HBC radiomatic TC693 UHF transceiver for data transfer User Manual UM TC693 V2
HBC-radiomatic GmbH UHF transceiver for data transfer UM TC693 V2
Installation Manual
User Manual
Transceiver Module TC693
UM-TC693-V2.DOC / SEBB/DOKUS Page 1 / 5
HBC-radiomatic GmbH • 74564 Crailsheim • Germany
Information and specifications subject to change without notice. 2011-05-10
www.hbc-radiomatic.com
HBC – Transceiver Module
T
TC
C
6
69
93
3
User Manual
Transceiver Module TC693
UM-TC693-V2.DOC / SEBB/DOKUS Page 2 / 5
HBC-radiomatic GmbH • 74564 Crailsheim • Germany
Information and specifications subject to change without notice. 2011-05-10
www.hbc-radiomatic.com
Manufactured by: HBC-radiomatic GmbH
Haller Strasse 47 – 53
74564 Crailsheim, Germany
Tel: +49 79 51 3 93–0
Fax: +49 79 51 3 93–50
E-mail: info@radiomatic.com
http://www.hbc-radiomatic.com
HBC-radiomatic GmbH is not liable for any misprints or errors! – All rights reserved.
™ HBC-radiomatic is a registered German trademark.
© 2011 – 11 , HBC-radiomatic GmbH , 74564 Crailsheim , Germany
No part of any software or of the present document may be reproduced in any manner whatsoever without the expressed
written permission of HBC-radiomatic GmbH.
User Manual
Transceiver Module TC693
UM-TC693-V2.DOC / SEBB/DOKUS Page 3 / 5
HBC-radiomatic GmbH • 74564 Crailsheim • Germany
Information and specifications subject to change without notice. 2011-05-10
www.hbc-radiomatic.com
Table of Contents
Warnings ................................................................................................. 4
Installation………………………………………………………………………..5
Technical Data ........................................................................................ 5
User Manual
Transceiver Module TC693
UM-TC693-V2.DOC / SEBB/DOKUS Page 4 / 5
HBC-radiomatic GmbH • 74564 Crailsheim • Germany
Information and specifications subject to change without notice. 2011-05-10
www.hbc-radiomatic.com
Warnings
FCC
Part 15.21 Statement
NOTICE:
Changes or modifications made to this equipment not expressly approved by (manufacturer name) may void
the FCC authorization to operate this equipment.
Part 15.105 Statement
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IC
RSS-GEN – User Manual Statements (English/French)
Licence exempt
This device complies with complies with Part 15 of the FCC Rules and Industry Canada licence-
exempt RSS standard(s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le onctionnement.
User Manual
Transceiver Module TC693
UM-TC693-V2.DOC / SEBB/DOKUS Page 5 / 5
HBC-radiomatic GmbH • 74564 Crailsheim • Germany
Information and specifications subject to change without notice. 2011-05-10
www.hbc-radiomatic.com
Installation
The module is installed by plugging it into the suitable interface (38 pins) on the receiver
or transmitter board. An additional screw, which must be added, holds the module in his
interface.
Technical Data
Common data (RX+TX):
Frequency range: 902.000 ... 917.975 MHz
Operating voltage: + 3.3 ... 4.6 V
Channel pattern: 25 kHz
LF transmission bandwidth: 150 Hz .... 4.8 kHz
Modulation type: F2D
Operating temperature range: -30 ... +70 °C
Transmitter:
Maximum field strength: 50 mV/m @ 3 m
Frequency deviation: +/- 5 kHz
Current consumption when transmitting: 100 mA
Switch-over time (RX-TX): < 1 ms
Receiver:
Sensitivity: -108 dBm (20dB S/N)
First IF: 45 MHz
Second IF: 455 kHz
Current consumption when receiving: 70 mA
Switch-over time (TX-RX): < 1 ms
LF output voltage: 120 mV RMS at +/-5 kHz deviation (internal test point only!)
IP3: 0 dBm
