Global Traffic Technologies OPTICOMGPS5 FHSS Module User Manual Installation manual
Global Traffic Technologies, LLC FHSS Module Installation manual
Installation manual
Copyright © 2000-2016, Global Traffic Technologies, LLC
79-1000-1471-0
Revision C.2
OPTICOMGPS5 Radio Transceiver Module
User Manual
Page 2 of 2
Copyright © 2000-2016, Global Traffic Technologies, LLC
Ownership Disclaimer
This document contains confidential information that is the sole property of Global Traffic
Technologies (GTT) and is intended for use by their employees and designees. The user shall keep
the contents of this document confidential and protect it from disclosure to outside parties. Any
copying, distribution, or re-use, either in part or in whole, without the express written consent of
Global Traffic Technologies is prohibited.
Trademark Conventions
The following is the list of registered trademarks of Global Traffic Technologies:
Opticom™
All instances of Opticom, Opticom Infrared and Opticom GPS contained within this document are understood
to reference these trademarks without repeating the ™ symbol.
Page 3 of 3
Copyright © 2000-2016, Global Traffic Technologies, LLC
Table of Contents
1.INTRODUCTION ........................................................................................................................... 4
1.1Scope .......................................................................................................................................................................................... 4
1.2Definitions, Acronyms, and Abbreviations ....................................................................................................................... 4
2.PROTOCOL SPECIFICATION ...................................................................................................... 5
2.1Roles ............................................................................................................................................................................................ 5
2.2Error Detection & Recovery................................................................................................................................................... 5
2.3Flow Control .............................................................................................................................................................................. 5
2.4Character Format ..................................................................................................................................................................... 5
2.5Supported Data Types ............................................................................................................................................................ 6
2.6Message Format ....................................................................................................................................................................... 6
3.SETUP AND CONFIGURATION MESSAGES .............................................................................. 8
3.1Set Mode (M) .............................................................................................................................................................................. 8
3.2Set Framing Configuration (F) .............................................................................................................................................. 9
3.3Hop Table Configuration (H) ............................................................................................................................................... 10
3.4Hop Table Row Index (I) ....................................................................................................................................................... 14
3.5Transmit Slot Data (T) ........................................................................................................................................................... 15
3.6Receive Slot Data (r) .............................................................................................................................................................. 16
3.7Broken Mode Report (b) ....................................................................................................................................................... 17
3.8Signal Strength Report (s) ................................................................................................................................................... 17
3.9Set Serial Number (N) ............................................................................................................................................................ 18
3.10 Set Attenuation Level (G) ........................................................................................................................................ 19
3.11 Erase Faults (J) ........................................................................................................................................................ 20
4.QUERY MESSAGES ................................................................................................................... 21
4.1Module Identity Query (D) .................................................................................................................................................... 21
4.2Mode Query (Q) ....................................................................................................................................................................... 22
4.3Framing Configuration Query (C) ...................................................................................................................................... 23
4.4Hop Table Configuration Query (A) ................................................................................................................................... 24
4.5Broken Mode (B) ..................................................................................................................................................................... 25
5.HARDWARE INTERFACE .......................................................................................................... 26
6.AGENCY STATEMENTS ............................................................................................................ 27
7.REVISION HISTORY ................................................................................................................... 31
Page 4 of 4
Copyright © 2000-2016, Global Traffic Technologies, LLC
1. Introduction
1.1 Scope
This specification defines and controls the serial communications interface between the Global Traffic Technologies
(GTT) Radio Module controller and the RF module controller through which the configuration and control of the RF
module is performed.
1.2 Definitions, Acronyms, and Abbreviations
This section contains descriptions of terms, acronyms, and abbreviations that are used throughout this document.
3D – Three dimensional
RF – Radio Frequency
PPS – Pulse Per Second
Page 5 of 5
Copyright © 2000-2016, Global Traffic Technologies, LLC
2. Protocol Specification
The following subsections detail the structure of the protocol. Individual message types are defined in the next major
section.
2.1 Roles
This protocol is intended to be used in a point-to-point mode only meaning one GTT controller to one RF module. The
devices act as near peers in that the GTT device assumes the role of a master device in order to perform
configuration of the RF module. However, once operations have begun, the RF module autonomously reports inbound
data as it occurs while the GTT controller periodically sends content to be transmitted and the time index to be used in
frequency hopping.
2.2 Error Detection & Recovery
All devices are expected to detect framing, checksum and overflow errors. If a device detects a communication error
such as these, the device will not send a response to the received message. It is the sender’s responsibility to detect
the lack of response from the receiving device and resend the command if it so chooses. During configuration, the
GTT controller will perform retries to ensure that the RF module is fully configured prior to enabling over-the-air
operation.
If a device receives a message without error, but the message contains invalid data, or the requested operation
cannot be performed due to the current context of the receiving device, then the device is expected to provide
information in the response to the sender that it could not carry out the command.
Under operational conditions (i.e. over-the-air), the messages are transfers of data, not diagnostics or configuration.
Failure of a transfer (See annotations in the message section) shall not require a retry since loss of a single data is
non-critical (i.e. either repeated or new data will be arriving momentarily).
2.3 Flow Control
No flow control shall be supported by this protocol.
2.4 Character Format
The supported binary character format is the following:
Start bits: 1
Data bits: 8
Stop bits: 1
Parity: None
Page 6 of 6
Copyright © 2000-2016, Global Traffic Technologies, LLC
2.5 Supported Data Types
In order to specify the message formats, the following data type definitions are necessary:
Type Size Range
UCHAR 8 bits 0..255
CHAR 8 bits -128..127
USHORT 16 bits 0..65535
SHORT 16 bits -32768..32767
ULONG 32 bits 0..4,294,967,295
LONG 32 bits -2,147,483,648..2,147,483,647
Each byte (where a byte is 8 bits in size) of these data types is serial transmitted least-significant bit first, most-
significant bit last. Multi-byte data types are transmitted least-significant byte first, most significant byte last. For
example, an unsigned short with value 1234H would be transmitted as a byte with value 34H followed by a byte with
value 12H (i.e. little endian).
2.6 Message Format
Messages are sent from the host to the radio in multiple of 8 bytes. For messages that are not even multiples of 8
bytes, the remaining package is padded with trailing zeros (0).
Messages have the following structure:
<Header><Length><Command><Data><Checksum>
with the fields further defined below:
<Header>
The <Header> shall be a single UCHAR with a value 0x02 representing an STX.
A message receiver begins assembling a new incoming message when it receives a <Header> meeting this
specification.
<Length>
16 bit value specifying the number of bytes to follow including the checksum.
<Command>
The <Command> is composed of a single ASCII CHAR. Commandsare defined in section 5.Commandsthat are
initiated by the host are always an uppercase character. Commands that initiated by the RF module or responses
to host commands are always a lowercase character.
Page 7 of 7
Copyright © 2000-2016, Global Traffic Technologies, LLC
<Data>
The <Data> field is an optional, variable length field which has a format that is context dependent for
each<Message ID>. The maximum length for this field is not limited by the protocol.
<Checksum>
The <Checksum> field is a single USHORT field which is the 16-bit sum (sum modulo 216) of all the bytes in the
message prior to this field. This sum includes the <Header>,<Length>,<Command>, and <Data> fields.
Page 8 of 8
Copyright © 2000-2016, Global Traffic Technologies, LLC
3. Setup and Configuration Messages
3.1 Set Mode (M)
Used by the host to change the operational mode of RF module. Offline mode is an idle mode where operational
setup occurs. Online mode is an active operations mode where normal transmit and receive functions are performed.
Tests modes are receive test mode and transmit test mode. RF Module responds with the new active mode or a
Broken Mode status.
Offline Mode is characterized by no RF activity (transmitter off, receiver off) and no frequency hopping.
Online Mode is possible when the RF module has been completely configured.
Note: When enabled, programming mode may use a different protocol
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 4
for this message.
Command UCHAR 1 Single ASCII character ‘M’ for mode.
Mode UCHAR 1 Values are :
0 – Offline Mode
1 – Online Mode
2 – Transmit Test Mode
3 – Programming
Sent by RF Module:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 5
for this message.
Command UCHAR 1 Single ASCII character ‘m’mode acknowledge.
Status UCHAR 1 Values are:
0 – Accepted
1 – Invalid mode
2 – Cannot change mode, insufficient information or
setup
Current Mode UCHAR 1 Values are :
0 – Offline Mode
1 – Online Mode
2 – Transmit Test Mode
3 – Programming
4 – Broken Mode
Page 9 of 9
Copyright © 2000-2016, Global Traffic Technologies, LLC
3.2 Set Framing Configuration (F)
Used by the host to configure the number of slots to occur in each frequency hop, number of data slots, and the
individual slot configurations. All slots are assumed to be receive slots until configured otherwise.
Note: the first one or more slots of a frame may not be useable if the transmission time is less than 3.167 msec. This
time is needed by the radio to tune to the new frequency.
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum.
Value is 4 + (number of slots * 2).
Command UCHAR 1 Single ASCII character ‘F’ for framing configuration.
Number of
slots/hop UCHAR 1 Number of slots to follow. This value should always be
set to 186 to be compatible with the legacy radio system
and is a FCC requirement. Any other value will void
FCC certification. The default value is 186.
For
each
slot
Slot
Size USHORT 1 Number of bytes in each slot are defined as follows:
Slot A0 = 128 bytes (1 slot)
Slot I 1 to I 25 = 128 bytes each (25 slots)
Slot V 1 to V 100 = 64 bytes each (100 slots)
Slot C 1 to C 60 = 30 bytes each (60 slots)
Any other values will not be compatible with the existing
Opticom GPS Radio System.
Slot sizes must be even number of bytes.
Sent by RF Module:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 4
for this message.
Command UCHAR 1 Single ASCII character ‘f’ for framing configuration
acknowledge.
Status UCHAR 1 Values are:
0 – Accepted
1 – Invalid number of slots
2 – Invalid size
3 - Exceeds maximum byte total
Page 10 of 10
Copyright © 2000-2016, Global Traffic Technologies, LLC
3.3 Hop Table Configuration (H)
Used by the host to specify the set of frequencies to be used in the hopping sequence. Frequencies are specified in
rows and columns. Each row is indexed by the seconds since midnight calculated from the UTC time reported by the
GPS receiver modulo the number of rows. The host will calculate the seconds since midnight and row index each
second.
Sent by Host:
Data Element Base
Type Instances Description
Length USHORT 1
Number of bytes to follow including checksum. Value is
5 + (number of row * number of columns)
Command UCHAR 1
Single ASCII character ‘H’ for hop table configuration.
Number of rows UCHAR 1 Number of seconds before repeating. Default is 25.
This value should always be set to 25 to be compatible
with the legacy radio system and is a FCC requirement.
Any other value will void FCC certification.
Number of columns UCHAR 1 Number of frequency changes per second. Default is 3.
This value should always be set to 3 to be compatible
with the legacy radio system and is a FCC requirement.
Any other value will void FCC certification.
For
each
row
Channel1 UCHAR 1 Receive channel for 1s
t
hop in this second. Integer
channel value. Valid range is 1 to 75.
Channel2 UCHAR 1 Receive channel for 2nd hop second.
Channel3 UCHAR 1 Receive channel for 3r
d
hop in this second.
Channeln UCHAR 1 Receive channel for nth hop in this second.
Sent by RF Module:
Data Element Base
Type Instances Description
Length USHORT 1
Number of bytes to follow including checksum. Always
4for this message.
Command UCHAR 1 Single ASCII character ‘h’ for hop table configuration
acknowledge.
Status UCHAR 1
Values are:
0 – Accepted
1 – Invalid channel
2 – Invalid size
3 – Invalid channel sequence
Page 11 of 11
Copyright © 2000-2016, Global Traffic Technologies, LLC
Hop Table Channels and Associated Frequencies:
Channel
Number Receive Frequency
1 2401024
2 2402048
3 2403072
4 2404096
5 2405120
6 2406144
7 2407168
8 2408192
9 2409216
10 2410240
11 2411264
12 2412288
13 2413312
14 2414336
15 2415360
16 2416384
17 2417408
18 2418432
19 2419456
20 2420480
21 2421504
22 2422528
23 2423552
24 2424576
25 2425600
26 2426624
27 2427648
28 2428672
29 2429696
30 2430720
31 2431744
32 2432768
33 2433792
34 2434816
35 2435840
36 2436864
37 2437888
38 2438912
39 2439936
40 2440960
41 2441984
42 2443008
43 2444032
44 2445056
45 2446080
46 2447104
47 2448128
48 2449152
49 2450176
Page 12 of 12
Copyright © 2000-2016, Global Traffic Technologies, LLC
50 2451200
51 2452224
52 2453248
53 2454272
54 2455296
55 2456320
56 2457344
57 2458368
58 2459392
59 2460824
60 2461848
61 2462872
62 2463896
63 2464920
64 2465536
65 2466560
66 2467584
67 2468608
68 2469632
69 2470656
70 2471680
71 2472704
72 2473728
73 2474752
74 2475776
75 2476800
Default Hop Table Channels:
Row Column Channel
Number
1 1 2
2 57
3 54
2 1 4
2 50
3 58
3 1 8
2 52
3 6
4 1 48
2 60
3 10
5 1 46
2 42
3 12
6 1 62
2 44
3 40
7 1 14
2 38
3 64
Page 13 of 13
Copyright © 2000-2016, Global Traffic Technologies, LLC
8 1 18
2 16
3 66
9 1 68
2 32
3 20
10 1 72
2 22
3 30
11 1 34
2 1
3 74
12 1 28
2 36
3 24
13 1 70
2 26
3 3
14 1 55
2 53
3 5
15 1 49
2 59
3 9
16 1 51
2 7
3 47
17 1 61
2 11
3 45
18 1 41
2 13
3 63
19 1 43
2 39
3 15
20 1 37
2 65
3 19
21 1 17
2 67
3 69
22 1 31
2 21
3 73
23 1 71
2 29
3 33
24 1 35
2 75
3 27
25 1 56
2 25
3 23
Page 14 of 14
Copyright © 2000-2016, Global Traffic Technologies, LLC
3.4 Hop Table Row Index(I)
Defines the transmit and receive frequencies for the next 1 second interval by specifying the row index into the Hop
Table.
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 4
for this message.
Command UCHAR 1 Single ASCII character ‘I’ for hop table row index.
Hop Table Index UCHAR 1 Index into the Hop table configured at startup. Indexed
by seconds since midnight modulo number of rows in
Hop Table.
Sent by RF Module:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 4
for this message.
Command UCHAR 1 Single ASCII character ‘i’ for hop table row index.
Status UCHAR 1 Values are:
0 – Accepted
4 – Invalid Index
Page 15 of 15
Copyright © 2000-2016, Global Traffic Technologies, LLC
3.5 Transmit Slot Data (T)
The Transmit Slot Data message is used by the host to instruct the RF module on which slot of the slots defined in the
Framing Configuration to broadcast the supplied data. The slot, number of bytes and the data are specified. Data is
only broadcast for the next time period as defined by the framing configuration.
Data must be received by the radio no later than 50 msec prior to the 1PPS.
Only 1 TX slot per unit is allowed (i.e. no multiple broadcasts within a single frame).
Sent by Host:
Data
Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Value is
6 + value of Size)
Command UCHAR 1 Single ASCII character ‘T’ for Transmit Slot Data.
Slot UCHAR 1 Must be one of the slots defined in the framing
configuration. Range of values is 1 to Number of slots. A
value of 0 is not used.
Size USHORT 1 Number of bytes to be broadcast. Length is limited by
the size of the slot defined in the framing configuration
and the maximum size for a single transmission.
The size will be the width of the slot. If the data
Data UCHAR[Size] 1 Data to be broadcast. First byte [index 0] is first to be
broadcast over the air.
Sent by RF Module:
Data
Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 4
for this message.
Command UCHAR 1 Single ASCII character ‘t’ for Transmit Slot Data
acknowledgement.
Status UCHAR 1 Values are:
0 – Accepted
1 – Invalid slot
2 – Invalid size
Page 16 of 16
Copyright © 2000-2016, Global Traffic Technologies, LLC
3.6 Receive Slot Data (r)
A Receive Slot Data message is sent at the conclusion of each slot regardless of whether data was received or not.
If no data was received, then the Size field specifies 0, the data field is omitted, the received CRC is 0, the calculated
CRC is 0, and the RSSI is the valued that was sampled during the slot.
Sent by RF Module:
Data
Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Value is
12 + value of Size).
Command UCHAR 1 Single ASCII character ‘r’ for Receive Slot Data.
Slot UCHAR 1 Must be one of the slots defined in the framing
configuration.
Size USHORT 1 Number of bytes received. Length is limited by the size
of the slot defined in the framing configuration.
Data UCHAR[Size] 1 Data received. . First byte [index 0] is first to be received
over the air. Field is omitted if length is 0.
TX CRC USHORT 1 Transmitted CRC. Calculated by transmitter.
RX CRC USHORT 1 Calculated CRC on the receive side.
RSSI UCHAR 1 Received Signal strength indicator.
SNR UCHAR 1 Approximation of Signal to noise ration 0-255
representing 0-25.5 dB. At 10 dB, running at .01 BER.
Sent by Host:
No acknowledgement. Assumed that new data will with the next frequency hop.
Page 17 of 17
Copyright © 2000-2016, Global Traffic Technologies, LLC
3.7 Broken Mode Report (b)
A Broken Mode Report message is sent to the GTT controller whenever a failure is detected.
Sent by RF Module:
Data
Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Value is
4 + number of failures).
Command UCHAR 1 Single ASCII character ‘b’ for Broken Mode Report.
Number of
Failures UCHAR 1 Count of failure codes to follow.
Failure UCHAR Number of
failures
Active failure indications.
1 – No 1 PPS detected
2 – VSWR fault
Sent by Host:
No acknowledgement.
3.8 Signal Strength Report (s)
The Signal Strength Report message is sent to the GTT controller at the end of every frame. There is an RSSI value
for each slot in the frame. The report is sent even if none of the slots had data in them.
Sent by RF Module:
Data Element Base
Type Instance
s Description
Length USHORT 1
Number of bytes to follow including checksum.
Value is 3 + number of slots).
Command UCHAR 1
Single ASCII character ‘s’ for Signal Strength
Report.
For
each
slot
RSSI UCHAR Number
of slots in
the frame
The RSSI for each slot defined in the framing
configuration.
Sent by Host:
No acknowledgement.
Page 18 of 18
Copyright © 2000-2016, Global Traffic Technologies, LLC
3.9 Set Serial Number (N)
Used by the host controller to set the radio module’s serial number.
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 13
for this message.
Command UCHAR 1 Single ASCII character ‘N’ for Set Serial Number.
Serial Number UCHAR[10] 1 Format is: RAyywwssss where
RA denotes RF module with OMAP processor (dual core)
yy demotes the last two digits of the year and ww is the
week since the beginning of the year and
ssss is the sequence number as labeled on the radio
board.
RByywwssss denotes RF module with TMS processor
(single core).The yy, ww and ssss fields are the same.
Sent by RF Module:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 3
for this message.
Command UCHAR 1 Single ASCII character ‘n’ for Set Serial Number
acknowledge.
Page 19 of 19
Copyright © 2000-2016, Global Traffic Technologies, LLC
3.10 Set Attenuation Level (G)
Used by the host controller to set the radio module’s transmit attenuation level.
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 4
for this message.
Command UCHAR 1 Single ASCII character ‘G’ for Set Attenuation Level.
Attenuation
Level UCHAR 1 Valid range of values is 0-15.A value of 0 is no
attenuation and a value of 15 is maximum attenuation.
Sent by RF Module:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 4
for this message.
Command UCHAR 1 Single ASCII character ‘g’ for Set Attenuation Level
Acknowledge.
Status UCHAR 1 Values are:
0 – Accepted
5 – Invalid attenuation
Page 20 of 20
Copyright © 2000-2016, Global Traffic Technologies, LLC
3.11 Erase Faults (J)
Used by the host controller to clear any existing fault indicators.
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always
43for this message.
Command UCHAR 1 Single ASCII character ‘J’ for Erase Faults.
Sent by RF Module:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 3
for this message.
Command UCHAR 1 Single ASCII character ‘j’ for Erase Faults acknowledge.
Page 21 of 21
Copyright © 2000-2016, Global Traffic Technologies, LLC
4. Query Messages
4.1 Module Identity Query (D)
Used by the host controller to query the make/model and firmware revision of the unit.
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 3
for this message.
Command UCHAR 1 Single ASCII character ‘D’ for Query Identity.
Sent by RF Module:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 22
for this message.
Command UCHAR 1 Single ASCII character ‘d’ for Identity acknowledge.
Serial Number UCHAR[10] 1 Format is: RMssssssss where
RM denotes RF module and
ssssssss is the sequence number as labeled on the
radio board.
Refer to GTT Serial Number Format specification 79-
1000-0205-0
Firmware
Revision UCHAR[9] 1 ASCII string representing the revision string.
Format is: XX.XX .XXX Leading zeros to be supplied if
single digit version number.
Page 22 of 22
Copyright © 2000-2016, Global Traffic Technologies, LLC
4.2 Mode Query (Q)
Used by the host controller to query the current operating mode of the unit.
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 3
for this message.
Command UCHAR 1 Single ASCII character ‘Q’ for query mode.
Sent by RF Module:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 4
for this message.
Command UCHAR 1 Single ASCII character ‘q’ for Mode Acknowledge
Current Mode UCHAR 1 Values are :
0 – Offline Mode
1 – Online Mode
2 – Transmit Test Mode
3 – Programming
4 – Broken Mode
Page 23 of 23
Copyright © 2000-2016, Global Traffic Technologies, LLC
4.3 Framing Configuration Query (C)
Used by the host controller to query the current framing configuration of the unit.
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always
3for this message.
Command UCHAR 1 Single ASCII character ‘C’ for QueryFraming
Configuration.
Sent by RF Module:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Value is 4
+ (Number of slots * 2).
Command UCHAR 1 Single ASCII character ‘c’ for Framing Configuration
acknowledge.
Number of
slots/hop UCHAR 1 Number of slots to follow. Maximum of 255 slots. Default
is 186.
For
each
slot
Slot
Size USHORT 1 Number of bytes in this slot. Maximum size is dictated by
the number of slots. Total number of bytes sent per frame
cannot exceed 16,000.
Page 24 of 24
Copyright © 2000-2016, Global Traffic Technologies, LLC
4.4 Hop Table Configuration Query (A)
Used by the host controller to query the Hop Table Configuration of the unit.
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 3
for this message.
Command UCHAR 1 Single ASCII character ‘A’ for queryHop Table
Configuration.
Sent by RF Module:
Data Element Base
Type Instances Description
Length USHORT 1
Number of bytes to follow including checksum. Value is
5 + (number of rows * number of columns)
Command UCHAR 1 Single ASCII character ‘a’ for Hop Table Configuration
acknowledge.
Number of rows UCHAR 1 Number of seconds before repeating. Maximum of 25 rows.
Default is 25.
Number of columns UCHAR 1 Number of frequency changes per second. Maximum
of 5 columns. Default is 3.
Note: rows * columns MUST be less than or equal to
75.
For
each
row
Channel1 UCHAR 1 Receive channel for 1s
t
hop in this second.
Channel 2 UCHAR 1 Receive channel for 2nd hop second.
Channel 3 UCHAR 1 Receive channel for 3r
d
hop in this second.
Channel n UCHAR 1 Receive channel for nth hop in this second.
Page 25 of 25
Copyright © 2000-2016, Global Traffic Technologies, LLC
4.5 Broken Mode (B)
Used by the Host to query the reasons behind a Broken Mode report.
Sent by Host:
Data Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Always 3
for this message.
Command UCHAR 1 Single ASCII character ‘‘B’ for Query Broken Mode
Report.
Sent by RF Module:
Data
Element Base Type Instances Description
Length USHORT 1 Number of bytes to follow including checksum. Value is
4 + Number of failures)
Command UCHAR 1 Single ASCII character ‘b’ for Broken Mode Report.
Number of
Failures UCHAR 1 Count of failure codes to follow.
Failure UCHAR Number of
failures
Active failure indications.
1 – No 1 PPS detected
2 – VSWR fault
Page 26 of 26
Copyright © 2000-2016, Global Traffic Technologies, LLC
5. Hardware Interface
The following table provides the signal interface to the 20 pin interface connector
Pin Number Signal Name Description
1 GND
Signal/Power Ground
2 5V
5VDC Input
3 NC
4 NC
5 RXD
UART Receive Data Input
6 TXD
UART Transmit Data Output
7 J4.7
General Purpose Input/Output
8 GPIO2
General Purpose Input/Output 2
9 RESET
Reset Input – Active High
10 STATUS
Status Output
11 BOOT
Boot Mode Select – Active High
12 1PPS
1 Pulse Per Second Input
13 GND
Signal/Power Ground
14 3.3V
3.3VDC Input
15 NC
16 NC
17 GPIO4
General Purpose Input/Output 4
18 GPIO2
General Purpose Input/Output 2
19 GPIO3
General Purpose Input/Output 3
20 GPIO1
General Purpose Input/Output 1
Page 27 of 27
Copyright © 2000-2016, Global Traffic Technologies, LLC
6. Agency Statements
FCC Statements
Compliance Statement (Part 15.19)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
Warning (Part 15.21)
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
FCC Interference Statement (Part 15.105 (b)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
RF Exposure (OET Bulletin 65)
To comply with FCC/IC RF exposure requirements for mobile transmitting devices, this transmitter should only be used or
installed at locations where there is at least 20cm separation distance between the antenna and all persons.
To comply with FCC/IC RF exposure limits for general population / uncontrolled exposure, the antenna(s)
used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons
and must not be co-located or operating in conjunction with any other antenna or transmitter.
Page 28 of 28
Copyright © 2000-2016, Global Traffic Technologies, LLC
Industry Canada Statements
Section 7.1.2 of RSS-GEN
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or
lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the equivalent isotopically radiated power (e.i.r.p.) is not more than
that necessary for successful communication.
User manuals for transmitters equipped with detachable antennas shall also contain the following notice in a
conspicuous location:
This radio transmitter IC 7275A-OPTICOM5 has been approved by Industry Canada to operate with the antenna types
listed
below with the maximum permissible gain and required antenna impedance for each antenna
type indicated. Antenna types not included in this list, having a gain greater than the maximum
gain indicated for that type, are strictly prohibited for use with this device.
This device has been designed to operate with the antenna(s) listed below, and having a maximum gain of 5dBi.
Antennas not included in this list or having a gain greater than 5dBi are strictly prohibited for use with this device. The
required antenna impedance is 50 ohms.
List of all Antennas Acceptable for use with the Transmitter
Laird # MAF94192 Internal to radio assembly.
HOW TSEN # S-001-1 Internal to radio assembly.
Mobile Mark # DM2-2400/1575. 15 Foot integrated cable.
Panorama # TRNBG-7-27 With C29NP-5SMA. 5 Meter cable.
Mobile Mark # SMW-304-3C3J3J-WHT-360. 30 Foot integrated cable.
Section 7.1.3 of RSS-GEN
This Device complies with Industry Canada License-exempt RSS standard(s). Operation is subject to the following two
conditions: 1) this device may not cause interference, and 2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Industrie Canada déclarations
Section 7.1.2 du RSS-GEN
En vertu du Règlement sur l'industrie canadienne, cet émetteur radio ne peut fonctionner qu'avec une antenne
et un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Pour réduire le risque
d'interférence d'autres utilisateurs, le type d'antenne et son gain doivent être sélectionnés de manière à ce que
la puissance isotopique rayonnée équivalente (e.i.r.p.) n'excède pas ce qui est nécessaire pour une
communication réussie.
Page 29 of 29
Copyright © 2000-2016, Global Traffic Technologies, LLC
Les manuels d'utilisation pour des émetteurs équipés des antennes détachables contiendront également la
notification suivante dans un endroit remarquable
Cet émetteur radio IC 7275A-OPTICOM5 a été approuvé par Industrie Canada pour fonctionner avec les types
d'antennes énumérées ci-dessous avec le gain maximal admissible et l'impédance d'antenne requise pour chaque
antenne type indiqué. Types d'antenne non inclus dans cette liste, ayant un gain supérieur au maximum gagner indiqué
pour ce type, sont strictement interdites pour une utilisation avec cet appareil.
Cet appareil a été conçu pour fonctionner avec l'antenne (les antennes) ci-dessous et ayant un gain maximum de 5 dB.
Les antennes non incluses dans cette liste ou dont le gain est supérieur à 5 dB sont strictement interdites pour cet
appareil. L'impédance d'antenne requise est de 50 ohms.
Liste de toutes les antennes acceptables pour une utilisation avec l'émetteur
Laird # MAF94192 Internal to radio assembly.
HOW TSEN # S-001-1 Internal to radio assembly.
Mobile Mark # DM2-2400/1575. 15 Foot integrated cable.
Panorama # TRNBG-7-27 With C29NP-5SMA. 5 Meter cable.
Mobile Mark # SMW-304-3C3J3J-WHT-360. 30 Foot integrated cable.
Section7.1.3du RSS-GEN
Cet appareil est conforme avec Industrie Canada norme exempte de licence RSS(s). Son fonctionnement est soumis aux
deux conditions suivantes:1) cette appareil peut ne pas causer l'interférence et 2) cet appareil doit accepter toute
interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement de l'appareil.
Responsibilities to comply with FCC and Industry Canada Regulations
The OPTICOMGPS5 Module has been certified for integration only into products manufactured by GTT under
the following conditions:
1. The antenna(s) must be installed such that a minimum separation distance of 20cm is maintained
between the radiator (antenna) and all persons at all times.
2. The transmitter module must not be co-located or operating in conjunction with any other antenna or
transmitter.
As long as the two conditions above are met, further transmitter testing will not be required. However, GTT is
still responsible for testing their end-product for any additional compliance requirements required with this
module installed (for example, digital device emissions, PC peripheral requirements, etc.).
IMPORTANT NOTE: In the event that these conditions cannot be met (for certain configurations or co-location with
another transmitter), then the FCC and Industry Canada authorizations are no longer considered valid and the FCC ID
and IC Certification Number cannot be used on the final product. In these circumstances, GTT will be responsible for re-
evaluating the end product (including the transmitter) and obtaining a separate FCC and Industry Canada authorization.
Page 30 of 30
Copyright © 2000-2016, Global Traffic Technologies, LLC
End Product Labeling
The OPTICOMGPS5Module is labeled with its own FCC ID and IC Certification Number. If the FCC ID and IC
Certification Number are not visible when the module is installed inside another device, then the outside of the device
into which the module is installed must also display a label referring to the enclosed module. In that case, the final
end product must be labeled in a visible area with the following:
“Contains Transmitter Module FCC ID: VJB-OPTICOMGPS5”
“Contains Transmitter Module IC: 7275A-OPTICOM5”
or
“Contains FCC ID: VJB-OPTICOMGPS5”
“Contains IC: 7275A-OPTICOM5”
The OPTICOMGPS5 Module must only use the approved antenna(s) listed above, which have been certified with this module.
GTT has to be aware not to provide information to the end user regarding how to install or remove this RF module or
change RF related parameters in the user manual of the end product.
To comply with FCC and Industry Canada RF radiation exposure limits for general population, the antenna(s)
used for this transmitter must be installed such that a minimum separation distance of 20cm is maintained
between the radiator (antenna) and all persons at all times and must not be co-located or operating in
conjunction with any other antenna or transmitter.
Page 31 of 31
Copyright © 2000-2016, Global Traffic Technologies, LLC
7. Revision History
Date Revision Status Description of Changes
April 26, 2016 A Obsoleted Initial release
November 8, 2017 B Obsoleted Updated for new module, OpticomGPS5.
Added SMW304 antenna. Added note for 5 dBi
antennas.
December 27, 2017 C Obsoleted Updated channel list to show channels 1 to 75.
Corrected Hopping sequence (changed on 5/25/11)
Added cable number for Panorama TRNBG-7-27
antenna.
January 4, 2018 C.1 Obsoleted Added FCC statements to section 3.2 and 3.3
January 12, 2018 C.2 Active Fixed Industry Canada statement in section 7.1.2
Remove OEM reference in Responsibilities to comply
with FCC and Industry Canada Regulations.
