CB18ControlBoxInstructions

1.ProductOverview

ProductName：ControlBox

ProductModelNo.：CB18

FCCID:2AEQWCB18HHC004



2.Environmentrequirement

Operationtemperature:+10℃~+40℃.

Storagetemperature:－10℃~65℃.

OperatingHumidity：10%~80%RH，non‐condensing.

StorageHumidity：10%~85%RH，non‐condensing.



3.DirectionsforOperation

Tousethecontrolbox,thePSK2920Aswitchpowersupplymustbeconnectedasthecontrol

boxpowersupply.TheCH18remotecontrolmustalsobepairedtobeused.Detailedusagefor

eachportisasfollows:

Beforeuse,theCH18remotecontrolandCB18controlboxmustbepaired:

Pressandholdthebutton,approx.15seconds,untiltheremote’sfrontindicatorlights

up.Then,connectittothecontrolboxPowerplug.Afterthebeepsound,thepairingiscomplete

andremotecanoperate.

Indicator

light

2/3



4.Theportisintroduced

4.1“HDMotor”：ConnectstotheHeadmotor,andlifts/lowersheadsection.

4.2“FTMotor”：ConnectstotheFootmotor,andlifts/lowersfootsection.

4.3“TiltMotor”：ConnectstotheTiltmotor,andadjuststilt.

4.4“Power”：Connectstothepowersupplybox,controlspowersupply.

4.5“USB”：ConnectstotheUSBadapterbox,andUSBadapterboxandUSBsocketconnection.

4.6“LED”：Connectswithlights.

4.7“SYN”：Samesteps.Connectanothercontrolbox,andtwocontrolboxeswillsynchronize

4.8“HDMassage”：ConnectstoHeadmassagemotor,controlsstrengthofheadmassageand

on/off.

4.9“FTMassage”：ConnectstoFootmassagemotor,controlsstrengthoffootmassageand

HeadMotorPort

FootMotorPort

PowerInputconnection

USB

Connection

LED

Connection

SYNCCord

Connection

FootMassage

MotorPort

HeadMassage

MotorPort

TiltMotorPort

3/3



on/off.



5.Mattersneedingattention：

5.1Thefunctionwillonlyworknormallyinproperworkingpowerconditions.

5.2Controlboxinputvoltagemustbelessthan29.2VDC.

5.3TheCH18remotecontrolisneededforpropercontrol.

5.4Ifproblemsareidentified,theymustbetreatedbyprofessionalpersonnel.



6.Additionalattentionforuser：

6.1ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital

device,pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonable

protectionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,

usesandcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe

instructions,maycauseharmfulinterferencetoradiocommunications.However,thereisno

guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoes

causeharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturning

theequipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneor

moreofthefollowingmeasures:

—Reorientorrelocatethereceivingantenna.

—Increasetheseparationbetweentheequipmentandreceiver.

—Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris

connected.

—Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

6.2Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo

conditions:(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustaccept

anyinterferencereceived,includinginterferencethatmaycauseundesiredoperation.

6.3ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolled

environment.EndusersmustfollowthespecificoperatinginstructionsforsatisfyingRFexposure

compliance.TomaintaincompliancewithFCCRFexposurecompliancerequirements,please

usingaminimumseparationdistanceof5mmfromthedevice.

Thistransmittermustnotbeco‐locatedoroperatinginconjunctionwithanyotherantenna

ortransmitter.

6.4For Intentional and unintentional radiators the manual shall caution the user that changes

or modifications not expressly approved by the party responsible for compliance could void the

users authority to operate the equipment
