Green Packet Berhad IF250-GP LiTE Band 7 Indoor CPE User Manual IF 250 131128

Green Packet Berhad, Taiwan LiTE Band 7 Indoor CPE IF 250 131128

Users Manual

www.greenpacket.com
TAIWAN
DATASHEET
IF-250
VISION
INTOUCH
TAIWAN
TAIWAN
INTELLIGENCE
PORTABLE
PORTABLE
CONNECTION
CONNECTION
CONNECTION
INFINIT
TECHNOLOGY
INFINIT
INTERACT
VISION
VISION
BEST
SUCCESSFUL
WI-FI
ALWAYS BEST CONNECTED
GLOBAL
GLOBAL
COLLECTION
INTERACT
COLLECTION
INTOUCH
VISION
DEVICES
vision
DEVICES
Innovating To Improve Lives
ALWAYS BEST CONNECTED
INTELLIGENCE
MANAGEMENT
MANAGEMENT
SHANGHAI
SINGAPORE
SAN FRANCISCO
SAN FRANCISCO
SHANGHAI
SINGAPORE
SINGAPORE
KUALA LUMPUR
KUALA LUMPUR
INTOUCH
BEST
BANGKOK
BANGKOK
TAIWAN
SAN FRANCISCO
KUALA LUMPUR
PORTABLE
GLOBAL
LTE LiTE Indoor Modem
IF-250, equipped with high-gain built-in omni-antenna,
serves as an affordable residential wireless broadband
solution for 4G carriers operating on FDD-LTE Band 7.
Simply connect IF-250 to PC with the factory-shipped USB cable,
and then you are ready to go!
FDD-LTE Indoor Modem IF-250
Following Green Packet's wireless broadband solution design
legacy, IF-250 is equipped with built-in omni- antennas with
peak gain up to 8dBi, delivering more EIRP than other
indoor units of the same category.
IF-250WN-200
FDD-LTE
Wi-Fi
SMART
PHONE
NB
USB Cable
802.11n 1x1
up to 150 Mbps
5V DC Power
5dBi dipole antenna
LAN Port x 1
enets
DATASHEET
Auto Firmware Upgrade Mechanism
In addition to TR-069, a common device management
practice, IF-250 allows operators to complete firmware
upgrade via HTTP or FTP file server.
Once connected to the Internet, the mechanism
inside CPE will automatically check with operators'
remote file server and identify whether an upgrade
is available.
With proper setting enabled, this makes eNodeB
off-balance possible, avoiding overwhelming upgrade
request or traffic directed to one single eNodeB at the
same time.
www.greenpacket.com
In conform with 3GPP Rel. 9 and being FDD-LTE Cat-4
configurable, IF-250 is competent to communicate with
any Cat-4 eNodeB. This helps to make the most of
eNodeB resources and increase communication
efficiency.
As part of LTE LiTE portfolio, IF-250 features to provide FDD-LTE
connectivity and deliver stable throughput in streamlined
and affordable hardware design.
Category-4 Proven Throughput
Higher antenna efficiency suggests more percentage of
transmitter power can be radiated out by antenans.IF-250
has the antenna efficiency over 70%, assuring to make
the best of its built-in high-performance antenna.
High Performance Built-in Antenna
On any CDC or RNDIS platform, IF-250 will get started to
set up 4G connectivity and provide the Internet access
once it is connected to the USB port. This takes no
learning curve for subscribers getting familiar with how
to use IF-250!
Cat-4
Category 4 configurable, which facilitates
the service and communications between
CAT-4 eNodeB and IF-250.
High performance antenna, which helps to
complement indoor service coverage.
Powered on by USB. True plug and play,
without driver installation.
CAT-4
DL UL DL UL
CAT-3
CPE configured as Cat.4 device
CPE configured as Cat.3 device
147Mbps 50Mbps 120Mbps 40Mbps
100Mbps 50Mbps 90Mbps 40Mbps
*Subject to optmized MCS config. and UL window size.
Hosted (w/t WCM) Hostless (w/o WCM)
IF-250 is designed to power on via USB and does not
require driver installation on subscribers' side.
Plug-and-Play
Particularly concocted for remote technical assistance,
all the WAN, or FDD-LTE, packets may be redirected to
LAN and saved to the local machine as log files for
further interpretation. This does not involve techncial staff
attending the filed and, thus, facilitates operators'
troubleshooting process.
Log Analysis via WAN Traffic Mirroring
USB
Desktop
Laptop
IF-250
Laptop
Working with Green Packet WN-200* to enable broadband
sharing is an economic approach to making the best of
FDD-LTE connectivity.
4G Broadband Share via Wi-Fi Router
*Not included in IF-250 package.
30
20
2300
2325 2350 2375 2400 2570 2595 2620 2690 (MHz)
90
80
70
60
50
40
Antenna 1
Antenna 2
Antenna Gain Efficiency (%)
7.2
7
2300
2325 2350 2375 2400 2570 2595 2620 2690 (MHz)
8.4
8.2
8
7.8
7.6
7.4
Antenna 1
Antenna 2
Antenna Peak (dBm)
*Subject to the OS version that supports RNDIS or CDC.
DATASHEET
LTE
• USB 2.0 x 1
• Power & Data x 1 (Blue)
• LTE signal x 3 (Green)
• Local FW update via Web GUI
• OTA via HTTP / FTP update
• TR-069*
USB
LED Indication
Device Management
SIM Card
• Windows OS / MAC OS / Ubuntu 13.04 /
Fedora 19 / Chromebook / OTG-enabled Android
Plug-and-play ; no driver installation required
Supported OS
• 3GPP Rel. 9Standard
User Interface
•
SIM Slot x 1
Support 1.8V / 3.3V USIM
* Requires extra IOT effort
PDN • Support Multiple PDN
Max. RF Transmit Power • 23 dBm, 3GPP-compliant
Frequency Range • FDD-LTE Band 7
Uplink : 2500 MHz ~ 2570 MHz
Downlink : 2620 MHz ~ 2690 MHz
• Comply with 3GPP TS 36.101
» 5MHz: QPSK 1/3 = -100 QPSK 1/2 = -97
QPSK 3/4 = -94 16QAM 1/2 = -91
16QAM 3/4 = -86 64QAM 2/3 = -83
64QAM 3/4 = -80 64QAM 4/5 = -79
» 10MHz: QPSK 1/3 = -97 QPSK 1/2 = -94
QPSK 3/4 = -91 16QAM 1/2 = -88
16QAM 3/4 = -83 64QAM 2/3 = -80
64QAM 3/4 = -77 64QAM 4/5 = -76
» 15MHz: QPSK 1/3 = -95.2 QPSK 1/2 = -92.2
QPSK 3/4 = -89.2 16QAM 1/2 = -86.2
16QAM 3/4 = -81.2 64QAM 2/3 = -78.2
64QAM 3/4 = -75.2 64QAM 4/5 = -74.2
» 20MHz: QPSK 1/3 = -94 16QPSK 1/2 = -91
QPSK 3/4 = -88 16QAM 1/2 = -85
16QAM 3/4 = -80 64QAM 2/3 = -77
64QAM 3/4 = -74 64QAM 4/5 = -73
Rx Sensitivity (dBm)
• IPv4
• IPv4-IPv6 dual stack
• IPv6
• NAT/NAPT
• VPN Pass-through
Internet Protocol
NAT
DHCP • DHCP Client
• DHCP Server
• FTP ALG
• H.232 ALG
• PPTP ALG
• SIP ALG
NAT ALG
Operation Mode
• DHCP
• Static
• MTU
IP Configuration
Method
Antenna
• Built-in FirewallFirewall
Port Forwarding • Support
• NAT Mode (Up to 5 devices)
• Bridge Mode via IP Pass-through
Networking
• 165 x 166 x 43 (mm)Dimensions (H x W x D)
• 250g (Device only)
Weight
• < 3.3 W (23dBm+)
• < 5 mW (LTE idle mode)
Power Consumption
• 0C ~ 40C (Operating)
• -20C ~ 70C (Storage)
Temperature
Electrical & Mechanical
• 10%~85% non-condensing (Operating)
• 5%~95% non-condensing (Storage)
Humidity
• RoHS compliant
Material
• 400,000 hours
MTBF
• IF-250 FDD-LTE indoor USB modem x 1
• Box dimension:
184 x 182 x 60 (mm)
• USB 2.0 cable (2m) x 1
• Package weight: 300g
• 1Tx / 2Rx
Built-in Omni-antenna up to 8dBi at peak gain
• RF
EN301908-1
EN301908-13
• Safety
EN60950-1
• EMC
EN301489-1, -24
EN300386
• SAR
EN62311
CE
• FCC Part 27M
• FCC Part 15B
• FCC 2.1091 (RF Exposure)
FCC
Regulation Compliance
* Note:
While in operating, the SIM slot cover shall be firmly closed.
IF series doesn't support SIM card hot swapping.
23 +/- 1 dBm, 3GPP compliant
FDD-LTE Indoor Modem IF-250
Copyright © 2001-2011 Green Packet Berhad. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed,
stored in a retrieval system, or translated into any language, in any form by any means, without the written permission of Green Packet
Berhad. Green Packet Berhad reserves the right to modify or discontinue any product or piece of literature at anytime without prior notice.
DATASHEET
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user‘s authority to operate the equipment.
This equipment complies with radio frequency (RF)
exposure limits adopted by the Federal Communica-
tions Commission for an uncontrolled environment. This
equipment should be installed and operated with
minimum distance 20 cm between the radiator & your
body.
FCC RF Exposure Compliance
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guaran-
tee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
**************************************************************************************************************************************
**************************************************************************************************************************************
