Guard RFID Solutions AT ACTIVE RFID TAG USED FOR LOCATION AND PERIMETER PROTECTION OF ASSETS User Manual Tag Exciter Location Appliance

Guard RFID Solutions ACTIVE RFID TAG USED FOR LOCATION AND PERIMETER PROTECTION OF ASSETS Tag Exciter Location Appliance

Users Manual

PRODUCT INFORMATION
02-00001-101 Specifications Subject to Change Without Notice. © 2009 Guard RFID Solutions, Inc.
Guard RFID Solutions Inc.
#140 – 766 Cliveden Avenue
Delta, BC
Canada V6M 6C7
Tel: 866.785.7343
Fax: 604.524.4018
www.guardrfid.com
Conforms to UL-294
FCC ID: VZKAT
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT
SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
Article Tags
AT-1BLF, AT-2BLF
FE A T U R E S :
Small and light for deployment on small or large articles
36 months battery life
Tamper detection and motion sensors
Waterproof
DE S C R I P T I O N :
The AT-1BLF and AT-2BLF are Active Tags for tracking, location and protection of Articles and
Equipment.
Both tags have locating Beacon message capability, and include a Low Frequency (LF) Receiver so
that it can be instantly detected at locations that are equipped with GuardRFID’s Tag Exciters. This
detection method enables GuardRFID’s system to control doors, for example, so as to protect a
tagged article from leaving the perimeter, or to support applications where better granularity of tag
location is required.
The AT-1BLF transmits periodic Beacon messages at a constant rate, while the AT-2BLFhas an
integrated motion detector which is used to alter the Beacon rate based on whether the tag is
stationary or in motion. The AT-2BLF also contains a tamper detection mechanism.
Transmission of data from the Tags is exceptionally rapid, allowing literally hundreds of Tags to be
detected simultaneously at choke points, and also enabling a high density of Tags to coexist within
the system coverage area. Both Tags are designed to be either mounted using an
adhesive “peel and stick” label at the back of the Tag, or by employing GuardRFID’s
patented tag mounting mechanism. The tag mount enables the Article Tags to be
mounted on round and cylindrical surfaces, such as poles and power cables.
SP E C I F I C A T I O N S :
A T - 2 B L F
Part Number
61-10201
Transmit Frequency
433 MHz
Receive Frequency
125 KHz
Battery Life
36 months
Beacon Interval
10 minutes static,
12 seconds moving
Sensors
Motion and Tamper
Dimensions
1.1 x 0.48” (28 x 12.2 mm)
Weight
8 gm
Operating Temperature
-4° F to 122°F (-20°C to 50°C)
Humidity
0 – 95% RH non-condensing
Regulatory
FCC Part 15 Approved
Warranty
Prorated over 36 months
