GWN7610
802.11ac Wireless Access Point
The GWN7610 is a high-performance 802.11ac wireless access point for enterprises, oce buildings, retail centers,
hotels, hospitals, convention centers and more. It oers simultaneous dual-band Wi-Fi (2.4GHz and 5GHz) using the
latest 3x3 MIMO 802.11ac technology to maximize bandwidth, increase signal strength and expand Wi-Fi coverage.
The GWN7610 uses a controller-less design which allows each access point to manage it’s own network independently
without being tied to a central network controller, eliminating the need to purchase extra controller hardware and
software. This enterprise wireless access point is powered and can be managed by Grandstream’s scalable and
intuitive network management system which allows for the management of multiple access points at a single site. The
GWN7610 can also be managed by Grandstream’s GWN7000 Enterprise Multi-WAN Gigabit Router. With support for
300 plus devices per AP, dual Wi-Fi support, industry leading 3x3 MIMO wireless technology and support for 802.11ac,
the GWN7610 is an ideal wireless access point for large and small wireless/VPN solutions.
Supports 802.11ac, which
oes speeds up to 5 times
faster than 802.11n
Oers Wi-Fi speeds up
to 1300MBps; contains
2 auto-sensing Gigabit
ports
Supports both PoE and
PoE+ to integrate with
existing infrastructure
Easy setup and management
using a web-based network &
cloud management systems
Advanced Wi-Fi security
features including WEP,
WPA/WPA2-PSK, WPA/
WPA2-Enterprise
3x3 MIMO technology
maximizes bandwidth,
increases signal strength
and expands coverage area
Supports 300+ concurrent
clients per access point
Supports guest and
paid access for network
management and
monetization
Oers simultaneous
dual band Wi-Fi
signals
Network Management
Manage networks consisting of
GWN7610 APs directly from the
products’ intutive web user interface.
A Cloud-based interface is coming
soon for easy management of large
deployments.
Controller-less Design
The GWN7610 can be fully managed
and controlled via its web user
interface - eliminating the need
to purchase a seperate controller
that is usually required by other
manufacturers.
802.11ac
Support for 802.11ac allows the
GWN7610 to oer supercharged
Wi-Fi speeds up to over 1 Gigabit per
second.
3x3 MIMO technology
Industry-leading 3x3 MIMO allows
the GWN7610 to transmit and
receive via three simultaneous
streams at all times, oering
more bandwidth capacity when
downloading and uploading data to
and from the wireless network.
Simultaneous Dual-band
Wi-Fi
Each GWN7610 supports both
2.4GHz and 5GHz connections,
therefore doubling networks
speeds by creating 2 seperate Wi-Fi
networks that lower interference and
can be used for dierent purposes.
GWN7000 Integration
GWN7610 APs can also be fully
managed via the GWN7000 router
- ideal for multi-site and VPN
deployments.
300+ Clients per GWN7610
Each GWN7610 can support more
than 300 simultaneous clients
Intuitive Management Interface
Single-Site Management
info@grandstream.com www.grandstream.com
Multi-Site Management
Headquarters Oce 1 Oce 2 Factory/Warehouse
GWN Series: Deployment and Set Up
Simple Set up
Set up is easy, simply:
Easily Monetize any network
Payments can be collected easily, via a landing
page. Customers must log into the landing page
for internet access. This makes the GWN Series
ideal for use in cafes, restaurants, and hotels.
Large-Scale Solutions
The GWN is exible, making it ideal for both small
and large scale deployments. The GWN can provide
the perfect wireless solution for large residential
complexes as well as a small cafe. A large oce
campus can connect all employees using the same
SSID and credentials, so when moving from oor to
oor, building to building, or branch oce to branch
oce, internet access is uninterrupted. This saves
employees time and increases productivity.
A single coee chain can deploy the GWN series
company-wide in both its cafes and corporate
oces while managing it all from the Unied
Management Interface.
Benets of a company-wide deployment include:
Think Bigger
info@grandstream.com
info@grandstream.com www.grandstream.com
1. Connect the GWN70xx router and
GWN76xx access point to the LAN.
2. Access the device from the Web UI and pair the
GWN 76xx.
3. Congure the SSID and password.
• Linking multiple locations together for
easy management
• No single point of failure, ensuring
redundant infrastructure
• Local cafe employees do not have to manage
internet access
• Private and guest networks are securely
hosted from the same router
www.grandstream.com
Wi-Fi Standards IEEE 802.11 a/b/g/n/ac
Antennas 2.4 GHz, gain 3 dBi, internal antenna
5 GHz, gain 3 dBi, internal antenna
Wi-Fi Data Rates
IEEE 802.11ac: 6.5 Mbps to 1300 Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5 Mbps to 450 Mbps
IEEE 802.11b: 1, 2, 5.5, 11 Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Frequency Bands
2.4G : 2.400 - 2.4835 GHz
5G : 5.150 - 5.250 GHz
Wi-Fi Security WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES)
MIMO 3x3:3 2.4GHz, 3x3:3 5GHz
Range 175 meters
Target TX Power 5G:26dBm; 2.4G:26dBm
Maximum RX Sensitivity -97dBm
BSSID 8 BSSID per radio
Concurrent Clients 250+
Guest/Paid Access Supported
Network Interfaces 2x autosensing 10/100/1000 Base-T Ethernet Ports
Auxiliary Ports 1x USB 2.0 port, 1x Reset Pinhole, 1x Kensington lock
Mounting Indoor wall mount or ceiling mount, kits included
LEDs 3 tri-color LEDs for device tracking and status indication
Network Protocols IPv4, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
QoS 802.11e/WMM, VLAN, TOS
Deployment and Management
< 50 AP: Light-weight Master in AP
< 500 AP: Full Master
> 500 AP: Cloud Based Master
Power Save Indoor wall mount or ceiling mount, kits included
Power and Green Energy Eciency
Power adapter: Supports 24VDC/1A power input
POE Input Max Input voltage: 67VIEEE 802.3af/ 802.3at compliant
Max Power for POE: 25.5W
Environmental
Operation: 0°C to 40°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing
Physical
Package Content GWN7610 802.11ac Wireless AP,Mounting kits, Quick Start Guide
Compliance FCC, CE, RCM, IC
Specications
5.725 - 5.850 GHz
US:2.4G : 2.412- 2.462 GHz EU:2.4G:2.412-2.472GHz
5G : 5.180 - 5.240 GHz 5G:5.180-5.240GHz
5.745- 5.825 GHz
US/IC:2.4G : 2.412- 2.462 GHz EU/AU:2.4G:2.412-2.472GHz
