HOTA TECHNOLOGY D6PRO AC/DC Dual Channel Smart Charger User Manual D6 Pro
SHENZHEN HOTA TECHNOLOGY CO.,LTD AC/DC Dual Channel Smart Charger D6 Pro
User Manual
使
用
说
明
1、连接电源、等待开机自检完成；
2、选择已连接好电池的通道；
3、通过显示屏及飞梭键设置适用于您的电池的充电参数；
4、开始享用。
通道选择
通道1平衡口
通道2平衡口通道2输出口
飞梭键
通道1输出口
5V输出
AC接口
DC接口 无线充电
升级口
功能参数
净重
输入电压
充电功率
放电功率
555g
USB输出口 5V / 2.1A
外部放电电流 1~15A x 2
AC100~240V / DC 6.5~30V
DC 325W x 2
AC 200W (自动分配)
内部放电: 15W x 2(平衡口10Wx2）
外部放电: 325W x 2(650W)
平衡电流
显示屏尺寸
充电电流 放电电流 0.1~3A x 2
最大1600mA x 2
2.8〃320×240 26万色
外形尺寸 108mm×105mmx76mm
存储温度 -20~60°C
工作温度 0~40°C
电池类型
LiHv/LiPo/LiFe/Lilon/Lixx : 1~6S
NiZn/Nicd/NiMH : 1~16S
Smart Battery : 1~6S
Lead Acid(Pb) : 2~24V
Enelop : 1~16S
0.1~15A x 2
AC/DC双通道智能充电器
外观专利：201730627674.9 无线专利：201721700843.8
安全注意事项：
1、使用过程中确保充电器远离热源及潮湿环境，并注意通风散热；
2、切勿让儿童操作充电器，请勿让充电器离开视线范围工作；
3、正确设定电池充放电的参数，错误的设定可能导致意外；
4、使用结束后，应尽快断开输入电源及移除电池。
接入电源前请确保电源输出电压与充电器工作电压范围相符。
警 告！
远离火源！
www.hota-exp.com
USB
5V 2.1A
Internal discharge:15W × 2(balance port 10W）
External discharge:325W × 2(650W)
1. Connect the power supply, wait for self-testing to be completed;
2. Select the channel you wanna use then connect your battery to the
chosen channel;
3. Set up charging parameters applicable to your battery through the
display and speed shuttle key;
4. Enjoy.
Channel
Switch
Balance Port
for Channel 1
Balance Port for Channel 2
Speed Shuttle Key
USB Port 5V
AC Port
DC Port Wireless Charging
Update Port
Specifications
Net Weight
Input Voltage
Charge
Power
Discharge
Power
555g
USB Output 5V / 2.1A
External Discharge Current
1~15A x 2
AC100~240V / DC 6.5~30V
DC 325W x 2
AC 200W
(Support power distribution）
Balance Current
Screen Size
Charge Current
Discharge Current 0.1~3A x 2
1600mA x 2
2.8〃320×240 260000 colors
Dimensions 108×105x76mm
Storage Temperature
-20~60°C
Operating Temperature
0~40°C
Battery
Type
LiHv/LiPo/LiFe/Lilon/Lixx : 1~6S
NiZn/Nicd/NiMH : 1~16S
Smart Battery : 1~6S
Lead Acid(Pb) : 2~24V
Enelop : 1~16S
0.1~15A x 2
AC/DC Dual Channel Smart Charger
Appearance Patent: 201730627674.9 Wireless Patent: 201721700843.8
www.hota-exp.com
USB
5V 2.1A
Battery Port for Channel 2
Battery Port
for Channel 1
Instructions
WARNING!
FIRE HAZARD!
NEVER USE CHARGER UNSUPERVISED!
Batteries pose a SEVERE risk of fire if not propely handled.
Read Entire operation manual before using charger.
This unit may emit heat during use.
Only operate this device in a cool ventilated area away from flammable objects.
Failure to observe safety procedures may cause damages to property or injury.
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving an tenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
