HON HAI PRECISION IND WINB1 Bluetooth Module User Manual J27H022 00
HON HAI Precision Ind. Co., Ltd. Bluetooth Module J27H022 00
Users Manual
COMPANY CONFIDENTIAL
J27H022.00
Bluetooth Module
User Manual
Rev. 1.0
Prepared by Reviewed by Approved by
Gallon Tao
WIN-B1
COMPANY CONFIDENTIAL
Index
1. REVISION HISTORY...................................................................................................................................................3
2. INTRODUCTION ..........................................................................................................................................................4
3. PRODUCT SPECIFICATION .....................................................................................................................................5
4. PRODUCT REQUIREMENTS AND CHARACTERISTIC......................................................................................6
5. ANTENNA SPECIFICATION .....................................................................................................................................7
6. MECHANICAL DRAWING .......................................................................................................................................11
7. SCHEMATIC ...............................................................................................................................................................11
COMPANY CONFIDENTIAL
1. Revision History
Date Change Note REV
Note
2010-09-20 Initial Release 1.0
COMPANY CONFIDENTIAL
2. Introduction
Project Name: Bluetooth 2.1+EDR module
This documentation describes the product specification of the Bluetooth 2.1+EDR module.
It is a confidential document of Foxconn.
2.1 Scope
This Bluetooth module is available in the 2.4-GHz ISM band, it is compatible with
Bluetooth specification v2.1+EDR. It supports basic rate of 1Mbps with GFSK
modulation, and EDR 2Mbps for DQPSK and 3Mbps for 8DPSK.
2.2 Function
¾ Class 2 specification RF output power (max +4 dBm)
¾ Full piconet and scatternet operation
¾ Supports 2Mbps, 3Mbps Enhanced Data Rate.
¾ USB 2.0 full-speed compliant interface
¾ Full support for power saving modes
¾ FW via on-line downloading and upgrade
COMPANY CONFIDENTIAL
3. Product Specification
3.1 WiFi RF Specification
Bluetooth Standards v2.1+EDR
Operating Frequency 2.400 – 2.4835
Data Rate Basic Rate: 1Mbps
Enhanced Data Rate: 2Mbps, 3Mbps
Modulation Schemes GFSK(1Mbps), DQPSK(2Mbps), 8DPSK(3Mbps)
Transmitter Output Power
GFSK Transmitter Output Power: -6dBm~ +4dBm (Class 2 Specification)
EDR Relative Transmit Power: (P
GFSK
-4dB) < P
DPSK
< (P
GFSK
+1dB)
Receiver Sensitivity
Typical -87dBm @1Mbps (PER<0.1%)
Typical -89dBm @2Mbps (PER<0.01%)
Typical -85dBm @3Mbps (PER<0.01%)
3.2 Electrical Specification
Absolute Maximum Ratings
These specification indicate levels where permanent damage to the device can occur. Functional
operation is not guaranteed under these conditions. Operation at absolute maximum conditions for
extended can adversely affect long-term reliability of the device.
Recommended Operating Condition
Value Element Symbol
Minimum Typical Maximum
Unit
DC supply voltage for the device VDD 3.0 3.3 3.6 V
Function operation is not guaranteed outside this limit, and operation outside this limit for extended
periods can adversely affect long-term reliability of the device.
Current Consumption
Idle: 8mA @3.3V
Transmit: 30mA @3.3V
Receive: 28mA @3.3V
Rating Symbol Value Unit
DC supply voltage for the device VDD 3.0~3.6 V
Regulatory Information
USA-Federal Communications Commission (FCC)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
Caution
Any changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
Labeling
Hon Hai Precision Bluetooth module WIN-B1 labelled as below.
FCC ID: MCLWINB1
The proposed with FCC ID label format is to be placed on the module. If FCC ID
is not visible when the module is installed into the system, “Contains FCC ID:
MCLWINB1” shall be placed on the outside of final host system.
Caution: Exposure to Radio Frequency Radiation.
To comply with FCC RF exposure compliance requirements, a separation
distance of at least 20 cm must be maintained between the antenna of this
device and all persons. This device must not be co-located or operating in
conjunction with any other antenna or transmitter.
Canada-Industry Canada (IC)
This device complies with RSS 210 of Industry Canada.
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may
cause undesired operation of this device.
The term “IC” before the equipment certification number only signifies that the
Industry Canada technical specifications were met.
Caution: Exposure to Radio Frequency Radiation.
To comply with IC RF exposure compliance requirements, a separation distance
of at least 20 cm must be maintained between the antenna of this device and all
persons. This device must not be co-located or operating in conjunction with any
other antenna or transmitter.
