Protocol

Global Traffic Technologies, LLC Opticom Radio Transceiver RF Module Serial Protocol

User Manual

Navigation menu

Namespaces

Views

Navigation
