HLCRIO132(FCC ID 2ABS5-EWC-4000)_User manual
MODEL: HLCRIO132
(Easy One Touch Wireless Qi Standard Charging Car Mount)
User Manual & Limited Warranty
HSM Co., Ltd
www.hsmtech.com
HLCRIO132 Includes,
Product Overview
HLCRIO132 User Manual & Warranty Cigar Charger (Option)
How to use HLCRIO132
1. Place HLCRIO132 on where necessary and connect it to power source.
* A. Powerful Gel Suction enables the unit to be used in wide area such as at home, at the office and
even in the car staying on the textured dashboard tightly.
B. When HLCRIO132 is properly connected to power source, LED light turns to Orange
2. Place the phone on the unit. The Phone have to
be equiped with ‘RECEIVER’
* Wireless charging Receiver is not included in the package
* Extend the arms of the unit. Place your phone into mount
and slightlly push to work ‘one touch button’ to lock.
3. If the unit placed properly, Green light turns on
and flickers. If Orange light flickers, use ‘Bottom
extendable bracket’ and move the phone up and
down until the Green light turns on. When the
‘Bottom bracket release button’ is pushed, the
‘Bottom extendable bracket’ will be pulled up
and down.
4. When fully charged, Green LED light stops flickering.
* Check the charging status through charging icon on your smart phone.
* Foreign material between the phone and charing mount or poorly adjusted ‘Bottom extendable
bracket’ may block charging.
LED Status Indicator Charge status
Orange Connected to power source
Orange flickers Phone is not installed to the mount properly, RX doesn’t meet TX
Green flickers Charging
Green Fully charged
HLCRIO132 properly acquired qi Certificate from WPC(Wireless Power Consortium)
MODEL: EWC-3000
(Easy Flex One Touch Wireless Charging Mount)
구 성 품
Safety Precautionst
Limited Warranty
Specification
These saftey precasutions are for keeping users away from danger along with loss of property.
Read these safety precautions before using HLCRIO132.
HSM takes no responsibilities for any injuries and damages caused by not following below notice.
▶ Do not install HLCRIO132 on where interferes with driving.
Avoid Gear, Handle, Brake, Airbag depolyment zone in the car
▶ Do not operate the unit during the driving. It may cause accident.
▶ Do not use broken power cords, plugs and loosened sockets.
▶ Do not touch plugs with wet hands or remove the power pulling cords with force.
▶ Do not bend the power cord with force.
▶ Do not place your unit near metal objects such as coins, keys, cell phones, jewelries.
▶ Charging battery process may cause heat. When heat get sever, stop charging
the unit and cool it down.
▶ Touching overheated unit with bare hands can cause skin burn includes red rash and
pigmentation on skin.
▶ Do not store or exposure your unit to flammable objects such as gas stoves,
microwave oven or high pressure container. This can cause fire or accident
▶ Do not drop the unit or exposure it to external shock.
▶ Do not keep the unit on a sloped surface. This may cause damage to the unit or break
components inside.
▶ Keep the unit away from small children or pet, not to be bitten or sucked. This may
damage your unit or cause fire.
▶ Keep the unit in a dry circumstance. Prolonged exposure to moisture cuase damage
to the parts and curcuit board.
▶ Use this unit for original purpose only.
▶ Do not disassemble, modify or repair the unit. It can cause electric shock.
▶ Limited warranty does not cover the unit which has unauthorized disassembling,
modification ro repairs.
HSM warrants this product and all parts thereof, only to the original end-user purchaser to
be free from defective materials and workmanship for first twelve(12) months beginning on
the date of purchase of the product.
Customer center: 822-573-5466
The limited warranty does not cover,
1) Claims for loss of use/inconveniences due to any malfunction, damage caused by light-
ing, water or other liquid intrusion, fire, flood, accident, negligence, misuse or improper
handling/operation.
2) Product that has been damaged due to installation, repairs, alteration or modification by
unauthorized service organization or person.
3) Defects or parts requiring replacement due to the ordinary wear and tear, corrosion rust
or stains, scratches, dents on the casing or pair work of the products.
This warranty covers only United States.
FCC Compliance statements
FCC compliance statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Warning : During operation, the user must keep a minimum separation distance of 10 cm with the RF devices.
Product Name Easy Flex Wireless
Charging Mount Model HLCRIO132
Purchase date Y M D
Purchase place Price
Model no. HLCRIO132
Color Black
Material PC ABS
Dimension 89*102*81mm
Weight 200g
Wireless Technology Qi standard
Input Voltage 5.0V 2.0A
Charging port Micro USB
Suction type Sticky suction Gel Pad
