Users Guide

TV Box
Important Product Information Guide
©2014 DRAFTv0.1CONFIDENTIAL 5/30/14
This guide contains safety, handling, disposal, recycling and regulatory information.
To avoid injury to people or equipment, carefully read all safety information
and operation instructions contained in this guide before using your device.
Important Safety and Handling Information
Failure to follow these safety instructions could result in fire, electric shock, or
other injury or damage to the device or other property.
LOCATION
●Place the TV Box indoors to avoid exposure to lightning, rain, or sun. Do not
place it near a radiator, a heat register, or an open window.
●Maintain at least 4 inches (10 cm) of clearance between the TV Box and any other
appliances susceptible to electromagnetic influences, such as a TV or a VCR.
However, electronic devices that are not affected by electromagnetic influences
can be located closer to the device.
●If you place the TV Box on a rack or a bookcase, make sure that there is
adequate ventilation and that you have followed the manufacturer’s
instructions for mounting.
●Do not place the TV Box on an unstable surface where it can fall. If the TV Box falls,
it can cause serious injury to a person and serious damage to the device.
VENTILATION
●Make sure that the slots on bottom of the TV Box are not blocked. Sufficient
airflow around the device is required for proper operation.
●Do not expose the TV Box to an exposed flame.
●Operate device in a location where the temperature is between 0º and 40 C
(32º to 104º F).
POWER SUPPLY
●Operate the TV Box using only the type of power supply specified on the label. If
you do not know the type of power supplied to your home, contact your local
power company.
●Disconnect the power supply before you start any maintenance or
installation procedures.
©2014 DRAFTv0.1CONFIDENTIAL 5/30/14
●The TV Box has no on/off switch. To disconnect the device from power, you
must disconnect the power cord. Make sure the power cord is always easily
accessible.
●When connecting or disconnecting the TV Box , always hold the plug by its sides.
Keep fingers away from the metal part of the plug.
OVERLOADING
●Make sure that the wall outlet, extension cord, and adapter have a sufficient
power rating for the TV Box . If not, this can cause an electric fire shock.
CONNECTION TO THE TV
●Disconnect the power supply before you connect or disconnect the cable from the
TV to avoid causing damage to the TV.
ATTACHMENTS
●Do not use any unsupported attachments, as these may be hazardous or cause
damage to the TV Box .
●Do not move the TV Box if another device, such as a TV, computer, or other
electronic device, is connected to it.
WATER, LIQUIDS, WET LOCATIONS
●Do not use expose the TV Box to rain, liquids, or moisture.
●Do not put any objects filled with liquid, such as vase, on the TV Box.
●Do not not use the TV Box outdoors. It is meant for indoor use only.
LIGHTNING, STORM, OR NOT IN USE
●During a thunderstorm or when left unattended and unused for long periods
of time, unplug the TV Box from the wall outlet. This prevents damage to the
device from lightning and power surges.
CLEANING
●Disconnect the TV Box from the wall outlet before you clean it.
●Use a moist cloth to clean the TV Box . Do not use solvents.
EXTRANEOUS OBJECTS
●Do not insert anything through the openings in the TV Box , where they can
touch dangerous voltage points or damage parts.
©2014 DRAFTv0.1CONFIDENTIAL 5/30/14
REPLACEMENT OF PARTS
●When replacement of parts is required, be sure the service technician uses
replacement parts specified by the manufacturer or those that have the same
characteristics as the original part. Unauthorized substitution can result in damage
to the TV Box .
Repairing or Modifying the Device
Do not attempt to open the TV Box or disassemble it. Opening the device can
cause electric shock and voids the limited warranty. No user-serviceable parts
are inside.
Service should be provided by an authorized service provider only. If the TV Box has
been in contact with liquids, punctured, or subjected to a severe fall, unplug it and have it
checked out by an authorized service provider before using it.
Handling
The TV Box can be damaged by improper storage or handling. Be careful not to drop
the device when transporting it.
Choking Hazard
The TV Box contains small parts, which could present a choking hazard to small
children. Keep the TV Box and its accessories away from small children.
Connectors and Ports
Never force a connector into a port. Check for obstructions on the port. If the
connector and port do not join with reasonable ease, they probably do not match.
Make sure that the connector matches the port and that you position the connector
correctly before inserting it into the port.
Exposure to Radio Frequency Energy
The TV Box contains radio transmitters and receivers. When the device is on, it sends
and receives radio frequency (RF) energy through its antenna. The device is designed,
tested1, and manufactured to comply with the limits for exposure to RF energy set by
the Federal Communications Commission (FCC) of the United States. If you are
concerned about exposure to RF energy, you can further limit your exposure by
turning off the Wi-fi and Bluetooth functions.
This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
1 The device was tested by UL VERIFICATION SERVICES, FREMONT, CA according to measurement standards and
procedures specified in FCC CFR 47 Part 2, FCC CFR 47 Part 15, FCC 06-96, FCC KDB 789033, ANSI C63.10-2009.
©2014 DRAFTv0.1CONFIDENTIAL 5/30/14
Additional Information
For more information from the FCC about exposure to RF energy, go to
www.fcc.gov/oet/rfsafety. The FCC and the U.S. Food and Drug Administration (FDA)
also maintain a consumer website at
www.fda.gov/RadiationEmittingProducts/RadiationEmittingProductsandProcedures
/ HomeBusinessandEntertainment/CellPhones/default.htm to address inquiries
about the safety of mobile phones. Please check the website periodically for
updates.
For information about the scientific research related to RF energy exposure,
see the EMF Research Database maintained by the World Health Organization
at: www.who.int/emf
Regulatory Compliance Information
FCC Compliance Statement
The TV Box complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) The device may not cause harmful interference, and
(2) the device must accept any interference received, including interference that
may cause undesired operation. See instructions if interference to radio or
television reception is suspected.
Regulatory
Certification Number
FCC
A4RGFHD200
Note: This equipment has been tested2 and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications and
television reception. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning
2 The device was tested by UL VERIFICATION SERVICES, FREMONT, CA according to measurement standards and
procedures specified in FCC CFR 47 Part 2, FCC CFR 47 Part 15, FCC 06-96, FCC KDB 789033, ANSI C63.10-2009.
©2014 DRAFTv0.1CONFIDENTIAL 5/30/14
the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
○Reorient or relocate the receiving antenna.
○Increase the separation between the equipment and receiver.
○Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
○Consult the dealer or an experienced radio/TV technician for help.
Important: Changes or modifications to this product not authorized by vendor
could void the EMC and wireless compliance and negate your authority to operate
the device. The TV Box has demonstrated EMC compliance under conditions that
included the use of compliant peripheral devices and shielded cables between
system components. It is important that you use compliant peripheral devices and
shielded cables between system components to reduce the possibility of causing
interference to radios, televisions, and other electronic devices.
This product was tested for FCC compliance under conditions that include the use of
certified peripheral devices and certified shielded cables and connectors between
system components. You can obtain certified peripheral devices and the proper shielded
cables and connectors through an authorized dealer. For non-certified peripheral devices,
contact the manufacturer or dealer for assistance.
Wireless Radio Use
This TV Box is restricted to indoor use when operating in the 2.35 to 5.25 GHz frequency
band.
©2014 DRAFTv0.1CONFIDENTIAL 5/30/14
ROHS
Model
Name
GFHD200
PowerSupply
InputVoltage
100120V~
Type
50/60Hz,0.6A
PowerConsumption
12V 1.5A
©2014 DRAFTv0.1CONFIDENTIAL 5/30/14
