HARRIS TR-0137-E Bluetooth Dongle User Manual FCC Part 15

HARRIS CORPORATION Bluetooth Dongle FCC Part 15

User Manual

Rhein Tech Laboratories, Inc. Client: Harris Corporation
360 Herndon Parkway Model: Harris Bluetooth Adapter
Suite 1400 IDs: OWDTR-0137-E/3636B-0137
Herndon, VA 20170 Standards: FCC 15.247/IC RSS-247
http://www.rheintech.com Report #: 2014211DSS
41 of 45
Appendix J: User Manual
Please refer to the following page.
FLORIDA
NEW
YORK
VIRGINIA
BRAZIL
UNITED
KINGDOM
UAE
SINGAPORE
Part 15
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference,
and
2.
This device must accept any interference
received, including interference that may cause
undesired operation.
FCC and IC IDs
FCC ID: OWDTR-0137-E
IC: 3636B-0137
HVIN: 14002-2015-01
RF Exposure Warning!
Keep product 20 cm away from your body or bystander
during radio operation. The typical handheld two-way
radios were certified under mobile usage condition (i.e.,
keep 20 cm away from the user body). Use of closer
than 20 cm may exceed the US RF exposure limit and
should be avoided.
Regulatory
Changes or modifications not expressly approved by
the manufacturer could void the user’s authority to
operate the equipment.
This device complies with Industry Canada license-
exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause
interference, and (2) this device must accept any
interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique
subi, même si le
brouillage est susceptible d'en compromettre le
fonctionnement.
Troubleshooting (Cont.)
My Bluetooth Adapter is connected to my radio, but
I cannot hear any transmissions with my radio.
Ensure you have a Bluetooth Audio Device paired with
the adapter for proper transmit and receive functionality.
NOTICE!
The material contained herein is subject to U.S. export
approval. No export or re-export is permitted without
written approval from the U.S. Government. Rated:
EAR99; in accordance with U.S. Dept. of Commerce
regulations 15CFR774, Export Administration
Regulations.
Credits
Harris and assuredcommunications are registered
trademarks of Harris Corporation. Bluetooth is a
registered trademark of Bluetooth SIG, Inc.
Troubleshooting
My wireless audio accessory will not pair with the
Bluetooth Adapter.
Follow the instructions to place the Bluetooth Adapter
into the correct pairing mode and then activate the
pairing mode on the accessory. Ensure that the
Bluetooth Adapter and accessory being paired are
within one meter of each other, and that the BT
accessory is a Harris-supported BT device.
My wireless audio accessory worked before, but is
not working now.
Ensure the Bluetooth Adapter is properly connected to
the radio and that the radio is turned on. Ensure that
your wireless audio accessory has a fully charged
battery and is turned on. If the device still does not
work, re-pair the Bluetooth Adapter to the wireless
accessory.
My Bluetooth Adapter is connected to my radio, but
I cannot transmit with my radio.
Ensure you have a Bluetooth Audio Device paired with
the adapter for proper transmit and receive functionality.
User Manual
14221-1600-2070
Rev.A, April 2016
Harris® Bluetooth® Adapter
14002-2015-01
FLORIDA
NEW
YORK
VIRGINIA
BRAZIL
UNITED
KINGDOM
UAE
SINGAPORE
Part 15
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference,
and
2.
This device must accept any interference
received, including interference that may cause
undesired operation.
FCC and IC IDs
FCC ID: OWDTR-0137-E
IC: 3636B-0137
HVIN: 14002-2015-01
RF Exposure Warning!
Keep product 20 cm away from your body or bystander
during radio operation. The typical handheld two-way
radios were certified under mobile usage condition (i.e.,
keep 20 cm away from the user body). Use of closer
than 20 cm may exceed the US RF exposure limit and
should be avoided.
Regulatory
Changes or modifications not expressly approved by
the manufacturer could void the user’s authority to
operate the equipment.
This device complies with Industry Canada license-
exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause
interference, and (2) this device must accept any
interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique
subi, même si le
brouillage est susceptible d'en compromettre le
fonctionnement.
Troubleshooting (Cont.)
My Bluetooth Adapter is connected to my radio, but
I cannot hear any transmissions with my radio.
Ensure you have a Bluetooth Audio Device paired with
the adapter for proper transmit and receive functionality.
NOTICE!
The material contained herein is subject to U.S. export
approval. No export or re-export is permitted without
written approval from the U.S. Government. Rated:
EAR99; in accordance with U.S. Dept. of Commerce
regulations 15CFR774, Export Administration
Regulations.
Credits
Harris and assuredcommunications are registered
trademarks of Harris Corporation. Bluetooth is a
registered trademark of Bluetooth SIG, Inc.
Troubleshooting
My wireless audio accessory will not pair with the
Bluetooth Adapter.
Follow the instructions to place the Bluetooth Adapter
into the correct pairing mode and then activate the
pairing mode on the accessory. Ensure that the
Bluetooth Adapter and accessory being paired are
within one meter of each other, and that the BT
accessory is a Harris-supported BT device.
My wireless audio accessory worked before, but is
not working now.
Ensure the Bluetooth Adapter is properly connected to
the radio and that the radio is turned on. Ensure that
your wireless audio accessory has a fully charged
battery and is turned on. If the device still does not
work, re-pair the Bluetooth Adapter to the wireless
accessory.
My Bluetooth Adapter is connected to my radio, but
I cannot transmit with my radio.
Ensure you have a Bluetooth Audio Device paired with
the adapter for proper transmit and receive functionality.
User Manual
14221-1600-2070
Rev.A, April 2016
Harris® Bluetooth® Adapter
14002-2015-01
FLORIDA
NEW
YORK
VIRGINIA
BRAZIL
UNITED
KINGDOM
UAE
SINGAPORE
Part 15
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference,
and
2.
This device must accept any interference
received, including interference that may cause
undesired operation.
FCC and IC IDs
FCC ID: OWDTR-0137-E
IC: 3636B-0137
HVIN: 14002-2015-01
RF Exposure Warning!
Keep product 20 cm away from your body or bystander
during radio operation. The typical handheld two-way
radios were certified under mobile usage condition (i.e.,
keep 20 cm away from the user body). Use of closer
than 20 cm may exceed the US RF exposure limit and
should be avoided.
Regulatory
Changes or modifications not expressly approved by
the manufacturer could void the user’s authority to
operate the equipment.
This device complies with Industry Canada license-
exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause
interference, and (2) this device must accept any
interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique
subi, même si le
brouillage est susceptible d'en compromettre le
fonctionnement.
Troubleshooting (Cont.)
My Bluetooth Adapter is connected to my radio, but
I cannot hear any transmissions with my radio.
Ensure you have a Bluetooth Audio Device paired with
the adapter for proper transmit and receive functionality.
NOTICE!
The material contained herein is subject to U.S. export
approval. No export or re-export is permitted without
written approval from the U.S. Government. Rated:
EAR99; in accordance with U.S. Dept. of Commerce
regulations 15CFR774, Export Administration
Regulations.
Credits
Harris and assuredcommunications are registered
trademarks of Harris Corporation. Bluetooth is a
registered trademark of Bluetooth SIG, Inc.
Troubleshooting
My wireless audio accessory will not pair with the
Bluetooth Adapter.
Follow the instructions to place the Bluetooth Adapter
into the correct pairing mode and then activate the
pairing mode on the accessory. Ensure that the
Bluetooth Adapter and accessory being paired are
within one meter of each other, and that the BT
accessory is a Harris-supported BT device.
My wireless audio accessory worked before, but is
not working now.
Ensure the Bluetooth Adapter is properly connected to
the radio and that the radio is turned on. Ensure that
your wireless audio accessory has a fully charged
battery and is turned on. If the device still does not
work, re-pair the Bluetooth Adapter to the wireless
accessory.
My Bluetooth Adapter is connected to my radio, but
I cannot transmit with my radio.
Ensure you have a Bluetooth Audio Device paired with
the adapter for proper transmit and receive functionality.
User Manual
14221-1600-2070
Rev.A, April 2016
Harris® Bluetooth® Adapter
14002-2015-01
Introduction
The Harris Bluetooth (BT) adapter allows you to use a
compatible Harris
wireless headset or other audio
accessory with your radio. Harris recommends the use
of Harris-
branded BT Accessories. Any other BT
Devices are not guaranteed to work with this Harris
Adapter.
Supported Radios
The following Harris radios support the Bluetooth
adapter:
P5300 P5400
P5500 P7300
XG-75P/Pe XG-15P
Status LED Messages
1 flash every 4 seconds
Normal operation
2 flashes per second Audio accessory pairing
mode active
1 long flash for 3
seconds
Successfully paired or re-
paired
No indication
Radio is turned off
Controls and Connections
Quick Start
1.
Connect the Bluetooth Adapter to a compatible
Harris portable radio.
2.
Pair the Bluetooth Adapter with a compatible
wireless audio accessory.
3. Test and use.
Connecting the Adapter to the Radio
1. Always turn off the radio before connecting the
Bluetooth Adapter to the radio.
2. Plug the Bluetooth Adapter into the radio’s UDC
port.
3. Tighten the retaining screw.
4. Turn on the radio. The radio operates normally until
a wireless audio accessory is paired with the
Bluetooth Adapter. See next section for pairing
directions.
5. The Pair/PTT button on the BT Adapter functions as
a PTT button when paired with a Bluetooth
accessory. The radio’s internal microphone and
speaker are disabled as long as the Bluetooth
Adapter is paired with a Bluetooth accessory.
Pairing with an Audio Accessory
1. Turn off the radio to which the Bluetooth Adapter is
connected. Wait at least three seconds.
2. Turn the radio on while holding down the Pair/PTT
button on the Bluetooth Adapter.
3. Continue to hold the Pair/PTT button down for
approximately five seconds. Release the Pair/PTT
button when the status LED begins to flash two
times per second.
4. The Bluetooth Adapter is now in audio accessory
pairing mode. Activate the pairing mode on your
compatible wireless audio accessory.
5. Once the wireless audio accessory and Bluetooth
Adapter are paired, the status LED on the adapter
shows a constant blue light for three seconds.
6.
If the Bluetooth Adapter does not detect a
compatible wireless accessory within 60 seconds of
being put into pairing mode, the adapter exits
pairing mode and resumes normal operation.
7. Once successfully paired, you can operate your
radio using your compatible wireless accessory.
Transmit and Receive Operation
The Harris Bluetooth Adapter automatically routes radio
calls based on the following priority:
• Calls will be routed to a wireless accessory if one is
paired with Bluetooth Adapter.
• If no wireless headset or audio accessory is paired
to the Bluetooth Adapter, the wireless accessory is
turned off, or the wireless Bluetooth accessory is
out of range, the radio reverts to normal operation
and audio comes out of the radio’s speaker.
NOTE:
When a new accessory is connected,
paired, disconnected, or powered off, it may take
several seconds for the audio from received radio
calls to be routed appropriately.
Transmit and Receive Operation (Cont.)
When transmitting, the operator’s voice is picked up by:
• The microphone in the wireless headset or audio
accessory if one is paired.
• If no audio accessory is paired with the Bluetooth
Adapter, or the paired wireless audio accessory is
turned off or moved out of the Bluetooth Adapter’s
range, the internal microphone in the attached radio
is used.
The Bluetooth Adapter may temporarily mute the radio’s
speaker, causing incoming calls to be missed, in any of
the following situations:
• The adapter is attached to the two-way radio and no
wireless headset or wired accessory is paired.
• The wireless headset is turned off or runs out of
battery power.
• The wireless headset goes out of range of the
Bluetooth adapter.
NOTE: This mute state only occurs until the BT
timeout (5 seconds) is reached or BT is disabled.
Introduction
The Harris Bluetooth (BT) adapter allows you to use a
compatible Harris
wireless headset or other audio
accessory with your radio. Harris recommends the use
of Harris-branded BT
Accessories. Any other BT
Devices are not guaranteed to work with this Harris
Adapter.
Supported Radios
The following Harris radios support the Bluetooth
adapter:
P5300 P5400
P5500 P7300
XG-75P/Pe XG-15P
Status LED Messages
1 flash every 4 seconds
Normal operation
2 flashes per second Audio accessory pairing
mode active
1 long flash for 3
seconds
Successfully paired or re-
paired
No indication
Radio is turned off
Controls and Connections
Quick Start
1.
Connect the Bluetooth Adapter to a compatible
Harris portable radio.
2.
Pair the Bluetooth Adapter with a compatible
wireless audio accessory.
3. Test and use.
Connecting the Adapter to the Radio
1.
Always turn off the radio before connecting the
Bluetooth Adapter to the radio.
2. Plug the Bluetooth Adapter into the radio’s UDC
port.
3. Tighten the retaining screw.
4. Turn on the radio. The radio operates normally until
a wireless audio accessory is paired with the
Bluetooth Adapter.
See next section for pairing
directions.
5. The Pair/PTT button on the BT Adapter functions as
a PTT button when paired with a Bluetooth
accessory. The radio’s internal microphone and
speaker are
disabled as long as the Bluetooth
Adapter is paired with a Bluetooth accessory.
Pairing with an Audio Accessory
1. Turn off the radio to which the Bluetooth Adapter is
connected. Wait at least three seconds.
2. Turn the radio on while holding down the Pair/PTT
button on the Bluetooth Adapter.
3. Continue to hold the Pair/PTT button down for
approximately five seconds. Release the Pair/PTT
button when the status LED begins to flash two
times per second.
4. The Bluetooth Adapter is now in audio accessory
pairing mode. Activate the pairing mode on your
compatible wireless audio accessory.
5. Once the wireless audio accessory and Bluetooth
Adapter are paired, the status LED on the adapter
shows a constant blue light for three seconds.
6.
If the Bluetooth Adapter does not detect a
compatible wireless accessory within 60 seconds of
being put into pairing mode, the adapter exits
pairing mode and resumes normal operation.
7. Once successfully paired, you can operate your
radio using your compatible wireless accessory.
Transmit and Receive Operation
The Harris Bluetooth Adapter automatically routes radio
calls based on the following priority:
• Calls will be routed to a wireless accessory if one is
paired with Bluetooth Adapter.
• If no wireless headset or audio accessory is paired
to the Bluetooth Adapter, the wireless accessory is
turned off, or the wireless Bluetooth accessory is
out of range, the radio reverts to normal operation
and audio comes out of the radio’s speaker.
NOTE:
When a new accessory is connected,
paired, disconnected, or powered off, it may take
several seconds for the audio from received radio
calls to be routed appropriately.
Transmit and Receive Operation (Cont.)
When transmitting, the operator’s voice is picked up by:
• The microphone in the wireless headset or audio
accessory if one is paired.
• If no audio accessory is paired with the Bluetooth
Adapter, or the paired wireless audio accessory is
turned off or moved out of the Bluetooth Adapter’s
range, the internal microphone in the attached radio
is used.
The Bluetooth Adapter may temporarily mute the radio’s
speaker, causing incoming calls to be missed, in any of
the following situations:
• The adapter is attached to the two-way radio and no
wireless headset or wired accessory is paired.
• The wireless headset is turned off or runs out of
battery power.
• The wireless headset goes out of range of the
Bluetooth adapter.
NOTE: This mute state only occurs until the BT
timeout (5 seconds) is reached or BT is disabled.
Introduction
The Harris Bluetooth (BT) adapter allows you to use a
compatible Harris
wireless headset or other audio
accessory with your radio. Harris recommends the use
of Harris-
branded BT Accessories. Any other BT
Devices are not guaranteed to work with this Harris
Adapter.
Supported Radios
The following Harris radios support the Bluetooth
adapter:
P5300 P5400
P5500 P7300
XG-75P/Pe XG-15P
Status LED Messages
1 flash every 4 seconds
Normal operation
2 flashes per second Audio accessory pairing
mode active
1 long flash for 3
seconds
Successfully paired or re-
paired
No indication
Radio is turned off
Controls and Connections
Quick Start
1.
Connect the Bluetooth Adapter to a compatible
Harris portable radio.
2.
Pair the Bluetooth Adapter with a compatible
wireless audio accessory.
3. Test and use.
Connecting the Adapter to the Radio
1.
Always turn off the radio before connecting the
Bluetooth Adapter to the radio.
2. Plug the Bluetooth Adapter into the radio’s UDC
port.
3. Tighten the retaining screw.
4. Turn on the radio. The radio operates normally until
a wireless audio accessory is paired with the
Bluetooth Adapter.
See next section for pairing
directions.
5. The Pair/PTT button on the BT Adapter functions as
a PTT button when paired with a Bluetooth
accessory. The radio’s internal microphone and
speaker are
disabled as long as the Bluetooth
Adapter is paired with a Bluetooth accessory.
Pairing with an Audio Accessory
1. Turn off the radio to which the Bluetooth Adapter is
connected. Wait at least three seconds.
2. Turn the radio on while holding down the Pair/PTT
button on the Bluetooth Adapter.
3. Continue to hold the Pair/PTT button down for
approximately five seconds. Release the Pair/PTT
button when the status LED begins to flash two
times per second.
4. The Bluetooth Adapter is now in audio accessory
pairing mode. Activate the pairing mode on your
compatible wireless audio accessory.
5. Once the wireless audio accessory and Bluetooth
Adapter are paired, the status LED on the adapter
shows a constant blue light for three seconds.
6.
If the Bluetooth Adapter does not detect a
compatible wireless accessory within 60 seconds of
being put into pairing mode, the adapter exits
pairing mode and resumes normal operation.
7. Once successfully paired, you can operate your
radio using your compatible wireless accessory.
Transmit and Receive Operation
The Harris Bluetooth Adapter automatically routes radio
calls based on the following priority:
• Calls will be routed to a wireless accessory if one is
paired with Bluetooth Adapter.
• If no wireless headset or audio accessory is paired
to the Bluetooth Adapter, the wireless accessory is
turned off, or the wireless Bluetooth accessory is
out of range, the radio reverts to normal operation
and audio comes out of the radio’s speaker.
NOTE: When
a new accessory is connected,
paired, disconnected, or powered off, it may take
several seconds for the audio from received radio
calls to be routed appropriately.
Transmit and Receive Operation (Cont.)
When transmitting, the operator’s voice is picked up by:
• The microphone in the wireless headset or audio
accessory if one is paired.
• If no audio accessory is paired with the Bluetooth
Adapter, or the paired wireless audio accessory is
turned off or moved out of the Bluetooth Adapter’s
range, the internal microphone in the attached radio
is used.
The Bluetooth Adapter may temporarily mute the radio’s
speaker, causing incoming calls to be missed, in any of
the following situations:
• The adapter is attached to the two-way radio and no
wireless headset or wired accessory is paired.
• The wireless headset is turned off or runs out of
battery power.
• The wireless headset goes out of range of the
Bluetooth adapter.
NOTE: This mute state only occurs until the BT
timeout (5 seconds) is reached or BT is disabled.
