Golden Vision Technology Developing G3604B1080PH Full VR / Panoramic Camera User Manual
Shenzhen Golden Vision Technology Developing Co.,LTD Full VR / Panoramic Camera Users Manual
User Manual
1
Quick Guide for Watching
APP
1.Softwara installation&download and
install APP for smart phones
安卓手机
3.Configuration and watch
2.User registration / login
苹果手机
Search "V380"in the App Store
install app
Search "V380"in Google play
install app
Mode 1:WIFI Smartlink
Deives which support Smartlink configuration can issue a voice prompt"wait ting for wifi smartlink
configuration".Th e default setting of Other devices like outdoor cameras is APHotspot Modeand it
can be configured accourding to "AP Quick Configuration"or "Hotspot Configuration".
Important Note:
1.The WIFI Camera default Mode is:WIFI smart Link
2.if you want to change the WIFI router,you need to reset the
WIFI Camera:Push the WIFI Camera "Reset"button for10
seconds(some model PTZ Camera’s reset button at the
Bottom of the Camera),then the Camera will restore the
default setting.
3.You can set the Camera to work as the independed Access
Point(Hotpot)by push the "reset"button on the camera for
1~2 seconds if the Camera smartlink mode,o r change the
mode by APP’s "Network setting"
2
①Image capture ②Sound monitoring ③Voice intercom
④Lens direction ⑤Image mode
① ② ③ ④ ⑤
First, user should make s ure
that the Mobile phone has
already connected to the proper
WIFI router Access point
Step 1:
Click the "WIFI Smart Lin k"
Menu,the ul show as below
picture:
Step 2:
lnput the Access point Router’s
password (make usre that its
SSID is correct)and click the
"Next"botton
After you done that,the W IFI Camera will try to connect the Access Point Router with the SSID
and password you have inputed.The prosess will take 30~60 seconds after the WIFI Camera
connect the WIFI Access Point router successfully the WIFI Camera ID will be added to the devi
ce list Last,you can click the item on the devic e list,then you can see the live video
3
Mode 2:AP mode configuration
1.Open the phone WIFI,
Hot spots of connection
equipment(MV* is a hot
spot at the beginning).
2.On APP, click"Add
networking equipment"
3.Click on the "local search", search out th e equipment after clicking "add selected equipment",
click "add equipment, equipment config uration and netwo rk settings, check the" station mode ",
select the WIFI router, an d fill in the router's WIFI password, and save, hear the voice prompt"
routing connection equipment complete the "complete con figuration
4
Mode 3:Quick AP config(this mode can not be suported by iphone
iphone user have to connect the camera AP by manual
With AP Mode selected,please
click "Device Unlinked"on your
app,click "AP Quick Setup"and
the device will be appeared.
(Because the default setting of
outdoor cameras is AP Hotspot
Mode,please long-press the
Reset key to activate AP Hotpot
Mode.)
5 67
6.More functions
7.Modify and delete
5.Device settings
4.Video playback
Choose device
Serach the record files The record files
Record playback
screenshot
lasr
stop/play
next
playback
mode
progress
bar
sound
After choosing device,
you can configure it.The
introduction to various
funtions is as follows
1.Network Setting:
AP mode and station mode can be interchanged;
Set the Camera work as a independed Access Point(Hotpot),(The wifi Camera work AP mode:
as a WIFI Access Point,the p refix is"MV",ex,"MV31000000")
Set the Camera work as wifi station,the came ra will connect the wifi router you Station mode:
selected and you can access you camera by internet
2.Record Setting:
continuius recording;automatic record:
record with alarm event;record-on-alarm:
record the sound;audio record:
standard-definition(VGA),high- definition(72 0P/960P)(choose high-definition record resolution:
record,with big record files and short sto rage time in memory c ard)
3.Alarm&Prompt:
close or Open the alarm;disarm switch:
master switch for all voice prompts;voice masrer switch:
switch for movement alarm voice;alarm voice prompts:
enable the voice promptsvoice language:
4.Date&Time:
able to adjust time of device;
5.User Management:
able to modify the username and password of ca mera
1.Network Setting 2.Record Setting 3.Alarm&Prompt
4.User Management 5.Static IP
Configuraton
6.Detect update
6.Static IP configurantion:
Equipment can be static IP is set to manual configuration or automatic configuration
7.Version information:
able to obtain information of device syste m and hardwate
8
Mobile phone alarm notice
setting
View,to share,delete pictures,
view,delete the vidro
Server Area Selection
Check device configuration
insturction and FAQS
Setting the APP’s password
Update latest versionof APP
automatically online
1.Delete:able to delete one device entry individually
able ti modify ID number,username and passw ord 2.Edit:
of the device(if you enter error username an d password,
you can modify it here directly,rather than adding another
device entry)
Protection,remova l of equipment can be3.Arm:
playback the snap picute 4.Megs:
Long press the device ID to proceed bulk deletions(On 5.
the android mobile phones do not support this operation)
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: 1) this device may not cause harmful interference, and 2) this device must accept any
interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution：Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
