HYUNDAI MOBIS ADCB0J3AN DISPLAY CAR SYSTEM User Manual Part 2

HYUNDAI MOBIS CO., LTD. DISPLAY CAR SYSTEM Part 2

Contents

User Manual Part 2

2-6 I Radio/Media
Features Description
Preset
Frequencies
•Shows the stored presets for user selection.
•After selecting frequency, press and hold
the preset button for more than 0.8 seconds.
A beep sound will be heard and the fre-
quency is to be stored in the selected preset
button.
Channel Logo Displays the current channel logo.
Channel Info Displays the current channel number and name.
Content Info Displays the artist, title and other information
about the current playing song.
Category Info Displays the category of the currently playing
song.
Band Changes to the desired band from among FM,
AM, and SiriusXM.
Direct Tune Used to search for the desired channel by
entering the channel number.
Scan Plays all receivable channels for 10 seconds
per item.
Category Lock If pressed, only the channels for the current cat-
egory can be searched or scanned.
Category
Selection Buttons
Used to select the previous/next category.
Play Live Switches to the live broadcast mode.
Skip Backward
Repeats the previously broadcasted program.
•Holding for less than 0.8 seconds: Moves to
the previous segment.
•Holding for more than 0.8 seconds: Moves to
the previous 5 seconds.
SiriusXM™
You can access the radio player either by pressing the
RADIO
key or by selecting the Radio menu option from All Menus on the
Home screen. Select the SiriusXM™ band from the radio player.
SiriusXM™ Mode Display Controls
i
Information
• If you press the
RADIO
key when the power is off, the power will turn
on and a radio broadcast will be tuned from the current mode.
• If you are in the SiriusXM™ mode, select the SiriusXM™ radio widget
from the Home screen to access the radio player.
• When the power is off, pressing the
RADIO
key will turn the power on
and play a SiriusXM™ Radio broadcast.
SiriusXM™ I 2-7
02
Features Description
Play/Pause Pauses/plays the current broadcasting program.
Skip/Forward Moves to the next segment.
Ta g
Saves the current music’s tag information to the
head unit. If connected to iPod, the tag informa-
tion can be saved on the device.
Presets Shows the stored presets for user selection.
SoundHound
Runs the SoundHound feature.
For more details regarding this feature, refer to the
SoundHound information in the Info section.
List
Moves to the channel list.
Menu
•What is on My Presets?
The program schedule saved in my preset. (For
more details, see Section 2.8. Viewing Menu.)
•Featured Favorites
Theme channels recommended by SiriusXM™ .
(For more details, see Section 2.8. Viewing Menu.)
•Preset Scan
Plays preset channels for 10 seconds each.
•Sound Settings
Moves to the Sound Settings.
SEEK/TRACK
•When pressed quickly (less than 0.8 seconds):
Plays the previous/next channel.
•When pressed and held (more than 0.8 sec-
onds): Continuously changes the channel until
the key is released and plays the current chan-
nel.
TUNE Changes the channel.
2-8 I Radio/Media
Selecting through
Channel/Category List
Select the
List
▶ Select the desired cat-
egory and channel.
Select the desired category and the chan-
nel. Once selected, the previous screen
will be restored and the selected channel
will begin playing.
If you select the
Skip
button, you can
scan channels using the
SEEK
TRACK
key or the
TUNE
knob by skipping the
channels that you chose to skip.
Direct Tune
Enter the number of the channel you want
to receive.
Viewing Menu
Using the
Menu
button on the right, you
can view the program schedule and infor-
mation about the Featured Favorites pro-
vided by SiriusXM™ .
Before Using the Bluetooth® Handsfree
Bluetooth Connection
Bluetooth Phone
part.3 Bluetooth
3-2 I Bluetooth
Before Using the Bluetooth
®
Handsfree
What is
Bluetooth
®
Wireless Technology?
•
Bluetooth
® Wireless Technology refers
to a short-distance wireless network-
ing technology which uses a 2.45GHz
frequency to connect various devices
within a certain distance.
•Supported within PCs, external devices,
Bluetooth® phones, PDAs, various elec-
tronic devices, and automotive environ-
ments,
Bluetooth®
Wireless Technology
to be transmitted at high speeds without
having to use a connector cable.
•Bluetooth® Handsfree refers to a device
which allows the user to conveniently
make phone calls with Bluetooth®
mobile phones through the Multimedia
system.
•The Bluetooth® Handsfree feature may
not be supported in some mobile phones.
For more information on mobile phone
compatibility, visit the HYUNDAI website
- HYUNDAI Motor America: https://www.
hyundaiusa.com/bluetooth
WARNING
- Distracted Driving
• Focus on the road while driving. The driver's
primary responsibility is in the safe and
legal operation of the vehicle. Drivers should
not use any hand held devices or other
equipment or vehicle systems that distract the
driver during vehicle operation.
• Do not stare at the multimedia screen for long
periods of time while driving. Staring at the
screen for prolonged periods of time can lead
to traffic accidents and can result in personal
injuries.
Precautions for Safe Driving
•Bluetooth® is a feature that enables driv-
ers to make handsfree calls. Connecting
the head unit with a Bluetooth® phone
allows the user to conveniently make
calls, receive calls, and manage the
phonebook. Before using
Bluetooth®
Wireless Technology, carefully read the
contents of this user’s manual.
•Excessive use or operations while driv-
ing may lead to negligent driving prac-
tices and be the cause of accidents. Do
not operate the device excessively while
driving.
•Viewing the screen for prolonged peri-
ods of time is dangerous and may lead
to accidents. When driving, view the
screen only for short periods of time.
Bluetooth
Before Using the Bluetooth
®
Handsfree I 3-3
03
CAUTIONS upon Connecting
Bluetooth® Phone
•Before connecting the head unit with
the mobile phone, check to see that the
mobile phone supports Bluetooth® fea-
tures
•Even if the phone supports
Bluetooth®
Wireless Technology, the phone will
not be found during device searches if
the phone has been set to hidden state
or the Bluetooth® power is turned off.
Disable the hidden state or turn on the
Bluetooth® power prior to searching/
connecting with the head unit.
•If Auto Connection is used, the
Bluetooth® phone is automatically con-
nected when the ignition is turned on,
making it unnecessary to have to con-
nect the phone with the head unit every
time.
•If you do not want automatic connection
with your Bluetooth® device, turn the
Bluetooth® feature off of the Bluetooth®
device.
•Park the vehicle when connecting the
head unit with the mobile phone.
•Bluetooth® connection may become
intermittently disconnected in some
mobile phones. Follow these steps to
try again.
1. Turn the Bluetooth® function within
the mobile phone OFF/ON and try
again.
2. Turn the mobile phone power OFF/
ON and try again.
3. Completely remove the mobile
phone battery, reboot, and then
again.
4. Reboot the Multimedia System and
try again.
5. Delete all paired devices from both
of Phone and Head Unit sides and
then try again
•The Handsfree call volume and quality
may differ depending on the mobile
phone.
•Pairing Bluetooth® devices and use of
other Bluetooth® features are not sup-
ported when the vehicle is in motion. For
safety, please first park your vehicle.
•If you continue having issue download-
ing your contacts to your vehicle, con-
tact your mobile phone provider.
3-4 I Bluetooth
Bluetooth Connection
Pairing a New Device
Before you can use the Bluetooth feature,
you must first pair/connect your mobile
phone to your car.
Up to 5 Bluetooth devices can be paired.
Only one Bluetooth device can be con-
nected at a time.
Pairing a New Device by Selecting
Phone/Call
Press the
PHONE
key or key in
the steering wheel remote control. ▶ Pair
your car after your mobile phone detects
the Bluetooth device. ▶ Enter the passkey
or accept the authorization popup. ▶
Connect Bluetooth.
Pairing a New Device Through the
Phone Settings
Press the
SETUP
key. ▶ Select
Bluetooth
.
▶Select
Bluetooth Connection
. ▶ Select
Add New
. ▶ Pair your car after your
mobile phone detects the Bluetooth
device. ▶ Enter the passkey or accept
the authorization popup. ▶ Connect
Bluetooth.
The default passkey is 0000.
The vehicle name above is an example.
Check the actual information on the product.
Connecting Bluetooth Devices
Connects the Bluetooth devices that you
add.
Connecting Devices by Selecting
Phone/Call
Press the
PHONE
key or key in
the steering wheel remote control. ▶
Select the name of the device to connect.
▶Connect Bluetooth.
Bluetooth Connection I 3-5
03
Connecting Devices Through the
Phone Settings
Press the
SETUP
key. ▶ Select
Bluetooth
. ▶
Select
Bluetooth Connection
. ▶ Select the
name of the device to connect. ▶ Connect
Bluetooth.
Disconnecting
Bluetooth Devices
Disconnects Bluetooth devices that are
connected.
Press the
SETUP
key. ▶ Select
Bluetooth
. ▶
Select
Bluetooth Connection
. ▶ Select the
name of the device to disconnect.
Deleting Bluetooth Devices
Deletes the Bluetooth devices that you
added. Note that deleting a Bluetooth
device will delete all Call History and
Contact Info downloaded along with it.
Press the
SETUP
key. ▶ Select
Bluetooth
. ▶
Select
Bluetooth Connection
. ▶ Select
Delete Devices
. ▶ Select the device name to
delete. ▶ Select
Delete
.
Setup
Sound Settings
Display Settings
Bluetooth Settings
Blue Link Settings (For Blue Link Model)
Home Screen Settings
Wi-Fi Settings
Clock Settings
Voice Recognition Settings
Language Settings
Keyboard Settings
Screen Saver Settings
System Info
part.8 Setup
8-2 I Setup
Setup
Setup
Setup is the screen to control Audio sys-
tem settings.
To enter the screen, press the
SETUP
key or the
Setup
icon in All Menus.
Features Description
Sound
Provides the sound
control options for Position,
Bass, Mid, Treble, Volume
and Advanced settings.
Display Provides the Mode/
Illumination settings.
Bluetooth
Provides the Bluetooth
Connection/Auto
Connection Priority/
Bluetooth System
Information settings.
Blue Link
Provides the Activation/
Modem Information settings.
(For Blue Link Model)
Connectivity
For more details, refer to
Connectivity guide.
Home
Screen
Provides the function to cus-
tomize the three menu items
at the bottom of the Home
Screen.
Features Description
Wi-Fi
Provides the Wi-Fi On and
Network Connection set-
tings. (optional)
Clock Provides the Time and View
settings.
Voice
Recognition
Provides the Guidance and
Priority settings.
Language Provides the Change
Language settings.
Keyboard Provides settings to switch
keyboard layouts.
Screen
Saver
Provides the Clock/None
settings.
System
Info
Provides software and stor-
age space information.
Display Off Provides the Display Off
(touch activation) function.
Setup I 8-3
08
Sound Settings
Adjusts the sound effects for the whole
system.
i
Information
• Advanced sound settings may differ according
to selected AMP option.
• The seat shape may differ according to
vehicle model.
Display Settings
Adjusts the level of illumination for the
entire system.
Features Description
Mode
Select any of LCD illumi-
nation change modes:
Automatic (changes
the level automatically),
Daylight, and Night.
Illumination
Set the levels of illumina-
tion for day and night.
Select
Default
to initialize
the settings.
Default Resets the display to fac-
tory default settings
Display Off Provides the Display Off
(touch activation) function.
Features Description
Position
Select the Up/Down/Left/
Right button to control
sound positioning.
Select
Center
to concen-
trate the sound on the
center of vehicle.
Tone
Drag the slide bar to
control bass/mid/treble
settings.
Select
Center
to initialize
the settings.
Features Description
Advanced
Select additional audio
options such as “Speed
Dependent Volume
Control” that automatically
controls Audio volume
according to vehicle
speed as well as “Variable
EQ”.
Default Resets the sound to fac-
tory default settings.
Beep Select to activate a beep
when pressing buttons.
8-4 I Setup
Bluetooth Settings
Changes Bluetooth phone settings.
Bluetooth Settings
Press the
SETUP
key ▶ Select
icon.
Bluetooth Connection Settings
Press the
SETUP
key ▶ Select
▶Select
Bluetooth Connection
Features Description
Paired Device
List
Displays the paired
Bluetooth device list.
When selecting from
the list, the device is
connected or discon-
nected.
Bluetooth
Audio
Connection
Status
An icon appears when
you make a Bluetooth
Audio connection.
Bluetooth
Hands-Free
Connection
Status
An icon appears when
you make a Bluetooth
Hands-free connec-
tion.
Add New Register a new
Bluetooth device.
Delete Devices Select and delete a
paired device.
Help
Switches to the
Bluetooth Connection
Help screen.

Navigation menu
