Guangzhou Juan Optical and Electronical Tech Joint Stock WG-20W-4 4 Channel Wireless 1080p Gateway with SD Card Recording User Manual
Guangzhou Juan Optical & Electronical Tech Joint Stock Co., LTD 4 Channel Wireless 1080p Gateway with SD Card Recording
User manual
General
A gateway that
can work as WNVR but use TF
card to record. It can
add up to 4 WIFI cameras, and
could be remote access by cellphone.
It can also
work
as a switch, to expand wired NVR or wired DVR
to add WIFI cameras.
Features
Add up to 4 WIFI cameras
90 dB Audible alerts Recording to TF Card locally or to WNVR
Standalone and compatible with WNVR series
*IFTTT / Google home / Alexa integration*
Add device
Step
Add to Home WIFI
Add to WNVR
Add
cameras
to Gateway
1
Connect the Ethernet
cable from router to
gateway
Press reset button for 3
seconds
Press the SYNC button for 3
seconds
2
Open Night Owl
connect
Use an Ethernet
cable to
connect to WNVR and
gateway directly
Press the camera reset button
for 3 seconds
3
Scan the QR code at
the back of the
gateway
In NVR Menu, click
Match code
Wait until done
4
Input admin
password
Press the SYNC button
for 3 seconds
5
Wait until done
User manual
Product name:4 Channel Wireless 1080p Gateway with SD Card Recording
Model:WG-20W-4-JUN,WG4-2I,WG4-2I-16SD
Brand:NIGHT OWL
Spec
GW-4 v1.0
Basic
FOB Price USD $14
Supplier Name Juan
Factory Model number
Components
Main IC Hi3518Ev200
WIFI mainchipset RTL8188EUS
Main function
Speaker Enabled Yes
Speaker Output 8Ohm 0.5Watt
Speaker Distance 20ft
Recording TF card(up to 128GB)
Recording type Motion / Doorbell / Manual(by app)
Camera Connection
Connection Type WIFI IEEE 802.11 b/g/n
Max connected cameras 4
Wireless range MAX 360ft Line of sight
General
Weatherproof Rating N/A
Power Supply DC5V 1A
Operating Humidity (%) Humidity 95% or less (non-condensing)
Operating Temperatures (F) 32ºF to 122ºF
Weight (Product Only)(lbs) TBC
Dimensions (Product Only) L x W
x H (inches) TBC
Power Consumption Per Camera ≤5W
Network
Network connection RJ45 10/100M
WIFI connection (to camera) IEEE 802.11 b/g/n
Transmission rate
11b: 11Mbps
11g: 54Mbps
11n: 150Mbps maxmum
Antenna Gain 1.5 dBi
ONVIF Version N/A
Protocols: TCP/IP, UDP, HTTP, DHCP, DNS, NTP, QoS
Dimensions / Weights
Sell Unit UPC N/A
Sell Unit Dimensions L x W x H
(inches) N/A
Sell Unit Weight (lbs) N/A
Master Pack UPC N/A
Master Pack Size N/A
Master Pack Dimensions L x W x
H (inches) N/A
Master Pack Weight (lbs) N/A
Package Contents
List all contents separately
1. 1 x Gateway;
2. 1 x DC 5V 1A power adaptor, 9ft power
cable;
3. 1 x Mounting Hardware;
4. 1 x QSG
Accessories Photos(except for
the user manual)
Ref Photo
FCC Caution.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
