HUNG WAI A18RK31 Android player main board with wireless module User Manual

HUNG WAI HOLDINGS LIMITED Android player main board with wireless module

User manual

User Manual
For
Android player Main board
with
wireless module
This user manual pertains to Android player Main board with Wireless module. The Main board can be assembled in the
Android based Advertising Media Player and Android based Advertising Set-Top-Box listes as below;
Model
Model Description
DT101-AS4-800
10.1" Android non-touch LCD Media Player
DT101-AC4-800
10.1" Android touch LCD Media Player
DT133-AS4-720
13.3" Android non-touch LCD Media Player
DT133-AC4-720
13.3" Android touch LCD Media Player
DT156-AS4-720
15.6" Android non-touch LCD Media Player
DT156-AS4-1080-SL
15.6" Quad Core Media Player Slim Housing
DT156-AC4-720
15.6" Android touch LCD Media Player
DT156-AC4-1080-SL
15.6" Quad Core Media Player Slim Housing
DT173-AS4-1080
17.3" Android non-touch LCD Media Player
DT173-AS4-1080-SL
17.3" Quad Core Media Player Slim Housing
DT173-AC4-1080
17.3" Android touch LCD Media Player
DT173-AC4-1080-SL
17.3" Quad Core Media Player Slim Housing
DT185-AS4-720
18.5" Android non-touch LCD Media Player
DT185-AS4-720-SL
18.5" Quad Core Media Player Slim Housing
DT185-AC4-720
18.5" Android touch LCD Media Player
DT185-AC4-720-SL
18.5" Quad Core Media Player Slim Housing
DT215-AS4-1080
21.5" Android non-touch LCD Media Player
DT215-AS4-1080-SL
21.5" Quad Core Media Player Slim Housing
DT215-AC4-1080
21.5" Android touch LCD Media Player
DT215-AC4-1080-SL
21.5" Quad Core Media Player Slim Housing
InVision A4-1080
Invision Android Advertising Set-Top-Box
1. Specifications:
PCBA dimension: 87.5 X 143mm
Assemble method: the module will be screwed on the housing and used as a Main board for Android based
Advertising Media Player and Android based Advertising Set-Top-Box
Input port:
1pc 5.5mm female barrel jack - for +12V power input
1pc DTCN-A-15F 15-pin female connector for additional control PCBA connection
1pc SD Card Slot - for SD
1pcs I2C interface for resistive/ capacitive touch screen
Output port:
1group of connector for LCD Screen of the Media Player, 1200 x 800 resolution or greater
2pcs Antenna connector for 2.4G + 5G WiFi network
1pc 3.5mm headphone jack - for 85mW audio
2pcs DTCN-A-2F - 2-pin female connector for SP1-SP2
Other ports:
1pc DTCN-A-4F - 4-pin female connector for UART connection
1pc RJ45 jack - for hardwired network compatibility
1pc mini USB receptacle
2pcs USB-A standard USB receptacle
Antennas:
External antenna with 2.5dBi gain which is can not replaced by end-user . Provided by Lian
Chuang Xin (Shenzhen) Ltd, Co. P/N: ANT-1569SMA20-00-A
Operation temperature:-20 to+50
Voltage(AC /60Hz):102-138V/ AC
Frequency Stability: +/-10 ppm
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
The modular can be installed or integrated in mobile or fix devices only. This modular cannot be installed in
any portable device, for example, USB dongle like transmitters is forbidden. This modular complies with
FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be
co-located or operating in conjunction with any other antenna or transmitter. This modular must be installed
and operated with a minimum distance of 20 cm between the radiator and user body.
The device is indoor use only.
If the FCC identification number is not visible when the module is installed inside another device, then the
outside of the device into which the module is installed must also display a label referring to the enclosed
module. This exterior label can use wording such as the following: “Contains Transmitter Module FCC ID:
2AB6Z-A18RK31 Or Contains FCC ID: 2AB6Z-A18RK31
when the module is installed inside another device, the user manual of this device must contain below
warning statements;
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired
operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment. The device is indoor use only
The devices must be installed and used in strict accordance with the manufacturer's instructions as described
in the user documentation that comes with the product
Any company of the host device which install this modular with limit modular approval should perform the test of
radiated emission and spurious emission according to FCC part 15C 15.247 and 15.209 requirement Only if the
test result comply with FCC part 15C 15.247 and 15.209 requirementthen the host can be sold legally.
