TW-100



Wearable Watch Tracker

User Manual



Ver 1.0



TableofContents

Introduction................................................................................................................‐1‐

Features......................................................................................................................‐1‐

Specifications .............................................................................................................‐2‐

GettingStarted...........................................................................................................‐3‐

TW‐100DeviceConfiguration ....................................................................................‐6‐

OperationMode .........................................................................................................‐8‐

SettingsofTW‐100...................................................................................................‐10‐

FCCWarning .............................................................................................................‐15‐

CEWarning............................................................................... 錯誤!尚未定義書籤。



‐1‐



Introduction

TW‐100isawearabletypeofpersonaltrackerthatdesignedinwristwatchstyleand

intendedforsafetymonitoringforeldersandchildren.TW‐100equipswithboth

microphoneandspeakerthatallowshands‐freetwo‐waycommunicationcapability.

Also,theNotificationbuttonoffersaneasywaytomakeaphonecalltothose

pre‐setphonebooksandsendsNotificationalerttogetherwithjustasingleclick.The

deviceintegrateswithaback‐endplatformservicesallowsusertoconfiguredevice

remotelyandalsohelpusertogetunderstoodwherethedeviceisimmediatelyor

periodicallybysendingGPRS/SMScommandstothedevice.



Features

z 　Quad‐BandGSM/GPRS

z 　2Way‐Voicecommunication

z 　NotificationbuttonforinstantcalloutandSMS/GPRSalert.

z 　Configurablephonebookformakingphonecall.

z 　Speaker‐phonecapability

z 　Regular/Real‐timetrackingbyremoteconfiguration

z 　PowerLow/OffalertviaSMS/GPRS

z 　OLEDdisplay96x64resolution

z 　Supportwebservicesforlocationtracking.

z 　IPX4waterproof.

z 　RechargeableLi‐ionbattery.



‐2‐



Specifications

HardwareSpecifications

Network Quad‐BandGSM/GPRS

GSMAntennaType Monopoleantenna

GPS HighSensitivityGPS

GPSAntennaType PatchAntenna12x12x4

OperatingTemperature ‐20°~45°C

Humidity 5%to95%Non‐condensing

Battery Rechargeable320mAhbattery

HardwareButtons 4Buttons

Flashmemorysize Internal4MB

Display OLEDdisplay

Chargingconnector DC5V/1A,microUSB

Chargingtime Upto3Hours

Dimension 47.8mm(D)x14.3mm(H)

Weight 50g

Speaker/Mic Yes

Devicefunctions ‐Locationreportmodes(ping/periodic)

‐NotificationreportmodeviaSMS/GPRS

‐Preset3contactsand10whitelistcontacts

allowtocall‐in

‐Speakerphonecapabilityfor2wayvoicecomm.

‐Voicemonitorfunction

‐Autopowersavingmode

Waterproof SupportIPX4Waterproof



‐3‐



GettingStarted

• Includedaccessories



TW‐100





MicroUSBCable





ACCharger

(Option)



• PreparingyourSIMCardforGPRS‐activation

1. Inform your GSM service provider to activate the GPRS function,

get the APN information, the user name, and user password.



‐4‐



• InstalltheSIMCard



1.Pleasemakesure

TW‐100ispoweroff.

Unlock4screwswiththe

properscrewdriver.

2.Removetherearcover.3.Removethebattery

carefullyandthenpush

theSIMcardcover

downward(opened).

 

4.OpentheSIMcard

cover.

5.CarefullymakesuretheSIM

cardisinstalledcorrectly,with

thecontact(goldpart)ofthe

SIMcardfacingdownward.

CloseSIMcardcoverandpush

itupward(locked).

6.Putthebatteryonthe

originalplace.





7.Puttherearcoverand

thenLock4screws

accordingly.





‐5‐



• ChargeTW‐100

IfyouareusingtheTW‐100forthefirsttime,

chargetheTW‐100foratleast3hours.(The

includedbatteryismanufacturer‐approved

forusewiththeTW‐100.Theuseof

anyotherbatterymightdamageTW‐100.)



• PowerTW‐100On/Off



PowerOn:

Pressandholdthe“Power”keyfor5seconds.

TheLCDandbacklightwillturnon.



PowerOff:

PressandholdthePowerkeyuntilthedisplay’s

poweroffbarfullyfinishes.ThentheLCDand

backlightwillturnoff.



‐6‐



TW‐100DeviceConfiguration



1Power(Long

click)/Reject/Back

Holddowntopowerthedeviceon/off.

Whenthereisanincomingcallorduringa

phonecall,presstorejectorhangupthecall.

Inthe“SettingsMenu”,presstocancelthe

settingandbacktothelastpage.

2MicroUSBPortUsedforchargingtheTW‐100.

3MicrophoneMicrophone.

4Notification(Long

click)/Answer/Confirm

/Menu

MakesureUIisdisplayedfirst.Holdtosenda

notificationmessagetotheassignedphone

numberandmakeanotificationcalltothe

assignnumber.

Whenthereisanincomingcall,presstoanswer

thephonecall.

Presstoenterintothe“SettingsMenu”.In

“SettingsMenu”,presstoconfirmthatsetting.

5SpeedDial#1(Long

click)/IncreaseVolume/

Up/ClockSwitch

Holdthebuttondowntocallthespeeddial#1.

Duringaphonecall,pressthisbuttonto

increasethevolumelevel.

In“SettingsMenu”,pressingthisbuttonwill



‐7‐



scrollup.

Shortpressthebuttontoswitchtotheother

kindofclock.

6LCDLCD.

7SpeedDial#2(Long

click)/Decrease

Volume/Down/Clock

Switch

Holdthebuttondowntocallthespeeddial#2.

Duringaphonecall,pressthisbuttonto

decreasethevolumelevel.

In“SettingsMenu”,pressingthisbuttonwill

scrolldown.

Shortpressthebuttontoswitchtotheother

kindofclock.

8SpeakerUsedforlisteningtotheotherpartyduringthe

phonecall.



‐8‐



OperationMode



GeneralIcons



Thisiconwouldbedisplayed,when

youcallsomeonebutitfails.



Thisiconwouldbedisplayed,when

thephonecallisended.

Batteryisbeingcharged.



Batteryisfullycharged.

Batterycapacityisverylow.



Thisiconwouldbedisplayedwhen

thealarmclockistriggered.



TextInfo



LocalTime

Itwillshowthelocaltimeafteryourtimezoneis

selectedontheserver.Youcouldrefertothe



‐9‐



detailsinthechapterofSettingsofTW‐100.

Date

Showsthepresentdate.WhenTW‐100isused

forthefirsttime,thedateissettofactory

settings.Youcouldrefertothedetailsinthe

chapterofSettingsofTW‐100.

AlarmStatus

Thisiconwouldbedisplayedifyouenableoneof

thealarmsettings.

GSMSignal

Themorebarsthatarevisible,thestrongeristhe

signal.Ifyoudon’tinstallSIMcardinTW‐100,the

GSMsignalbarswouldturnwhite.

BatteryCapacity

Themorebarsthatarevisible,themoreisthe

batterycapacity.



‐10‐



SettingsofTW‐100



Inoperationmode,youcouldpress“Up”or“Down”or“Confirm”keyto

accesstothe“SettingMenu.”



Thereare7settingsinthe“SettingMenu”asshownbelow.

1)Time

2)Alarm

3)Ringtone/Volume

4)Language

5)PowerSaving

6)RestoreFactorySetting

7)About



‐11‐



1) Time

Use  or  toreach“Time”settingandpress  (Confirm).Thereare2

selectionsforthe“Time”setting:“Autotimeadjust”and“TimeSetting”.



z “Autotimeadjust”

Completethetimezonesettingontheserver.

Use  or  toreach“Autotimeadjust”andpress  (Confirm).

Use  or  toreach“Enable”andpress  (Confirm).“Done”wouldbe

displayedonUI.

TW‐100wouldshowthetimeaccordingtoUTCtime+timezonehourafter

TW‐100isrebooted.



z “TimeSetting”

Use  or  toreach“TimeSetting”andpress  (Confirm).

Use  or  toreachthenumberwhichyouwantandpress  (Confirm)

tosetYear/Month/Day.

Use  or  tosettheformatof24hoursorof12hoursandpress

(Confirm).

Use  or  toreachthenumberwhichyouwantandpress  (Confirm)

tosetHour/Minute.“Done”wouldbedisplayedonUI.



‐12‐



2) Alarm

Use  or  toreach“Alarm”settingandpress  (Confirm).Youcouldset5

setsofalarmclock.

Use  or  toreachoneoftheclocksettingsandpress  (Confirm).

Use  or  toreach“Enable”andpress  (Confirm).

Use  or  toreachthenumberwhichyouwantandpress  (Confirm)

tosetHour/Minute.“Done”wouldbedisplayedonUI.Forexample,youset

3:30asyouralarmsetting.Youwouldsee03:30‐amONdisplayedonUI.

Youcoulddisablethisclocksettingbyusing  or  toreachtheabove

setting03:30‐amONandpress  (Confirm).

Andthenuse  or  toreach“Disable”andpress  (Confirm).“Done”

wouldbedisplayedonUI.Youwouldsee03:30‐amOFFdisplayedonUI.

Youcouldfollowstep1to5tosetmorealarmsettingsordisablethem.



3) Ringtone/Volume

Use  or  toreach“Ringtone/Volume”settingandpress  (Confirm).There

are2selectionsforthe“Ringtone/Volume”setting:“Ringtone”and“Volume”.



z “Ringtone”

Use  or  toreach“Ringtone”settingandpress  (Confirm).

Use  or  toreachtheringtoneyouprefer.TW‐100wouldplaythe



‐13‐



selectedringtone.Press  (Confirm)toselectit.“Done”wouldbedisplayed

onUI.



z “Volume”

Use  or  toreach“Volume”settingandpress  (Confirm).

Press  toincreaseor  todecreasethevolumelevel.Whenyoureach

yourvolumelevel,press(Confirm).“Done”wouldbedisplayedonUI.



P.S.YoucouldadjustthevolumeofTW‐100duringthecall.



4) Language

Use  or  toreach“Language”settingandpress  (Confirm).Thereare2

selectionsforthe“Language”setting:“English”and“簡体中文(Simplified

Chinese)”.



z “English”

Use  or  toreach“English”settingandpress  (Confirm).“Done”

wouldbedisplayedonUI.

YouwouldseeyourUIlanguageischangedtoEnglish.



‐14‐



z “簡体中文”

Use  or  toreach“簡体中文”settingandpress  (Confirm).“Done”

wouldbedisplayedonUI.

YouwouldseeyourUIlanguageischangedtoSimplifiedChinese.



5) PowerSaving

PowersavingisforreducingthepowerconsumptionbysettingthetimeofLCDoff

withoutanykeypress.

Useor  toreach“PowerSaving”settingandpress  (Confirm).Thereare

4selectionsforthe“PowerSaving”setting:“off”,“5seconds”,“15seconds”and“30

seconds”.



Use  or  tochoosewhichsettingyoupreferandpress  (Confirm).

“Done”wouldbedisplayedonUI.



6) RestoreFactorySetting

Use  or  toreach“RestoreFactorySetting”settingandpress  (Confirm)

twotimes.Itwouldbeautomaticallyrebootedandrestorefactorysetting.



7) About

Use  or  toreach“About”settingandpress  (Confirm).Youcouldsee

TW‐100SWversion,IMEI,servername,serverportnumber,APNandreportinterval.

Afteryouchangethesettingsabovebytheserver’scommand,youcouldcheckyour

settinghere.



‐15‐



FCCWarning

FCCRFExposureInformation(SAR)

Thisdeviceisdesignedandmanufacturednottoexceedtheemissionlimitsfor

exposuretoradiofrequency(RF)energysetbytheFederalCommunications

CommissionoftheU.S.Government.Theexposurestandardforwirelessdevices

employsaunitofmeasurementknownastheSpecificAbsorptionRate(SAR).The

peakspatial‐averageSARlimitsforgeneralpopulation/uncontrolledexposureis1.6

W/kgaveragedoverany1gramoftissue,withtheexceptionsforthepartsofthe

humanbodytreatedasextremities,suchashands,wrists,feet,ankles,andpinnae,

wherethepeakspatial‐averageSARlimitis4W/kg,averagedoverany10gramsof

tissue.TestsforSARareconductedusingstandardoperatingpositionsacceptedby

theFCCwiththedevicetransmittingatitshighestcertifiedpowerlevelinalltested

frequencybands.TheFCChasgrantedanEquipmentAuthorizationforthisdevice

withallreportedSARlevelsevaluatedasincompliancewiththeFCCRFexposure

guidelines.



FCCPart15.19Labellingrequirement.

Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe

conditionthatthisdevicedoesnotcauseharmfulinterference.



NOTE:Thisequipmenthasbeentestedandfoundtocomplywiththelimitsfora

ClassBdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesigned

toprovidereasonableprotectionagainstharmfulinterferenceinaresidential

installation.

Thisequipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnot

installedandusedinaccordancewiththeinstructions,maycauseharmful

interferencetoradiocommunications.However,thereisnoguaranteethat

interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescause

harmfulinterferencetoradioortelevisionreception,whichcanbedeterminedby

turningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe

interferencebyoneormoreofthefollowingmeasures:

‐Reorientorrelocatethereceivingantenna.

‐Increasetheseparationbetweentheequipmentandreceiver.

‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe

receiverisconnected.

‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



‐16‐



FCCPart15.21Warning

Notice:

Anychangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor

compliancecouldvoidyourauthoritytooperatetheequipment.



GlobalSat WorldCom TW100 Wearable Watch Tracker User Manual 07 Users Manual R02x

GlobalSat WorldCom Corporation Wearable Watch Tracker 07 Users Manual R02x

User manual

Navigation menu

Namespaces

Views

Navigation
