HUIZHOU GAOSHENGDA TECHNOLOGY WCT0LR2201J WIFI+BT module User Manual

Hui Zhou Gaoshengda Technology Co.,LTD WIFI+BT module Users Manual

Contents

User Manual

PRODUCTS USERMANUAL
PAGE 1
WCT0LR2201J
Version 1.0
WIFI+BT Module
IEEE
802.11a/b/g/n/ac
2T/2R
Model Number:
WCT0LR2201J
The WCT0LR2201J is a high-gain and low power consumption wifi module . It fully complies
with IEEE 802.11a/b/g/n/ac feature rich wireless connectivity at high standards,delivers
reliable,cost-effective,throughput from an extended distance.When
3.3V, USB bus and GND were connected,This module is working. The Bluetooth part supports
latest 4.1+HS operation.
Product Features
Product Description
◆ Complies with IEEE 802.11g;
802.11b; 802.11n ; 802.11a ; 802.11ac
standard for 2.4GHz and 5GHz Wireless
LAN.
◆TWO Transmit and TWO Receive
path(2T2R)
◆Supports Infrastructure modes
◆ Works with all existing network
frastructure.
◆Capable of up to 128-Bit WEP
Encryption.
◆Freedom to roam while staying
connected.
◆ UP to 866.7 Mbps High-Speed
Transfer Rate in 802.11ac mode of
operation.
◆ Operating Systems：Windows XP,
Win7,Win8, Win10, Linux
◆ Low power consumption.
◆Complies with PCI Express base
specification revision 1.1 for WLAN
◆Complies with USB2.0
FS-mode Specification for Bluetooth
◆ Easy to install and configure.
◆Bluetooth v4.1 LE+EDR;
Product Specification
Model
WCTOLR2201J
Product Name
WIFI+BT Module
Standard
802.11a/b/g/n/ac
Interface
WiFi：PCIE BT：USB
Data Transfer Rate
1,2,5.5,6,11,12,18,22,24,30,36,48,54,60,9
0,120 and maximum of 866.7Mbps
Modulation Method
QPSK,BPSK ,CCK(802.11b)
QPSK,BPSK,16QAM ,64QAM with OFDM
(802.11g)
BPSK,QPSK,16QAM ,64QAM with OFDM
(802.11n)
QPSK,BPSK,16QAM ,64QAM with OFDM
(802.11a)
QPSK,BPSK,16QAM ,64QAM, 256QAM
with OFDM (802.11ac)
Frequency Band
2.4GHz: CH 1~CH13 for FCC
5GHz: 5150~5250MHz, 5725~5850MHz
Transmit Power
< 20dBm
Operation Mode
Infrastructure
Operation Range
Up to 300 meters in open space
OS Support
Windows XP, Win7,Win8, Win10, Linux
Security
WEP, TKIP, AES, WPA, WPA2
Operating Voltage
3.3V±10%
Operating Temperature
0 ~ 60°C ambient temperature
Storage Temperature
-40 ~ 80°C ambient temperature
Humidity
5 to 95 % maximum (non-condensing)
PRODUCTS USERMANUAL
PAGE 2
WCT0LR2201J
Version 1.0
FCC/Industry Canada Statement (to be placed on End Products)
Federal Communications Commission (FCC) Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Caution: The user is cautioned that changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
—Consult the dealer or an experienced radio/PC technician for help.
IC Statement
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to
the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1)
l'appareil ne
doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout
brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement.
Note：5150MHz-5250MHz is only for indoor use for the end product.
PRODUCTS USERMANUAL
PAGE 3
WCT0LR2201J
Version 1.0
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of
20cm between the radiator and any part of your body.
Notice to OEM integrator
The end user manual shall include all required regulatory information/warning
as show in this manual.
The OEM integrator is responsible for testing their end‐product for any
additional compliance requirements required with this module installed.
If the FCC ID is not visible when the module is installed inside another device,
then the outside of the device into which the module is installed must also
display a label referring to the enclosed module. The end product shall haves
the words “Contains Transmitter Module FCC ID: 2AC23-WCT0LR2201J, IC:
12290A-WCT0LR2201J”.
