5.Matters Need Attention
Try to keep away from the metal space;
Avoid the furniture , microwave oven blocked;
Avoid the space where the audio, video and data lines are wound, and
keep the space away from them as large as possible;
Ensure that as close as possible to the coverage of wireless Wi-Fi
signals. Switching network environment;
In the new network environment, please press the reset hole about 5
seconds, After hearing the horn sounds short voice and then connect
to the network。
01
YI IOT Smart Camera
1.Product introduction
Packing list: YI IOT Smart Camera × 1, Manual × 1, USB Power Cord × 1,
Power Adapter × 1,Screw Accessories Package x 1
Manual
USB Power Cord
Power Adapter
Screw Accessories Package
YI IOT
Thank you for using smart cameraYI IOT
Component description
Reset Button Press and hold Reset for about 5 seconds. When the horn
sounds short voice, the reset is successful.
It is recommended to insert 8-64GB high-speed Micro SD card, otherwise
it will not be able to store, view historical video and support Important
functions such as firmware upgrading.
Basic Parameters
02
Product Name: Smart CameraYI IOT
Lens: 110°wide angle
Pixel:2.0MP
Video Compression: H.264 High Profile
Image Enhancement: Digital Wide Dynamic 3D Noise Reduction
Local storage: MicroSD card
Wireless Encryption: WEP/WPA/WPA2 Encryption
Power input: 5V 1.6A
Total power consumption: 3.5W (Max)
Wireless standard: 2.4G 802.11 b/g/n
Support Platform: Android/iOS
03
2.Install APP
Download APP: scan the QR code below to download and install.
Register and login: open the APP to registerand login according YI IOT
to the prompts.
Please make sure that there is a available Wi-Fi and the Internet is
connected.
Then go to APP home page, click the "+" on the main screen,Configure
according to the instructions in the APP. You can configure multiple
cameras at the same time
04
Find the USB port on the bottom of the device and plug in the power cord
to power it on,please wait 20 seconds until you hear "DiDiDi"
3. Add The Device
⑩History file(Make sure
insert Micro SD card )
⑥Cloud Storage
①Preview mode
②Recording
④Intercom button
③Mute button
05
⑤More settings
⑦Floating window
⑧Full screen preview
⑨Snapshot
4.APP Video Browsing Details
①
⑥
⑤
⑦
②
③
④
⑧
⑨
⑩
06
YI IOT Smart camera Three packs of certificates
3. Within 12 months from the date of your receipt, this product hasexper-
ienced the performance failures listed in the “Product Performance
Failure Table” The situation is determined by the after-sales service
center and free repair service is available.
07
The YI IOT Smart camera after-sales service is strictly based on the "Pe-
ople's Republic of China Consumer Rights Act" and "China The “Product
Quality Law of the People’s Republic of China” implements the after-sale
s three-package service. The service content is as follows:
1. Within 7 days from the date of your receipt, this product has a perfor-
mance failure listed in the "Product Performance Failure Chart"The
situation is determined by the after-sales service center, and return or
replacement service can be enjoyed for free;
2. Within 8 to 15 days from the date of your receipt, this product has the
performance listed in "Product Performance Failure Table"The fault
condition is determined by the after-sales service center and can be
exchanged for free or repaired service;
name
YI IOT
Smart
Camera
Performance failure
Damaged shell due to structural or material problems
The new device cannot be turned on normally.
The new device can not take video, connect the phone, the
button is invalid (inserting Mirco SD card)
New device camera image fuzzy imaging abnormality, abn-
ormal video
Product performance failure table
Non warranty regulation
1.Unauthorized repairs, misuse, collisions, negligence, abuse, fluids,
accidents, alterations, inaccuracies Use accessories other than this pro-
duct, or tear, alter stickers, security labels
2.Has exceeded three packs of validity；
4.Does not meet the performance failures listed in the "Product Perform-
ance Failures";
3.Damage caused by force majeure;
5.Due to human factors, this product and its accessories have caused the
performance failures listed in the “Product Performance Failure Table”.
08 09
The name and content of the harmful substances in the product
This product conforms to RoHS environmental protection requirements.
At present, there is no mature technology in the world to replace or
reduce the lead content in the electronic ceramics. porcelain, optical
glass, steel and copper alloy.
Part
Name
Harmful Substance
shell
Board
charger
annex
This form is based on the provisions of SJ/T 11364。
Pb Hg Cd Cr(VI) PBB PBDE
○○
○○○○
X○
○○○○
○○
○○○○
○○
○○○○
Maintenance records：
Maintenance time：
Fault conditions：
Fault cause：
Trouble shooting：
Return and exchange proof：
Date of validity：
Original device ID：
New device ID：
maintenance personnel signature：
Maintenance Department seal：
Maintenance voucher of intelligent
Customer: Mobile:
Address:
Model: camera ID:
Device store: Date of purchase:
Store address:
Store contact number:
Maintenance voucher of intelligent
Customer: Mobile:
Address:
Model: camera ID:
Device store: Date of purchase:
Store address:
Store contact number:
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
Note: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Maintenance records：
Maintenance time：
Fault conditions：
Fault cause：
Trouble shooting：
Return and exchange proof：
Date of validity：
Original device ID：
New device ID：
maintenance personnel signature：
Maintenance Department seal：*RF warning for Mobile device:
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 20cm between the radiator &
your body.
