Globaltronics gmbH & Co KG GT-9000 Manual

Manual

Remote Control Socket
Model: GT-FSI-07-US + GT-9000
Please read theentire instruction manual before using theproduct and
then save it for future reference. We reserve theright for any errors in
text or images and any necessary changes made to technicaldata.
If you have any questions concerning technical problems please
contact our Customer Services.
Safety
• This set of switches is suitable for controlling devices such as lights.
• Make sure that theload device is turned off before connecting it to
thereceiver.
•Never connect a load device with a higher power rating than 1800 W.
• These switches are intended for indoor use; do not expose them to
rain or moisture.
3. Eachreceiver has anindicator in thesocket showing which of
thebuttons (1, 2, 3,or 4) it is programmedfor. Theindicator
should be removed thefirst time thereceiver isused.
Iftheprogramming does not work for some reason, theprogramming
must be re-done. Referto theNew programming section.
Operating instructions
Note: Donot touch any of thebuttons on thetransmitter before
theLED indicator has stopped flashing, otherwise theprogramming will
change.
1. Plugreceiver Ainto anelectrical socket.
2. TheLED indicator on thereceiver will begin to flash slowly for
30seconds and then goout.
3. Theon/off switching of thesocket built into receiver Awill now be
controlled by button [ 1–ON ] and [ 1–OFF ]. TheLED indicator on
thereceiver will come on when thereceiver is switched on and go
out when thereceiver is switchedoff.
4. Theother three receivers will be controlled in thesame way but with
buttons [ 2–ON ], [ 2–OFF ] [ 3–ON ], [ 3–OFF ], and [ 4–ON ], [ 4–OFF ]
respectively.
5. Buttons [ 1-4–ON ] and [ 1-4–OFF ] are from theoutset pre-programmed
to control all four receivers simultaneously.
Note: Eachtime areceiver is unplugged from anelectrical socket and
plugged in again, it goes into learning mode (theLED indicator flashes
slowly) for 30 seconds.
In learning mode, achannel can be added or several channels can be
removed. Allthechannels, (1, 2, 3, 4 and 1-4) can be aput on one
receiver if desired. Referto theDeleting theprogramming and New
programming sections.
Deleting theprogramming
1. Unplug thereceiver from theelectrical socket.
2. Plugthereceiver into anelectrical socket after about 10 seconds.
3. TheLED indicator on thereceiver will flash slowly for 30 seconds
while it is in learningmode.
4. Pressthedesired [ OFF ] button while theLED indicator is flashing
to delete theprogramming. TheLED indicator will flash quickly
whilst theprogramming is being deleted.
5. Onceprogramming has been deleted, thereceiver is no longer
programmed to any of thebuttons on thetransmitter.
New programming
Thereceiver needs to be programmed to one of thebuttons 1, 2, 3,
4 or 1-4 as follows:
1. Unplug thereceiver from theelectrical socket.
2. Plugthereceiver into anelectrical socket after about 10 seconds.
3. TheLED indicator on thereceiver will flash slowly for 30 seconds
while it is in learningmode.
4. Press [ 1–ON ], [ 2–ON ], [ 3–ON ] , [ 4–ON ] or [ 1-4–ON ] whilst
theLED indicator is flashing to programme thereceiver to
the transmitter.
5. The LED indicator comes on when theprogramming is completed.
6. Follow thesame procedure with theother receivers.
TheLED indicator on thereceiver shows thestatus of thereceiver in
4differentways:
•Thereceiver socket is switched off when theLED indicator is noton.
•Thereceiver socket is switched on when theLED indicator ison.
•TheLED indicator flashes slowly for 30 seconds when thereceiver
is in learningmode.
•TheLED indicator flashes quickly whilst theprogramming is being
deleted.
Care and maintenance
• Unplug themains lead before cleaning theproduct.
• Clean theproduct using asoft, moistcloth. Onlyuse mild
detergents; never use solvents or strong, abrasive cleaning agents
for cleaning as these can damage theproduct.
Disposal
This product should be disposed of in accordance with local regulations.
Ifyou are unsure how to proceed, contact your local council.
Specifications
GT-FSI-07-US (receiver)
Rated voltage 120V AC, 60 Hz
Maxload 1800 W (15 A)
GT-9000 (transmitter)
Battery 12VDC,Type A 23
Frequency 433.92 MHz
Range up to 25 metres (line-of-sight)
Transmitter Receiver
Beforeuse
Inserting thetransmitter battery
1. Pressthecatch on thebattery cover in thedirection of thearrow
and removeit. Insert theincluded battery into thetransmitter
in accordance with themarkings in thebattery compartment.
Refitthebatterycover.
2. The receivers are already preprogrammed for buttons 1, 2,3
and 4 on the transmitter. Button E controls all three receivers
simultaneously.
Caution
This device complies with Part 15 of the FCC. Operation is subject to
the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
