Users Manual

Specifications:



InputVoltage:12VDC,0.2A

PowerConsumption:2.4WTyp.

Indicators:PowerON/RFConnectionOK

WarningLED

AlarmLED

AudibleEnunciator

Dimensions:4.53”x2.78”x1.5”

Weight:85g

Environmental:‐10°to+50°C

95%RH(non‐condensing)

Application

#8‐1600DerwentWay

Delta,BC

CanadaV3M6M5

T:604.998.4018

F:604.524.4018

www.guardrfid.com

Power/GoodRFconnection‐Solid

BadRFconnection‐Flashing

BK-A433W

ARGUS Wireless Bypass Keypad

TheKeypadrequires12VDCtooperate.ItisusuallyplacedwithintheLowFre‐

quencyfieldcreatedbyGuardRFID’sTagExciter,asshowninthediagrambelow.



WhenaprohibitedTagenterstheassociatedTagExciterfield,andadoororele‐

vatorissensedtobeclosed,theKeypademitsanaudibleWarningsignal,andthe

yellowLEDflashes.IfthedoorissensedtobeopenwhentheTagentersthefield,

afullAlarmconditionwillbedeclaredandamuchlouderaudiblesignalisemit‐

ted,andtheredLEDwillflash.TheseWarningandAlarmaudiblesoundsareter‐

minateduponenteringapre‐determineduniquePINcode.

AlarmWarning

125KHzRFField

TagExciterWirelessKeypad

Product Overview

TheARGUSBK‐A433WWirelessBypassKeypadisusedategresspointsto:

• Overrideamagneticdoorlockintheeventastaffmembertakesthere‐

sponsibilitytoallowegresstoaTagthatisnotnormallyallowedthrough

theegresspoint.AuniquePINcodeisrequiredtobeenteredontheKey‐

padinordertoperformthisfunction,whichisrecorded,alongwiththe

timeofday,withinGuardRFID’ssystem.

• AnnunciateWarningsandAlarmsategresspoints.



TheKeypadonlyrequirespowertooperate,andhasradiotransmittertocommu‐

nicatewiththeArgusTagReader/Controllerthatitisassociatedwithatthere‐

spectiveegresslocation.

Antenna

AudioTransducer

FrontViewSideView

Physical Features
