HYPERSYNES NANO Wireless BBQ Thermometer User Manual nano L
SHENZHEN HYPERSYNES CO.,LTD Wireless BBQ Thermometer nano L
Users Manual
Get to know the Device Put in the Battery
Download the APP
Enjoy your barbecue time
Power ON/OFF
WARNINGPair with your phone
Insert the device
USER
MANUAL
Power ON/OFF
Pairing Button
Battery
Cover
FOR
nano
Probe
Insert the probe into the food,
make sure the front tip of the
probe is in the center of the
food to get accurate
temperature.
DO NOT put the device
directly in fire flame.
Keep the main unit as far as possible
to fire.
The user interface of the app may be changed when update.
Please follow the instructions in the app.
Twist the battery cover counterclockwisely to unlock.
Put in batteries, make sure the side with an icon of +
is facing outside.
1
2
Twist the battery cover clockwisely to lock.
3
1
4
3
2
Search the keyword ‘easybbq’ in Appstore or Google Play,
or scan the following QR code with your phone.
Download and install it for free.
Choose food type and preference for the food where each
probe is inserted,
the app will display its current and tagert temperature.
When the food is ready, the app and the device will alarm.
Power ON:
Press and hold the power button for 3 seconds.
Power OFF:
Press and hold the power button for 3 seconds, with the LED
turning into white for 1 second.
Auto-off after 8 hours out of connection with phone.
Putting the device directly in fire flame will burn it!
The device has limited water resistence, DO NOT
wash the main unit in water!
Please clean it with a wet cloth instead.
Operation Is Subject To The Following Two Conditions:
(1) This device may not cause interference,
and (2) This device must acceptan interference,
including interference that may cause undesired
operation of this device.
App Store is a service mark of Apple Inc.
Google Play is a service mark of Google Inc.
Sensor probe
Press and hold the power button
on the device for 3 seconds to power
it on.
Keep the blue-tooth switch of your phone on.
Status Indicator
Blinking Green
Solid White
Blinking Blue
Launch the app, and follow the
instrucions in the app to pair and
activate the device:
Once Paired the device with your phone, you don’t need
to do it again, unless you change to other phones.
Press the Pairing Button (in the
back of the device);
Or, scan the bar code on the
package or on the device.
Connected successfully.
EasyBBQ app
420 C
for instantaneous test
350 C
for continual monitoring
PC (Polycarbonate)
main unit
100 C for continual monitoring
Cable
350 C for continual monitoring
Smart Wireless BBQ Thermometer
Status
Indicator
Cable
CR2032
3V
Current
Temperature
Target
Temperature
Options
Preference
Display
Temperature
History
Connection
Status
Timer
Preference
Setup
§ 15.19 Labelling requirements.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
§ 15.21 Information to user.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
§ 15.105 Information to the user.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
* RF warning for Portable device:
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
