Griffin Technology Inc. Bluetooth Module USer Manual
USer Manual
ForInternalUse
GriffinBluetoothModule100‐4077Guide
This device is granted modular approval for use in other devices and must be used
according to the following guidelines.
The Bluetooth module must use a copper plated cold rolled steel shield, it should be
28.7mm x 16.9mm and covers all of the circuitry except for the antenna, jumper resistors
on the SPI and USB interfaces (only used for testing/programming/configuration) and
varistors used for ESD protection on the power and signal lines. The shield must be
soldered along all four lines with a small gap for the antenna trace to exit and be
electrically connected to ground.
The module contains a PCB-trace type Printed Inverted-F Antenna (PIFA). As it is a PCB
trace antenna, this antenna is non-removable. The end user should not be able to access
the antenna or add an antenna. The module is only intended for use with this antenna,
and does not contain an RF connector of any sort for supporting additional antennas.
The module must be connected to an off-module host processor via a UART interface on
header J5
For the FCC, the modular transmitter must be labeled with its own FCC ID number, and, if
the FCC ID is not visible when the module is installed inside another device, then the
outside of the device into which the module is installed must also display a label referring
to the enclosed module. This exterior label can use wording such as the following:
“Contains Transmitter Module FCC ID: PAV100-4077” or “Contains FCC ID: PAV100-
4077.”
The user guide must have the following statement and information provided to the user:
“This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation. The manufacturer is not responsible for any radio or tv interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment.”
Company name, contact info, Product model#
ForInternalUse
GriffinBluetoothModule100‐4077Guide
Per Industry Canada requirements, the following (both English and French wording) must
appear in the user’s manual of the end product:
“Under Industry Canada regulations, this radio transmitter may only operate using an
antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry
Canada. To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut
fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour
l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son
gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire à l'établissement d'une communication satisfaisante.”
For Industry Canada, the module meets certification labeling requirements. Host devices
that contain separately certified modules do not need to be re-certified, provided that they
meet the following conditions:
• The host device, as a stand alone unit without any separately certified
modules, complies with all applicable Radio Standards Specifications.
• The host device and all the separately certified modules it contains jointly
meet the safety requirements of RSS-102, if applicable.
• The host device complies with the certification labeling requirements of each
of the modules it contains.
ForInternalUse
GriffinBluetoothModule100‐4077Guide
The user guide must contain the following statements (both English and French) with the
IC statement and company info:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
The manufacturer is not responsible for any radio or tv interference caused by
unauthorized modifications to this equipment. Such modifications could void the user’s
authority to operate the equipment. The device is available on the Canadian market under
part 6384A-1004077
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
Le dispositif est disponible sur le marché canadien en vertu 6384A partiel 1004077.
