Important Safety Instructions
CONDENSATION:
Moisture will form in the operating section of the unit if the unit
is brought from cool surroundings into a warm room or if the
temperature of the room rises suddenly. When this happens,
unit's performance will be impaired. To prevent this, let the
unit stand in its new surroundings for about an hour before
switching it on, or make sure that the room temperature rises
gradually.
Condensation may also form during the summer if the unit is
exposed to the breeze from an air conditioner. In such cases,
change the location of the unit.
HOW TO HANDLE THE LCD PANEL:
Do not press hard or jolt the LCD panel. It may cause the
LCD panel glass to break and injury may occur. If the LCD
panel is broken, make absolutely sure that you do not touch
the liquid in the panel. This may cause skin inflammation.
If the liquid gets in your mouth, immediately gargle and
consult with your doctor. Also, if the liquid gets in your eyes
or touches your skin, consult with your doctor after rinsing for
at least 15 minutes or longer in clean water.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used,
use caution when moving the cart/
apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
15. To reduce the risk of fire or electric shock, do not expose
this apparatus to rain or moisture. The apparatus shall
not be exposed to dripping or splashing and that objects
filled with liquids, such as vases, shall not be placed on
apparatus.
16. This equipment is a Class II or double insulated electrical
appliance. It has been designed in such a way that it does
not require a safety connection to electrical earth.
17. To prevent injury, this apparatus must be securely attached
to the wall in accordance with the installation instructions.
18. The MAINS plug used as the disconnect device. The
disconnect device shall remain readily operable.
19. Keep your TV away from moisture. Do not expose your TV
to rain or moisture. If water penetrates into your TV, unplug
the power cord and contact your dealer. Continuous use in
this case may result in fire or electric shock.
20. Do not expose batteries to excessive heat such as
sunshine, fire or the like.
21. Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
22. Apparatus shall not be exposed to dripping or splashing and
no objects filled with liquids, such as vases, shall be placed
on the apparatus.
The lightning flash with arrowhead symbol, within an
equilateral triangle is intended to alert the user to the
presence of uninsulated dangerous voltage within the
product's enclosure that may be of sufcient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
III
Important Safety Instructions
POSSIBLE ADVERSE EFFECTS ON LCD PANEL:
If a fixed (non-moving) pattern remains on the LCD Panel
for long periods of time, the image can become permanently
engrained in the LCD Panel and cause subtle but permanent
ghost images. This type of damage is NOT COVERED BY
YOUR WARRANTY. Never leave your LCD Panel on for long
periods of time while it is displaying the following formats or
images:
Fixed Images, such as stock tickers, video game patterns, TV
station logos, and websites.
Special Formats that do not use the entire screen. For
example, viewing letterbox style (16:9) media on a normal
(4:3) display (black bars at top and bottom of screen); or
viewing normal style (4:3) media on a widescreen (16:9)
display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction
but technical limitation. Therefore we disclaim any
responsibility for these symptoms.
LCD Panels are manufactured using an extremely high level
of precision technology, however sometimes parts of the
screen may be missing picture elements or have luminous
spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic equipment that
produces electromagnetic waves. Some equipment placed
too near this unit may cause interference.
Effect on infrared devices - There may be interference while
using infrared devices such as infrared cordless headphones.
End of life directives
Your TV also contains material that can be recycled and
reused. For disposal or recycling information, contact your
local authorities or the Electronic Industries Alliance at
www.eia.org (for USA), the Electronic Products Recycling
Association at http://www.eprassociation.ca (for Canada) to find
a recycler in your area.
Non-active pixels
The LCD panel contains almost 3 million thin film transistors,
which provide exceptionally sharp video quality. Occasionally,
a few non-active pixels may appear on the screen as a
fixed black (in the case of a dead pixel), blue, green, or red
point. These non-active pixels do not adversely affect the
performance of your TV, and are not considered defects.
Power source
WARNING
• Do not use a different power supply cord to plug the TV into
an AC outlet. Using a power cord that did not already come
with the TV could cause a fire, electrical shock or damage.
• Do not use a power voltage that is different than what the
manufacturer has already specified. This could cause a fire,
electrical shock or damage.
• If you do not plan to use this TV for a long time (due to a
lengthy trip or some other reason) then be sure to unplug it
from the AC outlet.
• Do not plug or unplug the AC cord when your hands are wet.
This may cause electrical shock.
• If an outside antenna or cable system is connected with the
TV, be sure the antenna or cable system is grounded so as to
provide protection against voltage surges and built-up static
charges.
No naked flame sources, such as lighted candles, should
be placed on the apparatus.
The WiFi Module complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This device
should be installed and operated with a minimum distance
of 20 centimeters between the radiator and your body. (only
applicable for Smart TV built-in wireless)
FCC RF Safety Caution Statement
This equipment complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment. This equipment
must be installed and operated in accordance with provided
instructions and must not be co-located or operating in
conjunction with any other antenna or transmitter. End-users
and installers must be provided with antenna installation
instructions and transmitter operating conditions for satisfying
RF exposure compliance.
RF Exposure Statement for Canada
The radiated output power of the Wireless Device is below
the Industry Canada (IC) radio frequency exposure limits. The
Wireless Device should be used in such a manner such that
the potential for human contact during normal operation is
minimized.
La puissance de sortie émise par l’appareil de sans fil Dell est
inférieure à la limite d'exposition aux fréquences radio d'Industry
Canada (IC). Utilisez l’appareil de sans fil Dell de façon à
minimiser les contacts humains lors du fonctionnement normal.
(only applicable for TV with RF port)
WARNING
Never place a television set in an unstable location. A television
set may fall, causing serious personal injury or death. Many
injuries, particularly to children, can be avoided by taking
simple precautions such as:
– Using cabinets or stands recommended by the manufacturer
of the television set.
– Only using furniture that can safely support the television set.
– Ensuring the television set is not overhanging the edge of the
supporting furniture.
– Not placing the television set on tall furniture (for example,
cupboards or bookcases) without anchoring both the furniture
and the television set to a suitable support.
IV
Important Safety Instructions
– Not placing the television set on cloth or other materials that
may be located between the television set and supporting
furniture.
– Educating children about the dangers of climbing on furniture
to reach the television set or its controls.
If your existing television set is being retained and relocated,
the same considerations as above should be applied.
Buy and install low-cost anchoring
devices to prevent TVs, dressers,
bookcases or other furniture from
tipping.
Attaching a Wall Mount or Stand to the TV
Make sure that your TV has adequate air circulation. Allow
enough space around the TV as shown below. Avoid operating
the TV at temperatures below 41°F(5°C).
WARNINGS:
• When you mount your TV on the wall or place it on furniture,
maintain a distance of at least 4 inches between the TV and
other objects (walls, cabinet sides, and so on) to ensure
proper ventilation. Failing to maintain proper ventilation may
cause the TV to overheat.
• Do not mount the TV at more then a 12 degree tilt.
• Do not use screws that differ from the length and diameter
that we have recommended (See the Instruction Manual or
Quick Start Guide).
• Do not fasten the screws too firmly. This may damage the TV
or cause it to fall, leading to personal injury. The manufacturer
is not liable for these kinds of accidents.
• Be careful when you touch the TV. Some parts may be warm
or hot.
• Do not place any type of fabric or papers underneath, on top
of, or beside the TV. This can block ventilation and cause a
fire.
• For detailed information about installing the wall mount
bracket, see the third-party manufacturer's instructions or
contact a professional installer for assistance.
• Do not operate or handle the TV with wet hands.
• Never place a television set in an unstable location. A
television set may fall, causing serious personal injury or
death.
Many injuries, particularly to children, can be avoided by
taking simple precautions such as:
– Using cabinets or stands recommended by the manufacturer
of the television set.
– Only using furniture that can safely support the television
set.
– Ensuring the television set is not overhanging the edge of
the supporting furniture.
– Not placing the television set on tall furniture (for example,
cupboards or bookcases) without anchoring both the furniture
and the television set to a suitable support.
– Not placing the television set on cloth or other material that
may be located between the television set and supporting
furniture.
– Educating children about the dangers of climbing on
furniture to reach the television set or its controls.
• If your existing television set is being retained and relocated,
the same considerations as above should be applied.
Correct way to attach a TV stand
Never install the TV set as follows:
Correct way to attach on the wall
Leave at least this much
space around the set.
Leave at least this much
space around the set.
4 inches
(10cm)
4 inches
(10cm) 4 inches
(10cm)
4 inches
(10cm)
4 inches
(10cm)
2 3⁄8 inches
(6cm)
12 inches
(30cm) 12 inches
(30cm)
Wall Wall
Air circulation is blocked.
Inadequate air circulation can cause the TV to
overheat.
1
Table of Contents
Shortcuts Instructions .....................................................................................................................2
Completing the First-Time Setup Menu ..........................................................................................3
Basic and Advanced TV Settings ...................................................................................................5
Accessing the Quick Setup Menu ................................................................................................................ 5
Picture Menu ................................................................................................................................................5
Sound Menu ................................................................................................................................................6
Channel Menu .............................................................................................................................................6
Network Menu .............................................................................................................................................6
System Menu ............................................................................................................................................... 7
About TV Menu ........................................................................................................................................... 8
Parental Controls .............................................................................................................................9
Getting familiar with the Home screen .........................................................................................11
Live TV .......................................................................................................................................... 12
Viewing channel information ......................................................................................................................12
Viewing a channel list ................................................................................................................................12
Creating a Favorites list ...........................................................................................................................12
Viewing your Favorites list ........................................................................................................................12
VOD ................................................................................................................................................. 13
Media .............................................................................................................................................. 14
Panels that appear on the Media screen ...................................................................................................14
File formats that may be supported ...........................................................................................................14
Viewing Videos ..........................................................................................................................................14
Browsing Content ......................................................................................................................................14
Viewing Pictures as a Slideshow ...............................................................................................................14
Apps ................................................................................................................................................ 15
Mirroring content from your device to the TV ........................................................................... 18
Software updates for your TV ..................................................................................................... 19
Quick Problem-Solving Tips ......................................................................................................... 20
2
Shortcuts Instructions
Shortcuts Instructions
You can use shortcuts on the remote control for fast operation. For more information about your TV remote, refer to the Quick Start
Guide in accessories.
Turning your TV on or off
To turn your TV on:
1. Connect the power cord to the back of the TV, then plug the power cord into an AC outlet.
2. When the TV is powered on, press the [ ] button on the remote to turn TV.
To turn your TV off, press the [ ] button on the remote.
NOTES
• When your TV is in standby mode, it is still consuming power. To completely disconnect power, please remove the plug from the
AC outlet.
• If your TV does not receive an input signal for several minutes, it automatically goes into standby mode
Selecting the Input Source
Select the Input Source depending on the video device you have connected to your TV.
To select the input source:
1. Turn on your TV, then press the [INPUT] button on the remote, the list of Source appears.
2. Press the [< / >] buttons to select the input source.
3. Press the [OK] button to confirm your selection.
Using the Live TV
To view broadcast programs, press the [Live TV] button on your remote.
Channel search guide
When you select TV as input, if no TV channels were saved before, you will be prompted to do a channel search. Before channel
tuning could start, you must specify the tune mode, Antenna or Cable. You can also go to Setting menu > Channel to change the
channel settings.
Launch Live TV
After channel tuning is done for the first time, the screen will display Live TV operating tips, including: how to start the channel list,
how to start channel info and so on.
[OK] Show channel list
[
v
] View channel info
[Back] View recent channels
View channel info
PRE-CH
Show channel list
3
Completing the First-Time Setup Menu
Now that you have attached the TV stand and connected your external devices, it's time to complete the first-time setup menu.
Completing the First-Time Setup Menu
Press the [Power] button on the remote to turn on the TV.
A splash screen that shows the RCA logo appears. Next, the First-Time Setup Menu begins by prompting you to choose your
Language, Country, and Time Zone. After the splash screen that displays the RCA logo appears, begin the first-time setup menu.
Screen Task
Language and Location
LANGUAGE AND LOCATION
Language
Language ModeTerms Network Input Done
English United State Select
Country Time Zone
1. Using the D-pad arrows of your remote, choose
your Language, Country and Time Zone.
2. Next, navigate to the Forward arrow and press [OK].
TIP: The edge of the drop-down boxes and the back and
forward arrows change to blue when you select them.
Terms of Service
TERMS OF SERVICE
Accept all
Accept EULA
Accept Terms of Serv...
Language ModeTerms Network Input Done
The EULA and Terms must be accepted in
order to continue.
1. Press [OK] on your remote to select Accept All.
2. When you’re done, then navigate to the Forward arrow and
press [OK].
TV Usage Mode
TV USAGE MODE
TV Mode
Home
Language
Home Mode
In Home Mode, your TV will automatically adjust the
brightness of your screen based on the ambient light in
the room.
ModeTerms Network Input Done
Select Home (which appears by default) and then navigate to the
Forward arrow to press [OK].
Note: ‘Store mode’ should only be selected by Retailers who plan
to demonstrate the TV.
Disclaimer: Images throughout this document are for illustrative purposes only and may differ from the actual product.
4
Completing the First-Time Setup Menu
Screen Task
Network Connection
NETWORK CONNECTION
Language Terms
Ethernet
Connecting Ethernet
Configure
WiFi
Mode Network Input Done
If your TV does not automatically detect an Ethernet con-
nection, then select Wi-Fi. When you’re done, select your
network from the list that displays and move to the next
screen.
TV Input Source
REMOTE BUTTON SETUP
TV AV COMPONENT
HDMI 4HDMI 3HDMI 2HDMI 1
NetworkInput DoneModeTermsLanguage
Select how you receive your TV channels. Choose
from one of the following sources below and then move
to the next screen.
• TV
• AV
• Component
• HDMI
NOTE: If you use an antenna to receive channels,
then you must complete the rst-time setup menu in
order to run a channel scan.
Congratulations! Your TV is now ready to use.
Press [OK] on your remote if you are fine with the selections that appear on the screen. Otherwise, navigate
to the back arrow on the screen to change your selection.
First-time Setup Menu (continued)
CONGRATULATIONS !
Your TV is now ready to use
TV Selections
English United States Eastern Home Mode Ethernet TV
OK
Language Terms Mode Network Input Done
5
Basic and Advanced TV Settings
Your RCA TV comes with many TV setting features to allow you to customize the picture based on your viewing preference and
environment. As you navigate throughout different screens to access settings, some of the indicators appear as words ‘On’ and ‘Off’
and some are open [o] and closed [I] symbols. An [o] indicator signifies a feature that is disabled.
Accessing the Quick Setup Menu
You can press the [Quick Setup] menu button [ ] and press the right arrow on the D-pad to view the full menu settings.
The Settings menu consists of the following settings:
• Picture
• Sound
• Channel
• Network
• System
• About TV
Picture Menu
If you’d like to configure the settings for your picture, then there are six types of picture
modes available: Vivid, Standard, Theater, Energy Saving, Game and Sport.
Once you choose the mode, you can adjust the picture based on the following settings:
Brightness: Adjust the Brightness level to generate lighter or darker images.
Contrast: Adjust the Contrast level to increase or decrease how bright images appear.
Color: Adjust the color intensity of the picture for a more vibrant image.
Aspect Ratio: Adjust the Aspect Ratio to stretch or zoom in on your picture. You can
choose from the following settings: Normal, Zoom, Wide, Cinema, 1:1 PLXEL MAP,
Panoramic, Direct or Auto.
Backlight: This TV has a Dynamic Backlight Control setting that you can turn off
and set to high or low. The Backlight setting enables you to adjust how bright you
want images to appear. In addition, an Eco Sensor setting is available that will enable
the TV to automatically adjust the picture settings according to the amount of ambient
light in your room. The Minimum Backlight setting enables you to adjust the lower
point of the dynamic backlight adjustment scope. This is a money-saving feature
because it reduces power consumption.
Advanced Picture Settings: Adjust advanced picture settings based on your viewing
preference.
• Display: Adjust advanced picture settings in the component source.
• OverScan: Disable the overscan for PC inputs to fully display all menu items at the
edges of the screen.
• Tint: Adjust the colors from a green to magenta tint to view the natural skin tones of
people on the screen.
• Sharpness: Adjust how sharp or soft edges of images appear.
• Noise Reduction: Improve how clear the picture appears by reducing noise.
• Adaptive Contrast: Automatically darken dark areas and lighten light areas of
images to see more details.
• Color Temperature: Select a preset color temperature.
• White Balance: Adjust the intensity of red, green and blue lights to view the true
colors of all images in the picture.
• Color Tuner: Adjust the Hue, Saturation and Brightness of color settings.
Restore Default Picture Settings: Restore all the picture settings in the current
picture mode to the factory default values.
Settings
Sound
Channel
Network
System
About TV
Picture Mode
Standard
Brightness
50
Contrast
50
Color
50
Aspect Ratio
Auto
Backlight
Advanced Picture Settings
Restore Default Picture Settings
6
Sound Menu
Sound Mode: Select a preset sound mode to suit the type of content you are listening
to: Standard, Theater, Music, Speech and Late Night.
Set the sound effects to suit your preference:
Configure your audio settings for your sound preferences. Once you choose the mode,
you can adjust the audio based on the following settings:
Advanced Audio Settings: Tune the audio settings and quality of the TV.
• Equalizer: Boost the volume at different frequencies.
• Lip Sync: Synchronize the displayed image with the audio output.
• Balance: Adjust the left and right speaker strength to optimize audio for a specific
location.
• Digital Audio Out: Select the digital audio output format that best suits the audio
device type. For example, choose RAW (which is uncompressed audio in RAW form)
if you have 5.1 Channel Surround Sound Speaker set up. Choose PCM if you have
an amplifier that does not support Dolby Digital technology.
• Digital Audio Delay: Adjust the digital audio output delay time to sync sound from
an external speaker with the images on the TV.
• TV Speaker & ARC: Select the TV speaker or an external speaker for sound output.
• Audio Out: Change the way audio is sent through the type of device that’s
connected to your TV Audio Out port.
Restore Default Audio settings: Restore all of the audio settings in current audio
mode to the factory default values.
Channel Menu
Tuner Mode: Select Tuner Mode if you receive TV channels over the air (antenna) or
directly through a cable connection without using a set top box. The input will be used
during a channel scan.
Auto Channel Scan: Automatically scan for channels to view programming from your
TV source.
Channel Skip: Skip a channel that your TV picked up during a previous channel scan
search.
Favorites List: Quickly access your most-watched channels by creating a Favorites
list.
Network Menu
Network Configuration: Set up the network to gain full access of Smart TV features.
• Connection Type: Ethernet
Choose a wired network connection to access the Internet.
• Ethernet: Display the network connection status.
• IP Setting Mode: Configure the IP setting for your network connection.
• Connection Type: Wireless
Choose a wireless network connection to access the Internet.
• Advanced Settings: Configure the advanced wireless network settings for the TV.
• Available Networks: Select an available network to connect. And you can also add
wireless network or refresh wireless network.
• Connection Type: Off
Turn off the Internet connection.
Network Information: View information about your network connection.
Anyview Stream: Share video, music or other content files from another device to
your TV screen.
Basic and Advanced TV Settings
Settings
Sound
Channel
Network
System
About TV
Sound Mode
Standard
Advanced Audio Settings
Restore Default Audio settings
Settings
Sound
Channel
Network
System
About TV
Tuner Mode
Antenna
Auto Channel Scan
Channel Skip
Favorites List
Settings
Sound
Channel
Network
System
About TV
Network Conguration
Network Information
Disconnected
Anyview Stream
On
TV Name
Smart TV
7
TV Name: Choose a name for your TV. The name will be shown to devices that are
available for sharing data.
System Menu
Location: Choose the location from where you will watch your TV.
Time: Set the current time based on your location.
• Time Zone: Select your time zone: Eastern, Indiana, Central, Mountain, Arizona,
Pacific, Alaska and Hawaii.
• Time Format: Set the time to display in a 12 or 24-hour format.
• Daylight Savings: Select whether to apply Daylight Savings Time to the TV.
• Date/Time: Set the Date and Time.
• Power On Timer: Enable the Power On Timer to Off, Once or Daily.
• Power Off Timer: Enable the Sleep Timer to Off, Once or Daily.
• Sleep Timer: Set the sleep timer to automatically turn the TV Off within a specified
time: Off, 10 Minutes, 20 Minutes, 30 Minutes, 40 Minutes, 50 Minutes, 60 Minutes,
90 Minutes and 120 Minutes.
Language: Adjust the default language settings for the TV.
Parental Controls: Turn On Parental Controls to block children from being able to
view certain programs. The default password is 0000.
• Locks: Enable or disables all locks. All selected locks can be turned off for parental
viewing and easily turned on again.
• Block Time: Block certain channels and programs during certain periods of time.
• Channel Block: Block programs by channels when you turn On the Parental
Controls feature.
• Program Block: Blocks programs according to their TV or MPAA (movie) rating
when you have turned on the Parental Controls feature and selected that rating to be
blocked.
• Input Block : Block content from devices that are connected to certain TV ports.
• Change PIN: Change your PIN that you use to access Parental Controls. If you want
to change your parental control password, first enter the new password then enter
the same password again.
NOTE
If you forget your password, call the RCA Consumer Electronics Care Center or
reset your TV back to the factory settings.
• Restore Parental Control Defaults: Restore Parental Control back to the factory
default setting.
Application Settings: Set settings for apps on your TV.
• Netflix : Remove this TV from your Netflix account. Please contact Netflix if you
want to stop being billed for you service.
• ESN : Display the Netflix Electronic Serial Number.
• VUDU : Remove this TV from your VUDU account. Please contact VUDU if you want
to stop being billed for you service.
Closed Caption: Adjust Closed Captioning settings.
• Analog Caption: Select an Analog Caption setting from Off, CC1-CC4, Text
1-TEXT4.
Off: To turn off the Analog Caption.
CC1-CC4: Closed captioning appears in a small banner across the bottom of the
screen. CC1 is usually the “printed” version of the audio.
Basic and Advanced TV Settings
Settings
Sound
Channel
Network
System
About TV
Location
USA
Time
Language
Closed Caption
Parental Controls
HDMI Function
Application Settings
Advanced Settings
8
CC2-CC4 display content are provided by the broadcaster.Text1-Text4: Closed
captioning that covers half or all of the screen. Text1-Text4 display content are
provided by the broadcaster.
• Digital Caption: Select a Digital Caption setting: Off,CS1-CS6.
• Digital CC Settings: There are two caption styles. One is the automatic function
set as the broadcaster, while the other is the custom style where you can adjust the
Style, Size, Font, Text Color, Text Opacity, Background Color etc.
HDMI Function : Configure how to control CEC-enabled devices with your TV remote.
• CEC & MHL Control: Allow HDMI devices to control each other.
• Device Auto Power Off: Automatically turn off HDMI CEC devices when the TV is
turned off .
• TV Auto Power On: Allow the TV to turn On with CEC-enabled devices.
• Device Connect: Allow CEC-enabled devices to communicate with each other
when connected through an HDMI cable.
• CEC Device Lists: View a list of all CEC-enabled devices.
NOTE
HDMI cables must be used to connect HDMI CEC-compatible devices to your TV.
The HDMI CEC feature of the connected device must be turned on.
If you connect an HDMI device that is not HDMI CEC-compatible, all the HDMI-CEC
Control features do not work.
Depending on the connected HDMI device, the HDMI-CEC Control feature may not
work.
Advanced Settings: Access the Advanced Settings menu.
• Menu Timeout : Set the amount of time that you’d like for the menu to display : Off,
10s, 20s , 30s or 60s.
• Use Mode: Set the TV to use in Home or Store Mode.
• Input Labels: Edit the input labels.
• Default LiveTV Source: Select the default input selected by the remote control Live
TV button.
• Setup Wizard: Use the Setup Wizard for instructions to help you set up your TV.
• Power Indicator: Set the Power Indicator light to stay On or Off when watching TV.
About TV Menu
About TV
• SystemInformation: View system information.
• LegalDisclaimer: Read the Legal Disclaimer.
• AutoFirmwareUpgrade: Set your TV to automatically receive the latest firmware.
• CheckFirmwareUpgrade: Check to ensure that your TV has received the latest
firmware.
• RestoreToFactoryDefault: Restore your TV back to the factory default.
Basic and Advanced TV Settings
Settings
Sound
Channel
Network
System
About TV
System Information
Legal Disclaimer
Auto Firmware Upgrade
On
Check Firmware Upgrade
Restore To Factory Default
9
Parental Controls
The Parental Controls setting allows you to block content that is not appropriate for children to watch. You can do this by creating
a 4-digit passcode. The factory-default passcode is 0000.
Turning Parental Controls 'On'
To access Parental Controls:
1. Press the [Quick Setup] menu button on your remote.
2. Press the right arrow button to display the full menu settings.
3. Select System > Parental Controls.
4. Press [OK] on your remote.
An Enter PIN window displays.
Using the numerical keypad on your remote, enter the factory-default passcode 0000 and press [OK].
Press the right arrow button on the D-pad to turn the locks 'On'.
You will see the other Parental Control settings change from a greyed out state and become highlighted. When this occurs, begin
adding other settings to the Block Time, Channel Block, Program Block, Input Block, Change PIN or Restore Parental Control
Defaults features.
All ratings that are higher than those you select are also blocked. For example, if you choose to block the PG-13 rating, then the
higher ratings (R and NC-17) are automatically blocked too.
Channel Block
Block programs by channels when you turn on the Parental Controls feature.
Block Time
Choose a time of day that you'd like to start blocking certain programs.
Program Block
Block programs according to their TV or MPAA (movie) rating when you have turned on the Parental Controls feature and selected
that rating to be blocked.
Input Block
Block content from devices that are connected to certain TV ports.
Change PIN
Change your PIN that you use to access Parental Controls.
Restore Parental Control defaults
Restore Parental Controls back to the factory setting.
Parental Controls
NOTE
10
Description of U.S. TV Ratings
Description of Age-based Ratings
U.S. Movie Ratings
Content Defined as
AAll
DSuggestive dialog
LCoarse or crude language
SSexual situations
VViolence
FV Fantasy Violence
TV-Y All children
TV-Y7 Directed to older children
TV-G General audience
TV-PG Parental Guidance Suggested
TV-14 Parents strongly cautioned
TV-MA Mature Audiences Only
Rating Defined as
GGeneral audience
PG Parental Guidance suggested
PG-13 Parents strongly cautioned
RRestricted
NC-17 No one 17 and under permitted
XA rating that has now been superseded by NC-17
Canadian English Ratings
Canadian French Ratings
If you forget your passcode, call the RCA Consumer Electronics Care Center or choose Restore Parental Control defaults
from the Parental Controls settings menu.
Rating Defined as
CChildren
C8+ Children 8 years and older
GGeneral programming that is suitable for all audiences
PG Parental Guidance
14+ Viewers 14 years and older
18+ Adult Programming
Rating Defined as
GGeneral (appropriate for all ages and must contain little to no violence or sexual content)
8ans+ General but inadvisable for young children(could contain scenes disturbing to children under eight).
Recommended for viewing with parent.
13ans+ Programming is appropriate for children 13 and older and may contain moderate violence, language
and some sexual situations.
16ans+ Recommended for children 16 and older and may contain strong violence, language and sexual
content.
18ans+ Programming intended for viewers that are 18 and older. Programming may contain extreme violence
and graphic sexual content/pornography.
Parental Controls
NOTE
11
Getting familiar with the Home screen
The simple design of the Home screen menu makes it easy to navigate. It serves as the central location to access Live TV, VOD,
Media or Apps and inputs on the back of the TV that you've connected external devices to.
To access the Home screen, press the [Home] button on your remote control and use the arrows on the D-pad to make your
selection.
Indicators and Icons on the top of the Home screen
You can always view the current time in the top right corner of the Home screen.
If your TV is connected to the Internet through a wireless connection, then an icon will display in the top right corner of the
screen. This location makes it very convenient for you to determine if you still have Internet connectivity as you use the TV.
In addition, if you have connected a device (such as a thumb drive) to a USB port and your TV recognizes it, then a device icon will
also display in the same area.
No Signal
COMPONENT
LiveTVVOD Media Apps
HDMI 1
AV
TV
COMPONENT
11:42 63°F
Figure 1. Home screen
Names of icon images that appear on the side of the Home screen
The following icon names represent the inputs on the back of the TV:
• TV
• AV
• Component
• HDMI 1
• HDMI 2
• HDMI 3
• HDMI 4
Each time you access the Home screen, the icons for your inputs will display on the right side of the screen. Inputs that you have
connected an external device to will be highlighted. Inputs that do not have an external device connected to are greyed out.
Names of icon images that appear on the bottom of the Home screen
The bottom of the Home screen displays the following icon names:
• Live TV
• VOD
• Media
• Apps
Getting familiar with the Home screen
12
Live TV
LiveTV
To view broadcast programs, select the Live TV icon on the screen or press the [Live TV] button on your remote.
Viewing Channel information
As you use the [Channel] button on your remote to scroll through channels, an information banner appears on the top of the screen.
2 3 4
9
10 11
51
68
7
Figure 2. Information banner
The information banner displays the following information:
• Channel number (1)
• Lock status (2)
• Input (3)
• Start/Stop time progress bar of the current program (4)
• Show identification (5)
• Television Network identifier (6)
• Current date and time (7)
• Prompt (8)
• Beginning and end time of the next program (9)
• Program name (10)
• More info (11)
If you are watching a particular channel, you can also press the up arrow on the [D-pad] of your remote to view channel information.
Viewing a channel list
After you have done an automatic channel scan (if you're using an Antenna) or are receiving your channels through a cable provider,
you can view your list of channels by pressing [OK] on your remote.
You will see the channel list display on the right side of the screen.
Creating a 'Favorites' list
To quickly access your most-watched channels, you can create a 'Favorites' list.
To create your 'Favorites' list:
1. Press the [Quick Setup] menu button on your remote.
2. Select Channel> Favorites List
3. Using the up/down arrows on the [D-pad] of your remote, select a channel and press [OK].
A heart-shaped indicator will appear beside the channel as confirmation that it has been successfully added.
Viewing your 'Favorites' list
To view channels that you've added to your Favorites list simply press [OK] on your remote to call out the Channel list.
The channel list appears on the right side of the screen and heart-shaped icons are shown next to the channels that make up your
Favorites list.
13
VOD
If you want to view content through Video-on-demand, then select the VOD icon to launch the main screen of the menu. Two rows of
logos for the following pre-installed Video-on-demand apps appear:
• Netflix
• Amazon Instant Video
• YouTube
• Vudu
• Dailymotion
• Viewster
These logos are fixed elements of the VOD menu screen design to provide a convenient way to launch the apps from the TV. To
the left of the logos, a thumbnail image of a movie poster is also shown. The poster is for a Vudu-recommended movie to rent or
purchase.
The thumbnails of the movie poster images that appear on this page are dynamic (meaning they will change) as long as your TV
is connected to the Internet. The poster image of the movie (or TV show) will change based on the latest movies that have been
released or popular TV shows.
LiveTVVOD Media Apps
12:42 63°F
Figure 3. VOD screen (as it appears for Canada market)
Netflix®
Netflix is a streaming media company that provides movies and TV shows for you to view online or stream right to your TV. If you
are a Netflix member, simply enter your email address and password to sign in to your Netflix account. If you don’t already have an
account, then you can try the service (FREE) for one month by creating an account. If you enjoy your trial membership, then you
don’t have to do anything. Your membership will automatically continue for as long as you choose to remain a member. Once you
click on the Netflix icon to launch the application, you can register for the service directly from your TV. Simply follow the prompts to
get started.
NOTE
Netflix is available in select countries. Streaming membership required.
Amazon Instant Video
In North America Amazon Instant Video is Only Available to Customers Residing in the United States.
YouTube and Viewster
You can use the YouTube and Viewster apps to view videos on the TV.
Vudu
Vudu is a video streaming service that enables you to rent or purchase High-Definition movies and TV shows. If you are not a Vudu
subscriber yet, then you will need to create an account to use the service. Once you click on the Vudu icon to launch the application,
you can register for the service directly from your TV. Simply follow the on-screen prompts to get started.
NOTE
VUDU is currently available in the U.S. only.
Dailymotion
You can use the Dailymotion app to view videos on the TV.
VOD
14
Media
Media is a central location for you to upload and view or listen to different types of content (for example, your photos, music and
movies) through the following methods:
• A USB thumb drive or hard drive
• Your mobile phone, tablet or other personal device: You can stream movies, pictures and photos that are stored on your
personal device and play or view the content on your TV.
When you connect your thumb drive or other personal device to the TV, the TV automatically detects it and displays a device icon in
the top right corner of the screen. Our company-developed HiMedia technology is what this Media feature is developed upon.
Panels that appear on the Media screen
The Media screen displays three panels: Picture, Video, Music.
File formats that may be supported
NOTE: Due to differences in programming tools and other factors, some of the file formats that are listed may or may not be
supported.
Medium File Format
Videos .avi(MPEG2, Divx), .mkv(Divx), .mpeg(MPEG2), .wmv(Divx,
XviD)
Picture .JPG
Music .avi(mp3, WMA, ac3), .mp3
Viewing Videos
While viewing videos you will see a number of icons appear at the bottom of the screen. You can use the [D-pad] button of your
remote to select these icons that will control the video.
Browsing Content
To browse through content based on the type that you wish to access:
1. Navigate to the appropriate menu tab on the left side of the screen and select Music, Video or Picture. The library of items
displays on the right side of the screen.
2. Navigate to the right side of the screen and click on the name of the folder that contains your content.
3. Make your selection to play or view the content.
If you want to close out of the Media center, then press the [Exit] button on your remote.
Viewing Pictures as a Slideshow
To view pictures in a slideshow:
1. Navigate to the Pictures tab.
2. Click on Start the Slideshow.
The slideshow of your pictures begins to play. To stop the slideshow, press the [OK] button on your remote and press it again to
restart it.
An Edit Picture window displays.
Media
15
Apps
Numerous factory-installed apps are available for you to choose from for your entertainment preferences.
LiveTVVOD Media Apps
12:42 63°F
Figure 4. Apps screen
'Hot Apps' section
The most popular apps appear at the top of the Apps Home screen in the 'Hot App's section. The second part of the screen (under
the 'All apps' section) provides a collective view of them to browse and select from.
Netflix®
Netflix is a streaming media company that provides movies and TV shows for you to view online or stream right to your TV. If you
are a Netflix member, simply enter your email address and password to sign in to your Netflix account. If you don't already have an
account, then you can try the service (FREE) for one month by creating an account. If you enjoy your trial membership, then you
don't have to do anything. Your membership will automatically continue for as long as you choose to remain a member. Once you
click on the Netflix icon to launch the application, you can register for the service directly from your TV. Simply follow the prompts to
get started.
NOTE
Netflix is available in select countries. Streaming membership required.
Vudu™
Vudu is a video streaming service that enables you to rent or purchase High-Definition movies and TV shows. If you are not a Vudu
subscriber yet, then you will need to create an account to use the service. Once you click on the Vudu icon to launch the application,
you can register for the service directly from your TV. Simply follow the on-screen prompts to get started.
NOTE
VUDU is currently available in the U.S. only.
Amazon Instant Video™
Amazon is an Internet video on demand service that offers television shows and movies for rent or purchase. If you are not an
Amazon subscriber yet, then you will need to create an account to use the service. Once you click on the Amazon icon to launch the
application, you can register for the service directly from your TV. Simply follow the on-screen prompts to get started.
NOTE
In North America Amazon Instant Video is Only Available to Customers Residing in the United States.
YouTube™
YouTube allows you to upload, view and share videos. You must create an account to use the service.
AccuWeather™
The AccuWeather app provides accurate local and national weather forecasts every minute and hour to help you plan. This app also
delivers up-to-date reports, video presentations and much more content.
To navigate through the AccuWeather center, press the left/right buttons on the [D-pad] of your remote to move the cursor and make
your selection.
Pandora®
Pandora is a service that streams various genres of music and provides recommendations.
NOTE
Pandora is available in select countries.
Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media,
Inc. Used with permission.
Apps
16
All Apps
Netflix YouTube TV Browser Vimeo TED Opera TV Store
Opera TV Store
TED
Vimeo
TV BrowserYouTube
Netflix
Toon Goggles YuppTV Dailymotion AccuWeather Viewster Game Center
Live TV
WOW TVChinaBlue
Kidoz
Anyview Cast
AOL On
Remove the app
Hot Apps
All Apps All 18
Figure 5. Collective view of all the factory-installed apps
Opera TV Store™
Opera TV Store contains cloud-based apps optimized for your TV. The apps range from Video, Music, Social Networking, Games
and News Information.
To begin using Opera TV Store, you simply need to accept the End-User License Agreement and then select the app that you want
to use.
Opera TV Browser
The Opera TV Browser allows you to surf the Internet on your TV and provides quick access to the Google™ search engine.
To view a website or search using the Opera TV Browser:
1. Using the [D-pad] on your remote, navigate to the Opera web browser icon underneath the Opera Store icon.
2. Press [OK] on your remote.
The browser window displays.
3. Using the [D-pad] on your remote, navigate up to the URL bar to place your cursor there.
4. Press [OK] on your remote to bring up the onscreen keyboard.
5. Type the website address or search term on the text field.
6. Press the [Blue] special function button towards the top of the remote (under the number pad).
The website address or search term you've typed populates in the URL bar window.
7. Select the forward arrow (to the right of the URL bar) and press [OK] on your remote to load the page or start the search.
Installing an App
Even though your TV has numerous factory-installed apps, there may be others that you'd like to download.
To install an app:
1. From the Home screen, click on the Opera TV Store icon.
2. Navigate to the Search tab at the top of the screen.
3. Begin typing the name of the app. As you begin typing the first two to three letters the Opera Store suggests words to quicken
your search time.
4. Use the [D-pad] of your remote to select the app.
A page displays that shows a written description of the app.
5. Click on Open or Add to Favorites.
Apps
17
Removing an App
You can only delete apps that you've downloaded to the TV. Factory-installed apps can not be deleted.
To delete an app:
1. From the Apps screen, use the directional arrows on the [D-pad] button of your remote to select the app that you want to
remove.
2. Press the [Red] special function button underneath the numerical keypad of your remote.
A dialog message displays that asks if you're sure you want to remove the app.
3. Press [OK] on your remote.
A confirmation message displays and the icon is removed from the Apps list screen.
NOTE
If an app is deleted,the information related to that app is also removed.
Moving App Icons around
Apps can not be moved around on the screen.
Customizing the name of your TV
If you have several TV's in your home then you may want to customize the name of your TV. By giving your TV a name, it will make
it easier for you to identify it when connecting devices to the TV to stream or mirror content.
To customize the name of your TV:
1. Press the [Quick Setup] menu button on your remote.
2. Go to Network>TV Name.
3. Select User Input to bring up the keyboard and begin typing the name.
4. When you are finished, power off the TV and power it back on for the change to take effect.
Apps
18
Using Anyview Cast to mirror content from your device to the TV
screen
The RCA Anyview Cast is an app that enables you to share (or cast) a video, audio or image from your Android-based device to the
TV.
From your tablet or phone
To mirror content from your tablet to the TV:
1. From the TV Settings, go to Network and turn on the Anyview Stream setting.
2. Press the [All Apps] button on your remote and select the Anyview Cast app.
3. Turn on your Android-based device and go to Settings > Display > Cast Screen.
NOTE: Some Android-based devices may not support casting.
4. Find your TV in the list of devices that displays and select it.
5. Wait for the ‘Creating Connection’ progress bar to complete on the TV screen and the video or image will display in a moment.
Mirroring content from your device to the TV
19
Software updates for your TV
The software (also referred to as firmware) is part of what powers your TV. RCA will provide software updates to continuously
enhance your TV and correct any issues that may impact your user experience; therefore, we recommend that you keep your
TV connected to the Internet to automatically receive updates when they are available.
You can choose to receive updates automatically or check for software updates and install them manually.
Checking for updates automatically
In order for your TV to receive software notification updates automatically, it must be turned 'On' and connected to the Internet.
The Auto Firmware Upgrade setting (which enables your TV to receive the updates automatically) is turned to 'On' by factory
default. If you turn the Auto Firmware Upgrade setting 'Off', it will disable this functionality of your TV.
Note: While your TV is on and checking for updates, the program that you are watching will not be interrupted.
Disabling the Auto Firmware Upgrade feature
If you do not want your TV to automatically check for updates and to receive notifications when they are available, then:
1. Using your remote, press the [Quick Setup] menu button.
2. Go to About TV > Auto Firmware Upgrade and turn the feature 'Off'
By doing this, you will have to manually check to see if you have the latest software update.
Checking for the latest firmware
To manually check for the latest firmware:
1. Using your remote, press the [Quick Setup] menu button.
2. Go to About TV > Check Firmware Upgrade.
Upgrade
Current version: V00.01.00a.F0116
Latest version: V000100aF0114
Upgrade content
Upgrade Cancel Never Reminder
Figure 6. Check Firmware screenshot
Manually installing software updates
If you have not kept your TV connected to the Internet or you turned the Auto Firmware Upgrade feature 'Off' then you'll need
to manually install the software.
If the Check Firmware Upgrade screen shows that an updated package is available, then:
1. From the Check Firmware submenu, select Download upgrade pack.
2. Follow the rest of the steps that display
Software updates for your TV
20
Quick Problem-Solving Tips
When you experience an issue with your TV, turn it off and on again. If this does not resolve the problem, then refer to the tips below.
If the problem is still not resolved, then contact us.
ISSUES POSSIBLE SOLUTIONS
There is no sound or picture from
the TV
• Check to see if the power cord is plugged into a power outlet.
• A power switch on the right side bottom edge of the front panel must be turned on. Press the Power
button on the remote control to activate the unit from 'Standby' mode.
• Check to see if the LED light is on or not. If it is, then the TV is receiving power.
I have connected an external
source to my TV and do not see a
picture and/or hear any sound
• Check for the correct output connection on the external source and for the correct input connection on the
TV.
• Make sure you have made the correct selection for the input mode for the incoming signal.
When I turn on my TV, there is a
delay for a few seconds before the
picture appears. Is this normal?
• Yes, this is normal. The TV is initializing and searching for previous setting information.
The picture is normal but there is
no sound
• Check the volume settings.
• Check if 'Mute' mode is set to On.
Sound but no picture or black and
white picture
• If the picture is black and white, unplug the TV from the AC outlet and replug it after 60 seconds.
• Check that the Color is set to 50 or higher.
• Try different TV channels.
The sound and/or picture is
distorted or appears wavy
• An electric appliance may be affecting the TV. Turn off any appliances that are nearby and move it farther
away from the TV.
• Insert the power plug of the TV set into another power outlet.
The sound and picture is blurry or
cuts out
• If using an external antenna, check the direction, position and connection of the antenna.
• Adjust the direction of your antenna or reset or ne tune the channel.
A horizontal or vertical stripe
appears on the picture and/or the
picture is shaking
• Check to see if there is an appliance or electric tool nearby that is causing interference.
The plastic cabinet makes a
"clicking" type of sound
• The 'click' sound can occur when the temperature of the television changes. This change causes the
television cabinet to expand or contract, which makes the sound. This is normal and the TV is OK.
The remote control does not work
• Conrm that TV still has power and is operational.
• Change the batteries in the remote control.
• Check if the batteries are correctly installed.
Disclaimer: Images throughout this document are for illustrative purposes only and may differ from the actual product.
NOTE
For usage in Mexico , operation of this equipment is subject to the following two conditions : 1 ) it is possible that this device doesn’t
cause any detrimental interference and 2 ) this device must take any kind of interference, including that which may cause its
malfunctioning.

Navigation menu
