User Guide
For
Laptop
ED20GM/ED20GMx
(x=0~9, A~Z or blank or “-“)
Regulatory Compliance
Information
FCC Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
For questions related to the EMC performance of this product,
contact:
Elitegroup Computer Systems Co., Ltd
No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan 11493
886-2162-1177
![](/img.php?id=3739581&img=bg3.png)
Canadian Department of Communications Compliance
Statement
This digital apparatus does not exceed the Class B limits for
radio noise emissions from digital apparatus set out in the Radio
Interference Regulations of the Canadian Department of
Communications. This device complies with Industry Canada
licence-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of
the device.
Le présent appareil numerique német pas de bruits radio
électriques dépassant les limites applicables aux appareils
numériques de la classe B prescrites dans le Réglement sur le
broullage radioélectrique édicté par le ministére des
Communications du Canada. Le présent appareil est conforme
aux CNR d’Industrie Canada applicables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes : (1) l’appareil ne doit pas produire de
brouillage, et (2) l’utilisateur de l’appareil doit accepter tout
brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
CE mark. Declaring compliance to all the applicable
European Union (EU) directives. For CE mark related
questions:
Elitegroup Computer Systems Co., Ltd
No.239, Sec. 2, Ti Ding Blvd., Taipei, Taiwan 11493
886-2162-1177
French SAR/DAS
Votre ordinateur a un DAS. Pour plus d'informations, voir le
portail radiofréquences-sante-environnement:
www.radiofrequences.gouv.fr
In the European Union, this symbol indicates that
this product including battery must not be disposed
of with household waste. It is your responsibility to
hand it over to a designated collection point for the
recycling of waste electrical and electronic
equipment. For more information, please contact
your local waste collection center or the point of
![](/img.php?id=3739581&img=bg4.png)
purchase of this product.
Japan VCCI Statement
こ装置情報処理装置等電波障害自主規制協議会 。VCCI) 基準
に基くクラ B 情報技術装置すこ装置家庭環境使用すこ
を目的しいますこ装置ラオやテレビョン信機に近接
し使用さ信障害を引起こすこあます
扱説明書に従っ正しい扱いをし下さい
Taiwan battery recycling:
Translation – please recycle batteries
![](/img.php?id=3739581&img=bg5.png)
Attention: Teachers, Parents and Adult
Supervisors
This product is an educational tool designed for school children,
ages 6 and up. There must be supervision by an adult on
school children under 10 when using this laptop. It is a must to
have a thorough explanation to students on safe and proper
handling of the laptop, power supply, battery pack, and power
cord.
Be sure to keep the power cord away from
younger children
Please ensure that students understand the following:
As with all electrical products, precautions should be observed
during handling and use to prevent electric shock. The power
supply (adapter) should not be handled by the children.”
Emphasize to students that this device is an educational tool and
not a toy. The computer, power supply, battery pack or power
cord should not be dropped, crushed, stepped on or otherwise
abused.
Ensure students understand the safe and proper handling of
power cord and power supply. Misuse could result in serious
injury.
The teacher, parent or adult supervisor should periodically
inspect the computer; power supply and power cord for damage
and replace it, if necessary.
Students should report any damage or loose parts to their
teacher, parent or adult supervisor, immediately.
Do not leave the PC plugged in or “on” when enclosed in a
non-vented container, such as a school backpack, as overheating
may occur.
It is recommended that students should take a 5 minute break
every 30 minutes of use.
![](/img.php?id=3739581&img=bg6.png)
Safety Precautions
The following are lists of precautionary measures the students
must understand before using this computer inside the
classroom or home environment:
1.
Do not place near the fire or other sources of heat.
2.
Do not expose to magnetic fields.
3.
Do not expose to direct sunlight.
4.
Do not expose to rain or moisture.
5.
Do not place heavy objects to add heavy pressure on
the computer.
6.
Do not drop the computer.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT
TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
ATTENTION
RISQUE D'EXPLOSION SI LA BATTERIE EST REMPLACÉE PAR UN
TYPE INCORRECT. RECYCLEZ LES BATTERIES USAGÉES SELON LES
INSTRUCTIONS.
IT IS RECOMMENDED TO USE THIS COMPUTER IN AN ENVIRONMENT
WHERE THE AMBIENT TEMPERATURE IS NO MORE THAN 35°C.
![](/img.php?id=3739581&img=bg7.png)
Contents
1. Getting to know your computer ................................................. 1
Package contents .............................................................................................................. 1
Layout ...................................................................................................................................... 2
Front ............................................................................................................................. 2
Front end .................................................................................................................... 3
Right ............................................................................................................................. 3
Left ................................................................................................................................. 4
Digital pen (optional) ............................................................................................ 5
Function keys ........................................................................................................... 6
Folding the keyboard ....................................................................................................... 7
Your rotatable camera ..................................................................................................... 8
2. Using your computer .................................................................. 9
Powering ON/OFF ............................................................................................................ 9
Powering on your computer ............................................................................. 9
Powering on for the first time........................................................................... 9
Powering off your computer ........................................................................... 10
Putting your computer into sleep mode ................................................... 11
Waking up your computer ............................................................................... 11
Basic touchpad operations ......................................................................................... 12
Basic touchscreen operations .................................................................................. 13
Fingerprint ........................................................................................................................... 15
3. Windows Interface .........................................................................18
Desktop and virtual desktop experience ............................................................. 18
Taskbar ................................................................................................................................. 19
Start menu ............................................................................................................... 19
Search box - Cortana ........................................................................................ 20
App shortcuts area .............................................................................................. 21
Notification area ................................................................................................... 21
4. Setup and Connection .................................................................22
Settings screen ................................................................................................................. 22
Windows Activation ........................................................................................................ 23
Setup Your Microsoft Account ................................................................................... 23
Replacing Desktop with Start screen .................................................................... 24
Pin and unpin your app ................................................................................................ 24
Pinning an App to Start menu or taskbar ................................................ 24
Removing an App ................................................................................................ 25
Wireless LAN ..................................................................................................................... 25
Enabling wireless connection ........................................................................ 25
Micro SD Card Slot ......................................................................................................... 26
To insert your micro SD card ......................................................................... 26
To remove your memory card ....................................................................... 26
Connecting an External Device ............................................................................... 27
USB Connection ................................................................................................... 27
5. Battery ................................................................................................28
Charging your battery.................................................................................................... 28
Inspecting your battery status ................................................................................... 29
6. Windows Help and Troubleshooting .....................................31
Troubleshooting ................................................................................................................ 31
7. Specification ....................................................................................35
![](/img.php?id=3739581&img=bg9.png)
1
1. Getting to know your
computer
Package contents
Carefully unpack your box and take out the items listed as below. If any
of the items is missing or damaged, contact your dealer immediately:
• One laptop • One AC adapter
• Digital pen (optional) • Macro lens (optional)
• Thermal probe (optional) • This manual
![](/img.php?id=3739581&img=bga.png)
2
Layout
Front
No.
Name Function
1 Rotatable camera Often for taking self-portraits as well as for
video conferencing.
2 Microphone Mainly for sound and speech recording
3 Touchscreen
The main display of your laptop and a
see-touch device. You can look at it and
also touch it with your fingers to control it.
4 Power button Press it to power on/off your laptop.
5 Windows key Press here to open the Start menu.
6 Touchpad Allows you to control your system using
figure gestures
![](/img.php?id=3739581&img=bgb.png)
3
Front end
No.
Name Function
1 Speaker
The sound system has two speakers for
playing music, notification sounds, and
other audio data.
Right
No.
Name Function
1 Digital pen
holder
This is where you rest the provided digital
pen.
2 Digital pen
Use it to perform touch operations and
typing comfortably as if you were doing
them with your own fingers.
![](/img.php?id=3739581&img=bgc.png)
4
Left
No.
Name Function
1 USB Type-C port
Plug your USB Type-C supported
devices here.
Plug the provided adapter here to
charge the battery.
2 Charging indicator
It shows the charging status of your
laptop. It shows blue when the battery
is fully charged.
3 Micro SD card slot Plug your micro SD card here
4 USB Type-A port Plug your USB Type-A devices here.
5 Combo Audio jack for
microphone/headphone
Plug your 3.5mm headphone here
![](/img.php?id=3739581&img=bgd.png)
5
Digital pen (optional)
No.
Name Function
1 Eraser button
With the button being pressed, the tip
of your digital pen acts like an eraser
and enables you to erase the content
previously made on the touch screen.
This button may require the
support from your application.
2 Barrel button
This button provides two functions in
default:
a. Right click: Perform a touch on
your desired item or object with the
button being pressed.
b. Selecting items or objects: Press
and hold this button and drag your
pen on the screen over the desired
items or objects to select them.
![](/img.php?id=3739581&img=bge.png)
6
Function keys
The following function keys are no need to press Fn to make them work.
Mute or unmute your
system.
Increases the display
brightness.
Decreases the volume
level.
Opens the Settings
screen.
Increases the volume
level
Play or Pause
Switches display
output between your
display, external
monitor (if connected)
and both.
Push here to talk to
Cortana, if available.
Decreases the display
brightness
![](/img.php?id=3739581&img=bgf.png)
7
Folding the keyboard
This laptop supports a swiveling 11.6-inch touchscreen that can
be used in several different ways. Opening the device as a
standard laptop gives you access to the keyboard and touchpad,
while folding the keyboard behind the screen turns it into a tablet.
You also can prop the notebook's screen up in stand mode, which
is ideal for viewing videos and presentations.
![](/img.php?id=3739581&img=bg10.png)
8
Your rotatable camera
Form the angle at which the camera facing forward, you can adjust the
camera angle downward to make it facing down at an angle of 35
degree.
Or, you can turn it over a full 200 degree to use it like a rear-facing
camera.
![](/img.php?id=3739581&img=bg11.png)
9
2. Using your
computer
Powering ON/OFF
Powering on your computer
1. If this is the first time you turn this computer on, connect the AC
adapter and fully charge the battery.
2. Press the power button (normally 1 to 2 seconds). You shall see the
screen turning on.
Powering on for the first time
The laptop will require you to do the initial setup, which including:
![](/img.php?id=3739581&img=bg12.png)
10
Activate your Windows 10
Sign in to or create your Microsoft account
Setup a wireless connection and more
Please follow the instruction to complete the initial setup.
Powering off your computer
Save all your data before powering your computer off.
To power off your system, following the steps below:
A. By Start menu
1. Click the Windows icon
in the low-left corner of
the Desktop. Or, press
on the Windows key in
the keyboard.
2.
In the Start menu,
click the Power icon,
as shown on the right,
3. Select <Shut down> from the
power option menu, as shown
on the right.
![](/img.php?id=3739581&img=bg13.png)
11
Putting your computer into sleep mode
When you will be away from your computer for a short time, put the
computer to sleep.
Do one of the following:
• Close the display panel
• Press the power button briefly one time.
• Open the Start menu and then select <Power> → <Sleep>.
Waking up your computer
Note: It is recommended that you put your computer to sleep before
you move it. Especially, if your laptop comes with a traditional hard
disk, instead of a modern SSD, moving your computer while the
hard disk is spinning can sometimes damage the hard disk, causing
loss of data.
Do one of the following:
A: Pressing the power button briefly one time.
B: Pressing the windows key.
C: Tapping the touchpad, or opening the display panel.
![](/img.php?id=3739581&img=bg14.png)
12
Basic touchpad operations
The touchpad works like a traditional mouse. With it, you can move the
cursor and perform left-click, right-click, double-click actions. However,
the actual available actions are application dependent.
Action name Explanation
Left-clicking (or Clicking) Tap once on the touchpad surface or press
once on the low-left corner of the
touchpad.
Right-clicking Press once on the low-right corner of the
touchpad.
Dragging Press and continue to hold down the left
corner and then move (drag) your finger
across the touchpad surface.
Vertical scrolling
Drag two fingers up or down on the
touchpad.
Horizontal scrolling
Drag two fingers left or right on the
touchpad.
![](/img.php?id=3739581&img=bg15.png)
13
Basic touchscreen operations
When you fold your laptop into a tablet, it is ideal for you to use your
fingers or the digital pen to perform many actions on it.
• Don’t use sharp objects to touch the screen. Or, the screen may be
damaged or scratched.
• Don’t touch the touchscreen with a conductive material. It may cause a
malfunction.
• The supporting functions are application dependent.
Gesture name Explanation
Tap
Touch once on an item to start an app, open a
link, or perform an optional function. This is
similar to a left-click with a mouse.
Double-tap
Slightly press twice with your finger to select
an item.
Press and hold Press and leave your finger on an item. This
brings up detailed information or opens a
menu with more options for the item. This is
similar to a right-click with a mouse.
![](/img.php?id=3739581&img=bg16.png)
14
Pinch
or
Move two fingers together or apart while
touching the screen. This is to zoom in and
out on visual apps, such as pictures and
maps.
Rotate
Place two or more fingers on an item and then
turn your hand.
This enables you to turn an object. (Note:
Not all items can be rotated, depending upon
the app.)
Slide
Drag your finger across the screen.
This can scroll through lists and pages, and
can also move an object or be used to draw or
write, depending upon your apps.
![](/img.php?id=3739581&img=bg17.png)
15
Fingerprint
If you see this icon on the right side of the power
button, you laptop comes with the fingerprint login
feature.
To activate this feature, please follow the following steps to complete the
setup:
1. Open the Settings page and select Accounts.
For how to open the Settings page, please refer to page 21.
2. In the Accounts page, select “Sign-in options”.
Note: Before setting your fingerprint sign-in option, you need to set your
password first if you have not set one yet.
![](/img.php?id=3739581&img=bg18.png)
16
3. In the Fingerprint field, click “Setup”. This will activate a feature
called Windows Hello.
4. Click “Get started” here, and the system will ask you to swipe your
finger with the popup box as shown below.
The system will request you to repeat this process for several times.
![](/img.php?id=3739581&img=bg19.png)
17
Here, you may be asked to set your PIN in case that the Windows Hallo
becomes unavailable for some reasons.
After you follow the instructions shown on the screen, you are able to
login to your laptop with your fingerprint.
![](/img.php?id=3739581&img=bg1a.png)
18
3. Windows
Interface
Desktop and virtual desktop experience
The Desktop screen is as shown below and natively provides
virtual desktop feature.
To launch the feature you can click the app icon as shown
on the left or just press Window key and TAB key of your
keyboard in the same time.
![](/img.php?id=3739581&img=bg1b.png)
19
Taskbar
The black bar on the bottom of the desktop is called Taskbar. It provides
several key features and they are:
Start menu
Search box
App shortcuts area
Notification area
Start menu
To open the Start menu, you can either click on the
windows icon (which is also known as Start button) located
at the left end of the taskbar or press once on the windows
key of the keyboard. And the Start menu will appear, as shown below
For how to setup this menu, please refer to page 20.
![](/img.php?id=3739581&img=bg1c.png)
20
Search box - Cortana
Next to the Start menu is the search box, as shown below.
When you select this box, a window will pop out as shown below.
This is the Cortana icon. Cortana is a new virtual
assistant built into your Windows 10. Click here to
finish the setup and you can control Cortana with
either keyboard or voice commands, and use it to
perform intelligent searches and more.
After you setup the Cortana settings, the search box will look like
![](/img.php?id=3739581&img=bg1d.png)
21
App shortcuts area
In this area, you can put the shortcuts of your frequently used apps. For
how to arrange this area, please refer to p.20
Notification area
The right part of the taskbar holds several icons that show you the status
of your laptop, as shown below.
This is an area called Notification Area, where
Click here to show more hidden status
icons.
Shows you the current battery status.(For
detail, please refer to page 25)
Shows you the status of your wireless
network connection.
Click here to open a touch keyboard, with
which you can type text directly on the
screen.
Click here to show the system notifications
and several shortcuts.
![](/img.php?id=3739581&img=bg1e.png)
22
4. Setup and
Connection
Settings screen
To access to the Settings
screen:
1. Click the Windows icon in
the low-left corner of the
Desktop. Or, press on the
Windows key in the
keyboard.
2. Click the Settings icon.
This will open the Settings screen, as shown below
Next, the following sections will guide you through the basic setup of your
windows system.
![](/img.php?id=3739581&img=bg1f.png)
23
Windows Activation
To use all features of your Windows
laptop, you may need to activate your
Windows system. Follow the following
steps to register and activate your
Windows.
1. Open the Start menu and click <Settings >.
2. Click <Update & security>
3. Select <Activate>.
4. Follow the instructions to activate your windows.
Setup Your Microsoft Account
To share files or settings with
other devices running Windows
10, you need to setup a Microsoft
Account. Furthermore, if you
want to download or purchase
apps from the Microsoft Store,
such Microsoft Account is
required.
To setup your Microsoft account
1. Open the Settings screen and select <Accounts> .
2. Select <Your account >
3. Select <Sign in with a Microsoft account instead>.
4. Follow the instruction to register your account information.
![](/img.php?id=3739581&img=bg20.png)
24
Replacing Desktop with Start screen
If you are more familiar with the
interface similar to the Start
screen introduced in Windows 8
series, you can set your laptop to
show the Start screen instead of
the Desktop every time when you
power on your laptop. To do so, do
the following steps:
1. Open the Settings screen.
2. Select <Personalization>.
3. In the Personalization screen, enable the option <Use Start full
screen>
After these steps, you will see the Start screen every time you turn on
your laptop.
Pin and unpin your app
Pinning an App to Start menu or taskbar
To add an app:
1. Open the Start menu
2. Right-click on the app that you want to
appear on your Start menu or taskbar, and
an option menu appears.
3. Click <Pin to Start> or <Pin to taskbar> to add the app to your Start
menu or taskbar .
![](/img.php?id=3739581&img=bg21.png)
25
Removing an App
To remove an app:
1. Right click the app that you want to remove from your Start menu or
taskbar.
2. Click <Unpin from Start> or <Unpin from taskbar> to remove it from
your Start menu or taskbar.
Wireless LAN
Enabling wireless connection
1. Open Settings menu and select
<Network & Internet>.
2. Select <Wi-Fi> and set the
function to ON, as shown below
![](/img.php?id=3739581&img=bg22.png)
26
.
3. Click the option “Show available networks”, and a network list will
appear on the right part of your screen.
4. Click your desired network’s name in the list, and then click Connect.
Follow the instruction on the screen to establish the connection.
Note: Some networks require a network security key or password for
connection. If necessary, ask the network administrator or the Internet
service provider (ISP) for the required information.
Micro SD Card Slot
You can utilize your micro SD cards as removable disks and conveniently
exchange data with digital devices such as a digital camera, digital
camcorder, MP3, etc.
To insert your micro SD card
1. Insert the micro SD card into the card slot.
2. Follow the message on the screen to open and view the files.
3. A Windows Explorer runs and shows all the folders and files in the
micro SD cards, and you can save, move and delete data as you are
handling a storage device.
To remove your memory card
1. Press the card and release. The card will pop up.
2. Pull the card out by holding the end of the card.
![](/img.php?id=3739581&img=bg23.png)
27
Connecting an External Device
USB Connection
Your computer comes with one USB Type-C and one USB Type-A port
supporting a wide range of USB devices.
Once you plug a USB device into a USB port on your computer, Windows
automatically loads a driver for that device. After the driver has been
loaded one time, you can disconnect and reconnect the same device
without performing any additional steps.
Note: If Windows requires you to install the driver before connecting,
check the documentation provided by the device’s manufacturer before
connecting the device.
To disconnect a USB storage device, make sure you click
the Safely Remove Hardware icon (as shown on the left)
in the notification area of the taskbar to remove the
device before disconnecting.
Note: If your USB device uses a power cord, connect the device to a
power source before connecting it.
![](/img.php?id=3739581&img=bg24.png)
28
5. Battery
Charging your battery
1. Plug the USB Type-C head of the
adapter into the USB Type-c port,
which you can find on the left side
of your laptop.
2. Plug the adapter into a
wall-socket.
3. You shall see the battery indicator
lights up in red.
4. When the battery is fully charged,
the battery indicator will turn into
blue
While system is off, it takes around 5 hours to fully charge the battery.
After fully charged, the battery Life reaches 6 hours on full HD video
playback
Note: If the remaining power in your battery capacity is 90% or
above, plugging the adapter will not fully charge your battery.
![](/img.php?id=3739581&img=bg25.png)
29
Inspecting your battery status
In Desktop, move the cursor to the battery icon in the taskbar. A pop-up
dialog box appears and shows you the remaining battery percentage, as
shown below.
The battery icon reveals the status of your battery, which described
as below.
Battery is fully charged
Battery is starting to drain
Battery is about to completely
drain, and you should stop using your
computer and charge it at once.
Battery is being charged.
The battery is an expendable supply, so when using it over a long time,
the capacity/battery life is shortened. If the battery life is reduced to
under half of its initial time, we recommend purchasing a new battery.
30
When not using the battery for a long time, store the battery after
charging it to 30-40% of its capacity. This extends the battery life time.
![](/img.php?id=3739581&img=bg27.png)
31
6. Windows Help and
Troubleshooting
Troubleshooting
This section describes some common problems and suggested
solutions, and ways to recover your computer from a crash.
Be aware that the problems and solutions described here are meant
only as a guide. They are not definitive problem solving techniques.
For certain problems, you might need help from your reseller or your
service provider.
When you observe a problem, stop operation immediately, because
taking further action might result in data loss or damage. Take a note
of what the system is doing and what actions you performed before
the problem occurred. Provide detailed information to your service
provider for quicker problem resolution.
For about any problem, follow these steps:
1. Restart your laptop.
2. Check your Wi-Fi connection.
3. Reset your Wi-Fi connection.
4. Plug your laptop to a wall socket to charge it for at least one
hour.
![](/img.php?id=3739581&img=bg28.png)
32
Screen problems
When I turn on the
computer, nothing appears
on the screen.
• If the screen is blank, make sure that:
- The AC adapter is connected to the
computer and the power cord is plugged
into a working electrical outlet.
- The computer power is on. (Press the
power button 6 seconds to force the
power off, and power it on again.)
• If these items are properly set, and the
screen remains blank, have the computer
serviced.
My screen goes blank while
the computer is on.
• Your laptop is in its sleep mode. Do one
of the following to resume from sleep
mode:
- Press any key on the keyboard for 2 to 3
seconds.
- Press the power button.
- Press the windows key button.
Sleep problems
The critical low-battery error
message appears, and the
computer turns off
• The battery power is getting low.
Connect the AC adapter to the computer.
The computer enters sleep
mode immediately after
Power-on.
• Make sure that the battery is charged.
- The operating temperature may be too
hot. Move to a cooler environment and try
to wake the computer.
![](/img.php?id=3739581&img=bg29.png)
33
The computer does not
return from sleep mode and
the computer does not
work.
• If your computer is in sleep mode,
connect the AC adapter to the computer,
then press the key button or the power
button.
• If your computer is powered-off, connect
the AC adapter to the computer, then
press the power button to resume
operation.
Display problem
The screen is blank. • Do the following:
- If you are using the AC adapter, or using
the battery, and the battery status
indicator is on, press Fn+F11 to make the
screen brighter.
- Press the power button to resume from
sleep mode.
- If the problem persists, follow the
solution in the next problem “The screen
is unreadable or distorted.”
The screen is unreadable or
distorted.
• Make sure that:
- The screen resolution and color quality
are correctly set.
- The monitor type is correct.
Incorrect characters appear
on the screen.
• Are the operating system or programs
installed correctly? If they are installed
and configured correctly, have the
computer serviced.
Sound problems
No sound can be heard • Make sure that:
![](/img.php?id=3739581&img=bg2a.png)
34
from the speaker even
when the volume is turned
up.
- The Mute function is off.
- The combo audio jack is not being used.
- Speakers are selected as the playback
device.
Other problems
Your computer does not
respond.
• To turn off your computer, press and hold
the power button for 6 seconds or more. If
the computer still does not respond,
remove the AC adapter.
• Your computer might lock when it enters
sleep mode during a communication
operation. Disable the sleep timer when
you are working on the network.
The connected external
device does not work.
• Do not connect or disconnect any
external device cables other than USB
while the computer power is on.
Otherwise, you might damage your
computer.
• When using a high power consumption
external device such as an external USB
optical disk drive, use an external device
power adapter. Otherwise, the device may
not be recognized.
![](/img.php?id=3739581&img=bg2b.png)
35
7. Specification
Processor
Intel® Celeron ® Processor
N4000 4M Cache, up to 2.5 GHz
Intel® Celeron ® Processor
N4100 4M Cache, up to 2.3 GHz
Intel®
Pentium
® Processor
N5000 4M Cache, up to 2.6 GHz
Memory
4 GB/8 GB on board
LPDDR4 single channel, Speed up to
2400MHz
Storage
64GB/128GB eMMC
Support 128GB/256GB SATA SSD
(optional)
Dimension
Lid: 295.2 x 203.85mm
Base: 298.5 x 207.3mm X 19.9 mm/.
Weight
Under 1.5 kg
Wireless
AC3165
Wi-Fi 1x1 802.11 a/b/g/n/ac
Bluetooth 4.2 +EDR
RTL8822BE
Wi-Fi 2x2 802.11 a/b/g/n/ac
Bluetooth 4.2 +EDR
![](/img.php?id=3739581&img=bg2c.png)
36
Touchscreen
TFT Color LCD, LED Backlight
11.6” with 1366 X 768 (HD)
10 point touch
Mutual Capacitive Sensing Techniques
Cameras
2.0M, w/o flash LED
Resolution support 2M (4:3 format) still
image and HD720P(1280x720, 16:9)
motion image.
Rotate angle: -35~+200deg.
Battery
3 cells (3250mAh, 37W, 3.85V )
Model No.: ED20-2S4500-S4L8
Input/Output
1 x USB 2.0 port Type-A
1 x Type-C(PD/USB3.0/DP)
1 x combo audio jack for headphone
/microphone/ thermal probe
1 x MicroSD 3.0 card reader
1 x SIM slot (Optional)
Speaker &
Microphone
Speaker :
Build-in 2 Speakers (1W , 8Ω)
Microphone:
2 digital mic on base support Mic array
![](/img.php?id=3739581&img=bg2d.png)
37
Language
English
Spanish
Portuguese
Arabic
Turkish
Russian
Simplified Chinese
Thai
Greek
Hungarian
Traditional Chinese
German
Hebrew
Italian
Latin Spanish
Brazil Portuguese
French
AC adapter
DC Output: 19V/2.1A
40 Watts, USB type C plug
Automatics Voltage adjustment between
100 and 240VAC
Input Frequency 50/60Hz
DC Output: 19V/2.37A
45 Watts, USB type C plug
Automatics Voltage adjustment between
100 and 240VAC
Input Frequency 50/60Hz
Certification
EMC
CE
FCC
NCC
RF FCC&SAR / RED
Safety&
Environment
UL / CB
CCC / CEL
WEEE
RoHS
UL 696
CPSIA
![](/img.php?id=3739581&img=bg2e.png)
38
Others
Vibration test:
MIL-STD-810F/EN-60068
Drop test :
MIL-STD-810F/GB/ T4857
(70 cm)
Acoustic test :
ISO3745/ISO7779
Water Resistance 100cc
on keyboard/touchpad
Dust proof IP5 on A, B
face only.
Design
ready
Energy Star Compliance
6.1
Erp 6
CEC
